2 of 2
GeneracPowerSystems,Inc.•S45W29290HWY.59,Waukesha,WI53189•generac.com
©2010GeneracPowerSystems,Inc.Allrightsreserved.Allspecificationsaresubjecttochangewithoutnotice.Bulletin094700000S-A/PrintedinU.S.A.01/06/11
100 - 400 Amps, 600 VAC
200,000 200,000 200,000 200,000 200,000
200 400 400 600 600
J,T J,T J,T J,T J,T
14,000 25,000 25,000 35,000 35,000
150 300 300 600 600
•TestedinaccordancewiththewithstandandclosingrequirementsofUL1008andCSAStandards
•Currentratingsarelisted@480VAC
GTS Enclosure Enclosure Wall Mount Enclsoure Weight
Rated Voltage Height Width Bolt Pattern Depth (lbs.)
Amps H W M1 M2 D1 D2
100 All 36 24 18 37.5 12.7 10 180
150-200 120/240 36 24 18 37.5 12.7 10 185
150-200 120/208 36 24 18 37.5 12.7 10 185
150-200 277/480 48* 30* 24 49.5 14.8 12 265
150-200 600 48* 30* 24 49.5 14.8 12 265
300-400 120/240 36 24 18 37.5 12.7 10 245
300-400 120/208 36 24 18 37.5 12.7 10 245
300-400 277/480 48* 30* 24 49.5 14.8 12 325
300-400 600 48* 30* 24 49.5 14.8 12 325
* Note: On NEMA 1 enclosures only, door overlaps enclosure – door dimensions are 48.8 H X 30.8 W. All dimensions in inches.
UtilityVoltage
Dropout........................................................................................................................75-95%(Adj.)
Pickup..........................................................................................................................85-95%(Adj.)
LineInterrupt..........................................................................................................0.1-10Sec.(Adj.)
EngineMinimumRun........................................................................................................... 5-30Min.(Adj.)
EngineWarmup.............................................................................................................. 5Sec.-3Min.(Adj.)
ReturntoUtility.................................................................................................................... 1-30Min.(Adj.)
EngineCooldown................................................................................................................. 1-30Min.(Adj.)
StandbyVoltage......................................................................................................................85-95%(Adj.)
StandbyFrequency..................................................................................................................80-90%(Adj.)
TimeDelayNeutral............................................................................................................0.1-10Sec.(Adj.)
TransferonExercise................................................................................................................ On/OffSwitch
WarmupTimerBypass............................................................................................................ On/OffSwitch
TimeDelayNeutralBypass...................................................................................................... On/OffSwitch
InphaseMonitor...................................................................................................................... On/OffSwitch
LOGIC CONTROL w / Inphase Monitor
(1LUGPERPOLE) (1PROVIDED)
100 2/0–14AWG 4 2/0–14AWG 2/0–14AWG
150 400MCM–4AWG 4 350MCM–6AWG 350MCM–6AWG
200 400MCM–4AWG 4 350MCM–6AWG 350MCM–6AWG
300 600MCM–4AWG 4 600MCM–4AWG 350MCM–6AWG
or2–[250MCM–1/0AWG] [250MCM–1/0AWG]** 350MCM–6AWG
400 600MCM–4AWG 4 600MCM–4AWG 350MCM–6AWG
or2–[250MCM–1/0AWG] [250MCM–1/0AWG]**
*NotincludedinGTSwithswitchedneutral.**Allowablewirerangeinbracketsisfor2wiresperlug.
