Gefen GTB-UHD600-18S-RT User manual

GTB-UHD600-18S-RT
GTB-UHD600-28S-RT
User Manual
PRINTER'S INSTRUCTIONS:
INSTR,USER,ECO GTB-UHD600-18S RT,28S - P/N 10032049 Rev-A, CMYK, 20LB MEAD BOND, 8.5” x 11”, TOL. +/- 0.125",
SCALE: 1:1, FRONT & BACK, FOLDING: ALBUM FOLD - BINDING: SADDLE-STITCH
18S-RT
28S-RT

2
Table of Contents
Important Safety Instructions .............................................................. 5
Technical Support......................................................................................6
Email ...............................................................................................6
Web ................................................................................................6
Mailing Address .......................................................................................6
Warranty Information ...................................................................................6
Contacting Gefen Technical Support......................................................... 6
Licensing ............................................................................. 7
Features .............................................................................. 8
GTB-UHD600-18S-RT ..................................................................................8
GTB-UHD600-28S-RT ..................................................................................9
Features .............................................................................. 9
Package Contents...................................................................... 10
Introduction - GTB-UHD600-18S-RT ...........................................11
GTB-UHD600-18S-RT Connections - Input/Output ............................................. 12
GTB-UHD600-18S-RT Connections - Power .................................................. 13
GTB-UHD600-18S-RT Test Pattern Button/Factory Reset........................................ 14
Splitter Connection Instructions ........................................................... 15
Video ..............................................................................................15
Power .............................................................................................15
GTB-UHD600-18S-RT Sample Diagram ..................................................... 16
Introduction - GTB-UHD600-28S-RT ...........................................17
GTB-UHD600-28S-RT Connections - Input/Output ............................................. 18
GTB-UHD600-28S-RT Connections - Power .................................................. 19
GTB-UHD600-28S-RT Connections - LED Status .............................................. 20
GTB-UHD600-28S-RT Test Pattern Button / Factory Reset....................................... 21
GTB-UHD600-28S-RT - Sample Diagrams ................................................... 22
Splitter Connection Instructions ........................................................... 23
Video ..............................................................................................23
Power .............................................................................................23
Splitting and Scaling ..................................................................................23
Network Setup ........................................................................ 24
EDID Modes .........................................................................................25
CEC Control .........................................................................................25
IP to CEC ...........................................................................................25
EDID Modes and Smart CEC Control........................................................ 25
Network Conguration using Syner-G ...................................................... 26
Firmware Update ...................................................................... 28
Web Interface Firmware Update ..........................................................................28
Manual Firmware Update ...............................................................................28
Firmware Update ...................................................................... 28
RS-232 and IP Conguration ............................................................. 29
UDP Conguration ..................................................................... 30
Command Defaults ..................................................................... 30

3
Table of Contents
Commands List........................................................................ 31
CEC Control .........................................................................................31
Discovery Service.....................................................................................31
Help ...............................................................................................31
Input Status .........................................................................................31
Manage EDID ........................................................................................31
Master Status........................................................................................32
Network Settings .....................................................................................32
Output Status .......................................................................................32
Routing ............................................................................................33
System Settings ......................................................................................33
Test Pattern .........................................................................................33
Commands ........................................................................... 34
CEC CONTROL .........................................................................................34
CEC Auto ON (#GET_ / #SET_) ...........................................................................34
CEC Auto OFF (#GET_ / #SET_)...........................................................................34
CEC Interval (#GET_ / #SET_) ............................................................................34
CEC ON ............................................................................................35
Input CEC ...........................................................................................35
Output CEC..........................................................................................35
Commands ........................................................................... 36
DISCOVERY SERVICES .................................................................................36
Discovery (#GET_ / #SET_)..............................................................................36
HELP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
INPUT STATUS .........................................................................................36
Active Signal (#GETS_).................................................................................36
Color Depth (#GETS_)..................................................................................36
Chroma Sub-Sampling Ratio (#GETS_) .....................................................................37
HDCP Status (#GETS_) .................................................................................37
HPD Status (#GETS_) ..................................................................................37
Refresh Rate (#GETS_) .................................................................................38
Resolution (#GETS_)...................................................................................38
Scan Mode (#GETS_) ..................................................................................38
Video Mode (#GETS_)..................................................................................38
EDID Mode (#GET_ / #SET_).............................................................................39
External EDID ........................................................................................39
Input EDID ..........................................................................................39
Internal EDID (#GET_)..................................................................................40
Output EDID (#GET_) ..................................................................................40
MASTER STATUS .......................................................................................40
NETWORK SETTINGS....................................................................................41
Gateway (#GET_ / #SET_) ..............................................................................41
IP Address (#GET_ / #SET_) .............................................................................41
IP Conguration (#GET_) ...............................................................................41
IP Mode (#GET_ / #SET_) ...............................................................................42
MAC Address ........................................................................................42
Netmask (#GET_ / #SET_) ..............................................................................42
Remote UDP IP Address (#GET_ / #SET_) ...................................................................42
Remote UDP Communication Port (#GET_ / #SET_) ...........................................................43
Telnet Access (#GET_ / #SET_)...........................................................................43
Telnet Port (#GET_ / #SET_) .............................................................................43
UDP Access (#GET_ / #SET_) ............................................................................44

