Cinterion®Java Terminals
Hardware Interface Overview
Version: 03
DocId: EHSxT_BGS5T_HIO_v03

GENERAL NOTE
THE USE OF THE PRODUCT INCLUDING THE SOFTWARE AND DOCUMENTATION (THE "PROD-
UCT") IS SUBJECT TO THE RELEASE NOTE PROVIDED TOGETHER WITH PRODUCT. IN ANY
EVENT THE PROVISIONS OF THE RELEASE NOTE SHALL PREVAIL. THIS DOCUMENT CONTAINS
INFORMATION ON GEMALTO M2M PRODUCTS. THE SPECIFICATIONS IN THIS DOCUMENT ARE
SUBJECT TOCHANGEATGEMALTOM2M'SDISCRETION. GEMALTO M2M GMBH GRANTS A NON-
EXCLUSIVE RIGHT TO USE THE PRODUCT. THE RECIPIENT SHALL NOT TRANSFER, COPY,
MODIFY, TRANSLATE, REVERSE ENGINEER, CREATE DERIVATIVE WORKS; DISASSEMBLE OR
DECOMPILE THE PRODUCT OR OTHERWISE USE THE PRODUCT EXCEPT AS SPECIFICALLY
AUTHORIZED. THE PRODUCT AND THIS DOCUMENT ARE PROVIDED ON AN "AS IS" BASIS ONLY
AND MAY CONTAIN DEFICIENCIES OR INADEQUACIES. TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, GEMALTO M2M GMBH DISCLAIMS ALL WARRANTIES AND LIABILITIES.
THE RECIPIENT UNDERTAKES FOR AN UNLIMITED PERIOD OF TIME TO OBSERVE SECRECY
REGARDING ANY INFORMATION AND DATA PROVIDED TO HIM IN THE CONTEXT OF THE DELIV-
ERY OF THE PRODUCT. THIS GENERAL NOTE SHALL BE GOVERNED AND CONSTRUED
ACCORDING TO GERMAN LAW.
Copyright
Transmittal, reproduction, dissemination and/or editing of this document as well as utilization of its con-
tents and communication thereof to others without express authorization are prohibited. Offenders will be
held liable for payment of damages. All rights created by patent grant or registration of a utility model or
design patent are reserved.
Copyright © 2016, Gemalto M2M GmbH, a Gemalto Company
Trademark Notice
Gemalto, the Gemalto logo, are trademarks and service marks of Gemalto and are registered in certain
countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corpora-
tion in the United States and/or other countries. All other registered trademarks or trademarks mentioned
in this document are property of their respective owners.
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Cinterion®Java Terminals Hardware Interface Overview
2
Page 2 of 50
Document Name: Cinterion®Java Terminals Hardware Interface Overview
Version: 03
Date: 2016-05-26
DocId: EHSxT_BGS5T_HIO_v03
Status Confidential / Released

Cinterion®Java Terminals Hardware Interface Overview
Contents
124
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 3 of 50
Contents
0 Document History...................................................................................................... 7
1 Introduction.................................................................................................................8
1.1 Related Documents ...........................................................................................9
1.2 Terms and Abbreviations...................................................................................9
1.3 Regulatory and Type Approval Information .....................................................11
1.3.1 Directives and Standards....................................................................11
1.3.2 Safety Precautions..............................................................................14
1.4 Product Label...................................................................................................16
2 Product Concept.......................................................................................................17
2.1 Key Features at a Glance................................................................................17
3 Interface Description ................................................................................................20
3.1 Overview..........................................................................................................20
3.2 Block Diagram..................................................................................................21
3.3 Operating Modes .............................................................................................22
3.4 RS-232 Interface..............................................................................................23
3.4.1 9-Pole D-sub Connector .....................................................................23
3.5 USB Interface...................................................................................................24
3.6 GPIO Interface.................................................................................................24
3.6.1 Serial Interface ASC1 .........................................................................27
3.6.2 Digital Audio Interface.........................................................................28
3.6.3 I2C Interface........................................................................................29
3.6.4 SPI Interface.......................................................................................30
3.6.5 PWM Interface....................................................................................31
3.6.6 Pulse Counter.....................................................................................31
3.6.7 Analog-to-Digital Converter (ADC)......................................................31
3.6.8 DSR0 signal........................................................................................31
3.7 Ethernet Interface ............................................................................................32
3.8 Power Supply...................................................................................................33
3.9 Power Up/Power Down Scenarios...................................................................34
3.9.1 Turn Java Terminals on......................................................................34
3.9.2 Reset/Restart Java Terminals.............................................................34
3.9.3 Turn Java Terminals off......................................................................35
3.9.4 Disconnecting power supply...............................................................35
3.10 Automatic thermal shutdown............................................................................36
3.11 Hardware Watchdog........................................................................................36
3.12 RTC..................................................................................................................36
3.13 SIM Interface....................................................................................................37
3.14 Status LEDs.....................................................................................................38
3.15 RF Antenna Interface.......................................................................................39

