Texas Instruments DLP LightCrafter Display 3010 User manual

User's Guide
DLPU029A–October 2014–Revised January 2015
DLP®LightCrafter™ Display 3010 EVM User’s Guide
Topic ........................................................................................................................... Page
1 DLP®LightCrafter™ Display 3010 EVM Overview..................................................... 2
2 Applicable Documents.......................................................................................... 2
3 What is in the LightCrafter Display 3010 EVM.......................................................... 3
4 Light Engine........................................................................................................ 4
5 Quick-Start Procedure.......................................................................................... 4
6 Circuit Description ............................................................................................... 5
7 EVM Setup .......................................................................................................... 8
1
DLPU029A–October 2014–Revised January 2015 DLP®LightCrafter™ Display 3010 EVM User’s Guide
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

DLP®LightCrafter™ Display 3010 EVM Overview www.ti.com
1 DLP®LightCrafter™ Display 3010 EVM Overview
This user’s guide presents an overview of the DLP LightCrafter Display 3010 evaluation module (EVM)
and a general description of the main features and functions. It will explain the first steps to get started,
shows a detailed description of the push buttons function, the on board LEDs and the main connectors. It
will give the user a successful start with his first DLP LightCrafter Display 3010 evaluation module.
Figure 1. DLP LightCrafter Display complete EVM
In addition to this document, the following documents shown in Section 2 should be used.
2 Applicable Documents
The following documents are applicable to the DLP LightCrafter™ Display 3010 EVM and are available at
TI.com www.ti.com.
• DLP3010 (.3 720p) DMD data sheet, TI literature number DLPS051
• DLPC3438 controller data sheet, TI literature number DLPS035A
• Software Programmer's Guide, TI literature number DLPU020A
• DLP LightCrafter Display EVM GUI Tool User's Guide, TI literature number DLPU021
If you need assistance refer to the DLP and MEMS TI E2E community support forums. forums.
LightCrafter is a trademark of Texas Instruments.
DLP is a registered trademark of Texas Instruments.
All other trademarks are the property of their respective owners.
2DLP®LightCrafter™ Display 3010 EVM User’s Guide DLPU029A–October 2014–Revised January 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

www.ti.com What is in the LightCrafter Display 3010 EVM
3 What is in the LightCrafter Display 3010 EVM
The DLP LightCrafter Display module consists of three subsystems:
• Light engine – includes the optics, red, green, and blue LEDs, and a 1280 × 720 (720p) DMD capable
of 300 lumens out-of-the-box.
• Driver board – includes the DLP chipset comprising of DLPC3438 Controller and DLPA2005
PMIC/LED driver.
• System board – includes MSP430, ITE HDMI receiver, USB-Serial Bridge controller and several
connectors for external inputs (HDMI, USB, etc.)
Figure 2. DLP LightCrafter Display EVM Block Diagram
3
DLPU029A–October 2014–Revised January 2015 DLP®LightCrafter™ Display 3010 EVM User’s Guide
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

80.35
56.97
21.00
20.50
Light Engine www.ti.com
4 Light Engine
The optical engine in the EVM is developed by eProtech and is production ready.
The light engine consists of the following components:
• 0.3-inch 720p DMD (DLP3010)
• OSRAM red, green and blue LED
Table 1. Optical Engine specifications
Parameter Min Typ Max Unit
Brightness 125 Lum
LED Current 2.4 A
Brightness Uniformity 75%
Throw Ratio 1.65
Offset 100%
Focus Range 5 50 inch
Image diagonal size 5 50 inch
Figure 3.
5 Quick-Start Procedure
This quick-start assumes default conditions as shipped.
1. Power up the DLP LightCrafter™ Display 3010 EVM by applying an external DC power supply (5 V
DC, 3.0 A) to the J12 connector. Note: Use an AC-DC switching power supply which accepts 50-60Hz
100-240 VAC inputs, and outputs a nominal 5 VDC at maximum 3 A output current. The PWRON
(D16) and SYSPWR (D15) LED will turn on to indicate that 5 V power is applied
2. Move the SW_ONOFF switch to the ON position to turn the DLP LightCrafter Display 3010 EVM on.
When the LightCrafter Display 3010 EVM is turned on, the PROJ_ON LED will turn on.
3. After the DLP LightCrafter Display 3010 EVM is turned on; the projector will default to displaying a DLP
LightCrafter Display splash image.
4. The focus of the image can be adjusted on the optical engine.
4DLP®LightCrafter™ Display 3010 EVM User’s Guide DLPU029A–October 2014–Revised January 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

