Generalmusic eLEM TM 12.2 ACTIVE Quick start guide

1 r

r2

3 r
+
-
+
-
CONVY IN
CONVY HOUT
CONVY LOUT
HIGH
LOW

r4

5 r

r6
Spare Parts
1 887074 MALE-FEMALE SIGNAL CABLE (mt. 1.5)
2 768030 DISPLAY & SETTING BOARD
3 768019 SIGNAL INPUTS CONTROLS & MIDI INTERFACE BOARD
4 768028 POWER AMPLIFIER BOARD
5 768027 POWER SUPPLY BOARD
6 768026 CONVY PROCESSOR BOARD
7 767987 MAIN FILTER BOARD
8 727516 INPUTS & CONTROL PANEL
9 667488 METAL GRID
10 659027 CYL. KNOB WITE CAP
11 430054 WOODEN CABINET
12 347287 PLASTIC HANDLE
13 347286 HANDLE SET
14 347187 RUBBER HEANDLE
15 237062 TRANSFORMER (EU)
16 229029 1" B&C DRIVER
17 229014 M45 BBC CAST ALLUMINIUM
18 227035 12" LOUDSPEAKER
19 177476 AMPLIFIER HEAT SINK
20 177325 PLASTIC FLANGE
21 150591 RED GLASS DISPLAY
22 141202 XLR MALE CONNECTOR
23 141184 XLR FEMALE CONNECTOR
24 140526 GRAY BUTTON
25 140212 5 Ways DIN SOCKET
26 130297 EU 6A BLACK MAIN CABLE
27 120319 BLACK ZINC-PLATED WL 4x15 PAN HEAD SCREW (HEANDLES FIXING)
28 120125 BLACK ZINC-PLATED M5x35 C/SUNK SCREW (LOUDSPEAKER FIXING)
29 120111 BLACK ZINC-PLATED M6x25 PAN HEAD SCREW (BESBECO FLANGE FIXING)
30 120108 BLACK ZINC-PLATED M5x30 PAN HEAD SCREW (CAST ALLUMINIUM FIXING)
31 120099 BLACK ZINC-PLATED M4x25 PAN HEAD SCREW (METAL GRID FIXING)
32 120098 BLACK ZINC-PLATED M4x20 PAN HEAD SCREW(HEANDLE FIXING)
33 110614 10A F=6.3mm CURRENT-TAP (EU)(US)
34 110297 2 POLES 2 POS. SLIDE SWITCH
35 110291 BLACK BIPOLAR MAIN SWITCH WITH RED LED (EU)(US)
36 180637 ADHESIVE "GENERALMUSIC-LEM" BRAND
Inputs Controls Panel

7 r
BIAS ADJUSTMENT
Instruments, materials and tools:
- Audio Generator
- Dual Trace Oscilloscope
- Digital Voltmeter (or Multimeter)
- 4Ω500W and 8Ω100W Resistors
- Temperature Meter
Setup:
- Connect the Audio Generator to the input and set it to output at 2KHz sinusoidal signal.
- Insert the temperature sensor through the interstize between the heatsink and R93 (PTC).
- Connect the 4Ω500W resistor to the amplifier output instead of the woofer speaker and 8Ω100W instead of tweeter speaker.
- Connect the oscilloscope probes (setting 20V/div.,1ms/div.) on the loads.
- Insert the voltmeter terminals on R107.
ADJUSTMENT PROCEDURE
1) Turn on the amplifier, pressing "UP" "DOWN" and "MIDI" simultaneously, check that the display shows "C".
2) Set the input signal to 0dB (0.775Vrms).
3) When the temperature has reaches about 45°C (109°F) set the signal input to minimum (0 or - ).
4) Adjust the trimmer R111 to read a voltage of 6mV ±0.1 on the multimeter.
5) Check that the voltage across the R108 resistor has the same value.
6) At the same temperature condition, adjust the VR1 trimmer to read 2.2mV ±0.1 at R24 resistor.
7) Check that the voltage on the R25 resitor has the same value.
Veryfing:
1) Increase the input level to obtain an output voltage about of 0.5Vpp.
2) Check with the oscilloscope that the output signal is without a cross-talk distortion and eventually slightly
adjust the R111 or VR1 position until distortion disappears.
(Note: the voltage value across the R107 or R108 resistor must not exceed 10mV and the R24 or R25 resistor must
not exceed 4mV).
LIMITER ADJUSTEMENT
1) Increase the input level to 10dB, adjust the trimmer VR1 until clipping distortion disappears.
2) Verify tha the led change colour from green to red.
3) Re-connect the speakers instead of the 4Ωand 8Ωresistors.
TOURMASTER12.2 ACTIVE- Technical Specifications
SPEAKER SPECIFICATIONS
C O MPO NENTS High 1" driver with controlled directivity horn
Low 12" lowfrequency speaker
HIGH section POWER HANDLING W continuous 50
(EIA RS-426A) W peak 150
LOW section POWER HANDLING W continuous 300
(EIA RS-426A) W peak 900
IMPEDANCE High ohm 8
Low (nominal) 4
CONSTRUCTION Cabinet: bitch plywood
Finish: Black scratch-resistant paint
Protection grille:metal grille
WEIGHT kg - lbs. 32 - 70,4
DIMENSIONS mm - in. 400x610x396 - 157,5x240,2x156 (WxHxD)
PROCESSOR SPECIFICATIONS
INPUT Sensitivity dB 0
Impedance Kohm 30 (balanced) - 15 (unbalanced)
A/D converter bit 18
D/A converter bit 18
Dynamic range dB 105
Sampling rate kHz 48
CROSSOVER Frequency Hz 1800
Slope dB/oct. 24
HIGH section POWER AMPLIFIER W continuous 100
LOW section POWER AMPLIFIER W continuous 300
AMPLIFIERS DISTORTION THD+Noise <0,02%
CONTROLS VOLUME control
UP & DOWN selector buttons
MIDI button
Earth Lift
DISPLAY 2-digit display
SIGN/COMP LED
CONNECTORS 1 XLR-F + XLR-M (input + link)
MIDI IN & MIDI THRU
POWER SUPPLY see label on the apparatus
SYSTEM SPECIFICATIONS
FREQUENCY RESPONSE Hz 60÷20000 (-10dB)
SENSITIVITY MAX SPL SPL 1W/1m dB 98
continuous 124
DISPERSION ANGLE orizontal ° 80 (±5)
vertical 50 (±10)
DIRECTIVITY Factor (Q) dB 7
DIRECTIVITY Index Di 8,5 (+3,7, -2,3)

