Genius EYE 310 User manual

English
-1-
Eye 310 Features
1 SnapShot Button
2 Lens
Adjust the focus by twisting the
lens.
3 LED Indicator
4 Swivel Base
Installing the Eye 310
1. Please install the driver first and then connect Eye 310 to
the USB port.
2. Installing the Eye 310 driver
a. Insert the Eye 310 Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
“Driver” then simply follow the on-screen instructions.
c. Install “DirectX”from the CD.
Notice: If theAutorun screen doesn’t start, please follow these steps:
zClick on “Start Menu”.
zType D：\SETUP.EXE , then click “Enter” key.
(Assume your CD-ROM is in Drive D)
3. Insert the Eye 310’s USB cable to your desktop’s or laptop’s
USB port.

English
-2-
4. Complete software and hardware installation. You can
install the software you would like for video
conferencing or chat with your friends.
NOTE
To remove the driver installation:
Please go to the taskbar and follow “Start” Æ“Program” Æ“Eye 310”Æ
Click “Uninstall”, then follow the on-screen instructions to remove the
driver.
Genius Application (Windows Only)
You can use our software to capture the real-time image, record or
execute the simply security function.
To run the software, please go to the task bar and follow “Start”Æ
Click “Program”ÆChoose “Eye 310”ÆClick “Eye 310”. Or you may
execute the software by simply clicking the shortcut of “Eye 310”.
NOTE
After installing the driver of Eye 310, the system will automatically create a
file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images you take
using the Genius Application.

English
-3-
1. Description for the major icon
Preview mode
Snapshot mode
Video Clip Mode
Security monitoring system
Exit the Genius UI
Camera Control
NOTE
In the “camera control section”, you can personalize your camera
settings for different circumstances.

English
-4-
1-You can flip the image horizontally or vertically by choosing “Image Mirror”
or “Image Flip”.
-When the light is not sufficient, you may click on “Low Light” to get a clear
image.
2You can adjust different values for different circumstances and environment
3When you want a still image capture, you can select a resolution size you want.
4You may adjust values toward image appearance. Before adjusting values, you
have to unclick “Auto” to unlock.
5-Press “Reset” to return to the manufacturer’s settings.
-Press “Restore” to return to the previous settings.
-Press “Save” to save the values you set up.

English
-5-
6Select the correct frequency according to the country where you are using the
web camera. (Before doing this, you will need to select “Indoor”.)
7For high quality image, please click the monitor type you are using with the
web camera
8-If your web camera is located in backlight position, you may click “Backlight
compensation” to get a sharper image.
-You can have a black-and-white photo effect by clicking on “B/W Mode”.
2. Preview Mode
You can use the function buttons on the control panel to zoom in/out and
move upward/downward/left/right.
Zoom in the image
Zoom out the image

English
-6-
Move the image upward
Move the image downward
Move the image to the left
Move the image to the right
Resolution Selection
There are 2 categories of resolution: RGB24 and
I420. You can select 5 different image resolutions for
each of them. The file size of I420 will be smaller than
RGB24. So, I420 may be the better choice for
transmission.
3. SnapShot Mode
You can press the Snapshot button in the right of the circle to take a
picture right away and share with your friends.

English
-7-
Send photo by e-mail
Shoot continuously
Resolution selection
This section shows the resolution you selected in
the “Preview Mode”. If you want to change the
resolution, please click “ ”to go back to the
“Preview Mode” to make the changes.
4. Video Clip Mode
You can record real-time image in this section.
Send photo by e-mail

English
-8-
Convert AVI files into MEPG-1 format
Start recording
Stop recording
Exit the Video Clip Mode
To Create animation
Press to start; Press to stop
Press to return to the video recording mode
This function has to be under the resolution of RGB24 320 x
240 or I420 320 x 240. Please make sure the resolution is
correct before executing this function.
Resolution selection
This section shows the resolution you selected in the “Preview
Mode”. If you want to change the resolution, please click
“”to go back to the “Preview Mode” to make the changes.
5. Security Monitoring S
T
monitor automatically. It can also record anytime until the HD is fu
there’s no movement, it will shut down automatically after four
seconds or otherwise it will be active when detecting new movem
It’s a great security monitoring system at times when you’re not
around.
ystem
his function records any movements that appear in front of your ll. If
ent.

English
-9-
Start recording
Stop recording
Setup time of the security monitoring system
Set up the degree of the variance for every encessecond of recording image. When the differ
are over the setup degree, the system will alert
you.
Set up the different alerting sound effects
NOTE
rity Monitoring System” section, you can record in any size ofIn “Secu
image resolution. If you want to change the resolution, please click
“”to go back to the “Preview Mode” and make the changes.

English
-10-

MSN Messenger, Yahoo Messenger, AOL
MSN Messenger ction, you’ll need MSN Messenger version 6 or later. Ifa. For live video fun
you don’t have it, please refer to the website:
http://www.msnmessenger-download.com to d
Now, get to sign onto MSN Messenger service.
ownload.
b.
” to confirm.
the web
c. Choose a friend on the contact list and Click “OK
d. Double-click on your friends, who are available to chat. Click on
camera icon .
Your friend w ll te. i hen receive an invitation message. When your friend
Ya senger essenger at http://messenger.yahoo.com
confirms to talk, the video chat will start.
hoo Mes
a. Download Yahoo M and finish the
b.
Tools menu, then select “Start My Webcam”.
e. will then receive an invitation message. When your friend
AOL Instant Messenger stant Messenger free at http://www.aim.com
registration, if you don’t have it.
Sign onto Yahoo Messenger.
c. From the main window, click
d. Right-click on a name in your Messenger List and choose “View
Webcam”.
Your friend
clicks YES, the video chat will start.
a. You can download AOL In
b.
nd choose the friend you want to start
and finish the registration, if you don’t have it.
Sign onto AOL Instant Messenger.
c. Click on “Show Messenger Lists” a
with video chat.

