gefran VDI100 Series User manual
.... Instruction manual
VDI Modbus
Communication Protocol
Before using the product, read the safety instruction section carefully.
Keep the manual in a safe place and available to engineering and installation personnel during the product
functioning period.
Gefran S.p.A has the right to modify products, data and dimensions without notice. The data can only be used
for the product description and they can not be understood as legally stated properties.
Thank you for choosing this Gefran product.
We will be glad to receive any possible information which could help us improving this manual. The e-mail
All rights reserved
Prima dell’utilizzo del prodotto, leggere attentamente il capitolo relativo alle istruzioni di sicurezza.
Durante il suo periodo di funzionamento conservate il manuale in un luogo sicuro e a disposizione del person-
ale tecnico.
Gefran spa si riserva la facoltà di apportare modiche e varianti a prodotti, dati, dimensioni, in qualsiasi mo-
mento senza obbligo di preavviso.
I dati indicati servono unicamente alla descrizione del prodotto e non devono essere intesi come proprietà
assicurate nel senso legale.
Vi ringraziamo per avere scelto questo prodotto Gefran.
Saremo lieti di ricevere all’indirizzo e-mail: [email protected] qualsiasi informazione che possa aiutarci a
migliorare questo manuale.
Tutti i diritti riservati.
2 VDI100 • Instruction manual
Contents - Sommario
1. English .................................................................................................................................................5
1.1. Modbus Protocol Descriptions .................................................................................................................5
1.1.1. Communication Connection and Data Frame............................................................................................................5
1.1.2. Register and Data Format..........................................................................................................................................8
1.1.3. Parameter Data........................................................................................................................................................14
2. Italiano ...............................................................................................................................................21
2.1. Protocollo di comunicazione MODBUS..................................................................................................21
2.1.1. Communication Connection and Data Frame..........................................................................................................21
2.1.2. Registro e Formato Dati...........................................................................................................................................24
2.1.3. Dati parametri .........................................................................................................................................................30
VDI100 • Instruction manual 3
4 VDI100 • Instruction manual
1. English
1.1. Modbus Protocol Descriptions
1.1.1. Communication Connection and Data Frame
The inverter can communicate with a PC or PLC via RS485 or RS232 using the Modbus RTU or Modbus ASCII
protocol. The maximum frame length is 80 bytes.
Network Connection
Controller
(PLC / HMI or
PC)
VDI100
Node
Address 01
VDI100
Node
Address 02
VDI100
Node
Address 03
VDI100
Node
Address FE
6NC6NC6NC6NC
RS-485
Interface
S(+) S(-) S(+) S(-) S(+)S(-) S(+) S(-)
120Ω
1/4w
120Ω
1/4w
** Terminate the communications line with a (120 ohm, 1/4 watt) resistor at both ends.
CN6 Pin out PIN Signal PIN Signal
876 5 4321
1 RS-485 S+ signal 5 Tx signal
2 RS-485 S- signal 6 RS-485 S- signal
3 RS-485 S+ signal 7 VCC of isolated 5V power supply
4 Rx signal 8 GND of isolated 5V power supply
For RS-485 communication use pin 1 or pin 3 for S (+) and pin 2 or pin 6 for S (-)
Data Format Frame
STX(3AH) Start Bit = 3AH
Node Address Hi Communication Address (Station):
2-digit ASCII Code
Node Address Lo
Function Hi Function Code (command):
2-digit ASCII Code
Function Lo
Command Start Address
Command Start byte:
4-digit ASCII Code
Command Start Address
Command Start Address
Command Start Address
Data length
The length of the command:
4-digit ASCII Code
Data length
Data length
Data length
LRC Check Hi LRC Check Code:
2-digit ASCII Code
LRC Check Lo
END Hi End Byte:
END Hi=CR(0DH), END Li = LF(0AH)
END Lo
VDI100 • Instruction manual 5
Data Frame for RTU Mode
Master (PLC etc.) sends request to follower (inverter), and the follower sends a response to the master (PC,
PLC). The data received is illustrated here.
The data length varies depending on the command (Function).
Node Address
Function Code
DATA
CRC CHECK
Signal Interval
** The inverter response time is 10ms.
Node Address
00H: Broadcast to all the drivers
01H: to the No. 01 inverter
0FH: to the No.15 inverter
10H: to the No.16 inverter and so on...., max to No. 254 (FEH)
Function Code
03H: Read the register contents
06H: Write a WORD to register
08H: Loop test
10H: Write several data to register (complex number register write)
Checksum Calculation
LRC
ex. NODE ADDRESS 01H
FUNCTION 03H
COMMAND 01H
00H
+ DATA LENGTH 0AH
------------------------------------------
0FH ------------ 2’s complement
Checksum F1H
CS (H) 46H (ASCII)
CS (L) = 31H (ASCII)
CRC
CRC Check: CRC code covers the content from node address to DATA. Please calculate it according to the
following methods.
(1) Load a 16-bit register with FFFF hex (all1’s). Call this CRC register.
(2)ExclusiveORtherst8-bitbyteofthemessage,thelow-orderbyteofthe16-bitCRCregister,puttingthe
result in the CRC register.
