Gemtech TM-PATROLMAN Installation guide

TM-PATROLMAN
OPERATION AND MAINTENANCE
OF SOUND SUPPRESSOR
MODEL PATROLMAN
Before using this suppressor,
be certain you have read and
understand this manual.
Manufactured by
GEMTECH
Div. of Gemini Technologies, Inc.
P.O. Box 140618
Boise, Idaho 83714
ISSUED: February 2015

COPYRIGHTNOTICE:
©2015 Gemini Technologies, Inc.
All rights reserved. The contents of this publication may not be reproduced in any
form or by any means in whole or in part without the prior written permission of the
copyright owner.
Manufacturedby
GEMTECH
Division of Gemini Technologies, Inc.
P.O. Box 140618
Boise, Idaho 83714-0618
Phone: [phone]
FAX: [phone]
IMPORTANT
The manufacturer disclaims any liability for damages resulting from
any unauthorized modification of this product. Any modification of this
suppressor without prior express authorization from Gemtech’s Engi-
neering Department will void all warranties, both written and implied,
and will result in the assumption of all liability by the person perform-
ing the unauthorized modification.
CONTENTS:
GeneralDescription.........................................................................P. 2
AblativeWarning .............................................................................P. 2
AmmunitionRecommendations ......................................................P. 2
Safety Notes ...................................................................................P. 3
Physical Specifications ...................................................................P. 3
BarrelThreading ..............................................................................P. 4
SuppressorMounting/Dismounting..................................................P. 4
MaintenanceandCleaning ..............................................................P. 5
Warranty Statement ........................................................................P. 5
ReturnInstructions ..........................................................................P. 6

SOUND SUPPRESSOR PATROLMAN P.
GENERAL INFORMATION
ThePATROLMANsuppressor isoneofthefamily ofGemtechExtreme
Duty Silencers specifically designed to withstand the rigorous SOCOM mili-
tary standards for today’s harshest environments. Its lightweight titanium
andinconelconstruction exhibitsgreaterstrengththan regularstainlesssteel
suppressorsandwill outlastmostcompetitors’stamped bafflesforprolonged
engagements.Forweight,durability,andperformance,thePATROLMANsup-
pressoris unparalleled.
ThemodelPATROLMANsound suppressorisofferedina standard1/2-
28 (2A) thread mount only.
All muzzle attachments, including suppressors, will change barrel har-
monics and standing waves resulting in a slight change in point of impact
with the device in place. Because of its light weight, there is less point-of-
impact shift than most comparable sized suppressors for this caliber. The
degreeof changein thepointof impactwillvarywith thespecificweaponand
boththerigidity andmetallurgyofthe barrel.When usedwithstandardweight
law enforcement or military grade barrels, there will be no deleterious effect
on group size.
Thissuppressoriseffectiveinmarkedlyreducingthesoundofthemuzzle
blast,making itdifficultforan observertodetermine theoriginofthe shotand
reducingtheneed forshooterhearingprotection. Thereisnoway ofeliminat-
ing the ballistic crack (or sonic boom) of the projectile traveling downrange.
Thissuppressorcontains noexpendableparts.We recommendagainst
cleaning the interior of the suppressor. This instruction manual gives the
necessary instructions (P. 5) for maintenance of this unit.
USE OF ABLATIVE AGENTS (ARTIFICIAL ENVIRONMENT)
Do not fire this suppressor with any foreign material inside. This sup-
pressorisdesignedtooperatecompletelydry.Introductionofliquids, greases,
orother foreignmaterialscan causeabnormalpressuresandmustnever be
used.Any resultant damage is not covered under warranty.
AMMUNITION
ThePATROLMANsuppressor isdesignedto operatewithNATOspeci-
fication5.56x45NATOcartridges.Itisnotintendedtobeusedwithhandloaded
orforeign ammunitionthat exceedSAAMIor NATOpressure specifications.
The 5.56 cartridge is unique in that it contains a small mass of lead in
the core and a large surface area of copper jacket. After about 100 rounds
fullyautomatic orrapidsemi-automaticfire, theboretemperature willexceed
2

SOUND SUPPRESSOR PATROLMAN P.
SPECIFICATIONS
Caliber: 5.56x45NATO(.223Remington)
Length: 5.7 inches
Diameter: 1.5 inches
Weight: 12.3ounces
Materials: Titanium and inconel alloys
Finish: Blackhigh temperatureCerakote
Mount 1/2-28(2A) threadsonly
MinumumBarrel Length: 10.3 inches
Duty Cycle Limited FullAuto
(see ammunition section)
800°F and the bullet core will soften causing bullet instability, excessive
yaw, and probable baffle strikes.
SAFETY NOTES
1. Always handle weapons in a safe manner and assume they are
loadeduntil theyhavebeen cleared.
2. User installation or removal of the sound suppressor must be ac-
complishedin accordancewiththe instructionscontained inthis
book.
3.Operating Temperatures: Duringuse, thePATROLMANsuppres-
sor absorbs large quantities of heat from the burning propellant
gases. The elevated temperatures can pose a hazard to
personnel and materials that may contact the suppressor
when hot, and the suppressor must be allowed to cool to
ambient temperature before handling.
4. Only use the suppressor completely dry.
5. Before performing any installation or maintenance opera-
tion, always remove the magazine from the firearm, open
the action, and visually ascertain that the chamber is empty
and the weapon unloaded. Failure to do so can result in
potential for serious injury to the user and others in the
vicinity.
3