English
-11-
d. en receive an invitation message. When your friend Your friend will th
confirms to talk, the video chat will start.
NOTE
ake sure you already installed the camera driver and connected
e you close other webcam programs before running the
DPlayCam is an interactive multimedia software. It integrates the
DPlayCam includes two parts: DD ThemeParty and DD ThemeParty
ty
ayCam Software D-ROM drive. k on e
Please m
the camera to the computer before running video conferencing or video
chat programs.
Please make sur
video conferencing or video chat program.
D
DDPlayCam Software (Windows Only)
most advanced virtual interactive technology: facial recognition and
motion tracking, with cartoon characters, figures and amazing visual
effects. It allows you do a virtual role-play, interacting with a virtual
environment, morphing yourself into real time.
D
PrintCenter. DDPlayCam is for virtual role-play. DD ThemeParty
PrintCenter is for arranging the pictures you take in DD ThemePar
and printing them out.
1. Installing the DDPl
a. Insert the Eye 310 Installation CD into the C
b. The Autorun screen will bring up the installation screen. Clic
“DDPlayCam” then simply follow the on-screen instructions. Onc
finished, DD ThemeParty and DD PrintCenter are ready to go.

English
-12-
2. Running DD ThemeParty
a. Connect the web camera to the computer
b. Please go to the task bar and follow “Start”ÆClick “Program”Æ
Choose “DDPlayCam”ÆClick “DD ThemeParty”. Or you may
execute the software by simply clicking the shortcut of “DD
ThemeParty” .
DD ThemeParty Introduction
To run DD PlayCam DD Theme Party, you should set your
camera resolution to 320*240 and also check for your position before
the web camera. Please position your face around the center if possible.
Please note that if your camera resolution is not in 320*240, the
software will ask you to make the change. Please follow the on-screen
instructions to change the resolution to 320*240.
Tool Tip Function Description
About DD PlayCam Display DD PlayCam software version

English
-13-
Capture (Enter) Take a snapshot in process
Sequential Capture Take 12 snapshots as a GIF animation
DD PrintCenter Open DD PrintCenter application
Close Windows Exit application
Help Call help documentation
Minimize Windows Minimize skin
Mute Turn off audio
Technical Support Connect to technical support web service
View Photo View photo from captured pictures or animation.
3. Running DD PrintCenter
a. Connect the web camera into the computer
b. Please go to the task bar and follow “Start”ÆClick “Program”Æ
Choose “DDPlayCam”ÆClick “DD PrintCenter”. Or you may
execute the software by simply clicking the shortcut of “DD
PrintCenter” .
DD PrintCenter Introduction
DD PrintCenter lets you easily print digital photos by using a
variety of layout templates. Please note that as an indivisible part
of DD PlayCam software, this function allows you only to print
photos generated by DD PlayCam software and saved
automatically in the DD PlayCam folder within My Pictures.

English
-14-
a. Step 1: Select Paper Size and Layout or Load Document
DD PrintCenter provides you three standard paper sizes. They areA4,
4*6 and 3*5 inch styles.
Each paper size contains three types of layout templates. First, you
select a paper size and you can see three corresponding layout
templates on the right part of the window. Each layout template
shows you the actual size of a single photo and the number of photos
a single paper can print, such as 24 mm*18 mm. Select the layout by
directly clicking the template, and then click the Next button. Or
click Load button to open an existing DD PrintCenter document.

English
-15-
b. Step 2: Choose and Load Photo

English
-16-
You can see an empty layout template and thumbnail pictures that
you captured and saved in the DD PlayCam folder. Roll over any
pictures you want to print and drag it directly into an empty position
you would like to place it in the template. Or click an empty position
first and the frame of the position is marked immediately, double
click on the picture you want to print. You will see the picture you
have selected appear in that that position.
c. Step 3: Add, Delete and Save

English
-17-
If you want to print several copies from the same picture, you
do not have to repeat the steps for dragging. You only need to
select the target picture which you have already dragged into
template and click the “+” button. The picture will duplicate at
the next position automatically. One click, one duplication! If
you want to delete the picture that you have already dragged
into template, just select the target picture and click the -
button. On the other hand, if you want to save the whole
template with the selected pictures for printing next time or
elsewhere, just click on the “Save” button. The whole template
will be saved as a single JPEG file extension. In the save
combo box, you can select another file extension called PCF to
save the template layout you have edited as a DD PrintCenter

English
-18-
document. For the next time, you can use the Load button to
open the PCF file for further editing. You can also use Save as
a function to save a file as the format you indicated.
d. Step 4: Preview and Print
You can click the Preview button, then Print. However, please note
that DD PrintCenter does not provide functions for controlling or
adjusting any settings of your client printer device. We recommend
you should check your printer settings and the paper you have loaded
before printing.
NOTE
For further information about the DDPlayCam software, please go to the
task bar and follow “Start”ÆClick “Program”ÆChoose “DDPlayCam”
ÆYou can click “Click “DD ThemeParty Technical Support”; “DD
ThemeParty User Guide” or “DD ThemeParty Web Service” depends on
your requirement.

English
-19-
To remove the driver installation:
Please go to the taskbar and follow “Start” Æ“Program” ÆChoose
“DDPlayCam” ÆClick “DD ThemeParty Uninstallation”, then follow
the on-screen instructions to remove the driver.