(3)ShifttheCRCregisteronebittotheright(towardtheLSB),Zero-llingtheMSB,Extractandexaminesthe
LSB.
(4) (If the LSB was 0): Repeat Steps (3) (another shift)
(If the LSB was 1): Exclusive OR the CRC register with the polynomial value A001 hex (1010 0000 0000 0001),
putting the result in CRC register.
(5) Repeat Steps (3) and (4) until 8 shifts been performed. When this is done, a complete 8-bit byte will be
processed.
(6) Repeat Steps (2) through (5) for next 8-bit byte of the message, Continue doing this until all bytes have
beenprocessed.ThenalcontentintheCRCregisteristheCRCvalue.WhensendingtheCRCvalue,
theLow-orderbyteshouldbesentrstly,thentheHigh-orderbyte.Forexample,CRCvalue:1241Hex,the
high-order byte should be set to 41hex and low-order byte 12hex.
6 VDI100 • Instruction manual
CRC calculate program (C language):
UWORD ch_sum (UBYTE long, UBYTE *rxdbuff )
{
BYTE i = 0;
UWORD wkg = 0xFFFF;
while ( long-- ) {
wkg ^= rxdbuff++;
for ( i = 0 ; i < 8; i++ ) {
if ( wkg & 0x0001 ) {
wkg = ( wkg >> 1 ) ^ 0xa001;
}
else {
wkg = wkg >> 1;
}
}
}
return( wkg );
}
Error code
ASCII Mode RTU Mode
STX ‘:’ Node Address 02H
Address ‘0’ Function 83H
‘1’ Exception code 52H
Function ‘8’ CRC-16 High C0H
‘6’ Low CDH
Exception code ‘5’
‘1’
LRC Check ‘2’
‘8’
END ‘CR’
‘LF’
During a communication error the drive will response with an Exception Code and send a message back to the
main system consisting of a Function Code that is “ANDED (and 80h)” with 80 Hex.
Exception code Content
01 Function code error
02 Register number error
03 DATA setting error
04 Register number is over 32
VDI100 • Instruction manual 7
1.1.2. Register and Data Format
Command Data (Read / Write)
Register No. Bit Content
2500H
Reserved
Operation Signal
0 Operation Command 1 : Run 0 : Stop
1 Reverse Command 1 : Reverse 0 : Forward
2 External Fault 1 : Fault
3 Fault Reset 1 : Reset
4 Reserved
5 Reserved
6 Multi-function Comm S1 1 :“ON”
7 Multi-function Comm S2 1 :“ON”
8 Multi-function Comm S3 1 :“ON”
9 Multi-function Comm S4 1 :“ON”
A Multi-function Comm S5 1 :“ON”
B Multi-function Comm S6 1 :“ON”
C Multi-function Comm S7 1 :“ON”
D Multi-function Comm S8 1 :“ON”
E Inverter mode 1 : “ON”
F Torque Command set by Communication 1: “ON”
2502H *Frequency Command (Unit: 0.01Hz)
2503H Torque Command (+/-8192 corresponding to the rated torque +/-100%)
2504H Speed limit (+/- 120 corresponding +/-120%)
2505H AO1 (0.00V ~ 10.00V)
2506H AO2 (0 ~ 1000): Voltage (corresponding to 0.00~10.00V); Current
( corresponding to 4mA~20mA)
2507H DO
2508H Reserved
2509H Reserved
250AH Reserved
250BH Reserved
250CH Reserved
250DH Reserved
250EH Reserved
250FH Reserved
2510H G12-00 H-WORD
2511H G12-00 L-WORD
Note: Write in zero for Not used BIT, do not write in data for the reserved register.