Focus
Adjustment
www.ti.com Circuit Description
Figure 4. Optical engine with focus adjustment
5. Connect USB to the LightCrafter™ Display 3010 EVM and open the GUI on your Computer. If needed
connect a HDMI source to the EVM and communicate to the EVM over the GUI software.
6. When turning off the projector, turn off the SW_ONOFF switch prior to removing power cable. Note: To
avoid potential damage to the DMD it is recommended to turn off the projector with the SW_ONOFF
before disconnecting the power.
7. There are ten indicator LEDs on the DLP LightCrafter Display 3010 EVM (Table 2):
Table 2. LEDs on the DLP LightCrafter Display 3010 EVM
D15 SYSPWR 5 V Power applied
D16 PWRON Regulated 3V3 power on
D7 PROJ_ON On when Projector is turned on via SW_ONOFF
D6 RESETZ OFF when Projector is turned on vie SW_ONOFF
ON during DLPC3438 boot OFF when projector is
D5 HOST_IRQ running. Indication of DLPC3438 boot-up
completed and ready to receive commands
ON when HDMI cable plugged in, and external
D9 MSP2 video detected. OFF when external video is not
detected.
ON when Cypress CY3420 is I2C master OFF
D8 ACK when MSP430 is I2C master
ON when Cypress CY3420 requests the MSP430
D10 REQ to give Cypress master control of the I2C bus
Blinking when PC is communicating to flash over
D12 GPIO1 SPI
Blinking when PC is communicating to DLPC3438
D14 GPIO0 over I2C
6 Circuit Description
6.1 Connectors, Switch and Push buttons on Main Board
Table 3. List of installed Connectors on the main board
Installed Connectors/Headers Description
J12 Connector for 5 V external power supply interface
J7 Connector for USB cable
J2 Connector for Audio
J4 Connector for HDMI input
J1 MSP430 JTAG Programming interface connector
J13 Connector for the I2C interface (DevaSys box)
J6 60 pin connector for DLP LightCrafter Display board
J10 Header for 5 V DC power
5
DLPU029A–October 2014–Revised January 2015 DLP®LightCrafter™ Display 3010 EVM User’s Guide
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

Circuit Description www.ti.com
Table 3. List of installed Connectors on the main board (continued)
Installed Connectors/Headers Description
J11 Header for 5 V DC power
J3 Unsupported
J5 Unsupported
Table 4. List of installed Push buttons and Switch on main board
Installed Switches/Push buttons Description
SW1 Projector On/OFF Switch
Source Selection
• First press: TPG
PB-UP1 • Second press: HDMI input
• Third press: Splash screen
PB-SEL1 Cycle through displaying 7 curtain colors
PB-DOWN1 Flip image N/S or E/W
Cycle 9 different TPG patterns after TPG source selected
PB_LEFT1 Cycle 4 different Splash screens after Splash source selected
Change of Volume when HDMI input is selected
Change LED current total 7 steps
PB_RIGHT1 Change of Volume when HDMI input is selected
6DLP®LightCrafter™ Display 3010 EVM User’s Guide DLPU029A–October 2014–Revised January 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

www.ti.com Circuit Description
6.2 Connectors on DLP LightCrafter Display board
Table 5. List of installed Connectors on the DLP LightCrafter™ Display board
Installed Switches/Push buttons Description
J1 Connector for the DMD flex cable
J2 Connector for LED cable
J3 Connector for external temperature sensor (Requires removing R21)
J4 Connector for light sensor
J5 Future use
J6 60 pin connector for DLP LightCrafter Display board
7
DLPU029A–October 2014–Revised January 2015 DLP®LightCrafter™ Display 3010 EVM User’s Guide
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

Audio
Interface
Projector
ON/OFF
Switch
HDMI
Connector
5V Power
Connector
DLP
LightCrafter™
Display Board
Connector
USB
Connector
EVM Setup www.ti.com
7 EVM Setup
The DLP LightCrafter Display 3010 EVM is composed of three parts:
• Main board
• DLP LightCrafter Display board
• Engine with LED connection and Flex cable
The main board contains the connector for the power supply, a USB connector to communicate to the
DLP LightCrafter™ Display software, HDMI, audio and the connector for the DLP LightCrafter™Display
board. The main board also contains a switch to turn on the projector in case the DLP LightCrafter™
Display board and the engine are connected. Figure 5 shows the main connectors on the main board.
Figure 5. DLP LightCrafter Display main board
The DLP LightCrafter™ Display board has three main connectors: the LED connector, the Flex cable
connector, and the main board connector. To connect the main board to the DLP LightCrafter™ Display
board, refer to Figure 6. Note that the main board connector on the DLP LightCrafter™ Display board is
on the bottom while the LED and Flex cable connectors are on the top.
8DLP®LightCrafter™ Display 3010 EVM User’s Guide DLPU029A–October 2014–Revised January 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

LED
Connector
Flex Cable
Connector
www.ti.com EVM Setup
Figure 6. Connection Main Board and DLP LightCrafter Display board
The board itself and how it gets connected to the main board is shown in Figure 7
Figure 7. DLP LightCrafter Display
TA LED adapter board is connecting the three LEDs with the LED connector on the DLP LightCrafter™
Display board. The different connectors for each LED are named on the board as well as on the light
engine. Refer to Figure 8 to see the proper setup.
Ensure a good connection of the flex cable to the DLP LightCrafter™ Display board before turning it on.
9
DLPU029A–October 2014–Revised January 2015 DLP®LightCrafter™ Display 3010 EVM User’s Guide
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

EVM Setup www.ti.com
Figure 8. LED Connection
Figure 9 shows the final setup of all parts.
Figure 9. DLP LightCrafter Display complete EVM
Make sure that everything is setup correctly before continuing! Verify that the flex cable is connected
correctly to the LightCrafter Display board.
10 DLP®LightCrafter™ Display 3010 EVM User’s Guide DLPU029A–October 2014–Revised January 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated
