Owner’s Manual
GC1000S 10 Ton Kinetic Splitter
SAVE THIS MANUAL FOR FUTURE REFERENCE
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(888-436-3722)
MODEL NUMBER: _________________________
SERIAL NUMBER: _________________________
DATE PURCHASED:________________________
Original Language
010945

ii Owner’s Manual for 10 Ton Kinetic Splitter
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.

Owner’s Manual for Wide-Cut Lawn Mower iii
Table of Contents
Section 1: Safety Rules & General 
Information
Introduction ..................................................................1
Read This Manual Thoroughly ....................................1
Safety Rules .................................................................1
How to Obtain Service .................................................1
General Hazards ...........................................................2
Electrical Hazards ........................................................3
Safety and Operating Decals ......................................4
Section 2: General Information and Setup
Specifications ...............................................................5
Components and Controls ..........................................6
Know Your 10 Ton Kinetic Splitter .............................6
Remove Contents from Carton ...................................6
Assembling Unit ...........................................................7
Section 3: Operation
Operation and Use Questions ....................................9
Before Starting the Unit ...............................................9
Operating Zone ............................................................9
Starting the Motor ........................................................9
Stopping the Motor ......................................................9
Resetting the Circuit Breaker .....................................9
Handling Wood .............................................................9
Splitting Logs .............................................................11
Splitting Tough Logs .................................................11
Section 4: Maintenance
Maintenance Schedule ..............................................13
Lubrication .................................................................13
Rail Maintenance ........................................................13
Greasing the Rack .....................................................14
Adjusting and Replacing the Belt .............................14
Checking and Adjusting Belt Tension ........................14
Replacing the Belt .....................................................15
Adjusting Steel Bushing Over Center ......................16
Section 5: Troubleshooting
Troubleshooting .........................................................17

iv Owner’s Manual for Wide-Cut Lawn Mower
This page intentionally left blank.

Safety Rules & General Information
Owner’s Manual for 10 Ton Kinetic Splitter 1
Section 1: Safety Rules & General Information
Introduction
Thank you for purchasing this Generac 10 Ton Kinetic
Splitter. This unit has been designed to provide high-
performance, efficient operation, and years of quality use
when maintained properly.
The Generac 10 Ton Kinetic Splitter is designed and built
for consistent, reliable use. It is built to withstand frequent
handling under these conditions.
The information in this manual is accurate based on
products produced at the time of publication. The manu-
facturer reserves the right to make technical updates,
corrections, and product revisions at any time without
notice.
Read This Manual Thoroughly
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
If any section of this manual is not understood, contact
the nearest Independent Authorized Service Dealer
(IASD) or Generac Customer Service at 1-888-436-3722
(1-888-GENERAC), or visit www.generac.com for start-
ing, operating, and servicing procedures. The owner is
responsible for proper maintenance and safe use of the
unit.
SAVE THESE INSTRUCTIONS for future reference. This
manual contains important instructions that must be fol-
lowed during placement, operation, and maintenance of
the unit and its components. Always supply this manual
to any individual that will use this unit, and instruct them
on how to correctly start, operate, and stop the unit in
case of emergency.
Safety Rules
The manufacturer cannot anticipate every possible cir-
cumstance that might involve a hazard. The alerts in this
manual, and on tags and decals affixed to the unit, are
not all inclusive. If using a procedure, work method, or
operating technique that the manufacturer does not spe-
cifically recommend, verify that it is safe for others and
does not render the equipment unsafe.
Throughout this publication, and on tags and decals
affixed to the unit, DANGER, WARNING, CAUTION, and
NOTE blocks are used to alert operators to special
instructions about a particular operation that may be
hazardous if performed incorrectly or carelessly. Observe
them carefully. Alert definitions are as follows:
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that
they indicate. Common sense and strict compliance with
the special instructions while performing the action or
service are essential to preventing accidents.
How to Obtain Service
When the unit requires servicing or repairs, contact Gen-
erac Customer Service at 1-888-GENERAC (1-888-436-
3722) or visit www.generac.com for assistance.
When contacting Generac Customer Service about parts
and service, always supply the complete model and
serial number of the unit as given on its data decal
located on the unit. Record the model and serial numbers
in the spaces provided on the front cover of this manual.