4
UDP Port (#GET_ / #SET_) ..............................................................................44
UDP Remote Access (#GET_ / #SET_)......................................................................44
OUTPUT STATUS .......................................................................................45
HDCP (#GETS_) ......................................................................................45
HPD (#GETS_) .......................................................................................45
Output Mode (#GETS_).................................................................................46
Resolution Mode (#GETS_) ..............................................................................46
Rsense (#GETS_) .....................................................................................46
ROUTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
BL Skip Mode (#GET_ / #SET_) ..........................................................................47
BL Skip Timeout (#GET_ / #SET_).........................................................................47
R (Input 1/Input 2) ....................................................................................47
S (Get Current Input)...................................................................................47
Routing Mode (#GET_ / #SET_) ..........................................................................48
Unlock Timeout (#GET_ / #SET_) .........................................................................48
SYSTEM SETTINGS....................................................................................48
Factory Reset ........................................................................................48
Firmware Version .....................................................................................48
Reboot .............................................................................................48
TEST Pattern Control ..................................................................................49
Test Pattern (#GET_ / #SET_) ............................................................................49
Factory Default Settings ................................................................. 50
Input/Output Timing Supported Table ....................................................... 51
Specications......................................................................... 54
Table of Contents

5
Important Safety Instructions
GENERAL SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install or place this product near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. To reduce the risk of electric shock and/or damage to this product, never handle or touch this
unit or power cord if your hands are wet or damp. Do not expose this
product to rain or moisture.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Batteries that may be included with this product and/or accessories should never be exposed to
open ame or excessive heat. Always dispose of used batteries
according to the instructions.

6
Contacting Gefen Technical Support
Technical Support
1-707-283-5900
1-800-472-5555
8:00 AM to 5:00 PM Monday - Friday, Pacic Time
Email
[email protected]
Web
http://www.gefen.com
Mailing Address
Gefen
Nortek Security & Control, LLC
c/o Customer Service
5919 Sea Otter Place, Suite 100
Carlsbad, CA 92010 USA
Warranty Information
For the latest warranty coverage information, refer to the Warranty and Return Policy under
the Connect section of the Gefen website at http://www.gefen.com/connect/warranty-and-
return-policy
© 2021 Nortek Security & Control, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
Gefen and Nortek Security & Control, LLC reserve the right to make changes in the hardware, packaging, and any accompanying documentation without prior notice.