** If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Monitor Data (Read-only)
Register No. Bit Content
2520H
Operation Signal
0 Operation 1 : Run 0 : Stop
1 Direction 1 : Reverse 0 : Forward
2 Inverter ready 1 : ready 0 : unready
3 Fault 1 : Abnormal
4 Warning 1 :“ON”
5 Zero Speed 1 :“ON”
6 Is440V 1 :“ON”
7 Frequency Agree 1 :“ON”
8 Set Frequency Agree 1 :“ON”
9 Frequency Detection 1 1 :“ON”
A Frequency Detection 2 1 :“ON”
B Under Voltage 1 :“ON”
C Baseblock 1 :“ON”
D Freq Ref. not from Comm. 1 :“ON”
E Seq. not from Comm. 1 :“ON”
F Over Torque 1 :“ON”
8 VDI100 • Instruction manual
Register No. Bit Content
2521H
Error Description
0 30
1 UV 31
2 OC 32
3 OV 33
4 OH1 34
5 OL1 35
6 OL2 36
7OT 37
8 UT 38 CF07
9 SC 39
10 Ground OC 40
11 Fuse broken 41 OLDOP
12 Input Phase Loss 42
13 Output Phase Loss 43
14 PG Overspeed 44
15 PG Open 45
16 PG Speed Deviation 46
17 External Fault 01 47 SS1
18 External Fault 02 48 CF20
19 External Fault 03 49 RUN
20 External Fault 04 50
21 External Fault 05 51
22 External Fault 06 52
23 External Fault 07 53
24 External Fault 08 54
25 FB 55
26 OPR 56
27 57
28 CE 58
29 STO 59
30 Over Torque 2 61
2522H
DI State
0 Terminal S1
1 Terminal S2
2 Terminal S3
3 Terminal S4
4 Terminal S5
5 Terminal S6
6 Terminal S7
7 Terminal S8
8 Reserved
9 Reserved
A Reserved
B Reserved
C Reserved
D Reserved
E Reserved
F Reserved
2523H Frequency command (0.01Hz)
2524H Output frequency (0.01Hz)
2525H Reserved
2526H DC voltage command (0.1V)
2527H Output current (0.1A)
VDI100 • Instruction manual 9
2528H
Warning Description
0 No alarm 20 EF4 40 EF 60 Reserved
1 OV 21 EF5 41 Reserved 61 RETRY
2 UV 22 EF6 42 Reserved 62 SE07
3 OL2 23 EF7 43 RDP 63 SE08
4 OH2 24 EF8 44 Reserved 64 Reserved
5 Reserved 25 Reserved 45 OL1 65 OH1
6OT 26 CLB 46 HP_ER 66 FIRE
7 Reserved 27 Reserved 47 SE10 67 ES
8 Reserved 28 CT 48 Reserved 68 STP1
9 UT 29 USP 49 BB1 69 BDERR
10 OS 30 RDE 50 BB2 70 EPERR
11 PGO 31 WRE 51 BB3 71 ADCER
12 DEV 32 FB 52 BB4 72 Reserved
13 CE 33 VRYE 53 BB5 73 STP0
14 CALL 34 SE01 54 BB6 74 ENC
15 Reserved 35 SE02 55 BB7 75 STP2
16 EF0 36 SE03 56 BB8
17 EF1 37 Reserved 57 Reserved
18 EF2 38 SE05 58 Reserved
19 EF3 39 HPERR 59 Reserved
2529H Digital Output State
252AH AO1 (0.00V ~ 10.00V)
252BH
AO2 (0 ~ 1000): Voltage (corresponding to
0.00~10.00V); Current (corresponding to 4mA~-
20mA)
252CH Analog Input 1 (0.1%)
252DH Analog Input 2 (0.1%)
252EH Reserved
252FH VDI100/BDI50 Check
Note: Write in zero for Not used BIT, do not write in data for the reserved register.
* If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
10 VDI100 • Instruction manual
Read Holding Register [03H]
Readconsecutiveholdingregisters.Theaddressoftherstholdingregisterisspeciedintheprotocol
Example: Read frequency command from the inverter with node address 1.
ASCII Mode
Command Message Response Message (Normal) Response Message (Error)
3AH STX 3AH STX 3AH STX
30H Node Address 30H Node Address 30H Node Address
31H 31H 31H
30H Function 30H Function 38H Function
33H 33H 33H
30H
Starting Register
30H Data Length 30H Exception code
31H 32H 34H
32H 31H
Initial Save Register
34H LRC CHECK
33H 37H 30H
30H
Number of Reg-
isters
37H 0DH END
30H 30H 0AH
30H ? LRC CHECK
31H ?
?LRC CHECK 0DH END
? 0AH
0DH END
0AH
RTU Mode
Command Message Response Message (Normal) Response Message (Error)
Node Address 01 H Node Address 01H Node Address 01H
Function 03H Function 03H Function 83H
Starting
Register
High 0CH Data Length 02H Exception code 04H
Low 10H Initial Save
Register
High 17H CRC-16 High 40H
Number of
Registers
High 00H Low 70H Low F3H
Low 01H CRC-16 High B6H
CRC-16 High 86H Low 50H
Low 9FH
Loop back test [08H]
Check the communication between the master and the follower (inverter). The data used can be arbitrary.
ASCII Mode
Command Message Response Message (Normal) Response Message (Error)
3AH STX 3AH Node Address 3AH STX
30H Node Address 30H 30H Node Address
31H 31H Function 31H
30H Function 30H 38H Function
38H 38H
Test Code
38H
30H
Test Code
30H 30H Exception code
30H 30H 33H
30H 30H 30H LRC CHECK
30H 30H
DATA
36H
41H
DATA
41H 0DH END
0AH
35H 35H
33H 33H
37H 37H LRC CHECK
31H LRC CHECK 31H
42H 42H
END0DH END 0DH
0AH 0AH
VDI100 • Instruction manual 11
RTU Mode
Command Message Response Message (Normal) Response Message (Error)
Node Address 01 H Node Address 01H Node Address 01H
Function 08H Function 08H Function 88H
Test Code High 00H Test Code High 00H Exception code 03H
Low 00H Low 00H CRC-16 High 06H
DATA High A5H DATA High A5H Low 01H
Low 37H Low 37H
CRC-16 High DAH CRC-16 High DAH
Low 8DH Low 8DH
Write Single Holding Register [06H]
Writesingleholdingregister.Theregisteraddressoftheholdingregisterisspeciedinthemessage.
Example: Write a 60.00Hz frequency command to node address 1.