Safety Rules & General Information
2Owner’s Manual for 10 Ton Kinetic Splitter
General Hazards
(000620)
Personal injury. Operate only in daylight or in area lit
by artifical light. Failure to do so could result in death,
serious injury, property or equipment damage.
WARNING
Personal injury. Only allow qualified persons to
operate unit. Operation by unqualified persons could
result in death, serious injury, property or equiment
damage. (000421)
WARNING
(000377)
WARNING
Vision loss. Eye protection is required when
servicing unit. Failure to do so could result
in vision loss or serious injury.
Vision loss. Eye protection is required when
operating unit. Failure to wear appropriate eye
protection could result in vision loss or serious
injury. (000407)
WARNING
(000107)
Hearing Loss. Hearing protection is
recommended when using this machine.
Failure to wear hearing protection could
result in permanant hearing loss.
WARNING
(000637)
WARNING
Personal injury. Do not wear loose clothing or jewelry when
operating unit. Wear protective hair covering to contain long
hair. Failure to do so could result in death, personal injury,
equipment or property damage.
(000492)
Personal injury. Wear sturdy shoes with no-slip tread,
long pants, and gloves when operating this unit.
Failure to do so could result in death or serious injury.
WARNING
(000467)
Personal injury. Always verify all guards and shields are in
place prior to use. Removal or modification of guards and
shields could result in serious injury or equipment damage.
WARNING
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to
service this equipment and could result in death or
serious injury. (000215)
(000626)
WARNING
Personal injury. Do not operate if unit produces
abnormal noise or vibration. Doing so could result in
death, serious injury, property or equipment damage.
(000420)
WARNING
Personal injury. Keep people and pets away from
work area. Failure to do so could result in death or
serious injury.
WARNING
(000716)
Personal Injury. Never use machine other than for its
designed purpose. Doing so could result in death,
serious injury, and equipment or property damage.
(000466)
Personal injury. Never operate unit on slippery, wet,
muddy, or icy surfaces. Doing so could result in death,
serious injury, equipment or property damage.
WARNING
WARNING
(000720)
Personal Injury. Never hurry, overload the unit, or
attempt to split logs beyond the recommendations in
this manual. Doing so could result in death, serious
injury, or equipment or property damage.
WARNING
(000718)
Personal Injury. Allow only one operaton to operate
the unit at a time. This includes placing the log on the
beam. Failure to do socould result in death, serious
injury, and equipment or property damage.
WARNING
(000719)
Personal Injury. Before performing any maintenance
or service on this unit, shut off the motor, unplug the
power cord and wait five minutes for the unit to cool.
Failure to do so could result in serious injury.

Safety Rules & General Information
Owner’s Manual for 10 Ton Kinetic Splitter 3
Electrical Hazards
(000629a)
DANGER
Electrocution. Only an authorized technician should
attempt to service this equipment. Failure to follow
proper service requirements could result in death,
serious injury, or equipment or property damage.
(000711)
DANGER
Electrocution. Never use an extension cord that is not
rated for outdoor use. Doing could result in death,
serious injury, or equipment or property damage.
(000712)
DANGER
Electrocution. Never operate this unit if an electrical
hazard is present. Doing could result in death,
serious injury, or equipment or property damage.
(000713)
DANGER
Electrocution. Never operate this unit in wet
conditions and always store under a cover or in a
dry location. Failure to do so could result in death,
serious injury, or equipment or property damage.
(000714)
DANGER
Electrocution. Always grasp the electrical cord plug
when unplugging the cord from the outet. Make sure
your fingers do not touch the metal prongs. Failure to
do so could result in death or serious injury.
(000715)
DANGER
Electrocution. Never operate the unit unless the
electrical cord is plugged into a properly grounded
GFCI outlet, which supplies 110-120v power and is
protected by a 20 A circuit breaker. Failure to do so
could result in death or serious injury.
•Never use an extension cord longer than 25 ft
(7.62 m) and smaller than 12 AWG in diameter, or
longer than 50 ft (15.24 m) and smaller than 10
AWG in diameter; the cord will produce a voltage
drop that will prevent the motor from supplying full
power and may cause damage to the motor. Use of
a smaller diameter (larger AWG number) extension
cord could result in melting of the insulation or
even create a fire.
•Keep the electrical cord and/or extension cord
away from excessive heat, oil, and sharp objects.

