Gemini GOV12JW User manual

Steam Toaster Oven
Model No.型號：GOV12JW
1250W
蒸氣多士焗爐

1
1. When using this electric oven, basic precautions should always be followed, included the
followings:
2. Read all listed instructions.
3. Do not touch hot surface, use handles and knobs.
4. Close supervision is necessary when any appliance is used by or near children.
5. To protect against electric shock, do not immerse cold, plug or any parts of the oven in
water or other liquids.
6. Do not let cord hang over edge of table or counter, or touch hot surface.
7. Do not operate appliances with damaged cord or plug or after the appliance malfunctions,
or have been damaged in any manner. Return the appliance to the nearest authorized
service center of examination, repair, or adjustment.
8. The use of accessory attachments not recommended may cause hazard or injury.
9. Do not place on or near a hot gas or electric burner, or in a heated oven or in a microware
oven.
10. When operating the oven keep at least 4 inches of space on all sides of the oven to allow
for adequate air circulation.
11. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
or taking off parts, and before cleaning.
12. To disconnect, turn the control to OFF, then remove the plug. Always hold the plug, but
never pull the cord.
13. Extreme cautions must be used when moving an appliance containing hot oil or other
hot liquid.
14. Do not cover any parts of the oven with metal foil.
15. Be extreme cautions when remove the tray or disposing of hot grease or other hot liquid.
16. Do not use metal brushes when using the oven because it may be dangerous to come
into contact with live parts.
17. Never leave the appliances unattended while broiling or toasting.
18. Oversized foods and metal utensils must not be inserted in the oven as they may create
a fire or risk of electric shock.
19. A fire may cause if oven is covered or touching inflammable material, including curtains
draperies, walls and like, when on operation, Do not store any item on the oven during oper-
ation.
20. Extreme caution should be exercised when using containers constructed of anything
other than metal or glass.
21. Do not place any of the following materials on the oven: cardboard, plastic, paper or any-
thing similar.
22. Do not store any materials, other than recommended accessories in the oven.
23. Always wear protective, insulated oven gloves when inserting or removing any items
from the hot oven.
24. This appliance is for HOUSEHOLD USE ONLY, do not use outdoor.
25. Do not use appliance for other than intended use.
IMPORTANT SAFEGUARDS

2
26. This applian ce can be used by children aged from 8 years and above and persons with
reduced physical,sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
27.Children shall not play with the appliance. Cleaning and user maintenance shall nog be
made by children without supervised.
28. If the supply cord is damaged, it must be replaced by the After-sales Service Center or
a similarly qualified person in order to avoid a hazard.

Toast
Cheese on Toast
French Bread
Croissant
1
876
5
2 3
48
11
12
13
11
10
9
OFF
1
2
345
10
15
OFF
(Mins)
1. Door handle
2. Detachable door
3. Water inlet
4. Function knob
5. Timer knob
6. Power indicator
7. Crumb tray (removable)
Steam baking mode
Toast (Suggested baking time: 2 - 3 minutes)
Cheese on Toast (Suggested baking time: 3 - 4 minutes)
French Bread (Suggested baking time: 4 - 7 minutes)
Croissant (Suggested baking time: 2 - 3 minutes)
The above suggested bake time is according to the actual cooking conditions and your
desired texture.
8. Rubber foot
9. Heat element cover
10. Vapor water channel
11. Grill rack (detachable)
12. Water cup (10cc X 1pc)
13. Bake tray
The curves structure of tray is designed
to suit the toaster oven’s function. It is
normal that the bake tray may bend when
it is heated.
(Above product drawing is for reference only, appearance please refer to actual product.)
Toast
Bottom
TOP
TOP&Bottom
Cheese On Toast
French Bread
Croissant
Pure Baking mode (pure baking without water vapor, no need to add water to water channel)
The three baking mode funtions are:
OFF mode
When function knob in “OFF” position, the steam toaster oven will not turn on even the time
knob is
Set. This design can prevent the children accidentally turn on the steam toaster oven by
adjusting the timer knob.
3
Product Descriptions
Panel & Function descriptions
lower heat element / upper heat element / upper and lower heat elements

Before first use, remove the binding ties that secure the grill rack, take out all the
accessories, remove the POP sticker on glass door, rinse the accessories with clean
water and let them dry completely.
Install the door
Hook any end of the door shaft at the bottom of the glas door through the door shaft on
the machine, Then press the other end of the door shaft to the other end of the door
shaft, the glass door can be installed.
Head
Buttom
Head
Buttom
Less than 4.5cm
The detachable door must be fastened to the grill rack to close the door,otherwise the
door cannot be closed or dropped.
Refer to the above diagram, place the bread with head and buttom direction, the
bread will be more evenly browned.
The distance between grill rack and the upper hheat element is around 5.5cm. the
bread will be burned if it is too close with the upper heating element. Therefore,
please keep the thickness of the bread in less than 4.5cm.
The middle part and the corner of the steam toaster oven may have heat varies.
Make sure the function knob and timer knob are at “OFF” position. Plug in the steam
toaster oven to the power socket.
Put the bread or food on the middle of the grill rack or bake tray.
Install the grill rack
Hook the two hooks at the bottom of the grill to the rebound wire of inner oven pull the
grill forward so that the front end of the grill rack is fastened to the glass door.
4
Operation lnstructions
1.
2.
3.
If using the steam baking mode, please use the supplied water cup. Add water to the
waterinlet on the left side of the steam toaster oven. (Only apply to 4 steam baking
modes.)
4.