Cinterion®Java Terminals Hardware Interface Overview
Contents
124
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 4 of 50
4 Mechanics, Mounting and Packaging.....................................................................40
4.1 Mechanical Dimensions...................................................................................40
4.2 Mounting the Java Terminals...........................................................................43
4.3 Packaging........................................................................................................44
5 Full Type Approval....................................................................................................45
5.1 Gemalto M2M Reference Setup ......................................................................45
5.2 Restrictions......................................................................................................46
5.3 CE Conformity..................................................................................................46
5.4 EMC.................................................................................................................46
5.5 Compliance with FCC and IC Rules and Regulations .....................................47
6 List of Parts and Accessories..................................................................................49

Cinterion®Java Terminals Hardware Interface Overview
Tables
5
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 5 of 50
Tables
Table 1: Cinterion®Java Terminals overview .................................................................8
Table 2: Terms and abbreviations...................................................................................9
Table 3: Directives ........................................................................................................11
Table 4: Standards of North American type approval...................................................11
Table 5: Standards of European type approval.............................................................11
Table 6: Requirements of quality ..................................................................................12
Table 7: Standards of the Ministry of Information Industry of the
People’s Republic of China.............................................................................13
Table 8: Toxic or hazardous substances or elements with defined concentration
limits................................................................................................................13
Table 9: Java Terminals label information ....................................................................16
Table 10: Java Terminals‘ interfaces ..............................................................................20
Table 11: Overview of operating modes .........................................................................22
Table 12: 9-pole D-sub (female) RS-232........................................................................23
Table 13: GPIO connector pin availability and alternate pin functionalities....................26
Table 14: Overview of DAI/PCM signals.........................................................................28
Table 15: Female 8-pole RJ-45 Ethernet connector.......................................................32
Table 16: Female 6-pole Western plug for power supply, ignition, power down.............33
Table 17: Allowed maximum antenna gain (including cable loss)...................................39
Table 18: List of parts and accessories...........................................................................49

Cinterion®Java Terminals Hardware Interface Overview
Figures
6
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 6 of 50
Figures
Figure 1: Sample Java Terminal label (BGS5T USB)....................................................16
Figure 2: Java Terminals 3D view..................................................................................20
Figure 3: Block diagram .................................................................................................21
Figure 4: Pin assignment RS-232 (D-sub 9-pole female)...............................................23
Figure 5: EHS5T RS485: GPIO connectors (8-pin and 12-pin)......................................24
Figure 6: EHS6T USB/EHS6T LAN: GPIO connectors (8-pin and 12-pin).....................25
Figure 7: BGS5T USB: GPIO connectors (8-pin and 12-pin).........................................25
Figure 8: Long frame PCM timing, 256kHz....................................................................28
Figure 9: Characteristics of SPI modes..........................................................................30
Figure 10: 8-pole RJ-45 Ethernet connector (female)......................................................32
Figure 11: 6-pole Western jack for power supply, ignition, reset, typical connection.......33
Figure 12: SIM interface...................................................................................................37
Figure 13: Status LED......................................................................................................38
Figure 14: Antenna connector..........................................................................................39
Figure 15: Java Terminals 3D overview...........................................................................40
Figure 16: Java Terminals mechanical dimensions .........................................................41
Figure 17: Java Terminals exploded view........................................................................42
Figure 18: Mounting the Java Terminals..........................................................................43
Figure 19: Reference equipment for approval..................................................................45