7
Licensing
This product uses software that is subject to open source licenses, including one or more of
the General Public License Version 2 and Version 2.1, Lesser General Public License Version
2.1 and Version 3, BSD, and BSD-style licenses. Distribution and use of this product is
subject to the license terms and limitations of liability provided in those licenses. Specic
license terms and Copyright Notications are provided in the source code.
For three years from date of activation of this product, any party may request, and we
will supply, for software covered by an applicable license (e.g. GPL or LGPL), a complete
machine-readable copy of the corresponding open source code on a medium customarily
used for software interchange. The following software and libraries are included with this
product and subject to their respective open source licenses:
hlwIP
hjQuery
lwIP is licensed under the BSD license:
Copyright (c) 2001-2004 Swedish Institute of Computer Science.
All rights reserved.
Redistribution and use in source and binary forms, with or without modication, are
permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and
the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions
and the following disclaimer in the documentation and/or other materials provided with the
distribution.
3. The name of the author may not be used to endorse or promote products derived from this
software without specic prior written permission.
THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS’’ AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN
NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY
OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

8
GTB-UHD600-18S-RT
hSimultaneously displays an Ultra Hi-Def source on up to eight Ultra HD displays
hSpecically designed to support multiple layers of splitting/cascading in large video
distribution and signage applications, supporting hundreds of displays
hSupports resolutions up to 4K DCI-Cinema (4096 x 2160 at 60 Hz, 4:4:4 color space), 4K
Ultra HD (3860 x 2160 at 60Hz, 4:4:4 color space), 1080p Full HD, and 1920x1200 WUXGA
hSupports HDR (High Dynamic Range) 10-bit Deep Color at 4K 4:4:4
hSupports 12-bit Deep Color at 1080p 4:4:4
hSupports HDR to SDR conversion
hSupports 4K to 1080P Auto-Downscale
hSupports built-in 1080P test pattern generator
hIP control via Telnet and UDP
hSupports Smart CEC control including IP to CEC bridge
h3DTV pass-through
hLip Sync pass-through
hEDID Management and Audio Mode selectors for rapid integration of source and displays
hSupports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™
hSupports the use of DVI sources and DVI displays with HDMI-to-DVI adapters (not included)
hGefen Syner-G™ software’s Discovery and Show-Me features simplify initial IP conguration
hAdvanced EDID Management via Virtual Serial over USB, Telnet or UDP
hIn-eld rmware update via USB or via web interface
hLow-prole, surface-mountable enclosure
Features

9
Features
Commands
GTB-UHD600-28S-RT
hSimultaneously displays an Ultra Hi-Def source on up to eight Ultra HD displays
hSpecically designed to support multiple layers of splitting/cascading in large video
distribution and signage applications, supporting hundreds of displays
hSupports resolutions up to 4K DCI-Cinema (4096 x 2160 at 60 Hz, 4:4:4 color space), 4K
Ultra HD (3860 x 2160 at 60Hz, 4:4:4 color space), 1080p Full HD, and 1920x1200 WUXGA
hSupports HDR (High Dynamic Range) 10-bit Deep Color at 4K 4:4:4
hSupports 12-bit Deep Color at 1080p 4:4:4
hSupports HDR to SDR conversion
hSupports 4K to 1080P Auto-Downscale
hSupports built-in 1080P test pattern generator
hIP control via Telnet and UDP
hSupports Smart CEC control including IP to CEC bridge
h3DTV pass-through
hLip Sync pass-through
hEDID Management and Audio Mode selectors for rapid integration of source and displays
hSupports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™
hSupports the use of DVI sources and DVI displays with HDMI-to-DVI adapters (not included)
hGefen Syner-G™ software’s Discovery and Show-Me features simplify initial IP conguration
hAdvanced EDID Management via Virtual Serial over USB, Telnet or UDP
hIn-eld rmware update via USB or via web interface
hLow-prole, surface-mountable enclosure
hRoutes up to two Ultra Hi-Def sources to eight Ultra HD displays
hSupports auto input switching for source redundancy
hInput Select button to manually route between two inputs

10
Package Contents
h(1) 4K Ultra HD 600 MHz 1:8 Splitter w/HDR and Scaling
(1) 4K Ultra HD 600 MHz 1:8 Splitter Quick-Start Guide
OR
h(1) 4K Ultra HD 600 MHz 2:8 Splitter w/HDR and Scaling
h(1) 4K Ultra HD 600 MHz 2:8 Splitter Quick-Start Guide
AND
h(1) 5v/2.6A Power Supply (EXT-PS526AIP-LP-6)