There is 5cc and 10cc reference line on the water cup,suggested to add 10cc water
per time, the water will transform to steam in the process. If the baking time is less
than 3 minutes and within 1min 30s-2min-30s time range,please add 5cc water.
Pure baking mode (Lower heat element/Upper heat element/Lower & upper heating
element will not have water vapor, so no need to add water.
Do not splash water outside of the water inlet, or it may cause electric shock.
When cooking foods which are greasy or marinated with sauce, please wrap the
food with aluminum foil and put them on the bake tray. When use the grill rack,
make sure food do not leak through the rack, or you may use bake tray for rood in
small species.
Only the first bake will have obvious water vapor. Recommend to leave the door
open when continuous cooking, so that the steam toaster oven can cool down
before next cooking.
Close the door, select the mode by rotating the function knob.
If the cooking time is less than 5 minutes, turn the timer knob over 10 minutes and
rotate back to the required time.
When the cooking is finished, the timer knob will back to “OFF” position, it will have a
signal sound.
You may hear the timer continue to the tick sound even the timer knob is back to
“OFF” position which is a mormal phenomenon. It will stop after about 40s.
After use, turn the function knob to “OFF” position and uplug it from the power socket.
Frozen food may take longer to cook, please adjust the cooking time according to
the actual cooking condition.
The cooking time is varied with different food temperature,types,quantity etc. Please
adjust it according to the actual cooking condition.
Always pay attention to the food during cooking to avoid overcook. Cover the food
which easily overcook with aluminum foil.
The oven may emit smoke when first time use under normal operation and it will
soon disappear after 5-10 minutes. water vapor may condense around oven door
or on the door glass. This is because water evaporates from the food which is
normal.
There may be sounds when the oven is operating, it is due to heat expansion of
material and food, and it does not indicate any malfunction.
When cooking foods which are greasy or marinated with sauce (e.g. raw meat, fish,
deep-fried food, etc.), please wrap the food with aluminum foil and put them on the
bake tray. It is to avoid the food grease or sauces from spilling onto the heat
elements and cause fire.
Make sure the aluminum foil or cooking sheet does not touch the heat element cover
to avoid fire. Also, please note that the aluminum foil and cooking sheet could start a
fire depending on the cooking time and conditions.
When the sterm toaster oven starts baking, water should not be added to the water.
please add water before baking, because the steam pipe is controlled by a
separate thermostat and disconnected for about 2.5 minutes.
Please do not put the supplied water cup in a high-temperature condition e.g. the top
of the steam toaster oven, it may cause deformation.
If you want to switch off the oven duting cooing, you can turn the timer knob to “OFF”
manually.
Select the time by rotating the timer knob, the steam toaster oven will turn on.
5
Cooking Precautions:
5.
6.
7.
8.
1.
2.
3.
4.
5.
6.
7.
8.
9.

Must unplug the appliance before cleaning.
Do not rinse the steam toaster oven and the detacheable door under water tape. Wipe
the enclosure, cavity and door with a soft cloth soaked with water.
When clean the grill rack, bake tray and crumb tray, please use a soft cloth or sponge
soaked with mild detergent, then wash with clean water and wipe them dry.
Detach the grill rack: Open the door, press down the grill rack. Release the door
lock, the grill rack rebound, take out the grill rack. Make sure it must be put back in
place before use.
Detach the door: Pull up and take out the door. Make sure it must be put back in
place before use.
Nevr clean with harsh cleaning tools (e.g. metal-wired brush), or use poisonous or
corrosive deterent to clean.
A removable crumb tray is at the bottom of the steam toaster oven that can be pulled
out for cleaning. Make sure it must be put back in place before use.
When store, put the steam toaster oven in a box and store in a dry place.
When store, never wrap the power cord around the oven or put any pressure on the
power cord, it is to avoid the power cord damage.
After each use, must clean the steam toaster oven cavity when it is lukewarm. And also
clean the crumb tray, grill rack and bake tray to avoid smoke fire or metal erosion
caused by the accumulated grease or food residue. Always make sure the steam
toaster oven, power plug and all accessories are dried before use again.
Wipe the remaining water with dry cloth, clean the vapor water channel by spilling the
baking soda on it,wipe with a damp cloth or soft brush,then wipe with a clean damp
cloth and rub it dry.
6
Cleaning and Storage
1.
2.
3.
4.
5.
6.
7.
8.
9.

