Generay SSL-RC User manual

USER MANUAL
Wireless Remote
FOR DIGITAL SSL SERIES LEDS
SSL-RC

Wireless Remote for Digital SSL Series LEDs - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray SSL-RC 2.4 GHz Wireless Remote is a
dedicated remote for Genaray’s Digital SSL Series
LEDs. The 4-channel remote controls dimming on all
models, and it adjusts color temperature on bi-color
models from over 100 feet away. The stepped dial
controls the brightness in 1% increments, and the
color temperature in 50 K increments.
INTRODUCTION

Wireless Remote for Digital SSL Series LEDs - USER MANUAL 3
· Please read and follow these
instructions, and keep this
manual in a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Do not attempt to disassemble or
repair this product—doing so will
void the warranty, and Genaray will
not be responsible for any damage.
· Install the battery in the proper
orientation. Installing batteries in
the reverse orientation can cause
them to leak, overheat, or explode.
· Remove the battery when
storing the remote.
· Keep this product away from children.
· Images are for illustrative
purposes only.
PRECAUTIONS
Precautions

Wireless Remote for Digital SSL Series LEDs - USER MANUAL
4
PRODUCT
OVERVIEW
Battery cover
Battery
compartment
LCD
screen
Power button
Adjustment dial

Wireless Remote for Digital SSL Series LEDs - USER MANUAL 5
MODE SELECTION
Repeatedly pressing the adjustment dial
selects the three operating modes.
·Color temperature adjustment
mode: The color icon (C:) blinks.
·Power output adjustment mode:
The dimming icon (DIM:) blinks.
·Channel selection mode:
The channel icon (CH:) blinks.
1. Remove the battery case cover, and
install one AA battery. Make sure
it’s in the proper orientation. Then
replace the battery case cover.
2. Before using the transmitter,
make sure your Genaray Digital
SSL LED lights are turned on.
3. To turn on the transmitter, press the
transmitter’s power button. The LCD
screen will illuminate.
TURNING ON THE
REMOTE
instructions

Wireless Remote for Digital SSL Series LEDs - USER MANUAL
6
SETTING THE CHANNEL
Turn the adjustment dial to select the
channel (A–D). After five seconds, the
screen will return to the function page.
The "OFF" selection prevents you from
changing the settings inadvertently.
To set the light’s channel, refer to the
user manual that came with the light.
ADJUSTING THE COLOR TEMPERATURE
Use the transmitter to wirelessly
adjust the color temperature of one
or more Bi-Color SSL LEDs from
3000–5600 K in 50 K increments.
Turn the dial to adjust the color temperature.
The LED’s color temperature will change
as you turn the adjustment dial.
ADJUSTING THE POWER OUTPUT
The transmitter wirelessly adjusts the
brightness of one or more LED units from
0% (off) to 100% in 1% increments.
Turn the adjustment dial to fine-tune
the power output. The LED’s brightness
will change as you turn the dial.
instructions

Wireless Remote for Digital SSL Series LEDs - USER MANUAL 7
Press the power button to
turn off the remote.
If the SSL LEDs are still on, they will
remain at the last values that were set
on the remote. Their color temperatures
and brightness settings can still be
adjusted via their control boxes.
Channels: 4
Functions Supported: Dimming, color
temperature (bi-color LEDs)
Frequency: 2.4 GHz
Frequency Range: 100 ft. (30.5 m)
Power: AA Battery (×1)
Dimensions: 4 × 2.6 × 1 in. (10.2 × 6.5 × 2.5 cm)
Weight: 3 oz. (85 g)
SPECIFICATIONS
TURNING OFF THE
REMOTE
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under
normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement,
whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or
replacement, at Genaray’s discretion, of any product that fails during normal use of this product in its intended manner
and in its intended environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product has
been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper
installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER ANY EXPRESS WARRANTIES
NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have
additional rights that vary from state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return merchandise
authorization (“RMA”) number, and return the defective product to Genaray along with the RMA number and proof of
purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
© 2019 Genaray. All Rights Reserved. GG1
