Genesee Scientific MLX-106-GS User manual

Mini Centrifuges
Instruction manual
MINI
CENTRIFUGES
Genesee Scientific Corporation
900 Vernon Way El Cajon, CA 92020 USA
Tel:[phone](USA),[phone](International)
Fax: [phone](USA),[phone](International)
Email: [e-mail]
www.geneseesci.com

Introduction.........................................1
Cautions for Usage....................................1
Receiving and Inspection...............................2
Features.............................................3
Specifications.........................................3
Structure.............................................4
Replacing Rotors.....................................4
Operation Instructions..................................5
Maintenance..........................................5
Troubleshooting....................................... 6
Accessories..........................................6
Packing List..........................................7
Warranty Card.......................................8
Thank you for choosing Genesee's product. Mini centrifuges are popular laboratory equipment used
in clinical, environmental and industrial research. These personal centrifuges are ideal for quick spins,
filtrate of samples, cell separations and more.
The MLX mini centrifuge provides two rotors, micro-tubes and another for use of 0.2ml PCR strip tube.
The 6 x 1.5 ml rotor is designed to centrifuge up to six individual 1.5 ml plastic micro-centrifuge tubes.
It will also accept 0.5 ml and 0.4 ml tubes with the adapters supplied with the unit. Adapters are
available separately for 0.2 ml tubes. The strip tube rotor is designed to centrifuge two 8 x 0.2 ml strip
tubes. It will also accept up to 16 individual 0.2 ml tubes.
Before you use the unit, please read this entire manual carefully to understand how to operate, and
maintain. Your satisfaction with the unit will be increased if you take the time to read about its safety
and operational notices.
Keep this manual on-hand so it can be used by all operators of the unit. Be sure all operators
of the unit are given appropriate training before you put the unit in service.
1. Be sure you follow any city, county, or other ordinances in your area regarding the use of
this unit.
2. Use only approved accessories. Do not modify system components. Any alterations or
modifications to your instrument may be dangerous and will void your warranty.
3. Do not modify the power cord provided with the unit. If the plug does not fit an outlet,
have a proper outlet installed by a qualified electrician.
4. Never operate the centrifuge without a rotor fixed to the shaft.
5. Never fill tubes while they are in the rotor，liquid spillage may harm unit.
6. Never put hands in the rotor area unless the rotor is completely stopped.
7. Never move the centrifuge while the rotor is spinning.
8.Always load the rotor symmetrically. Each tube should be counterbalanced by anther tube.
1
Introduction:
Cautions for Usage:
Table of Contents
www.geneseesci.com
www.geneseesci.com

Features:
○ Ergonomically designed with small footprint.
○ The clear cover made of high strength plastic affords high visibility of samples;
○ Mini centrifuges are manufactured to precise specifications using the highest grade materials,
resulting in smooth runs;
○ With open lid cut off switch, the mini centrifuge units will stop automatically when the lid is open;
○ Digitally controlled power circuitry ensures precise rotating speed;
○ Different sized tubes can be centrifuged using our comprehensive selection of accessories.
Receiving and Inspection:
23
Your satisfaction and safety require a complete understanding of this unit, including its proper
function and operational characteristics. Be sure operators are given adequate training before
attempting to put the instrument in operation.
1.1 Inspection: Upon delivery please inspect the package for visible exterior damage, note and
describe on the freight bill any damage found and enter
your claim on the form supplied by the carrier.
1.2 Inspect for concealed loss or damage on the unit itself，If any, the carrier will arrange for official
inspection to substantiate your claim. Save the shipping crate until you are sure the unit has been
delivered in good condition.
1.3 Return Shipment: If for any reason you must return the unit, please contact your distributors
customer service department.
1.4 Accessories: Make sure that all of the equipment indicated on the packing slip is included with
the unit. Carefully check all packaging materials before discarding.
www.geneseesci.com
www.geneseesci.com
Specifications:
6000(rpm）
≤60dB
5℃-40℃
≤80%
1.4Kg
Head for 8 Tubes ( in 2 rows):8x0.2ml Standard Head:6x1.5ml
155×140×115mm
Open Lid Cut Off Switch
Model
Power Supply
Speed
G-force(RCF)
Noise Level
Enviromental Temperature
Relative Humidity
Gross Weight
Standard Heads
Figure Dimensions
Safety Feature
MLX-106-GS
2000(g)
AC 100-240V,50/60Hz