Cinterion®Java Terminals Hardware Interface Overview
0 Document History
7
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 7 of 50
0 Document History
Preceding document: "Cinterion®Java Terminals Hardware Interface Overview" Version 02
New document: "Cinterion®Java Terminals Hardware Interface Overview" Version 03
Preceding document: "Cinterion®Java Terminals Hardware Interface Overview" Version 01
New document: "Cinterion®Java Terminals Hardware Interface Overview" Version 02
New document: "Cinterion®Java Terminals Hardware Interface Overview" Version 01
Chapter What is new
1.4 Revised Table 9.
3.7 Added support for Power-over-Ethernet (PoE).
Chapter What is new
Throughout
document Added EHS5T-US RS485 as new product.
Chapter What is new
-- Initial document setup.

Cinterion®Java Terminals Hardware Interface Overview
1 Introduction
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 8 of 50
1 Introduction
This document1describes the hardware of the Cinterion®Java Terminals. The Java Terminals
come in five variants depending on the included Cinterion®module and the available interfaces:
•EHS5T RS485 contains a Cinterion®EHS5-E module and implements a USB 2.0 interface
with a USB-B connector as well as a 6-pole Western jack as plug-in power supply connec-
tor. Via a GPIO interface it also implements a RS-485 interface including power supply and
ignition line.
•EHS5T-US RS485 is identical to EHS5T RS485, but contains a Cinterion®EHS5-US mod-
ule instead of a Cinterion®EHS5-E module. Note: Unless otherwise mentioned EHS5T
RS485 refers to both product variants.
•EHS6T USB contains a Cinterion®EHS6 module and implements a USB 2.0 interface with
a USB-B connector and also a V.24 / V.28 RS-232 interface with a D-sub 9-pole female
socket as well as a 6-pole Western jack as plug-in power supply connector.
•EHS6T LAN containsa Cinterion®EHS6 module and implements an Ethernet interface with
a RJ-45 8-pin connector and also a V.24 / V.28 RS-232 interface with a D-sub 9-pole female
socket as well as a 6-pole Western jack as plug-in power supply connector.
•BGS5T USB contains a Cinterion®BGS5 module and implements a USB 2.0 interface with
a USB-B connector and also a V.24 / V.28 RS-232 interface with a D-sub 9-pole female
socket as well as a 6-pole Western jack as plug-in power supply connector.
Wherever necessary and appropriate this document distinguishes between these five variants.
Table 1 gives a short overview of the available interfaces for the different Java Terminals.
The scope of this document includes interface specifications, electrical as well as mechanical
characteristics of the Java Terminals. It specifies standards pertaining to wireless applications
and outlines requirements that must be adhered to for successful product design. The Java
Terminals are compact GSM/UMTS modems for the transfer of data in GSM/UMTS networks.
Industrial standard interfaces and an integrated SIM card reader allow using the Java Termi-
nals easily as GSM/GPRS/UMTS terminals.
1. The document is effective only if listed in the appropriate Release Notes as part of the technical docu-
mentation delivered with your Gemalto M2M product.
Table 1: Cinterion®Java Terminals overview
Module/Interface EHS5T RS485 and
EHS5T-US RS485 EHS6T USB EHS6T LAN BGS5T USB
Cinterion®module EHS5-E or
EHS5-US EHS6 EHS6 BGS5
RS-232 (Sub-D) - 
USB (USB-B) -
GPIO interface
(GPIOs,Power,ASC1,DAI,
SPI, I2C, RS-485)
(no SPI) (no RS-485) (no RS-485) (no RS-485,
no SPI)
Ethernet (RJ-45) - - -
Power supply (RJ-11) 
RF antenna 