Safety Rules & General Information
4Owner’s Manual for 10 Ton Kinetic Splitter
Safety and Operating Decals
See Figure 1-1. This unit features numerous safety and operating decals. These decals provide important operating
instructions and warn of dangers and hazards. Replace damaged or missing safety and operating decals immediately.
Decal part numbers can be found in the unit parts manual at www.generac.com.
010683
GC1000S
PN: 000000000 REV_X1(888)436-4811 www.Generac.com
Figure 1-1. Safety and Operating Decal Locations

Owner’s Manual for 10 Ton Kinetic Splitter 5
General Information and Setup
Section 2: General Information and Setup
Specifications
HP 2
Output Torque .025 in-lbs @ Full Load
Voltage 110
Full Load Current 14.5A
Output Power 1060W
Hertz 60HZ
Phase 1
Overload Protection Thermal Breaker
Outlet Cord 6 ft (1.8 m)
Frame Gauge 3 mm
Belt Size A-1180
Flywheel Weight 12.5 lb (5.6 kg)
Flywheel RPM* 490
Maximum Log Length 16 in (41 cm)
Maximum Log Diameter** 12 in (30.48 cm)
Cycle Time 1 second
Splitting Ability Out Splits 10 Ton Hydraulic
Wedge Height 5 in (12.7 cm)
Wheel Size 6 in (15.24 cm)
Machine Height 24.5 in (62.23 cm)
Machine Length 49 in (124.46 cm)
Machine Width 11.875 in (30.16 cm)
Weight 132 lb (59.87 kg)
*Per flywheel.
**The diameter listed is indicative of the maximum suggested size. A small log can be difficult to split when it contains knots or a
particularly tough fiber. On the other hand, it may not be difficult to split logs with regular fibers even if its diameter exceeds the
maximum indicated above.

6Owner’s Manual for 10 Ton Kinetic Splitter
General Information and Setup
Components and Controls
B
C
D
H
I
J
K
L
G
E
010947
F
A
Figure 2-1. Component Locations
ABelt guard EElectric motor ISplitting wedge
BON/OFF switch FTwo hand operation lever JFrame stand
CCircuit breaker switch GRam KFlywheel
DEngagement handle HCradle LBelt
Know Your 10 Ton Kinetic Splitter
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
See Figure 2-1. Be familiar with the controls and features
of the unit prior to operation. Read this manual thor-
oughly before assembling and operating this unit. Save
this manual for future and immediate reference.
Remove Contents from Carton
1. Remove and verify the carton contains the follow-
ing prior to assembly:
Description QTY
Phillips head screwdriver 1
12/14 mm wrench 1
2. Contact Generac Customer Service at 1-888-436-
3722 (1-888-GENERAC), or www.generac.com
with the unit model and serial number for any miss-
ing carton contents.
3. Record model, serial number, and date of pur-
chase on front cover of this manual.

Owner’s Manual for 10 Ton Kinetic Splitter 7
General Information and Setup
Assembling Unit
1. See Figure 2-2. Use a 14 mm wrench to remove
the two nuts and lock washers (A) that hold frame
stand (B) onto frame (C).
.
AB
010948
C
Figure 2-2. Assembling the Unit (1 of 2)
2. Remove the frame stand and rotate it 180°.
3. See Figure 2-3. Reinstall frame stand with handle
(D) on the outside using the nuts and lock washers
removed in step 1.
D
010949
Figure 2-3. Assembling the Unit (2 of 2)

8Owner’s Manual for 10 Ton Kinetic Splitter
General Information and Setup
This page intentionally left blank.