ASCII Mode
Command Message Response Message (Normal) Response Message (Error)
3AH STX 3AH STX 3AH STX
30H Node Address 30H Node Address 30H Node Address
31H 31H 31H
30H Function 30H Function 38H Function
36H 36H 36H
32H
Starting Register
32H
Starting Register
30H Exception code
35H 35H 33H
30H 30H 30H LRC CHECK
32H 32H 32H
31H
DATA
31H
DATA
0DH END
0AH
37H 37H
37H 37H
30H 30H
34H LRC CHECK 34H LRC CHECK
42H 42H
0DH END 0DH END
0AH 0AH
RTU Mode
Command Message Response Message (Normal) Response Message (Error)
Node Address 01 H Node Address 01H Node Address 01H
Function 08H Function 06H Function 86H
Start No High 25H Start No High 25H Exception code 03H
Low 02H Low 02H CRC-16 High 02H
DATA High 17H DATA High 17H Low 61H
Low 70H Low 70H
CRC-16 High 2DH CRC-16 High 2DH
Low 12H Low 12H
Write Multiple Holding Register [10H]
Writemultipleholdingregisters.Theaddressoftherstholdingregisterisspeciedinthemessage.
Example: Write a 60.00Hz frequency command to node address 1 and enable FWD run command.
12 VDI100 • Instruction manual
ASCII Mode
Command Message Response Message (Normal) Response Message (Error)
3AH STX 3AH STX 3AH STX
30H Node Address 30H Node Address 30H Node Address
31H 31H 31H
31H Function 31H Function 39H Function
30H 30H 30H
30H
Starting Register
32H
Starting Register
30H Exception code
31H 35H 33H
30H 30H 30H LRC CHECK
31H 31H 43H
30H
Number of Reg-
isters
30H
Number of Registers
0DH END
30H 30H 0AH
30H 30H
32H 32H
30H Number of Bytes* 43H LRC CHECK
34H 37H
30H
DATA 1
0DH
END
30H 0AH
30H 0AH
31H
31H
DATA 2
37H
37H
30H
33H LRC CHECK
42H
0DH END
0AH
* Number of bytes is register amount x 2
RTU Mode
Command Message Response Message (Normal) Response Message (Error)
Node Address 01H Node Address 01H Node Address 01H
Function 10H Function 10H Function 90H
Starting
Register
High 25H Starting
Register
High 25H Exception code 03H
Low 01H Low 01H CRC-16 High 0CH
Number of
Registers
High 00H Number of
Registers
High 00H Low 01H
Low 02H Low 02H
Number of Bytes* 04H CRC-16 High 1BH
DATA 1 High 00H Low 04H
Low 01H
DATA 2 High 17H
Low 70H
CRC-16 High 60H
Low 27H
* Data amount is register amount x 2
VDI100 • Instruction manual 13
1.1.3. Parameter Data
Function Register No Function Register No Function Register No
Group 0 Group 0 Group 1
0 – 00 0000H 0 – 43 002BH 1 – 00 0100H
0 – 01 0001H 0 – 44 002CH 1 – 01 0101H
0 – 02 0002H 0 – 45 002DH 1 – 02 0102H
0 – 03 0003H 0 – 46 002EH 1 – 03 0103H
0 – 04 0004H 0 – 47 002FH 1 – 04 0104H
0 – 05 0005H 0 – 48 0030H 1 – 05 0105H
0 – 06 0006H 0 – 49 0031H 1 – 06 0106H
0 – 07 0007H 0 – 50 0032H 1 – 07 0107H
0 – 08 0008H 0 – 51 0033H 1 – 08 0108H
0 – 09 0009H 0 – 52 0034H 1 – 09 0109H
0 – 10 000AH 0 – 53 0035H 1 – 10 010AH
0 – 11 000BH 0 – 54 0036H 1 – 11 010BH
0 – 12 000CH 0 – 55 0037H 1 – 12 010CH
0 – 13 000DH 0 – 56 0038H 1 – 13 010DH
0 – 14 000EH 0 – 57 0039H 1 – 14 010EH
0 – 15 000FH 1 – 15 010FH
0 – 16 0010H 1 – 16 0110H
0 – 17 0011H 1 – 17 0111H
0 – 18 0012H 1 – 18 0112H