SOUND SUPPRESSOR PATROLMAN P.
Thread1/2-28
Class 2A fit
0.600±0.025”
0.50
4
BARREL THREADING
ThePATROLMAN suppressorwasgaugedforalignmentand run-outon
a precision test fixture before shipping from the factory. To ensure proper
alignment, it is imperative that the barrel be threaded properly.
For unthreaded barrels, please refer to the drawing below. To ensure
concentricity, it is important that the barrel be threaded with the threads
coaxialwith theboreand theshoulderat thebackofthebarrel beexactly90°
to the bore axis. See the sketch below. Barrel threading service is available
fromGemtech.
A small (0.06”) thread relief is incorporated into the rear mount of the
suppressor.Athread reliefinthe barrelat theback ofthe threadsis optional.
MOUNTING the PATROLMAN
If present, remove the thread protector. Installation requires that the
suppressorbescrewed handtightonto thethreaded barrel.Ifdesired,a drop
of Loctite 242 (blue) may be used. The threads are standard right-hand.
Never use any type of washer, crush washer, or lockwasher when
mounting the suppressor. Crush washers or lockwashers will cause mis-
alignmentand damagenotcovered bywarranty.
Duringuse, suppressorswillbecome extremelyhot. Donottouch! Fail-
ure to comply may result in burns or melted clothing.
To remove,unscrewthe suppressorandreplacethethread protector.

SOUND SUPPRESSOR PATROLMAN P. 5
CLEANING
The PATROLMAN suppressor is constructed of 100% corrosion resis-
tant titanium and inconel.As such, there is no concern about corrosion from
the products of combustion of the propellant gases. We have found no
need for cleaning the inside of the suppressor. We strongly advise
against such efforts or immersion in solvents. Solvents will not drain
completelyand residualliquidmay causeunexpectedpressurepeaks which
can damage the unit. The high flame temperature burns out the majority of
anyremaining powderresidues.
All threads, mounting surfaces, and alignment surfaces should be in-
spected and remain clean. They may be cleaned with a brass brush or
nylonbrushdipped inCLP.
Unlike firearms, it is neither necessary nor desirable to clean centerfire
rifle suppressors. It is acceptable to blow out particulate matter with high
pressurecompressed air. Donot,under anycircumstances,attempt topass
a cleaning patch through the suppressor.
HUNTING NOTICE
Althoughmore statesarepermitting huntingwithsuppressors, itissug-
gested that the local state Fish & Game Department be consulted for the
most recent changes in the law.
LIMITED WARRANTY STATEMENT
Gemini Technologies, Inc., dba Gemtech, warrants to the initial retail
purchaser that Gemtech products will be free of defects in workmanship or
material and that the product meets manufacturing specifications at the
timeof manufacture.This warrantyis limitedto therepair orreplacement of
theproduct. Thisexpresslimitedwarrantyis exclusiveandno otherexpress
orimplied warrantyis otherwiseprovided.
GEMTECHMAKES NO WARRANTYOFMERCHANTABILITYOR
FITNESS FOR PARTICULAR PURPOSE.
Product technical specifications and/or designs may be changed
without notice. This warranty does not cover negligence, misuse, careless
orimproper handlingand/or operation,abuse, unauthorizedadjustmentsor
modifications, improper mounting/installation, ordinary wear and tear, the
failureto followmanufacturer instructionsand/or theuse ofinappropriate or
defectiveammunition.

SOUND SUPPRESSOR PATROLMAN P. 6
Gemtech shall have no liability for incidental or consequential
damages and under no circumstances will Gemtech be liable for
personal injury, property damage or economic loss.
This warranty and disclaimer is subject to all applicable laws some of
which may limit these terms.
WARRANTY REPAIRS: Return of a Damaged Suppressor
If a suppressor is damaged due to a manufacturing defect once it has
beenfired,it maybereturnedto Gemtechforrepairor replacement.Determi-
nation to repair or replace is made solely at our discretion and only after we
have had the opportunity to examine and determine that the cause of the
damage is due to a manufacturing defect. It is the responsibility of the cus-
tomer to cover shipping costs and insurance to return the suppressor to
Gemtechfor inspectionorrepair. Gemtechwillpayany reasonableshipping
and insurance costs to return the unit to you.
To assure proper legal procedures for any repair returns, fill out and pro-
vide a copy of the General Service Form with any packages sent to us.
(Visitgem-tech.com, navigateto CustomerSupport/Returnand RepairPoli-
ciestodownloadthefillableGeneral ServiceForm.pdf orcall208.939.7222)
BATFE no longer requires transfer on a Form 5 to the manufacturer for
repair. BATFE does require a letter accompanying the suppressor detailing
therepairsor modificationsrequired(satisfiedbyacompletely filledout Gen-
eral Service Form). BATFE also requires proof of ownership satisfied by a
photocopy of the front of the owner’s Form 3, 4, or 5.
NOTE: BATFE prohibits transferring the serial number to a new outer
tubeinthe caseofdamagetothe tube.Tubedamagerendering thesuppres-
sorunsafe willrequireanewsuppressor.