Owner’s Manual for 10 Ton Kinetic Spliter 9
Operation
Section 3: Operation
Operation and Use Questions
Call Generac Customer Service at 1-888-GENERAC (1-
888-436-3722) with questions or concerns about unit
operation and maintenance.
Before Starting the Unit
(000100a)
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
WARNING
Familiarize yourself with the controls and features of the
unit before operating. See Components and Controls.
Operating Zone
•See Figure 3-1. Stand in operator areas (A) when-
ever operating this unit.
•Stay in the operator areas at all times when the
ram is in motion.
•Never place any part of your body into a position
that causes an unsafe operating condition.
A
010950
A
Figure 3-1. Operator Zone
Starting the Motor
1. Position the unit on a flat, dry surface and chock
the wheels or screw down the frame stand to pre-
vent the unit from moving during use.
2. Plug the unit into a properly grounded 20, GFCI
protected outlet.
3. See Figure 3-2. Push toggle switch (A) into the ON
position
Stopping the Motor
See Figure 3-2. Push toggle switch (A) to OFF position.
Resetting the Circuit Breaker
See Figure 3-2. If the motor will not run when the power
switch is turned on and power is connected to the
machine, the circuit breaker switch may need resetting.
Push circuit breaker switch (B) to reset.
010951
AA
B
Figure 3-2. ON/OFF Switch and Circuit Breaker
Handling Wood
(000439)
WARNING
Equipment damage. Do not overload the log splitter.
Do not attempt to split logs beyond the units
capability. Doing so could result in serious injury or
equipment damage.
(000442)
WARNING
Personal injury. Do not reach or step across the
beam while the log splitter is running. Doing so
could result in death or serious injury.

(000440)
WARNING
Personal injury. Do not operate unit from outside the
operator zone. Doing so could result in death, serious
injury, or equipment damage.
(000441)
WARNING
Personal injury. Load logs by holding them in the
middle, not the ends. Loading logs by holding the
ends could result in serious injury.
(000443)
WARNING
Personal injury. Do not attempt to split logs across
the grain. Doing so could cause serious injury or
equipment damage.
(000444)
WARNING
Personal injury. Keep hands away from cracks in
partially split or stuck logs. These cracks can quickly
collapse, which could result in serious injury.
(000445)
WARNING
Personal injury. Do not attempt to remove partially
split wood by hand. Always fully retract the wedge to
dislodge logs. Failure to do so could result in serious
injury or equipment damage.
(000446)
WARNING
Personal injury. Do not attempt to catch logs after
splitting. Only pick up the logs from the ground.
Attempting to catch logs could result in serious injury.
10 Owner’s Manual for 10 Ton Kinetic Spliter
Operation
NOTE: Logs must be shorter than 16 in (41 cm). Never
split logs using an incorrect or unsafe method. Use the
photos included as a guide.
•See Figure 3-3. Do not hold log by ends. Never
use your foot to stabilize a log. Do not reach or
step across the beam while unit is running.
Figure 3-3. Do Not Hold at Ends
•See Figure 3-4. Do not split log against the grain.
Figure 3-4. Do Not Split Against the Grain
•See Figure 3-5. Do not cut angled wood. Verify
both ends are cut as square as possible. This pre-
vents logs from sliding out of position while under
pressure.
Figure 3-5. Do Not Cut Angled Wood

Owner’s Manual for 10 Ton Kinetic Spliter 11
Operation
•See Figure 3-6. Place hands on long sides of log.
Verify both ends of log are flat. If stabilizing log with
left hand, remove hand when splitting wedge
makes contact with the log.
Figure 3-6. Correct Log Loading Technique
Splitting Logs
This unit operates differently than a hydraulic splitter. Not
operating the machine properly will damage the machine.
When operating the unit consider the following:
•A rapid movement of the engagement handle is
necessary for the rack and pinion to engage and
disengage fully without damage.
•The engagement handle should never be stopped
in any location between the fully forward or fully
backward positions.
•Do not hold the handle in the forward position
when the ram stops moving forward. Always pull
the engagement handle rapidly to the back, auto-
retract position as soon as the log is split or when
the ram is at the end of the stroke or when the ram
stops moving forward due to a tough log
1. See Figure 3-7. Place the log on the log splitter.
Grasp the log on the sides near the middle of the
block. Center the log, side-to-side, on rail (A), veri-
fying one end is against splitting wedge (B).
B
A
Figure 3-7. Splitting Logs (1 of 2)
2. See Figure 3-8. With one hand, actuate and hold
two hand operation handle (C) in the direction
shown, then rapidly actuate engagement handle
(D) fully forward until it contacts the hard stop and
hold firmly until the ram reaches the end of its
travel.
B
A
C
D
Figure 3-8. Splitting Logs (2 of 2)
3. Immediately after the log is split, quickly actuate
the engagement handle back to the auto-retract
position to all the ram to return.
Splitting Tough Logs
If the ram stops before the end of the stroke while split-
ting a tough log, quickly actuate the engagement handle
back to the auto-retract position. Let the ram return and
allow the flywheels to gain momentum for another full
power split.

