Genex GX9000 User manual

Genex Audio Inc
GX9000 User Manual

Table of Contents
Transport Controls ..................................................................................................................................7
Play......................................................................................................................................................7
Stop .....................................................................................................................................................7
Fast Forward and Fast Reverse..........................................................................................................7
±10 Seconds........................................................................................................................................7
Previous and Next...............................................................................................................................7
Jog.......................................................................................................................................................8
Shuttle..................................................................................................................................................8
Varispeed ............................................................................................................................................8
Front Panel Displays...............................................................................................................................9
Timecode Display................................................................................................................................9
Absolute vs. Relative Timecode in FAT32 Disk Format....................................................................10
Setting the Relative Reference Point ................................................................................................10
Absolute vs. Relative Timecode in Genex Disk Format....................................................................10
Time Remaining / Cue Point Display.................................................................................................11
Menu Operation ....................................................................................................................................12
Displaying and Navigating the Menu.................................................................................................12
Changing Menu Levels......................................................................................................................12
Changing the Value of a Menu Option..............................................................................................13
Working with Media...............................................................................................................................14
Blanking Plates..................................................................................................................................14
Hard Drives........................................................................................................................................14
Magneto-Optical and DVD Drives.....................................................................................................16
Tape Drives.......................................................................................................................................16
Configuring Storage Devices ................................................................................................................17
Formatting Media...............................................................................................................................21
Projects and File Handling (FAT32 Format Only).................................................................................22
How Do I Create a Project?...............................................................................................................22
How are Project Files Named?..........................................................................................................23
How to Locate Project Files on a Disk Volume.................................................................................23
Navigating Through Folders..............................................................................................................24
Opening an ADL Project or Audio File ..............................................................................................24
Large File Handling ...........................................................................................................................24
Delete Project....................................................................................................................................25
Setting the Date and Time.................................................................................................................26
Set the Date.......................................................................................................................................26
Set the Time......................................................................................................................................26

What Does an ADL Contain?............................................................................................................26
Audio.....................................................................................................................................................31
Audio Formats...................................................................................................................................31
Digital Clocks ........................................................................................................................................34
PCM and DSD...................................................................................................................................34
Genex Format....................................................................................................................................35
FAT32................................................................................................................................................35
Sample Rate Conversion...................................................................................................................36
Playback................................................................................................................................................39
Audio Playback..................................................................................................................................39
Genex File Format.............................................................................................................................39
AES31 Audio File ..............................................................................................................................39
DSDIFF Audio File.............................................................................................................................39
AES31-DSD Audio File......................................................................................................................39
Loop Playback...................................................................................................................................40
Locate Operations.............................................................................................................................40
Storing a Timecode in a Locate Memory...........................................................................................41
Using Headphones................................................................................................................................43
Audio Recording....................................................................................................................................45
Making Initial Recordings ..................................................................................................................45
Record Modes ...................................................................................................................................46
Punch In Recording...........................................................................................................................49
Rehearsal..........................................................................................................................................49
Setting the Pre-Roll and Post-Roll Times..........................................................................................49
Auto Punch........................................................................................................................................50
Timecode...............................................................................................................................................51
The Take Logging System....................................................................................................................55
Entering Cue Points...........................................................................................................................56
Presetting Cue Point Counters..........................................................................................................56
Metering and the Display ......................................................................................................................59
System ..................................................................................................................................................61
Upgrading the GX9000 with New Software ..........................................................................................63
Rear Panel Connections.......................................................................................................................65
RS422 Connector Pinout...................................................................................................................65
I/O Card 25 Way D' Type Pinouts .....................................................................................................66

GX9000 User Manual Rev 2.1 Transport Controls
Transport Controls
Genex Audio Inc Page 7
Play
Press the Play button to start forward play at x1 speed. The upper alphanumeric display shows the
current time-code.
Stop
Press the Stop button to cancel the current transport mode.
Fast Forward and Fast Reverse
The operator can use the Fast Forward and Fast Reverse buttons to emulate the locate functions of
a tape deck. Repeated pressing doubles the search speed up to a maximum x32 in either direction.
Fast Forward automatically stops at 24:00:00:00 and Fast Reverse automatically stops at
00:00:00:00. Pressing Play from either Fast Reverse or Fast Forward instantly puts the unit into Play.
Pressing Stop instantly stops the unit. Audio output is muted during Fast Forward and Fast Reverse.
The Fast Forward and Fast Reverse buttons are not disabled when in record; the unit will drop out of
record and start spooling.
±10 Seconds
Press the +10 button to advance the unit 10 seconds in the forward direction. Press the -10 button to
retard the playback position by 10 seconds. If the unit is stopped when either button is pressed the
unit is parked at the new timecode position. If the unit is in play when the buttons are pressed,
playback continues at the new timecode. The +10 and -10 buttons are disabled when in record.
Previous and Next
The Previous button moves the transport to the first cue point prior to the current location. The Next
button selects the next cue point ahead of the current location. If the unit is in Play when either button
is pressed, playback continues from the new location, otherwise the unit is parked at the new location.
The Next and Previous buttons are disabled when in record.

