USER MANUAL
SpectroLED
BATON-BAT
RECHARGEABLE BATTERY HANDLE
FOR BATON-20 AND BATON-34

SpectroLED Rechargeable Battery Handle for Baton - USER MANUAL
2
BATON-BAT
OVERVIEW
Front / Top Back / Bottom
4-pin connector
Locking ring
Battery indicator lights
Bottom Cap
Battery indicator button
Power input
socket
1/4-20 socket
Power indicator
Red - charging
Green - fully charged

SpectroLED Rechargeable Battery Handle for Baton - USER MANUAL 3
ATTACHING THE BATTERY
HANDLE TO THE BATON
REPLACING THE
POWER CELL
PRODUCT
SPECIFICATIONS
1. Unscrew the bottom cap, and
remove the spent power cell.
2. Insert the new power cell with the
battery contact facing inward.
Battery Type: Rechargeable lithium-ion
Output: 2600 mAh, 22.2 V
Runtime: Baton-20: approximately 2 hr.
Baton-34: approximately 1 hr.
Charge Time: Approx. 5 hr.
Construction: Metal
Length: 9 in. (22.8 cm)
Weight: 1.4 lb. (648 g)
1. Align the XLR connector with the
pins on the bottom of the Baton.
2. Press the battery pack onto the
Baton, and turn the locking ring
clockwise to tighten until secure.
To check the remaining power in the battery
pack, press and hold the power indicator.
4 lights Fully charged
3 lights 75%
2 lights 50%
1 light 25% or less. Recharge the battery.

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with
the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own
risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
