Genesis 2018 G80 User manual

Looking For more detailed information? This Quick Reference Guide does not replace your vehicle’s
Owner’s Manual. If you require additional information or are unsure of a specific issue, we
recommend that you always refer to the vehicle’s Owner’s Manual or contact your authorized
retailer of Genesis Branded Products. The information contained in this Quick Reference Guide is
correct at the time of printing; however, specifications and equipment can change without notice.
No warranty or guarantee is being extended in this Quick Reference Guide, and Genesis Brand
reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment.
MAINTENANCE
Low tire pressure indicator /
TPMS malfunction indicator
Scheduled Maintenance
(Normal Usage)
3.8L / 5.0L 3.3T
Engine Oil And Filter Replace 7,500 or 12 mos. Replace 6,000 or 12 mos.
Fuel Additives Add 7,500 or 12 mos. Add 6,000 or 12 mos.
Tire Rotation Perform 7,500 or 12 mos. Perform 6,000 or 12 mos.
Vacuum Hose
Inspect 7,500 or 12 mos. Inspect 6,000 or 12 mos.
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Exhaust Pipe & Mufer
Front Brake Disc/Pads, Calipers
Rear Brake Disc/Pads
Steering Gear Box, Linkage & Boots/ Lower
Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Propeller Shaft
Air Cleaner Filer Inspect 7,500 or 12 mos. Inspect 6,000 or 12 mos.
Replace 22,500 or 36 mos. Replace 18,000 or 36 mos.
Climate Control Air Filter
(For Evaporator And Blower Unit) Replace 7,500 or 12 mos. Inspect 6,000 or 12 mos.
Fuel Tank Air Filter
Inspect 15,000 or 24 mos. 12,000 or 24 mos.
Vapor Hose & Fuel Filler Cap, Fuel tank
Brake Fluid
Parking Brake
Fuel Filter
Fuel Lines, Fuel Hoses And Connections Inspect 30,000 or 48 mos. Inspect 24,000 or 48 mos.
Front(AWD)/Rear Differential Oil
Valve Clearance (3.3T and 3.8L) Inspect 60,000 or 72 mos. Inspect 60,000 or 72 mos.
Drive Belt Inspect
First
60,000 or 72 mos. Inspect First 60,000 or 72 mos.
Subsequent, every
15,000 or 24 mos. Inspect Subsequent, every 12,000 or 24 mos.
Spark Plugs (Iridium Coated) Replace 105,000 Replace 42,000
Coolant Replace
First
120,000 or 120 mos. Replace
First
120,000 or 120 mos.
Subsequent, every
30,000 or 24 mos.
Subsequent, every
30,000 or 24 mos.
Automatic Transmission Fluid No checks or services required for Normal Usage driving.
*Check the engine oil regularly between recommended oil change. Genesis Branded Vehicle recommend Quaker
State oil.
*See Owner’s Manual for details.
☐TIRE PRESSURE MONITORING SYSTEM (TPMS)- page 36
☐PARKING ASSIST SYSTEM (PAS) - page 34
• To activate wipers move the switch down
to one of the three positions
(AUTO, LO, HI)
• To adjust "AUTO" speed move switch
• To spray washer fluid pull lever toward you
• Push lever up for a single wiper pass
☐WINDSHIELD WIPER / WASHER - page 09
AUTO
LO
HI
MIST
OFF
NOTE: Tire pressure may vary in colder temperatures causing the
low tire pressure indicator to illuminate. Inflate tires according to
the Tire Pressure Label located on the driver’s side door pillar.
If the PAS is OFF, it will automatically turn ON when in Reverse.
PAS will automatically turn OFF when driving forward and
speed is over 6 mph.
☐HOW TO DEFROST
1
Press the front defrost button.
2
Set to warmest temperature setting.
3
Set to highest fan speed.
WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
DEMONSTRATE AUTOMATIC CLIMATE CONTROL - page 18 – 19
☐DEMONSTRATE HOW TO SET THE CLOCK - page 29
NP150-G2018
(Rev 07/21/17)
Printing 07/24/17
☐GENESIS CONNECTED SERVICES – page 21-23
- Assist with creating MyGenesisUSA.com account
- Assist with Genesis Connected Services enrollment
- Show Genesis Connected Services Users Manual
- Encourage customers to press the Genesis Connected
Services button
GENESIS
G80
QUICK GUIDE

Roadside Assistance: 1-844-340-9742
SiriusXM®Radio: 1-800-967-2346
Genesis Customer Care &
Connected Services: 1-844-340-9741