12 Owner’s Manual for 10 Ton Kinetic Spliter
Operation
This page intentionally left blank.

Owner’s Manual for 10 Ton Kinetic Splitter 13
Maintenance
Section 4: Maintenance
Maintenance Schedule
WARNING
Risk of injury. Do not operate or service this machine
if not fully alert. Fatigue can impair the ability to
service this equipment and could result in death or
serious injury. (000215)
(000419)
CAUTION
Personal injury. Wear appropriate personal protective
equipment at all times while operating and servicing
unit. Failure to do so could result in personal injury.
Table 4-1. Regular Maintenance Checklist
Procedure Before Each Use Every 5 Hours Every 25 Hours
Check general equipment condition 
Perform rail maintenance 
Check belt 
Check the condition of the electrical cord 
Grease rack 
Clean motor exterior and cooling fins. 
Lubrication
All bearings are sealed units and should have sufficient
lubricant to last the life of your machine with normal use.
Perform machine lubrication per the following instruc-
tions.
Rail Maintenance
See Figure 4-1. Between each use, remove any debris
caught on the rail (A) or ram (B) and applying a rust pre-
ventative to any bare metal areas on the top of the rail.
This will assure the smoothest return action of the ram.
010951
A
B
Figure 4-1. Rail Maintenance
WARNING
(000719)
Personal Injury. Before performing any maintenance
or service on this unit, shut off the motor, unplug the
power cord and wait five minutes for the unit to cool.
Failure to do so could result in serious injury.

14 Owner’s Manual for 10 Ton Kinetic Splitter
Maintenance
Greasing the Rack
NOTE: Grease the rack every five hours.
1. See Figure 4-2. Use a screwdriver to remove the
11 guard screws, washers, and lock washers (A)
that secure the center guard (B).
2. Remove the guard screws, washers, and locknuts
that secure the flywheel and guard.
B
010722
A
Figure 4-2. Greasing the Rack (1 of 3)
3. See Figure 4-3. Disconnect return spring (C) from
eye bolt (D).
010723
C
D
Figure 4-3. Greasing the Rack (2 of 3)
4. See Figure 4-4. Pull the rack out and grease rack
teeth (E), top side of rack, and pinion (F).
010734
F
E
Figure 4-4. Greasing the Rack (3 of 3)
5. Push the rack back in and reinstall the return
spring to the eye bolt when finishing greasing.
6. Reinstall the guards.
Adjusting and Replacing the Belt
Checking and Adjusting Belt Tension
1. See Figure 4-5. Use a screwdriver to remove the
11 guard screws, washers, and lock washers (A)
that secure the center guard (B).
2. Remove the guard screws, washers, and locknuts
that secure the flywheel and guard.
B
010722
A
Figure 4-5. Adjusting Belt Tension (1 of 3)
3. See Figure 4-6. Place a straight edge (C) across
the top of belt (D).
010735
C
D
Figure 4-6. Adjusting Belt Tension (2 of 3)
4. Push on the top of the belt with about 10 pounds of
pressure. The belt should deflect approximately 1/2
in (1.27 cm) to 5/8 in (1.59 cm). If the distance is
not between 1/2 in (1.27 cm) to 5/8 in (1.59 cm),
adjust per the following directions.

