The GD8000 is designed for the rugged
user and tested to military extremes.
Whether used in a desert helicopter
mission, high security prison, or a patrol
car in northern Canada, the GD8000 will
provide years of rugged use at a low
cost of ownership.
Rugged
It Goes Where You Go
Meets and exceeds MIL-STD 810G
Withstands drop from 48” (non-operating)
Operating temperature -22°F (-30°C) to +145°F (63°C)
Tested to stringent helicopter vibration profile
Sealed against dust and water intrusion (IP65 and MIL-STD 810G
506.5, Procedure II)
Magnesium alloy casing and high impact resin
Crash-tested for in-vehicle safety (with approved vehicle dock)
Hazardous Location Class 1, Division 2 (UL 1604)
Ergonomic
Lightweight Full-Size Rugged Notebook (as low as 7.9 lbs)
Desktop quality, full-sized, sealed keyboard
Easy to use display latch, even with gloved hands
Optional NiteVue™ keyboard for enhanced contrast
Side I/O for ease of use
Intuitive design for easy operation
Integrated soft comfort front handle
Wireless
WWAN
3
, WLAN, Bluetooth, and GPS Available All In One System
Optimized antenna placement at top edge of display
Gobi 2000™ ready
Accurate GPS to within 2 meters
Switchable WWAN and WLAN for in-vehicle applications
Seamless roaming for uninterrupted coverage with persistant
software
CRMA™ Express for field upgrade ability to new WWAN
technologies
Optional High-Power WLAN
100 meter line-of-sight Bluetooth 2.0
Computing Performance
Run Multi-Threaded Applications, Like Moving GPS Maps
Intel® Core2 Duo; FSB 1066 MHz, 1.86 GHz
Intel® Graphics Media Accelerator 4500MHD with 1024MB
shared memory
Up to 8GB of ultra fast DDR3 memory
DynaVue® touchscreen display for outdoor viewability
GD8000
High Performance, Fully-Rugged Notebook

Durability Features:
Meets and Exceeds MIL-STD
810G specifications
Dust/Water Tight (IP65/IEC
60529/810G 506.5, Procedure
II)
Die-Cast Magnesium Chassis
SAE J1455 Vehicle Crash
Tested (with Certified Vehicle
Dock)
Operating System:
Microsoft® Windows® 7,
Professional 32-bit/64-bit
Microsoft® Windows® Vista
Business, SP1 32-bi
Microsoft® Windows® XP
Downgrade (custom only)t
CPU:
Intel®Core2 Duo (SL9400)
1.86 GHz Processor
FSB 1066 MHz, 6MB L2 Cache
SMBIOS Enabled
Memory:
1GB-8GB DDR3 SDRAM1
Video Graphics:
Intel®GMA 4500MHD
1024 MB Shared DVMT 5.0
Video Memory
Eco-Friendly Display:
Exceeds MIL-STD-3009
contrast ratio
13.3” LED backlit XGA outdoor
viewable DynaVue® display
GD8000 Product Specifications
Storage:
160GB or 320GB removable
HDD with heater
2.5 in. (6.35cm) ruggedized,
removable 5400 or 7200 RPM
SATA HDD2
128GB or 256GB industrial
grade SSD
Integrated Wireline
Communications:
56 Kbps V. 92 fax/modem
10/100/1000M bit Ethernet LAN
Integrated Wireless
Communications:
Up to 3 RF modems and a GPS
receiver can be integrated at
one time
Engineered for minimum
desense
MobilityXE™ software for
secure wireless access and
seamless roaming between
your wireless or wired WAN
and LAN coverage areas
Wireless LAN (Options):
Intel®Wi-Fi Link 5100 802.11
a/b/g/n network connections
2.4, 5.0 GHz dualband diversity
antennas
Wireless WAN3 (Options):
Choice of EV-DO/1xRTT/CDMA
or HSDPA/UMTS/EDGE/GSM
Common Radio Module
Architecture (CRMA) Express
with fully integrated, field
replaceable WWAN radio
modules
Integrated 800 - 2500 Ultra-
Wideband antennas
Wireless PAN (Options):
Bluetooth V 2+EDR
Class 1 (100m (328ft) line-of-
sight)
Integrated antenna
GPS (Options):
Fully integrated GPS
Di-electrically loaded high
performance quadrifilar helix
antenna
SiRFXTrac high sensitivity
GPS software for increased
acquisition and tracking
Audio:
Internal microphone and (2)
speakers PCI HD Audio with
AC97 compliance
Keyboard & Input:
Full-sized, 87-key sealed
keyboard
Choice of black, rubberized,
NiteVue™ glow-in-the-dark or
backlit keyboards
Localized versions available
Capacitive Touchpad
Expansion Slots:
Type II PC Card Slot (standard)
Optional SmartCard reader or
Express54™ card reader
Media Bay:
Swappable media bay accepts:
MULTI DVD-RW/CD-RW, or
secondary battery
I/O Interface:
RJ-11 (wireline modem)
RJ-45 (ethernet LAN)
3x USB 2.0 serial port (9-pin)
External video (15-pin)
Audio headphone (mini jack)
Microphone (mini jack)
Dimensions & Weight:
2.36”(H) x 12.0”(W) x 11.5”(D)
(60mm (H) x 305mm (W) x
292mm (D)
7.8 lbs (3.5 kg) Basic
configuration
Power Supply:
7200 mAH (79.9Wh) Lithium
Ion main battery
Optional 3800 mAH (41.1Wh)
Lithium Ion media bay battery
Battery life of 8 hours with
main battery, 12 hours with
secondary battery
Power Saver for user
selectable power management
optimization
Hot swappable battery option
Enhanced Security &
Protection:
Password security: Pre-boot,
Supervisor, User
Trusted Platform Module
security chip (TPM v1.2)
Fingerprint reader (optional)
Smart Card Reader (optional)
Kensington Cable lock slot
Stealth mode: To boot-up
without sound/light emissions
Computrace®theft recovery
and data protection agent in
BIOS (optional)4
Custom branding/label option
Accessories:
Vehicle Cradle with or without
RF Connectors
Office Dock
AC Adapter & Cord (90W )
Vehicle Adapter - 12V - 24V
(90W)
External battery chargers
Protective keyboard and
display overlays
Choice shoulder strap and
cases
Additional stylus available
Cargo pouch
Warranty:
3 year warranty
1
Total available memory will be less than 8GB. To
maximize 8GB memory, a 64-bit enabled processor
and operating system are required.
2
Actual formatted capacity varies based on
preloaded devices and operating system.
3
WWAN currently only supported in North America. For
country specific support, please contact your local sales
representative.
4
Requires software and activation to enable theft
protection.