Steering
wheel
adjustment
Page06
Instrument
cluster
Page14-15
Navigation
Page26
Head lights
and fog
lights
Page08
Climate
control
Page18-19
Driver's
main
controls
Page07
Wiper and
washer
Page09
Transmission
Page37-38
Table of contents
Automatic Emergency Braking (AEB) 36
Auto Hold 35
AUX, USB and iPod port 27
Blind Spot Detection system (BSD) 41
Bluetooth Operational Tips 24
Bluetooth Phone Pairing 20
Child - protector rear door lock 12
Climate control 18-19
Climate control system seat & seat warmer 31
Clock adjustment 29
Cruise control/Advance smart cruise control 41
Driver Attention Alert (DAA) 41
Driver Information System (DIS) 28
Drive mode integrated control system 42
Driver position memory system 05
Driver's main controls 07
Electronic Stability Control (ESC) 40
Electronic Parking Brake (EPB) 35
Engine start/stop button 05
Front seat adjustment 03
Fuel filler door 07
Genesis Connected Services 21-23
Headlights and fog lights 08
Headrest adjustment 04
Head up display 17
Heated steering wheel 32
HomeLink wireless garage control system 13
Instrument cluster 14-15
Interior lights 10
Lane Keeping Assist System (LKAS) 39
LCD display control/modes 16
Navigation 26
Paddle Shifter 39
Panoramic Sunroof 10
Parking assist system (PAS) 34
Multi-View Camera 33
Rearview camera 32
Rear window curtain 30
Seat belt adjustment 04
Smart key 02
Steering wheel adjustment 06
Steering wheel audio control 24
Tire Pressure Monitoring System (TPMS) 36
Transmission & paddle shifter 37-39
Trunk 11
Voice recognition tips 25
Wipers and washer 09
Engine start/
stop button
Page05
Cruise control/
Advanced smart
cruise control
Page41
AUX,USB
and iPod
Page27
Driver position
memory system
Page05
*Some vehicles may not be equipped
with all the listed features.
Use this Quick Reference Guide to learn
about the features that will enhance your
enjoyment of your Genesis Branded Vehicle.
More detailed information about these
features are available in your Owner’s Manual.
FREQUENTLY ASKED QUESTIONS
•Pair phone to your vehicle. Refer to page 20.
WARNING!
To reduce the risk of serious injury to yourself and others,
read and understand the important SAFETY INFORMATION
in your Owner’s Manual.

GETTING STARTED
Quick Reference Guide I 03
02 I Quick Reference Guide
Driver’s door Lock / Unlock
Smart key must be within 28~40 in.
from the outside door handle.
Press: Once – Unlock driver door
Twice – Unlock all doors
Third – Lock all doors
Lock
Unlock
Trunk unlock
Panic
NOTE: The key hole is located under
the key hole cover
B
.
SMART KEY
A
B
Remove mechanical key.
Press and hold the release button
A
to remove the mechanical key.
GENESIS
FRONT SEAT ADJUSTMENT
2
Forward and backward
1
Seat cushion length (for driver’s seat)
2
Seatback angle
3
Seat cushion height
1
Lumbar support
4
Seat bolster adjustment (for driver’s seat)
5
1
34
5
A

GETTING STARTED
Quick Reference Guide I 05
04 I Quick Reference Guide
HEADREST ADJUSTMENT
To Raise Headrest:
Pull headrest up.
To Lower Headrest:
Press lock button while pressing
down on headrest.
To adjust headrest forward:
Pull forward to 1 of 3 positions.
To adjust backward:
Pull it fully forward to the farthest
position and release it.
To Raise Center Headrest:
Rotate headrest forward.
Lift headrest up.
To Lower Center Headrest:
Press lock button while pressing
down on headrest.
Press button to rotate headrest
down.
GENESIS
With the ignition OFF and foot
OFF of brake pedal, press the
engine start / stop button.
• Once for ACC(Accessory) mode.
• Twice for ON mode.
• Three times for OFF.
ENGINE START/STOP BUTTON
To start the engine in any mode(including OFF), press
the engine start/stop button while pressing the brake pedal.
To shut the engine OFF, place shift lever in P(Park) and press
the engine start/stop button again.
Emergency situations
Shut off engine while drving
Press and hold engine start/stop button for more than 2 seconds or press
3 times consecutively within 3 seconds.
Restart engine while driving
Press engine start/stop button with shift lever in N(Neutral).
Storing
1. Adjust the driver’s seat, outside
rearview mirrors, steering wheel,
instrument panel illumination and
head up display.
2. Press the SET button. The
system will beep once.
3. Press one of the memory buttons
(1 or 2) within 5 seconds.
The system will beep twice.
Recalling
Press the desired memory button
(1 or 2). The system will beep once.
DRIVER POSITION MEMORY SYSTEM
NOTE: Transmission must be in P(Park).
SEAT BELT ADJUSTMENT (Front seat)
Pull up to raise.
Press button and
push down to lower.
A
A
Rear center headrest
NOTE: For resetting, please see
Owner’s Manual for procedure.