r8
Power Supply Board
768027 Power Supply Board (PCB#317170)
141060 * Con V M 12c Mini Mate Burndy
141013 * Con V F 10c P=1.27 Mmatch Amp
140081 * H 2c P=10 Terminal Block
140069 * H 3c P=10mm Terminal Block
110119 * Fuse Clip 10A max (EU) (US)
110029 * T4A Fuse 5x20mm (EU)
110020 * T2.5A Fuse 5x20mm (EU)
110018 * T630mA Fuse 5x20mm (EU)
100060 * 7815 +15V 1A Voltage Regulator
100059 * 7805 +5V 1A Voltage Regulator
100049 * 7915 -15v 1a Voltage Regulator
080168 * W02M 1.5A Rectifier Diodes Bridge
030882 * 10000uF 50V Snap-In Electrolytic Capacitor
030858 * 4700u 25V 20% Vert Electrolytic Capacitor
030560 * 4700u 80v 20% Snap-In Electrolytic Capacitor
030554 * 4700u 35v 20% Snap-In Electrolytic Capacitor
Signal Input Controls & MIDI Interface Board
768125 Signal Input Controls & midi Interface Board (PCB#313019)
757942 * Photores Coupler
230569 * FL5R200PNT EMI Coil For Signal
141202 * Xlr H M M21bc Nuova Asme
141184 * Xlr H F Riten Nc3fprh Neutrik
141064 * Con H M 9 C Mini Mate Burndy
141010 * 4 Contacts Vert Female Connector
140212 * Horizontal Female 5 Poles Din Socket
100602 * 74HC04 Hex Inverter
100061 * TL072 Dual J-Fet Operational Amplifier
100035 * 6N138 Optocoupler
090194 * BC560 TO92 LN Pnp Transistor
090183 * Bc550 To92 Ln Npn Transistor
080734 * Led 2.5x5mm Rect Diff Red-Grn
080245 * 7V5 1w 5% Zener Diode
080103 * 1N4148 100mA 75V Signal Diode
074570 * 5K lin. 31 clicks Potentiometer
070125 * 1K 20% Vertical Linear Trimmer
Display & Setting Board
768030 Display & Setting Board (PCB#319046)
141015 * Con V F 14c P=1.27 Mmatch Amp
140526 * Microswitch 100V 100ma 0.8mm
080717 * HDN1105 7 Segments Display
Mains Filter Board
767987 Mains Filter Board (PCB#315016) (EU)
768005 Mains Filter Board (PCB#315016) (US)
230565 * 2.5mH 250V 3A AC Line Filter
140010 * 3 Contacts P=10 Vert Terminal Block
110113 * Fuse Clip 5x20mm 6A max (EU)
110114 * Fuse Clip 6.3x32mm 10A max (US)
020493 * 100n 250Vac MKP EMI Capacitor “Siemens”
010719 * 2n2 250Vac 7A 20% AC Line “Y” Filter “Murata”
Power Amplifier Board
768028 Power Amplifier Board (PCB#319032)
141060 * Con V M 12c Mini Mate Burndy
141059 * Con V M 9 C Mini Mate Burndy
141058 * Con V M 6 C Mini Mate Burndy
110316 * Relay 24V / 1 Switch no 16A 250V
110307 * Relay 24V / 2 Switch 5A 250V
100084 * TL074 Quad J-Fet Operational Amplifier
100061 * TL072 Dual J-Fet Operational Amplifier
090920 * Mje803 To126 Npn Darl Transistor
090917 * MJE350 TO126 Pnp Transistor
090916 * MJE340 TO126 Npn Transistor
090201 * 2n5401 To92 Pnp Transistor
090200 * 2n5550 To92 Npn Transistor
090192 * BC307 TO92 Pnp Transistor
090182 * BC173C TO92 Npn Transistor
080261 * 10V1w 5% Zener Diode
080245 * 7V5 1w 5% Zener Diode
080241 * 5V6 1W 5% Zener Diode
080171 * Fe6b 6a 100V Fast Recovery Diode
080156 * 1N4002 1A 100V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
070106 * 470e 20% Horizontal Linear Trimmer
070082 * 220e 20% Horizontal Linear Trimmer
030715 * 1000u 6v3 20% Vert Electrolytic Capacitor
SPARE PARTS LIST
ACCESSORIES
