Genesys Aerial Height Adjustable User manual

Before Assembly,
Please Read this Leaet
Components Fittings Kit
Top Panel x1A
Adjustable Legs x2B
Underframe x1C
H I
M6
Bolt
x 30
6x5/8
Screw
x 2
4mm Allen Key
or Hex Screwdriver
A
B
C
F
Frame Feet x2D
D
E
H-K
Pozi Screwdriver
Adjustable Foot x4E
Controller x1F
Cable Port x2G
C
G
J
Cable
Clips
x 4
K
Mounting
Plate
x 1
Assembly Instructions
Aerial
Height Adjustable
Tools Required
2 Person Assembly

1
1. Lay the Top Panel (A) on a at surface with the holes
exposed. Position the Adjustable Legs (B) into position as
shown above.
2a. Positions of M6 Bolts (H) marked ‘x’ on Underframe (C)
3
2a
2. Place the Underframe (C) over the Adjustable Legs (B).
Using Allen Key, screw 22x M6 Bolts (H) into the frame and
tighten.
3. Attach 2x Adjustable Feet (E) to the Frame Foot (D)
D
B
y
3a
3a. Using an Allen Key, screw 4x M6 Bolts through the Frame
Foot (D) into the Adjustable Legs (B) marked ‘y’. Repeat on the
other side.
A
B
B
B
B
C
x
x
x
x
x
x x
x
x
x
x
x
x
x
x
x
x
x x
x
x
x
Hx =
C
E
D
2
x

4
4. Screw 2x 6x5/8 Screws (I) through the Mounting Plate (K) to
the underside of the Top Panel (A) making sure the at edge is
closest to the front of the desk.
5
5. Peel and stick the Cable Clips (J) to the underside of the Top Panel. Above shows the recommended positions.
4a
4a. Attach the Controller (F) to the Mounting Plate (K).
A
J
F
A
J
6
6. With help, ip the table over and insert the Cable Ports (G)
G