Owner’s Manual for 10 Ton Kinetic Splitter 15
Maintenance
5. See Figure 4-7. Loosen motor hardware (E) using
a 14 mm wrench on the bolt and a 17 mm wrench
on the nut.
6. Use a 17mm wrench to turn tension nut (F) in
against the frame to tighten if belt is too loose or
out to loosen if belt is too tight.
010735
F
E
Figure 4-7. Adjusting Belt Tension (3 of 3)
NOTE: The belt performs best with a slight amount of
slack to allow the belt to slip on the pulley when the
wedge encounters a tough log. Too much tension may
stall the Motor.
7. When the belt is at the proper tension, tighten the
Motor Hardware.
8. Reinstall the guards.
Replacing the Belt
1. See Figure 4-8. Use a screwdriver to remove the
11 guard screws, washers, and lock washers (A)
that secure the center guard (B).
2. Remove the guard screws, washers, and locknuts
that secure the flywheel and guard.
B
010722
A
Figure 4-8. Replacing Belt (1 of 3)
3. See Figure 4-9. Loosen motor hardware (C) using
a 14 mm wrench on the bolt and a 17 mm wrench
on the nut (D).
010735
D
C
Figure 4-9. Belt (2 of 3)
4. See Figure 4-10. Install a new belt (E) onto pulley
(G) and flywheel (F).
010735
F
E
G
Figure 4-10. Replacing Belt (3 of 3)
5. See Figure 4-9. Use a 17 mm wrench to tighten
the tension nut (D).
6. Set belt tension by turning the nut in against the
frame to tighten if belt is too loose or out to loosen
if belt is too tight.
NOTE: The belt performs best with a slight amount of
slack to allow the belt to slip on the pulley when the
wedge encounters a tough log. Too much tension may
stall the motor.
7. Tighten the motor hardware.
8. Reinstall the guard.

16 Owner’s Manual for 10 Ton Kinetic Splitter
Maintenance
Adjusting Steel Bushing Over Center
Only perform this adjustment if the engagement handle is
kicking back excessively when splitting a log. If you have
any questions, contact Generac Customer Service at 1-
888-GENERAC (1-888-436-3722) or visit www.gen-
erac.com for assistance.
1. See Figure 4-11. Use a screwdriver to remove the
11 guard screws, washers, and lock washers (A)
that secure the center guard (B).
2. Remove the guard screws, washers, and locknuts
that secure the flywheel and guard.
B
010722
A
Figure 4-11. Adjusting Steel Bushing (1 of 3)
3. See Figure 4-12. Push two hand operation lever
(C) to the side and move the engagement handle
(D) forward until it contacts the vertical adjustment
bolt (E).
NOTE: The ram may need to be pulled out so the teeth
on the rack and pinion line up.
4. Use a 17 mm wrench to loosen nut (F) and handle
retention nut (G).
NOTE: Do not adjust more than 1-1/4 revolutions when
adjusting off center. Adjustments too far off center will not
allow the rack teeth to engage fully and will cause dam-
age to the splitter
P
C
010736
F
D
E
G
Figure 4-12. Adjusting Steel Bushing (2 of 3)
5. Use a 14mm wrench to adjust the vertical adjust-
ment bolt so the engagement handle is approxi-
mately 1-3° off center towards the vertical
adjustment bolt.
NOTE: The engagement handle must move just past
center as it contacts the vertical adjustment bolt. If it is at
the center position, or off center in the wrong direction,
the force of splitting a log will be transferred through the
engagement handle and could cause injury.
6. Use a 17 mm wrench to tighten the locking nut and
handle retention nut. Verify the two hand operation
handle is able to move freely and return to the
locked position. If the handle cannot move freely,
loosen the handle retention nut 1/4 rotation at a
time until it can move freely.
7. Push the engagement handle all the way to the
return position then back into the split position to
confirm the steel bushing is moving just past cen-
ter.
8. See Figure 4-13. Check the gap at the end of
stopping bolt (H) and engagement handle (I) The
gap should be approximately 2 mm. If the gap
needs adjustment, hold the head of the bolt using a
17 mm wrench and loosen nut (J) using another
17mm wrench. Adjust the bolt as needed to correct
the gap and retighten the nut against the two hand
operation handle (K).
010735
H
J
I
K
Figure 4-13. Adjusting Steel Bushing (3 of 3)
9. Reinstall the Guards.
When using the splitter for the first time after this adjust-
ment, split smaller diameter logs with no knots to verify
that the adjustments are correct before trying larger
diameter tougher logs.