GX9000 User Manual Rev 2.1 Transport Controls
Genex Audio Inc Page 8
Jog
Press the Jog button to put the unit into Jog mode. The Jog LED will light to confirm the mode. In Jog
mode the Rotary Wheel can be used to move audio backwards and forwards in the same way as
moving a piece of tape across a magnetic head. The speed of playback is dependant on the speed of
the Rotary Wheel. To cancel Jog mode press any of the following buttons, Play, Stop, Fast
Forward, Fast Reverse, Jog, Shuttle, Varispeed, or perform a Locate operation. The Jog mode will
not currently operate in DSD mode.
Shuttle
Press the Shuttle button to enable Fast Forward or Fast Reverse in preset increments. The exact
speed is selected using the Rotary Wheel. The following options are available.
0 ±1.0 ±2.0 ±3.0 ±4.0 ±5.0 ±6.0 ±7.0 ±8.0 ±9.0
10.0 ±11.0 ±12.0 ±13.0 ±14.0 ±51.0 ±16.0 ±17.0 ±18.0 ±19.0
20.0 ±25.0 ±30.0 ±35.0 ±40.0 ±45.0 ±50.0
Turn the Rotary Wheel clockwise to select forward motion. Turn the Rotary Wheel counter clockwise
to select reverse motion. Playback automatically stops at 24:00:00:00 in the forward direction and
00:00:00:00 in the reverse direction. To cancel Shuttle mode press the Stop or Shuttle buttons. At
present, no audio is heard during shuttle.
Varispeed
The Varispeed range of the GX9000 is +/-24%. The rate can be adjusted in increments of 0.06%.
Press the Varispeed button to enable Varispeed mode. The Varispeed LED will light to confirm the
mode. Use the Rotary Wheel to select the desired rate. Pressing Record or pressing the Varispeed
button again will cancel Varispeed mode. Varispeed is currently only available on PCM rates below
50kHz

GX9000 User Manual Rev 2.1 Front Panel Displays
Front Panel Displays
Genex Audio Inc Page 9
The two alphanumeric displays provide information about the configuration of the unit as well as
timecode information relating to the currently selected project and media.
Timecode Display
In basic mode the upper alpha-numeric display shows timecode information. The source and format of
the timecode can be adjusted. Displaying frames is user selectable via the Setup menu. Press the
Timecode button to select the source for the Timecode display. The LED adjacent to the Timecode
button shows the selected Timecode source. The interpretation of ABS, REL and EXT is different
depending on the disk format of the selected volume.
Disk Format
Genex FAT32
ABS
Time elapsed since
00:00:00:00. The first cluster
of the disk corresponds to
00:00:00:00
Time elapsed since midnight
REL Time read from Timecode
track on disk. Time elapsed since previously stored relative origin
EXT Time read from external
Timecode input Time read from external Timecode input
Note that, when displaying timecode from an external source, this does not mean that external
timecode will be used as the timecode source for recording. Please see the Timecode section
regarding chasing to external timecode for record and playback.