887074 XLR Female-Male Signal Cable (1.5mt)
277309 Owner’s Manual
VARIOUS
667612 Inputs & Controls Panel
659027 Cyl. Knob White Cap
237062 Transformer (EU)
237063 Transformer (US)
177477 Amplifier Fixing Square
177475 Transformer Shield
150591 Display Red Glass
110614 Mains Socket
110291 Power Switch
667487 Upper Stirrup
667486 Left Side Stirrup
667485 Right Side Stirrup
110085 T630mA Fuse 6.3x32mm (US)
110036 T4A Fuse 6.3x32mm (US)
110035 T2.5A Fuse 6.3x32mm (US)
110029 T4A Fuse 5x20mm (EU)
110014 T2.5A Fuse 5x20mm (EU)
110010 T2A Fuse 5x20mm (EU)
110009 T630mA Fuse 5x20mm (EU)
717053 Wooden Parts
657250 * GEBERIT Black Tube
430058 * Wooden Cabinet
667609 Metal Grid
347287 Plastic Handle
347286 Plastic Setted Handle
347187 Plastic Grip
229029 1" DE25 8 OHM B&C Driver
229014 M45 BBC Cast Alluminium
227035 12" 12/052 8 OHM B&C Speaker
130297 Mains Cord (Europe Version)
130283 Mains Cord (U.S. Version)
Convy Board
768127 Convy Board (PCB#313020)
230569 * FL5R200PNT EMI Coil For Signal
141059 * Con V M 9 C Mini Mate Burndy
141058 * Con V M 6 C Mini Mate Burndy
141015 * Con V F 14c P=1.27 Mmatch Amp
141013 * Con V F 10c P=1.27 Mmatch Amp
141010 * 4 Contacts Vert Female Connector
100943 * MC33079 Quad Ln Op Amp
100919 * MC33078 Dual LN J-Fet Operational Amplifier
100737 * ADMOD79 2ch Ad Delta Modulator
100643 * AD1865N Dual 18bit Dac
100642 * TS93C46 1Kbit Eeprom Memory
100612 * 74HC374 Octal D-Type Flip-Flop
100614 * 74HC74 Dual Flip-Flop
100611 * 74HC373 Octal D-Type Latch
100602 * 74HC04 Hex Inverter
100579 * 80C32 Cpu Fc=16MHz
100061 * TL072 Dual J-Fet Operational Amplifier
100059 * 7805 +5V 1A Voltage Regulator
100058 * 7905 -5V 1A Voltage Regulator
080103 * 1N4148 100mA 75V Signal Diode
050494 * Resistor Array 10K X5 1/8w 5%
050492 * 10Kx8 1/8w 5% Resistor Array
010722 * 24.576MHz Quartz Resonator
010720 * 12MHz Ceramic Resonator With Capacitors
010703 * 24MHz Quartz Resonator
557025 * MICRO PROGRAM.CONVY
557011 * EPROM CONVY
105001 * CONVY Dsp Convolver
100737 * ADMOD79 2ch Ad Delta Modulator
100643 * AD1865N Dual 18bit Dac
100590 * 27C256 Eprom 256Kbit Ta=120ns
100579 * 80C32 Cpu Fc=16MHz
090920 * Mje803 To126 Npn Darl Transistor
090919 * Mje15031 To220 Pnp Transistor
090918 * MJE15030 TO220 Npn Transistor
090917 * MJE350 TO126 Pnp Transistor
090916 * MJE340 TO126 Npn Transistor
090913 * MJE4352 TO218 Pnp Transistor
090912 * MJE4342 TO218 Npn Transistor
090863 * TIP36C TO218 Pnp Transistor
090862 * TIP35C TO218 Npn Transistor
080819 * Ptc 70 Pth59f04bg222ts
080607 * Kbpc25 25a 200V Bridge Rec Dio
080606 * GBU8D 8A Rectifier Diodes Bridge
Notes:
Each spare part is single quantity unless otherwise specified
Asterisk prefix explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed first level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk =.......................
Any request for not above mentioned part must encompass specific description including:
1) Model name,
2) Section,
3) Module code,
4) Reference name,
5) Quantity number.