Cinterion®Java Terminals Hardware Interface Overview
1.1 Related Documents
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 9 of 50
1.1 Related Documents
[1] AT Command Set for your Java Terminal product
[2] Release Notes for your Java Terminal product
To visit the Gemalto M2M GmbH Website please use the following link:
http://m2m.gemalto.com
1.2 Terms and Abbreviations
Table 2: Terms and abbreviations
Abbreviation Description
ARP Antenna Reference Point
ATC AT Command
BTS Base Transceiver Station
CB Cell Broadcast
CODEC Coder-Decoder
DAI Digital Audio Interface
DCE Data Circuit terminating Equipment
DSR Data Set Ready
DTR Data Terminal Ready
EFR Enhanced Full Rate
EGSM Enhanced GSM
EMC Electromagnetic Compatibility
ESD Electrostatic Discharge
ETS European Telecommunication Standard
FDMA Frequency Division Multiple Access
G.C.F. GSM Conformity Forum
GSM Global Standard for Mobile Communication
HW Hardware
IC Integrated Circuit
IF Intermediate Frequency
IMEI International Mobile Equipment Identifier
I/O Input/ Output
IGT Ignition
ISO International Standards Organization
ITU International Telecommunications Union
kbps kbits per second

Cinterion®Java Terminals Hardware Interface Overview
1.2 Terms and Abbreviations
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 10 of 50
LVD Low voltage Directive
Mbps Mbits per second
MCU Microprocessor Controll Unit
MMI Machine Machine Interface
MO Mobile Originated
MS Mobile Station
MT Mobile Terminated
NC Not Connected
NTC Negative Temperature Coefficient
PA Power Amplifier
PCB Printed Circuit Board
PCM Pulse Code Modulation
PCS Personal Communication System
PD Power Down
PDU Protocol Data Unit
PoE Power over Ethernet
R&TTE Radio and Telecommunication Terminal Equipment
RF Radio frequency
RI Ring Indication
RX Receive direction
SIM Subscriber Identification Module
SMS Short Message Service
SW Software
TDD Time Division Duplex
TDMA Time Division Multiple Access
TX Transmit direction
UART Universal Asynchronous Receiver and Transmitter
Table 2: Terms and abbreviations
Abbreviation Description

Cinterion®Java Terminals Hardware Interface Overview
1.3 Regulatory and Type Approval Information
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 11 of 50
1.3 Regulatory and Type Approval Information
1.3.1 Directives and Standards
Java Terminals have been designed to comply with the directives and standards listed below1.
1. Standards of North American type approval do not apply to EHS5T RS485, 3G/WCDMA related stan-
dards do not apply to BGS5T USB.
Table 3: Directives
99/05/EC Directive of the European Parliament and of the council of 9 March 1999
on radio equipment and telecommunications terminal equipment and the
mutual recognition of their conformity (in short referred to as R&TTE Direc-
tive 1999/5/EC).
The product is labeled with the CE conformity mark - see Section 5.3.
2002/95/EC (RoHS 1)
2011/65/EC (RoHS 2) DirectiveoftheEuropean Parliamentand ofthe Council of 27 January 2003 (and revised on 8 June 2011) on the
restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS)
2002/96/EC Directive of the European Parliament and of the Council on waste electri-
cal and electronic equipment (WEEE)
2003/108/EC Directive of the European Parliament and of the Council of 8 December
2003 amending directive 2002/96/ec on waste electrical and electronic
equipment (WEEE)
Table 4: Standards of North American type approval
CFR Title 47 “Code of Federal Regulations, Part 15 B, Part 22 and Part 24 (Telecom-
munications, PCS)”; US Equipment Authorization FCC
OET Bulletin 65
(Edition 97-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields
UL 60 950-1 Product Safety Certification (Safety requirements)
NAPRD.03 V5.15 “Overview of PCS Type certification review board
Mobile Equipment Type Certification and IMEI control”
PCS Type Certification Review board (PTCRB)
RSS102 (Issue 4)
RSS132 (Issue 3)
RSS133 (Issue 6)
Canadian Standard
IEEE Std. C95.1-1999 IEEE Standard for Safety Levels with Respect to Human Exposure to
Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz
Table 5: Standards of European type approval
3GPP TS 51.010-1 “Digital cellular telecommunications system (Phase 2); Mobile Station
(MS) conformance specification”
ETSI EN 301 511 V9.0.2 Candidate Harmonized European Standard (Telecommunications series)
Global System for Mobile communications (GSM); Harmonized standard
for mobile stations in the GSM 900 and DCS 1800 bands covering essen-
tial requirements under article 3.2 of the R&TTE directive (1999/5/EC)
(GSM 13.11 version 7.0.1 Release 1998)
GCF-CC V3.49 Global Certification Forum - Certification Criteria