0 – 19 0013H 1 – 19 0113H
0 – 20 0014H 1 – 20 0114H
0 – 21 0015H 1 – 21 0115H
0 – 22 0016H 1 – 22 0116H
0 – 23 0017H 1 – 23 0117H
0 – 24 0018H 1 – 24 0118H
0 – 25 0019H 1 – 25 0119H
0 – 26 001AH
0 – 27 001BH
0 – 28 001CH
0 – 29 001DH
0 – 30 001EH
0 – 31 001FH
0 – 32 0020H
0 – 33 0021H
0 – 34 0022H
0 – 35 0023H
0 – 36 0024H
0 – 37 0025H
0 – 38 0026H
0 – 39 0027H
0 – 40 0028H
0 – 41 0029H
0 – 42 002AH
Function Register No Function Register No Function Register No Function Register No
Group 2 Group 3 Group 3 Group 4
2 – 00 0200H 3 – 00 0300H 3 – 43 032BH 4– 00 0400H
2 – 01 0201H 3 – 01 0301H 3 – 44 032CH 4 – 01 0401H
2 – 02 0202H 3 – 02 0302H 3 – 45 032DH 4 – 02 0402H
2 – 03 0203H 3 – 03 0303H 3 – 46 032EH 4 – 03 0403H
2 – 04 0204H 3 – 04 0304H 3 – 47 032FH 4 – 04 0404H
2 – 05 0205H 3 – 05 0305H 4 – 05 0405H
2 – 06 0206H 3 – 06 0306H 4 – 06 0406H
2 – 07 0207H 3 – 07 0307H 4 – 07 0407H
2 – 08 0208H 3 – 08 0308H 4 – 08 0408H
2 – 09 0209H 3 – 09 0309H 4 – 09 0409H
2 – 10 020AH 3 – 10 030AH 4 – 10 040AH
2 – 11 020BH 3 – 11 030BH 4 – 11 040BH
14 VDI100 • Instruction manual
Function Register No Function Register No Function Register No Function Register No
Group 2 Group 3 Group 3 Group 4
2 – 12 020CH 3 – 12 030CH 4 – 12 040CH
2 – 13 020DH 3 – 13 030DH 4 – 13 040DH
2 – 14 020EH 3 – 14 030EH 4 – 14 040EH
2 – 15 020FH 3 – 15 030FH 4 – 15 040FH
2 – 16 0210H 3 – 16 0310H 4 – 16 0410H
2 – 17 0211H 3 – 17 0311H 4 – 17 0411H
2 – 18 0212H 3 – 18 0312H 4 – 18 0412H
2 – 19 0213H 3 – 19 0313H 4 – 19 0413H
2 – 20 0214H 3 – 20 0314H 4 – 20 0414H
2 – 21 0215H 3 – 21 0315H
2 – 22 0216H 3 – 22 0316H
2 – 23 0217H 3 – 23 0317H
2 – 24 0218H 3 – 24 0318H
2 – 25 0219H 3 – 25 0319H
2 – 26 021AH 3 – 26 031AH
2 – 27 021BH 3 – 27 031BH
2 – 28 021CH 3 – 28 031CH
2 – 29 021DH 3 – 29 031DH
2 – 30 021EH 3 – 30 031EH
2 – 31 021FH 3 – 31 031FH
2 – 32 0220H 3 – 32 0320H
2 – 33 0221H 3 – 33 0321H
2 – 34 0222H 3 – 34 0322H
2 – 35 0223H 3 – 35 0323H
2 – 36 0224H 3 – 36 0324H
2 – 37 0225H 3 – 37 0325H
3 – 38 0326H
3 – 39 0327H
3 – 40 0328H
3 – 41 0329H
3 – 42 032AH
Function Register No Function Register No Function Register No
Group 5 Group 5 Group 6
5 – 00 0500H 5 – 33 0521H 6– 00 0600H
5 – 01 0501H 5 – 34 0522H 6 – 01 0601H
5 – 02 0502H 5 – 35 0523H 6 – 02 0602H
5 – 03 0503H 5 – 36 0524H 6 – 03 0603H
5 – 04 0504H 5 – 37 0525H 6 – 04 0604H
5 – 05 0505H 5 – 38 0526H 6 – 05 0605H
5 – 06 0506H 5 – 39 0527H 6 – 06 0606H
5 – 07 0507H 5 – 40 0528H 6 – 07 0607H
5 – 08 0508H 5 – 41 0529H 6 – 08 0608H
5 – 09 0509H 5 – 42 052AH 6 – 09 0609H
5 – 10 050AH 5 – 43 052BH 6 – 10 060AH
5 – 11 050BH 5 – 44 052CH 6 – 11 060BH
5 – 12 050CH 5 – 45 052DH 6 – 12 060CH
5 – 13 050DH 5 – 46 052EH 6 – 13 060DH
5 – 14 050EH 5 – 47 052FH 6 – 14 060EH
5 – 15 050FH 5 – 48 0530H 6 – 15 060FH
5 – 16 0510H 6 – 16 0610H
5 – 17 0511H 6 – 17 0611H
5 – 18 0512H 6 – 18 0612H
5 – 19 0513H 6 – 19 0613H
5 – 20 0514H 6 – 20 0614H
5 – 21 0515H 6 – 21 0615H
5 – 22 0516H 6 – 22 0616H
5 – 23 0517H 6 – 23 0617H
