Features
•2-in-1wireless combo adapter: bothWLAN and Bluetooth interfaces
•SupportsWLAN data transferrate up to54 Mbps
•AllmodernWLAN encryption securitystandardsincluding 256-bit
•Wireless connection withBluetoothenabledcomputers,mobilephones,
PDAs,etc.
•High-qualitywireless stereomusic
Specifications
•USB2.0interface, USB1.1 compatible, retractable connector
•WLAN: complieswithIEEE802.11g,IEEE802.11b,speed up to54
Mbps;security:WPA;64/128/256-bitWEP;TKIP/AES,WEP2; transmitter
output power:17 dBm(max); internalantenna type, gain:2.4GHzWireless
@±(typical): 2 dBi+/-1 dBi, working distanceup to 100 m
•Bluetooth:v.2.0+EDR,speedupto3Mbps,RFpowerupto18dBm
(Class I),working distanceup to100 m
•Dimensions: 77x26 x9.5mm
•Weight: 14 g
•Operating temperature: 0 ~40'C, 5 ~95%humidity
PackageContents
•USB2-in-1 dongle
•Drivers CD
•UserManual

4
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL
ThankyouforpurchasingtheGembird®NICW-U5Bluetoothand
WLAN Dongle!Thismanualwillhelpyou installand use itproperly.
The NICW-U5:
•High-speed wireless access to Internet
•Wireless high-qualitystereo music
•Exchange fileswithmobilephones
•Plug&Playeasyinstallation
•Suitableboth forlaptopsand desktop PCs
•SupportsWindows7
Installation
Pleasefollowthe stepsbelowto installthe softwareand driverforthis
Bluetooth andWLAN Dongle.

5
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL

6
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL

7
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL
Configuring wireless network inWindows®7
Windows®7operating systemhasso-called“Wireless Zero
Configuration”feature, whichcan beused to configureandcontrolthe
NICW-U5 Bluetooth and WLANDongle. Note: Wireless ZeroConfiguration
ismost appropriate tobe used at home and inSOHOlocalnetworks.
Wireless ZeroConfigurationshouldnot beusedinmediumorlarge
networksorin the networkswherea highdegree ofsecurityisrequired.
FollowthestepsbelowtoconfigureyourWLANDongleusing the
Wireless Zero Configuration:
1. Fromthe Start menu, select ControlPanel.
2. Click“NetworkConnections”.
3. Right-clickthenetwork connectionassociatedwith yourWireless
USBDongle and select “Properties”.
4. Clickthe “Wireless Networks” tab.
5. Checkthe “UseWindowsto configuremywireless networksettings”
checkbox.
6. Clickthe “View Wireless Networks” button.
7. Selectthe Access Point with which youwouldlike to connect.
8. Clickthe “Connect”button.
9. Enteryourlogin/password that isrequired bythisnetwork.

8
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL

9
GEMBIRD EUROPE B.V.
http://www.gembird.eu
NICW
-
U5BLUETOOTH ANDWLA
N DONGLE
USERMANUAL