FEATURES AND CONTROLS
Quick Reference Guide I 07
06 I Quick Reference Guide
Set the angle
2
and distance
3
with the switch
1
.
STEERING WHEEL ADJUSTMENTS
NOTE: Do not adjust while driving.
NOTE: Tighten fuel cap until one click is
heard.
Failure to do this may result in the
Check Engine Light illuminating.
FUEL FILLER DOOR
•Front power window switches.
•Press switch left/right to unfold/fold
mirrors.
•Rear power window switches.
•Press the L or R button to adjust the
mirror by using the directional switch.
If L or R button is still selected, both
mirrors will tilt downward when
reversing. Deselect L or R will disable
the auto tilt down feature.
Driver’s door
DRIVER'S MAIN CONTROLS
Outside Rearview Mirror
Press the lock or unlock button on the
smart key, and the mirrors will be
folded or unfolded when AUTO is set.
Power window lock button
Disables the power window switches
on the rear passenger doors.
Door Lock
Locks/unlocks all doors.
Window Switches
GENESIS
1
2
3

Quick Reference Guide I 09
FEATURES AND CONTROLS
08 I Quick Reference Guide
WIPERS AND WASHER
Auto control wipe interval adjustment
Adjust the control knob.
Windshield washer
Pull the lever gently toward you to
spray washer fluid on the windshield
and to run the wipers1-3 cycles.
Headlamp washer
Fluid will spray on headlamp
assemblies when headlamps are
turned ON. Will activate only once for
every ignition key cycle or only once
every 15 minutes.
Fast wiper speed
Slow wiper speed
MIST - Single wipe
AUTO -Auto control wipe
LO -Low wiper speed
HI -High wiper speed
OFF
HEADLIGHTS AND FOG LIGHTS
Parking light position
Flashing high beam
DRL OFF position
Auto light position
Flashing high beam
Headlight position
Flashing high beam
Headlight delay
Headlights may stay on for 15 seconds after exiting and locking vehicle.
Press the remote lock button twice to turn headlights off.
This feature can be enabled/disabled under the Lights menu in the User
Settings of the instrument cluster.
See Owner’s Manual for more detail.
Fog light
Turn signals and lane change
signals
Flashing high beam
PULL
PULL
High beam
PUSH
GENESIS
Smart High Beam Function
1. Select auto position on stalk.
2. Push lever forward to engage Auto High beam.
3. Push lever forward again to disengage.
See Owner's Manual for more details.

Quick Reference Guide I 11
FEATURES AND CONTROLS
10 I Quick Reference Guide
PANORAMIC SUNROOF
Sunshade
Sliding the sunroof
Tilting the sunroof
INTERIOR LIGHTS
Type A
Type B
1
1
1
1
2
2
3
3
Press the button
to open the trunk.
Power trunk:
To close, press and
hold until trunk is fully
closed.
TRUNK
Trunk main control button
Press to open.
Smart key needs to be
within range.
Use the mechanical key.
Trunk open button
Pressing the button
closes the power
trunk automatically.
Power trunk close button
Pressing the button
with the smart key in
proximity locks all the
doors and closes the
power trunk
automatically.
Power trunk lock button
Pressing the button
for more than 1
second opens the
power trunk
automatically.
Trunk open button on
the smart key
GENESIS
Front Map Lamp ( )
Push the switch to turn the map
lamp on or off.
1
Front Door Lamp ( )
Lights will turn on when any door
is open.
2
Front Room Lamp ( )
Push the switch to turn the room
lamp on or off.
3

Quick Reference Guide I 13
FEATURES AND CONTROLS
12 I Quick Reference Guide
CHILD-PROTECTOR REAR DOOR LOCK
Lock
Insert a key into the hole and turn it
towards the lock position .
Unlock
Insert a key into the hole and turn away
from the lock position .
HOMELINK WIRELESS GARAGE CONTROL SYSTEM
GENESIS
Smart Trunk
Trunk will open automatically when
detecting smart key within range near the
trunk for more than 3 seconds.
To enable Smart Trunk function:
Vehicle must be in P (Park) to adjust
settings in the User Setting mode.
1. Select "Door" in the User Settings
in the instrument cluster.
2. Check "Smart Trunk".
NOTE: Function is active after 15 seconds
when all doors are closed and locked. The
vehicle will also provide an audible and visual
alarm while activating. For more details, refer
to Owner's Manual.
Factory setting defaults Smart Trunk in OFF
position.
Standard Programming
To train most devices, follow
these instructions:
1. For first-time programming,
press and hold the two
outside buttons. ( , ),
HomeLink® Channel 1 and
Channel 3, until the indicator
light begins to flash (after
10 seconds). Release both
buttons. Do not hold the
buttons for longer than 20
seconds.
2. Position the end of your
hand-held transmitter 1-3
inches (2-8 cm) away from
the homeLink®button you
wish to program while
keeping the indicator light in
view.
3. Simultaneously press and
hold both the HomeLink®
and hand-held transmitter
buttons until the HomeLink®
indicator light changes from
a slow to a rapid blinking
light. Now you may release
both the HomeLink®and
hand-held transmitter
buttons.
Flashing Flashing

Quick Reference Guide I 15
INSTRUMENT CLUSTER
14 I Quick Reference Guide
GENESIS
Fuel gauge
Tachometer Speedometer
Engine coolant temperature gauge
Warning and
indicator lights
LCD display
(including trip computer)
Type A with 4.3" LCD Display
Type B with 7" LCD Display
Fuel gauge
Tachometer Speedometer
Engine coolant temperature gauge
Warning and
indicator lights
LCD display
(including trip computer)