5 – 24 0518H 6 – 24 0618H
VDI100 • Instruction manual 15
Function Register No Function Register No Function Register No
Group 5 Group 5 Group 6
5 – 25 0519H 6 – 25 0619H
5 – 26 051AH 6 – 26 061AH
5 – 27 051BH 6 – 27 061BH
5 – 28 051CH 6 – 28 061CH
5 – 29 051DH 6 – 29 061DH
5 – 30 051EH 6 – 30 061EH
5 – 31 051FH 6 – 31 061FH
5 – 32 0520H 6 – 32 0620H
Function Register No Function Register No Function Register No Function Register No
Group 6 Group 7 Group8 Group 8
6 – 33 0621H 7– 00 0700H 8– 00 0800H 8 – 41 0829H
6 – 34 0622H 7 – 01 0701H 8 – 01 0801H 8 – 42 082AH
6 – 35 0623H 7 – 02 0702H 8 – 02 0802H 8 – 43 082BH
6 – 36 0624H 7 – 03 0703H 8 – 03 0803H 8 – 44 082CH
6 – 37 0625H 7 – 04 0704H 8 – 04 0804H
6 – 38 0626H 7 – 05 0705H 8 – 05 0805H
6 – 39 0627H 7 – 06 0706H 8 – 06 0806H
6 – 40 0628H 7 – 07 0707H 8 – 07 0807H
6 – 41 0629H 7 – 08 0708H 8 – 08 0808H
6 – 42 062AH 7 – 09 0709H 8 – 09 0809H
6 – 43 062BH 7 – 10 070AH 8 – 10 080AH
6 – 44 062CH 7 – 11 070BH 8 – 11 080BH
6 – 45 062DH 7 – 12 070CH 8 – 12 080CH
6 – 46 062EH 7 – 13 070DH 8 – 13 080DH
6 – 47 062FH 7 – 14 070EH 8 – 14 080EH
7 – 15 070FH 8 – 15 080FH
7 – 16 0710H 8 – 16 0810H
7 – 17 0711H 8 – 17 0811H
7 – 18 0712H 8 – 18 0812H
7 – 19 0713H 8 – 19 0813H
7 – 20 0714H 8 – 20 0814H
7 – 21 0715H 8 – 21 0815H
7 – 22 0716H 8 – 22 0816H
7 – 23 0717H 8 – 23 0817H
7 – 24 0718H 8 – 24 0818H
7 – 25 0719H 8 – 25 0819H
7 – 26 071AH 8 – 26 081AH
7 – 27 071BH 8 – 27 081BH
7 – 28 071CH 8 – 28 081CH
7 – 29 071DH 8 – 29 081DH
7 – 30 071EH 8 – 30 081EH
7 – 31 071FH 8 – 31 081FH
7 – 32 0720H 8 – 32 0820H
7 – 33 0721H 8 – 33 0821H
8 – 34 0822H
8 – 35 0823H
8 – 36 0824H
8 – 37 0825H
8 – 38 0826H
8 – 39 0827H
8 – 40 0828H
Function Register No Function Register No Function Register No
Group 9 Group 10 Group 11
9– 00 0900H 10– 00 0A00H 11– 00 0B00H
9 – 01 0901H 10 – 01 0A01H 11 – 01 0B01H
9 – 02 0902H 10 – 02 0A02H 11 – 02 0B02H
16 VDI100 • Instruction manual
Function Register No Function Register No Function Register No
Group 9 Group 10 Group 11
9 – 03 0903H 10 – 03 0A03H 11 – 03 0B03H
9 – 04 0904H 10 – 04 0A04H 11 – 04 0B04H
9 – 05 0905H 10 – 05 0A05H 11 – 05 0B05H
9 – 06 0906H 10 – 06 0A06H 11 – 06 0B06H
9 – 07 0907H 10 – 07 0A07H 11 – 07 0B07H
9 – 08 0908H 10 – 08 0A08H 11 – 08 0B08H
9 – 09 0909H 10 – 09 0A09H 11 – 09 0B09H
10 – 10 0A0AH 11 – 10 0B0AH
10 – 11 0A0BH 11 – 11 0B0BH
10 – 12 0A0CH 11 – 12 0B0CH
10 – 13 0A0DH 11 – 13 0B0DH
10 – 14 0A0EH 11 – 14 0B0EH
10 – 15 0A0FH 11 – 15 0B0FH
10 – 16 0A10H 11 – 16 0B10H
10 – 17 0A11H 11 – 17 0B11H
10 – 18 0A12H 11 – 18 0B12H
10 – 19 0A13H 11 – 19 0B13H
10 – 20 0A14H 11 – 20 0B14H
10 – 21 0A15H 11 – 21 0B15H
10 – 22 0A16H 11 – 22 0B16H
10 – 23 0A17H 11 – 23 0B17H
10 – 24 0A18H 11 – 24 0B18H
10 – 25 0A19H 11 – 25 0B19H
10 – 26 0A1AH 11 – 26 0B1AH
10 – 27 0A1BH 11 – 27 0B1BH
10 – 28 0A1CH 11 – 28 0B1CH
10 – 29 0A1DH 11 – 29 0B1DH
10 – 30 0A1EH 11 – 30 0B1EH
10 – 31 0A1FH 11 – 31 0B1FH
10 – 32 0A20H 11 - 32 0B20H
10 – 33 0A21H 11– 33 0B21H