11
Introduction - GTB-UHD600-18S-RT
The Gefen GTB-UHD600-18S-RT routes one full bandwidth 4K Ultra HD 600 MHz source to
eight 4K Ultra HD 600 MHz or Full HD 1080p displays. Independent scalers built into each
output will automatically downscale the signal when connected to a 1080p TV.
This HDCP-compliant product has been specically designed to support over 10 layers
of splitting/cascading for awless performance in large video distribution and signage
applications, supporting hundreds of displays.
Cutting edge Smart CEC Management system built into the GTB-UHD600-18S-RT
communicates with the source, other compatible splitters and the displays. It guarantees
that a picture is always present on all displays by ensuring that connected displays are on
and switched to the correct input.
A built-in Pattern Generator helps in troubleshooting during installation or for routine
maintenance. Resolutions up to 4K DCI (4096 x 2160 at 60 Hz), 4K Ultra HD (3860 x 2160 at
60 Hz, 4:4:4 color space),1080p Full HD, and 1920x1200 WUXGA are supported. HDR and
multi-channel digital audio including 7.1 channels of LPCM and HBR (High Bit Rate) lossless
formats are also passed through. The Gefen 1:8 Splitter is the perfect choice for any small or
large 4K video distribution system.

12
GTB-UHD600-18S-RT Connections - Input/Output
 



ID Name Description
1Outputs To a combination of eight 4K Ultra HD 600 MHz displays, Full HD 1080p displays or additional
splitters.
2Inputs 4K Ultra HD 600 MHz Source
3Ethernet
Input
To a network switch, computer, cascaded compatible splitter or a third-party controller.
NOTE: The splitter ships in DHCP mode and if no DHCP server is found, it will use an APIPA
address (169.254.x.x). Gefen Syner-G™ software can be used to discover the unit on the
network.
4Mini-
USB Port
Mini-USB port can be used as a Virtual Serial Port for conguration, control and for rmware
updates.

13
GTB-UHD600-18S-RT Connections - Power
ID Name Description
1Power LED Illuminates blue when the splitter is powered on.
2Included 5V DC
Power Supply
Connect the included 5V DC locking power supply, and plug it into an available
electrical outlet.



14
GTB-UHD600-18S-RT Test Pattern Button/Factory Reset
ID Name Description
1Test Pattern Button
Press and hold the Test Pattern button for 3 seconds to output a 1080p 60Hz Color Bar
Test Pattern, which also displays the splitter’s MAC address.
This Test Pattern can be used during installation or routine maintenance to ensure that the
displays are receiving a valid signal and to help making picture adjustments.
When the Test Pattern is on, its associated LED will be illuminated green. Press and hold for
3 seconds to deactivate.
2Test Pattern LED The LED will illuminate green when Test Pattern is activated
3Factory Reset Return all settings to factory defaults. Press and hold the Test Pattern button for 10
seconds.
 

15
Splitter Connection Instructions
Video
1. Using an HDMI cable, connect an Ultra HD source to the Input port of the splitter.
2. Connect HDMI cables (not included), to Out 1 - Out 8 ports. The HDMI cables can then be
connected in any of the following ways:
hConnect the HDMI cables to Ultra HD displays.
Power
1. Connect the included 5V DC locking power supply to the 5V DC power receptacle on the rear
panel of the splitter.
2. Connect the power supply to an available electrical outlet.
Important
Cable quality is critical when handling 600 MHz HDMI signals. We
highly recommend Gefen Locking HDMI cables. They have been
designed and tested to work at 600 MHz and reliably transport the
full 18 Gbps throughput of HDMI 2.0.

16
GTB-UHD600-18S-RT Sample Diagram
GTB-UHD600-18S-RT
HDMI CABLE
Ultra HD
Source 1
(Up to 8)
Ultra HD
Displays
(Up to 8)
Ultra HD
Displays
EXT-UHD600-18S-RT
(1:8 Splitter for HDMI w/HDR)

17
Introduction - GTB-UHD600-28S-RT
The Gefen GTB-UHD600-28S-RT routes two full bandwidth 4K Ultra HD 600 MHz source to
eight 4K Ultra HD 600 MHz or Full HD 1080p displays. Independent scalers built into each
output will automatically downscale the signal when connected to a 1080p TV. This HDCP-
compliant product has been specically designed to support over 10 layers of splitting/
cascading for awless performance in large video distribution and signage applications,
supporting hundreds of displays.
Cutting edge Smart CEC Management system built into the GTB-UHD600-28S-RT
communicates with the source, other compatible splitters and the displays. It guarantees
that a picture is always present on all displays by ensuring that connected displays are on
and switched to the correct input.
A built-in Pattern Generator helps in troubleshooting during installation or for routine
maintenance. Resolutions up to 4K DCI (4096 x 2160 at 60 Hz), 4K Ultra HD (3860 x 2160 at
60 Hz, 4:4:4 color space),1080p Full HD, and 1920x1200 WUXGA are supported. HDR and
multi-channel digital audio including 7.1 channels of LPCM and HBR (High Bit Rate) lossless
formats are also passed through. The Gefen 2:8 Splitter is the perfect choice for any small or
large 4K video distribution system.
hUse up to two Full-Bandwidth 4K 600 MHz-capable HDMI cables to connect your HDMI
sources to the input of the splitter.
hConnect up to eight displays or additional splitters to the HDMI Outputs, using Full-
Bandwidth 4K 600 MHz-capable HDMI cables.
DVI sources and displays can be used with HDMI-to-DVI adapters
(Gefen part no. ADA-HDMIM-2-DVIFN).

18
GTB-UHD600-28S-RT Connections - Input/Output
ID Name Description
1Outputs To a combination of eight 4K Ultra HD 600 MHz displays, Full HD 1080p displays or
additional splitters.
2Inputs 4K Ultra HD 600 MHz Sources
3Ethernet
Input
To a network switch, computer, cascaded compatible splitter or a third-party controller.
NOTE: The splitter ships in DHCP mode and if no DHCP server is found, it will use an APIPA
address (169.254.x.x). Gefen Syner-G™ software can be used to discover the unit on the
network.
4Mini USB Port Mini USB port can be used as a Virtual Serial Port for conguration, control and for
rmware updates.





19
GTB-UHD600-28S-RT Connections - Power
ID Name Description
1Input Select LEDs
There are two Bi-color LEDs available to indicate the current input selected and
operation mode.
Auto Switching Mode (Default): A Blue Input LED Status indicates the current input
selected and that the splitter is in Auto Switching Mode.
Auto Switching Mode is used for source redundancy. HDMI Input 1 is always priority. If
Input 1 goes down, the splitter automatically switches to Input 2.
Manual Switching Mode: Toggling the Input switch will trigger Manual override.
A Green Input LED Status indicates the current input selected and that the splitter is in
Manual Switch Mode. Refer to the LED Status table for more details (next page).
2Input Select 4K Ultra HD 600 MHz Sources - Press and release the Select button to toggle
between HDMI inputs.
3Power LED The LED will illuminate green when Test Pattern is activated.
4Included 5V DC
Power Supply
Connect the included 5V DC locking power supply and plug it into an available
electrical outlet. When the splitter is powered-on, the Power LED will glow bright blue.





20
GTB-UHD600-28S-RT Connections - LED Status
Input 1 LED Input 2
Sync
Detected No Sync
Auto
Switch
Mode
Manual
Switch
Mode
Sync
Detected No Sync
Auto
Switch
Mode
Manual
Switch
Mode
Input 1
Selected LED Solid
LED Flashing
(500ms ON/
OFF pattern)
LED Color:
Blue
LED Color:
Green LED Inactive LED Inactive LED Inactive
LED
Inactive
Input 2
Selected
LED
Inactive LED Inactive LED Inactive
LED
Inactive LED Solid
LED Flashing
(500ms ON/
OFF pattern)
LED Color:
Blue
LED Color:
Green