Cinterion®Java Terminals Hardware Interface Overview
1.3 Regulatory and Type Approval Information
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 12 of 50
ETSI EN 301 489-1
V1.9.2 Candidate Harmonized European Standard (Telecommunications series) Electro Magnetic Compatibility and Radio spectrum Matters (ERM); Elec-
tro Magnetic Compatibility (EMC) standard for radio equipment and ser-
vices; Part 1: Common Technical Requirements
ETSI EN 301 489-7
V1.3.1 Candidate Harmonized European Standard (Telecommunications series) Electro Magnetic Compatibility and Radio spectrum Matters (ERM); Elec-
tro Magnetic Compatibility (EMC) standard for radio equipment and ser-
vices; Part 7: Specific conditions for mobile and portable radio and
ancillary equipment of digital cellular radio telecommunications systems
(GSM and DCS)
ETSI EN 301 489-24
V1.5.1 Electromagnetic Compatibility and Radio spectrum Matters (ERM); Elec- tromagnetic Compatibility (EMC) standard for radio equipment and ser-
vices; Part 24: Specific conditions for IMT-2000 CDMA Direct Spread
(UTRA) for Mobile and portable (UE) radio and ancillary equipment
ETSI EN 301 908-01
V5.2.1 Electromagnetic compatibility and Radio spectrum Matters (ERM); Base Stations (BS) and User Equipment (UE) for IMT-2000 Third Generation
cellular networks; Part 1: Harmonized EN for IMT-2000, introduction and
common requirements of article 3.2 of the R&TTE Directive
ETSI EN 301 908-02
V5.2.1 Electromagnetic compatibility and Radio spectrum Matters (ERM); Base Stations (BS) and User Equipment (UE) for IMT-2000 Third Generation
cellular networks; Part 2: Harmonized EN for IMT-2000, CDMA Direct
Spread (UTRA FDD) (UE) covering essential requirements of article 3.2 of
the R&TTE Directive
EN 62311-2008 Assessment of electronic and electrical equipment related to human expo-
sure restrictions for electromagnetic fields (0 Hz - 300 GHz)
EN 60950-1 (2006)+
A11:2009+A1:2010+
AC:2011+A12:2011
Safety of information technology equipment
Table 6: Requirements of quality
IEC 60068 Environmental testing
DIN EN 60529 IP codes
Table 5: Standards of European type approval

Cinterion®Java Terminals Hardware Interface Overview
1.3 Regulatory and Type Approval Information
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 13 of 50
Table 8: Toxic or hazardous substances or elements with defined concentration limits
Table 7: Standards of the Ministry of Information Industry of the People’s Republic of China
SJ/T 11363-2006 “Requirements for Concentration Limits for Certain Hazardous Sub-
stances in Electronic Information Products” (2006-06).
SJ/T 11364-2006 “Marking for Control of Pollution Caused by Electronic
Information Products” (2006-06).
Accordingto the“Chinese Administrationonthe Control
of Pollution caused by Electronic Information Products”
(ACPEIP)theEPUP,i.e., Environmental Protection Use
Period, of this product is 20 years as per the symbol
shown here, unless otherwise marked. The EPUP is valid only as longas
the product is operated within the operating limits described in the Hard-
ware Interface Description.
Please see Table 1.3.2 for an overview of toxic or hazardous substances
or elements that might be contained in product parts in concentrations
above the limits defined by SJ/T 11363-2006.