10 – 34 0A22H 11 – 34 0B22H
10 – 35 0A23H 11 – 35 0B23H
10 – 36 0A24H 11– 36 0B24H
10 – 37 0A25H 11 – 37 0B25H
10 – 38 0A26H 11 – 38 0B26H
10 – 39 0A27H 11– 39 0B27H
10 – 40 0A28H 11 – 40 0B28H
10 – 41 0A29H 11 – 41 0B29H
11– 42 0B2AH
11 – 43 0B2BH
Function Register No Function Register No Function Register No
Group 11 Group 12 Group 12
11 – 44 0B2CH 12– 00 High WORD: 2510H
Low WORD: 2511H 12 – 35 0C23H
11– 45 0B2DH 12 – 01 0C01H 12– 36 0C24H
11 – 46 0B2EH 12 – 02 0C02H 12 – 37 0C25H
11 – 47 0B2FH 12 – 03 0C03H 12 – 38 0C26H
11 – 48 0B30H 12 – 04 0C04H 12– 39 0C27H
11 – 49 0B31H 12 – 05 0C05H 12 – 40 0C28H
11 - 50 0B32H 12 – 06 0C06H 12 – 41 0C29H
11 - 51 0B33H 12 – 07 0C07H 12– 42 0C2AH
11 – 52 0B34H 12 – 08 0C08H 12 – 43 0C2BH
11 – 53 0B35H 12 – 09 0C09H 12 – 44 0C2CH
11 – 54 0B36H 12 – 10 0C0AH 12– 45 0C2DH
11 – 55 0B37H 12 – 11 0C0BH 12 – 46 0C2EH
11 – 56 0B38H 12 – 12 0C0CH 12 – 47 0C2FH
VDI100 • Instruction manual 17
Function Register No Function Register No Function Register No
Group 11 Group 12 Group 12
11 – 57 0B39H 12 – 13 0C0DH 12 – 48 0C30H
11 – 58 0B3AH 12 – 14 0C0EH 12 – 49 0C31H
11 – 59 0B3BH 12 – 15 0C0FH 12 - 50 0C32H
11 – 60 0B3CH 12 – 16 0C10H 12 - 51 0C33H
11 – 61 0B3DH 12 – 17 0C11H 12 – 52 0C34H
11 – 62 0B3EH 12 – 18 0C12H 12 – 53 0C35H
11 – 63 0B3FH 12 – 19 0C13H 12 – 54 0C36H
11 – 64 0B40H 12 – 20 0C14H 12 – 55 0C37H
11 – 65 0B41H 12 – 21 0C15H 12 – 56 0C38H
12 – 22 0C16H 12 – 57 0C39H
12 – 23 0C17H 12 – 58 0C3AH
12 – 24 0C18H 12 – 59 0C3BH
12 – 25 0C19H 12 – 60 0C3CH
12 – 26 0C1AH 12 – 61 0C3DH
12 – 27 0C1BH 12 – 62 0C3EH
12 – 28 0C1CH 12 – 63 0C3FH
12 – 29 0C1DH 12 – 64 0C40H
12 – 30 0C1EH 12 – 65 0C41H
12 – 31 0C1FH 12 – 66 0C42H
12 - 32 0C20H 12 – 67 0C43H
12– 33 0C21H 12 – 68 0C44H
12 – 34 0C22H 12 – 69 0C45H
Function Register No Function Register No Function Register No
Group 12 Group 13 Group 14
12 – 70 0C46H 13– 00 0D00H 14– 00 0E00H
12 – 71 0C47H 13 – 01 0D01H 14 – 01 0E01H
12 – 72 0C48H 13 – 02 0D02H 14 – 02 0E02H
12 – 73 0C49H 13 – 03 0D03H 14 – 03 0E03H
12 – 74 0C4AH 13 – 04 0D04H 14 – 04 0E04H
12 – 75 0C4BH 13 – 05 0D05H 14 – 05 0E05H
12 – 76 0C4CH 13 – 06 0D06H 14 – 06 0E06H
12 – 77 0C4DH 13 – 07 0D07H 14 – 07 0E07H
12 – 78 0C4EH 13 – 08 0D08H 14 – 08 0E08H
12 – 79 0C4FH 13 – 09 0D09H 14 – 09 0E09H
13 – 10 0D0AH 14 – 10 0E0AH
13 – 11 0D0BH 14 – 11 0E0BH
13 – 12 0D0CH 14 – 12 0E0CH
13 – 13 0D0DH 14 – 13 0E0DH
13 – 14 0D0EH 14 – 14 0E0EH
13 – 15 0D0FH 14 – 15 0E0FH
14 – 16 0E10H
14 – 17 0E11H
14 – 18 0E12H
14 – 19 0E13H
14 – 20 0E14H
14 – 21 0E15H
14 – 22 0E16H
14 – 23 0E17H
14 – 24 0E18H
14 – 25 0E19H
14 – 26 0E1AH
14 – 27 0E1BH
14 – 28 0E1CH
14 – 29 0E1DH
14 – 30 0E1EH
14 – 31 0E1FH
14 – 32 0E20H
18 VDI100 • Instruction manual
Function Register No Function Register No Function Register No
Group 12 Group 13 Group 14
14 – 33 0E21H
14 – 34 0E22H
Function Register No Function Register No Function Register No
Group 14 Group 15 Group 16
14 – 35 0E23H 15– 00 0F00H 16– 00 1000H