GX9000 User Manual Rev 2.1 Front Panel DisplaysPanel Displays
Absolute vs. Relative Timecode in FAT32 Disk FormatAbsolute vs. Relative Timecode in FAT32 Disk Format
For a FAT32 formatted volume the absolute (ABS) timecode displayed is the timecode coming into or
being generated by the unit and is relative to midnight on a 24 hour timeline. The user can program a
significant point on the 24 hour timeline as a reference point so that all times are measured from that
reference point. In Relative (REL) mode all times, cue points, locates, etc. are marked relative to the
reference point.
For a FAT32 formatted volume the absolute (ABS) timecode displayed is the timecode coming into or
being generated by the unit and is relative to midnight on a 24 hour timeline. The user can program a
significant point on the 24 hour timeline as a reference point so that all times are measured from that
reference point. In Relative (REL) mode all times, cue points, locates, etc. are marked relative to the
reference point.
The diagram below illustrates the use of the Relative Reference point for an audio clip starting at
01:00:00:00 on the destination timeline.
The diagram below illustrates the use of the Relative Reference point for an audio clip starting at
01:00:00:00 on the destination timeline.
Genex Audio Inc Page 10Genex Audio Inc Page 10
Setting the Relative Reference PointSetting the Relative Reference Point
Press the Timecode Selector button until the REL LED is lit. Locate to the timecode required to be
the relative origin. Press and hold the -/Clear button while simultaneously pressing the Enter button to
mark the point. The display will now show 00:00:00:00.
Press the Timecode Selector button until the REL LED is lit. Locate to the timecode required to be
the relative origin. Press and hold the -/Clear button while simultaneously pressing the Enter button to
mark the point. The display will now show 00:00:00:00.
Absolute vs. Relative Timecode in Genex Disk FormatAbsolute vs. Relative Timecode in Genex Disk Format
The Genex disk format is a linear format where the current time is directly proportional to the physical
location of the audio on disk, much like a tape machine. Absolute time using this format is analogous
to a tape counter with 00:00:00:00 corresponding to the first cluster on the disk. The ABS timecode is
a measure of how far through the disk you are. The Genex format makes a provision for a timecode
track embedded as a sub-code in the recorded audio. The timecode track can be read using the REL
display.
The Genex disk format is a linear format where the current time is directly proportional to the physical
location of the audio on disk, much like a tape machine. Absolute time using this format is analogous
to a tape counter with 00:00:00:00 corresponding to the first cluster on the disk. The ABS timecode is
a measure of how far through the disk you are. The Genex format makes a provision for a timecode
track embedded as a sub-code in the recorded audio. The timecode track can be read using the REL
display.
Relative timecode is the timecode read from the timecode track on the disk or generated by the
internal timecode generator. If no timecode is recorded on disk the display reads --:--:--:--.
Relative timecode is the timecode read from the timecode track on the disk or generated by the
internal timecode generator. If no timecode is recorded on disk the display reads --:--:--:--.
Start of Audio Clip at
01:00:00:00
Start of Timeline
ABS Zero End of Audio Clip
ABS 00:00:00:00 ABS 01:05:00:00 ABS 02:00:00:00
REL --:--:--:-- REL 00:00:00:00
REL origin set to
zero here.
REL 00:55:00:00
ABS and REL Timecode Dis
p
la
y
s for a FAT32 Disk Format

GX9000 User Manual Rev 2.1 Front Panel Displays
Genex Audio Inc Page 11
Time Remaining / Cue Point Display
In basic mode, the lower alpha-numeric display selectively shows Disk Time Remaining or the current
Cue Point. Press the adjacent Selector button to alternate between the two displays. Disk Time
remaining is displayed in hours, minutes and seconds only; there are no displayed frames. The Time
Remaining display counting down at a similar rate to the timecode display counting up is a useful
verification that data is being recorded to disk properly.
Cue points are records of events that happened during a recording. An event could be music starting,
a wrong note, the start of a new page, a false start, etc. The GX9000 allows you to log each type of
event as it happens, as a cue point, so that you can quickly and easily find it again. See chapter 12 for
a more detailed description of The Take Logging System.

GX9000 User Manual Rev 2.1 Menu Operation
Menu Operation
Genex Audio Inc Page 12
Many of the features of the GX9000 are configured using the menu system accessible from the front
panel.
While the menu structure is being accessed the Transport, Chase and Monitoring buttons are
available as normal.
Displaying and Navigating the Menu
Press the Setup button to access the menu. The LED within the Setup button lights up to show that
the menu is being displayed.
Menu headings are shown in the upper alpha numeric display, parameters or values are shown in the
lower display. The menu is three layers deep and the current menu level is indicated by dots in the
upper left hand segment;
one dot indicates one level down
two dots indicates two levels down
The top level of the menu is a selection of functional groups arranged in alphabetic order, no values
are available at this level.
Select a heading/group in the current menu level using the Rotary Wheel.
Changing Menu Levels
To move up and down menu levels use the Parameter Up and Parameter Down buttons.One of the
available submenu headings will now be displayed in the upper alpha numeric display.
To display alternative headings at any menu level, use the Rotary Wheel [3].

GX9000 User Manual Rev 2.1 Menu Operation
Genex Audio Inc Page 13
Changing the Value of a Menu Option
To select each of the available values for a chosen menu heading use the Value Up and Value
Down[UV] buttons.
For some menu headings you can enter values using the numeric keypad.
Press the Enter button to confirm the change. The lower alpha-numeric display will momentarily
indicate 'STORED' if the operation was completed successfully.