Cinterion®Java Terminals Hardware Interface Overview
1.3 Regulatory and Type Approval Information
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 14 of 50
1.3.2 Safety Precautions
The following safety precautions must be observed during all phases of the operation, usage,
service or repair of anycellular terminal or mobileincorporating Java Terminals.Manufacturers
of the cellular terminal are advised to convey the following safety information to users and op-
erating personnel and incorporate these guidelines into all manuals supplied with the product.
Failure to comply with these precautions violates safety standards of design, manufacture and
intended use of the product. Gemalto M2M GmbH assumes no liability for customer’s failure to
comply with these precautions.
When in hospitals or other health care facilities, observe the restrictions on the use
of mobiles. Switch off the cellular terminal or mobile if to be instructed to do so by
the guidelines posted in sensitive areas. Medical equipment may be sensitive to RF
energy.
The operation of cardiac pacemakers, other implanted medical equipment and
hearing aids can be affected by interference from cellular terminals or mobiles
placed close to the device. If in doubt about potential danger, contact the physician
or the manufacturer of the device to verify that the equipment is properly shielded.
Pacemaker patients are advised to keep their hand-held mobile away from the
pacemaker, while it is on. This personalsubgroup always should check thedistance
to the mobile.
Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it
cannot be switched on inadvertently. The operation of wireless appliances in an air-
craft is forbidden to prevent interference with communications systems. Failure to
observe these instructions may lead to the suspension or denial of cellular services
to the offender, legal action, or both.
Check the local and actual laws about these themes.
Do not operate the cellular terminal or mobile in the presence of flammable gases
or fumes. Switch off the cellular terminal when you are near petrol stations, fuel
depots, chemical plants or where blasting operations are in progress. Operation of
any electrical equipment in potentially explosive atmospheres can constitute a
safety hazard.
Yourcellular terminalor mobile receives and transmits radio frequencyenergy while
switched on. Remember that interference can occur if it is used close to TV sets,
radios, computers or inadequately shielded equipment. Follow any special regula-
tions and always switch off the cellular terminal or mobile wherever forbidden, or
when you suspect that it may cause interference or danger.
Road safety comes first! Do not use a hand-held cellular terminal or mobile while
driving a vehicle unless it is securely mounted in a holder for speakerphone opera-
tion. Before making a call with a hand-held terminal or mobile park the vehicle.
Speakerphones must be installed by qualified personnel. Faulty installation or oper-
ation can constitute a safety hazard.
Check the actual and local laws about these themes.

Cinterion®Java Terminals Hardware Interface Overview
1.3 Regulatory and Type Approval Information
16
EHSxT_BGS5T_HIO_v03 2016-05-26
Confidential / Released
Page 15 of 50
IMPORTANT!
Cellular terminals or mobiles operate using radio signals and cellular networks. In
that case connections cannot be guaranteedat all times under all conditions. There-
fore, you should never rely solely upon any wireless device for essential communi-
cations, for example emergency calls.
Remember, in order to make calls or receive calls the cellular terminal or mobile
must be switched on in a service area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or
phone features are in use (e.g. lock functions, fixed dialing etc.). You may need to
deactivate those features before you can make an emergency call.
Some networks require a valid SIM card to be properly inserted in the cellular ter-
minal or mobile.
If a power supply unit is used to supply the device it must meet the demands placed
on SELV circuits in accordance with EN60950. The maximum permissible connec-
tion length between the device and the supply source should not exceed 3m.
According to the guidelines for human exposure to radio frequency energy, an