14 – 36 0E24H 15 – 01 0F01H 16 – 01 1001H
14 – 37 0E25H 15 – 02 0F02H 16 – 02 1002H
14 – 38 0E26H 15 – 03 0F03H 16 – 03 1003H
14 – 39 0E27H 15 – 04 0F04H 16 – 04 1004H
14 – 40 0E28H 15 – 05 0F05H 16 – 05 1005H
14 – 41 0E29H 15 – 06 0F06H 16 – 06 1006H
14 – 42 0E2AH 15 – 07 0F07H 16– 07 1007H
14 – 43 0E2BH 15 – 08 0F08H 16 – 08 1008H
14 – 44 0E2CH 15 – 09 0F09H 16 – 09 1009H
14 – 45 0E2DH 15 – 10 0F0AH
14 – 46 0E2EH 15 – 11 0F0BH
14 – 47 0E2FH 15 – 12 0F0CH
15 – 13 0F0DH
15 – 14 0F0EH
15 – 15 0F0FH
15 – 16 0F10H
15 – 17 0F11H
15 – 18 0F12H
15 – 19 0F13H
15 – 20 0F14H
15 – 21 0F15H
15 – 22 0F16H
15 – 23 0F17H
15 – 24 0F18H
15 – 25 0F19H
15 – 26 0F1AH
15 – 27 0F1BH
15 – 28 0F1CH
15 – 29 0F1DH
15 – 30 0F1EH
15 – 31 0F1FH
15 – 32 0F20H
Function Register No Function Register No Function Register No
Group 17 Group 18 Group 19
17– 00 1100H 18– 00 1200H 19– 00 1300H
17 – 01 1101H 18 – 01 1201H 19 – 01 1301H
17 – 02 1102H 18 – 02 1202H 19 – 02 1302H
17 – 03 1103H 18 – 03 1203H 19 – 03 1303H
17 – 04 1104H 18 – 04 1204H 19 – 04 1304H
17 – 05 1105H 18 – 05 1205H 19 – 05 1305H
17 – 06 1106H 18 – 06 1206H 19 – 06 1306H
17 – 07 1107H 19– 07 1307H
17 – 08 1108H
17– 09 1109H
17 – 10 110AH
17 – 11 110BH
17 – 12 110CH
17 – 13 110DH
17 – 14 110EH
VDI100 • Instruction manual 19
Function Register No Function Register No Function Register No Function Register No
Group 20 Group 21 Group 21 Group 22
20– 00 1400H 21– 00 1500H 21–33 1521H 22 – 00 1600H
20 – 01 1401H 21 – 01 1501H 21 – 34 1522H 22 – 01 1601H
20 – 02 1402H 21 – 02 1502H 21 – 35 1523H 22 – 02 1602H
20 – 03 1403H 21 – 03 1503H 21 – 36 1524H 22 – 03 1603H
20 – 04 1404H 21 – 04 1504H 21 – 37 1525H 22 – 04 1604H
20 – 05 1405H 21 – 05 1505H 21 – 38 1526H 22 – 05 1605H
20 – 06 1406H 21 – 06 1506H 21 – 39 1527H 22 – 06 1606H
20 – 07 1407H 21 – 07 1507H 21 – 40 1528H 22 – 07 1607H
20 – 08 1408H 21 – 08 1508H 21 – 41 1529H 22 – 08 1608H
20 – 09 1409H 21 – 09 1509H 21 – 42 152AH 22 – 09 1609H
20 – 10 140AH 21 – 10 150AH 21 – 43 152BH 22 – 10 160AH
20 – 11 140BH 21 – 11 150BH 22 – 11 160BH
20 – 12 140CH 21 – 12 150CH 22 – 12 160CH
20 – 13 140DH 21 – 13 150DH 22 – 13 160DH
20 – 14 140EH 21 – 14 150EH 22 – 14 160EH
20 – 15 140FH 21 – 15 150FH 22 – 15 160FH
20 – 16 1410H 21 – 16 1510H 22 – 16 1610H
20 – 17 1411H 21 – 17 1511H 22 – 17 1611H
20 – 18 1412H 21 – 18 1512H 22 – 18 1612H
20 – 19 1413H 21 – 19 1513H 22 – 19 1613H
20 – 20 1414H 21 – 20 1514H 22 – 20 1614H
20 – 21 1415H 21 – 21 1515H 22 – 21 1615H
20 – 22 1416H 21 – 22 1516H 22 – 22 1616H
20 – 23 1417H 21 – 23 1517H
20 – 24 1418H 21 – 24 1518H
20 – 25 1419H 21 – 25 1519H
20 – 26 141AH 21 – 26 151AH
20 – 27 141BH 21 – 27 151BH
20 – 28 141CH 21 – 28 151CH
20 – 29 141DH 21 – 29 151DH
20 – 30 141EH 21 – 30 151EH
20 – 31 141FH 21 – 31 151FH
20 – 32 1420H 21 – 32 1520H
20 – 33 1421H
20 – 34 1422H
20 – 35 1423H
20 VDI100 • Instruction manual
Other manuals for VDI100 Series
2
Table of contents
Languages:
Other gefran Motherboard manuals
