Continuing the tradition of providing well fac-
tored active monitoring products, Genelec
introduces the
8030.LSE PowerPak
™, a
new comprehensive multi-channel monitoring
system specifically designed for post-production
suites and recording studios with control rooms
measuring less than 85 m
3
(3000 cubic feet) (W
x D x H). The 8030.LSE PowerPak™ system is
a perfectly tailored solution and simplifies the
process of creating a new multi-channel moni-
toring system or upgrading an existing stereo
monitoring environment to 5.1 surround.
The 8030.LSE PowerPak™ system consists
of five Genelec 8030A two-way, bi-amplified
active monitors, one Genelec 7060A LSE™
Series Active Subwoofer, and a Genelec
Acousti/Tape™ frequency/wavelength mea-
suring tape. In addition, a Genelec 8030.LSE
PowerPak setup guide is included for accurate
speaker placement, wiring and fine-tuning.
The cornerstone of the system is Genelec’s
revolutionary 7060A LSE™ Series Active
Subwoofer which employs Genelec’s propri-
etary Laminar Spiral Enclosure™ (LSE™)
technology. Designed for multi-channel pro-
fessional surround sound monitoring envi-
ronments, the LSE™ 7060A subwoofer
features a single 10” proprietary driver with
a 120 Watt power amplifier, a frequency
response of 29 Hz to 85 Hz (120 Hz) +/-3
dB, and has the ability to deliver an SPL of
108 dB at 1 meter. In addition, the 7060A
boasts Genelec’s new 6.1 bass management
system, which has six signal input and output
channels (L/C/R Front and L/C/R Rear), as
well as a discrete LFE signal input with a
selectable 85/120 Hz low-pass filter and a
summed signal output, providing flexibility and
easy connection.
The built-in bass management unit splits the
six main channel input signals into low and high
frequency components, accurately dividing the
input signal between the subwoofer and main
speakers. A dedicated LFE In input connector
enables easy set-up and accurate monitoring of
the LFE channel in 5.1 and 6.1 digital surround
sound systems.
The system also includes five Genelec
8030A two-way, bi-amplified active monitors.
The 8030A is a compact close-field system
featuring Genelec’s proprietary Minimum Dif-
fraction Enclosure™ (MDE™). The rounded
corners and continuously curving forms of the
enclosure blend seamlessly into the improved
Directivity Control Waveguide™ (DCW™),
effectively reducing diffraction and improving
imaging. Powered by a pair of 40 Watt ampli-
fiers, the Genelec 8030A monitors offer a
wide frequency response of 58 Hz to 20 kHz
(+/-2.0 dB) from a 5” woofer and
3
/
4
” hard-domed
tweeter. In addition to low harmonic distortion,
the 8030A also offers rear panel bass and
treble tilt room response controls. The MDE™
enclosure of the Genelec 8030A active moni-
tors is made of die cast aluminum, featuring
rugged construction while also providing effi-
cient heat dissipation capability and shielding
against RF interference. Each speaker is also
magnetically shielded for additional protection
when used in close proximity to video monitors.
The Iso-Pod™ table stand delivered with each
8030A has adjustable tilt so that the acoustical
axis can be pointed precisely towards the lis-
tener for best sound reproduction. The isolation
feature prevents colouration caused by conduc-
tion of unwanted vibration to the mixing console
or other mounting surface.
The 8030.LSE PowerPak
™
once properly
set up will provide an accurate and stable rep-
resentation of any multichannel audio signal,
yet its compact size makes it applicable to
almost any listening environment.
Genelec 8030.LSE PowerPak™
Multi-Channel Monitoring System
Data Sheet
PowerPak
System

8030.LSE PowerPak ™ Data Sheet
Genelec Document BBAGE030. Copyright Genelec Oy 1.2005. All data subject to change without prior notice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone [phone]
Fax [phone]
Email [email protected]
In the U.S. please contact
Genelec, Inc., 7 Tech Circle
Natick, MA 01760
Phone [phone]
Fax [phone]
Email [email protected]
www.genelec.com
7060A
Subsonic filter
(18 dB/octave) below 29 Hz
Upper bandwidth/LFE cutoff 85 Hz/120 Hz selectable
Connectors
Input 7 XLR female (6 Main + 1 LFE)
Output 7 XLR male (6 Main + 1 Sum Out)
XLR pin sequence pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
Input level for 100 dB SPL
output @ 1 m Variable from +6 to –12 dBu
Crossover frequency,
(sub/main channels) 85 Hz
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz ≥ 50 dB
Bass roll-off control operating From 0 to –6 dB @ 30 Hz
range in 2 dB steps
Phase matching control From 0 to 270° @ 85 Hz
in 90° steps
Bypass Bypasses the bass management for the main channels
LFE sensitivity Adjustable 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum In Changes subwoofer to Sum In mode, main inputs defeated
Test tone for phase adjustment 85 Hz
Remote LED connector (RJ11) Input for optional Power/Overload+Bypass remote controls
AMPLIFIER SECTION
7060A BASS MANAGEMENT SYSTEMSYSTEM SPECIFICATIONS
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
(+/- 3 dB) (Main channels)
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
free field @ 1 m on axis
(A-weighted)
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Dimensions
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A 8030A
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry)
Bass 120 W 40 W
Treble N/A 40 W
Amplifier system distortion
at nominal output
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
to region
Power consumption (average)
Idle 15 VA 10 VA
Full output 150 VA 80 VA
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
(+/- 3 dB) (Main channels)
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
(A-weighted)
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A
(18 dB/octave) below 29 Hz
Upper bandwidth/LFE cutoff 85 Hz/120 Hz selectable
Input 7 XLR female (6 Main + 1 LFE)
Output 7 XLR male (6 Main + 1 Sum Out)
XLR pin sequence pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
output @ 1 m Variable from +6 to –12 dBu
(sub/main channels) 85 Hz
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz ≥ 50 dB
Bass roll-off control operating From 0 to –6 dB @ 30 Hz
range in 2 dB steps
Phase matching control From 0 to 270° @ 85 Hz
Bypass Bypasses the bass management for the main channels
LFE sensitivity Adjustable 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum In Changes subwoofer to Sum In mode, main inputs defeated
Test tone for phase adjustment 85 Hz
Remote LED connector (RJ11) Input for optional Power/Overload+Bypass remote controls
7060A 8030A
Bass 120 W 40 W
Treble N/A 40 W
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
to region
Idle 15 VA 10 VA
Full output 150 VA 80 VA
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A 8030A
Bass 120 W 40 W
Treble N/A 40 W
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
Idle 15 VA 10 VA
Full output 150 VA 80 VA
8030.LSE POWERPAK ACOUSTIC SPECIFICATIONS
8030.LSE PowerPak
Recommended listening 1.7 to 2.5 m (5 to 8 ft)
distance
Typical max short term 108 dB, Flat response weighting
RMS SPL all channels driven
Suggested acoustic space max. 85 m
3
(3000 cubic feet)
8030.LSE PowerPak
Recommended listening 1.7 to 2.5 m (5 to 8 ft)
distance
Typical max short term 108 dB, Flat response weighting
Suggested acoustic space max. 85 m