45
Structure:
Replacing Rotors:
The centrifuge provides two interchangeable rotors. These are easily replaced using the Allen key
provided.
◇ Remove rotor:
Remove the screw under the rotor with the Allen key. Pull up the rotor from the motor shaft and remove it.
◇ Reassemble rotor:
Put the other new rotor to the motor shaft. Take care not to press the rotor down so far as to compress
the rubber collar at the base of the shaft. Fix the screw with the Allen key until it is tight.
◇ Never over-tighten the screw to prevent damaging the rotor or motor shaft.
Operation Instruction:
Maintenance:
A、Turn on the unit:
For Single Speed Models: Put “Power” rocker switch to position (I).
For Multi Speed Models: Select desired speed by dip switch at right. Then put “Power” rocker switch to
position (I).
◇ Before you start the machine, you must close the cover.
◇ Safe operation of the centrifuge requires that the rotor be loaded in a balanced fashion.
◇ The independent tubes, strip tubes and adapters must always be loaded symmetrically to ensure
proper balance.
◇ Never start the centrifuge with one strip tube in place only.
B、Turn off the unit:
Put “Power” rocker switch to position (O).
After the rotor stops, open the cover with the hand lever on the front, and then take out the tubes.
◇ Before using any cleaning or decontamination methods except those recommended by the
manufacturer, check with the manufacturer that the proposed method will not damage the equipment.
◇ Clean the centrifuge with damp cloth and non-corrosive detergent (ph<8).
◇ Do not immerse the centrifuge in liquid or pour liquids over it.
◇ After cleaning, ensure all parts are dried thoroughly before attempting to operate the unit.
Power Switch
1 2 3
Exchanging
Rotors:
Cover Rotor
Tab
www.geneseesci.com
www.geneseesci.com

6
Trouble Shooting:
Accessories:
For troubleshooting, please refer to the table below. If the problem is not resolved, please
contact the seller.
Troubles
Not spinning
The work is not normal
Reason Solution
The power is off
The fuse is broken
Turn on the power Plug the power cord
Replace it(1A/250V)
The unit is not steady
Tubes are not symetrical
Tubes are not balanced
The centrifuge tube's lid is not closed
The centrifuge tube is broken
Tubes are mixed sizes
Stabilize unit
Load tubes symetrically
Load balanced tubes
Close lid
Replace tube
Use similar tubes
Description Model Picture
Adapter for 0.5ml
Centrifuge Tube
Adapter for0.2ml
Centrifuge Tube
0.2ml 8-Place PCR
Strip Rotator
1.5mm Allen Key
MLXF-1
MLXF-2
MLXF-3
Description Qty
Machine
Remark
Instruction Manual
1
1
1
6
6
1
Optional Accessory
MLXF-1
MLXF-2
MLXF-3
1.5mm Allen Key
7
Packing List:
www.geneseesci.com
www.geneseesci.com

Save this card carefully please. When you need service, contact the service company with card & invoice.
WARRANTY CARD
Warranty Card
User Name
Address
Zip Code
Product Name
Serial number
Telephone
E-mail
Model
Purchase Date
1.Warranty period is 24 Months from purchase date.
Warranty Scope:
Warranty is not valid under the following circumstances:
1. Warranty term is expired.
2. Damage due to improper use, maintenance or handling.
3. Unmatched serial numbers, or modification of serial numbers.
Customer service hotline: [phone]
User: the above information should be completed by the seller.
Maintenance records
Name of service
Address
Maintenance sheet number
Name of service
Address
Maintenance sheet number
Name of service
Address
Maintenance sheet number
Maintenance date
Telephone
Maintenance staff signature
Maintenance date
Telephone
Maintenance staff signature
Maintenance date
Telephone
Maintenance staff signature
First
Second
Third
The following should be completed by maintenance staff.
