Page 4
KC Series 17, 19 & 21
HANDLE ASSEMBLY
Pre-5/2013 Old Parts
1, A
2 3, B
4
5
6
8
7
109 16
12
11
14
15
13
17
19
23
18
22
21
20
24
26, I
27
25
29
30 28
31
32
33
34
36
G
F
D
E J
H
C
A B I
35
Ref # Part # Description Required Ref # Part # Description Required
1 501044 Switchbox, Front and Back Polished 1 25 114280 Screw, Cable Hook 1
2 501028 Handle Bar 1 26 501080 Handle Tube, Chrome, Safety Switch Box 1
3 505188 Grip, Handle Red 2 27 501054 Nut, Lock with Nylon Insert 1
4 505185 Lever, Safety Red 1 28 505804 Screw, Strain Relief 1
5 505128 Decal, Switchbox Nameplate 1 29 505146 Cable Clamp 1
6 501054 Nut, Lock with Nylon Insert 2 30 605033 Cable, Heavy Duty 50' Red 1
7 505182 Spring, Safety Switch 1 31 505110 Strain Relief, Cable Spring 1
8 201600 Screw, Spring 1 32 505412 Screw, Switchbox Handle Tube 2
9 505189 Strain Relief, Cable 1 33 501027 Pivot Pin, Lever 2
10 505190 Screw, Strain Relief Cable 2 34 501524 Lever, Switch Red 2
11 505166 Terminal, Ring Type Insulated 1 35 505118 Screw, Switchbox 4
12 201600 Screw, Ground 1 36 142800 Screw, Handle Bar 2
13 505162 Spring, Switch 1 A 500044 Switchbox, Front and Back Polished 1
14 505172 Nut, Switch brass 1 B 505004 Grip, Handle Red 2
15 505173 Washer, Switch 1 C 505174 Lever, Safety Metal 1
16 505210 Circuit Breaker 1 D 505175 Spring, Safety Switch 1
17 505204 Boot, Clear Circuit Breaker 1 E 505176 Clamp, Cable 1
18 505560 Wire, Harness Assembly Switchbox 1 F 505169 Bracket, Switch 1
19 505203 Terminal, Insulated Female Right Angle 2 G 505178 Washer, Switch Lower 1
20 505195 Switch 1 H 505161 Insulator, Cover for Terminal 2
21 505168 Crimp Connector, Insulated 1 I 501067 Handle Tube, Chromed 1
22 201227 Grommet, Rubber Handle Tube 1 J 505193 Plug, Switchbox 1
23 505160 Wire, Tube Assembly Black 1 500022 Handle Assembly, Complete w/Cable Carton
24 501071 Cable Hook 1