Model
Colour
Rated Voltage
Rated Power
Net Weight
Capacity
Product Size (W x H x D)
GOV12JW
White
220V~ 50-60Hz
1250W
3.6KG
12L
355X205C295mm
7
Product Specifications

安全注意事項
1. 在使用本產品前，請遵循以下基本安全措施。
2. 仔細閱讀本使用說明書。
3. 在使用 焗爐時，不允許小孩子操作或接近焗爐。
4. 為防止觸電，嚴禁將電源線、插頭或電焗爐的任何部件浸入水中。
5. 電源線不能接觸焗爐的受熱面。
6. 不要讓電源線懸掛在桌子或櫃檯邊緣或接觸發熱表面。
7. 電源線、插頭、附件損壞或電器設備出現故障的情況下，為避免危險切勿作
電器，請聯繫指定的專職維修人員進行更換檢查。
8. 不要使用不建議使用的配件，以免發生危險及造成傷害。
9. 不要將焗爐放在靠近熱水器，電爐或微波爐等熱源的地方。
10. 在使用焗爐時，要保證焗爐每一邊至少有 0.1米 的空間，讓空氣流通。
11. 當不使用焗爐或清潔時，請先拔掉電源線插頭，要先冷卻才能進行拆卸配
件。
12. 斷開連接時，將定時器旋鈕調到“OFF”處，然後拔下電源插頭，拔下插頭
時，請務必抓住插頭，不要拉扯電源線。
13. 移動裝有熱油或其他高溫液體的器具時，必須格外小心。
14. 不要用金屬片去接觸焗爐的任何部件。
15. 移動托盤或處置熱油脂或其他高溫液體時要格外小心。
16. 焗爐在使用時，不要使用帶金屬的刷子去清潔，因可能與帶電部件接觸，
造成危險。
17. 當焗爐在使用時，請務必有人看管。
18. 體積較大的食物或玻璃，塑料類的器皿切勿放入焗爐內烘烤，以免危險。
19. 焗爐頂部不得盛放任何物品或覆蓋易燃物品（如窗簾，牆紙等），容易釀
成火災。
20. 使用一些由金屬或玻璃製成的容器時要格外小心。
21. 請勿將紙板，塑料，紙等類似易燃物品放在焗爐內加熱。
22. 不要將非本機的配件放入焗爐內。
23. 從焗爐內插入或取出物品時，一定要帶上耐高温隔热手套。
24. 本產品只可作家庭用途，不能放置戶外使用。
25. 不可讓本產品作非指定用途使用。
26. 該電器可適用於 8歲以上的兒童以及身體，感官或者智力能力下降和缺乏
經驗和知識的人群，他們使用該電器需要得到安全使用電器的監督或者指
導，並且了解所涉及的危險。
27. 成人應該指導小孩不可把玩此電器。
28. 定期檢查本產品的電源線。如果電源線損壞，必須由本公司售後服務部或
合格的電器技師更換，以避免危險。
8

Toast
Cheese on Toast
French Bread
Croissant
1
876
5
2 3
48
11
12
13
11
10
OFF
1
2
345
10
15
焗
焗
焗
蒸氣烘焗模式
可拆式
機
T o a s t
C h ee se O nToa s t
F r e n c h B r e a d
C r o is s a n t
分别為
（需加水入注水口）
只
注水口
氣
氣
下石英發熱管加熱 上石英發熱管加熱 上下石英發熱管加熱三種模式
氣
芝士
以上建議時間可按個人口味自行調整合適烘焗時間。
Bottom
TOP
TOP&Bottom
OFF
(Mins)
焗
(10ccX1件）
氣
石英
9

移除玻璃門上的廣告紙，用清水洗凈所有
配件及擦乾,
玻璃門安裝步驟如圖示，將玻璃門底部的一端門軸穿過本機上的門軸卡鉤後，再將另
一端門軸按壓至另一端的門軸卡鉤內，然後再安裝烤架。
蓋
焗
氣
氣
蒸氣烘烤焗模式。）
機身左
厚度小於4.5厘米
安裝烤架步驟如圖示，將烤架底部的兩耳掛鉤住烤爐內壁回彈的支架，接著將烤架往前拉，讓
烤架前端“ ”穿扣在玻璃門扣上即可固定烤架。
可拆卸的爐門的扣必需與烤架扣上才能把爐門關上，否則爐門不能合上或掉下。
5.5厘米
10
牆

距時間
分 分
秒
（下石英發熱管/上石英發熱管/上下石英發熱管）不會產生蒸氣，切勿注水。
氣
秒
氣
氣
氣
約40秒左右停止。
位置。
4. 首次烘烤時會有黑煙及臭味冒出，5到10分種後臭味會消散。
架
於水
注水口 先加水再開機，因為蒸汽管
氣
由單獨溫搈器控制，兩分半鐘左右蒸氣管斷開，之後再加水沒用了。
11

先用吸水毛布將水槽中的水吸乾，然後
盤，碎屑盤
氣
氣
氣
氣
12

５０－６０
GOV12JW
3.6公斤
355X205X295毫米
13

太平家庭電器
13
