Genius ISLIM 2000AF User manual

English
i
Table of Contents
iSlim 2000AF Features 1
Installing the iSlim 2000AF 2-3
About Genius Application-WebCAM Mate 3
1. Main Menu 4-8
2. Picture Mode 9-11
3. Video Mode 12-13
4. Security Mode 13-16
Using MSN Messenger,Yahoo Messenger,AOL 17-18
CrazyTalk Avatar Creator 19-43
CrazyTalk CamSuite 44-70
Trouble shooting for web camera 71

English
-1-
Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries:
zThis product is designated for separate collection at an appropriate
collection point. Do not dispose of as household waste.
zFor more information, contact the retailer or the local authorities in charge
of waste management.
1.SnapShot Button
Press the snapshot button to take
images under WebCAM Mate.
2.IM Button
Press the IM button can connect
with MSN or Skype application.
3.Microphone
4. Auto Focus Lens
Auto focus will enable the lens to
5.LED Indicator
iSlim 2000AF is connected to the
computer's USB port and the LED
will light up when performing video
application.
6.Swivel and Clipping Base
The adjustable clipping base fits
easily to almost anything - notebook
panel, CRT, and LCD monitors.
iSlim 2000AF Features

English
-2-
iSlim 2000AF supports UVC (USB Video Class) which can plug and play
in Windows XP SP2, Vista or above OS without a device driver
installed.
1. Make sure your PC OS system is Windows XP SP2, Vista or above.
2. Position the webcam and connect the USB cable to an available
USB port on your computer. Windows automatically detects the
device.
3. Now iSlim 2000AF is ready for running with any application. The
web camera can work properly with any video chat software that
supports a video feature.
4. In Windows Vista:
You can use Genius application software to capture a real-time image,
record or execute the simple security function. The Snapshot function
will work in the Genius application software.
5. In Windows XP SP2:
a. Double-click the My Computer icon.
Alternatively, click Start →My Computer.
Installing the iSlim 2000AF

English
-3-
b. Select “USB Video Device” and double-click, and the video
appears on the screen automatically.
NOTE
To check if Windows XP system is SP2 (Service Pack 2).
−Click the My Computer icon on your desktop or in the Windows
Start menu.
−When the menu that appears, click Properties.
If your Windows XP system isn’t SP2 (Service Pack 2), go to the
website: http://microsoft.com to upgrade your version.
You can use Genius WebCAM Mate software to capture the
real-time image, record or execute the simple security function.
NOTE
After installing the Genius Application software, the system will
automatically create a file (C:\WINDOWS\Album or
C:\WINNT\Album)to save the images you take using the Genius
Application.
Genius application available in windows Vista/XP.
About Genius Application-WebCAM Mate

English
-4-
1. Main Menu
Item Mode Description
Picture Mode Still image capture mode.
Video Mode Video recording mode.
Security Mode Security monitoring mode.
Device
Selection Select different webcam device.

English
-5-
Item Mode Description
Resolution
Selection
Resolution selections according to
device.
YUY2: 1600 x 1200, 1280 x 960, 800 x
600, 640 x 480, 352 x 288, 320 x 240,
176 x 144, 160 x 120 pixels.
MJPG: 3360 x 2520, 1280 x 960, 800 x
600, 640 x 480, 352 x 288, 320 x 240,
176 x 144, 160 x 120 pixels.
Property page Preference setting to view your setting
and properties.
Exit Exit the Genius UI.

English
-6-
Property page
Property page allows user to adjust a person like property of the webcam.
-Video Proc Amp
Item Description
Brightness enables you to adjust the brightness of the displayed
image or video to suit your own preference.
Contrast enables you to control the ratio between dark and light
according to your own preference.

English
-7-
Item Description
Hue is any color in the rainbow that you choose to pick.
Saturation enables you to set the color reproduction from black
and white to a full color image or video according to your own
preference.
Sharpness can soften and sharpen images to achieve different
effects.
Gamma enables you to brighten dark areas within the displayed
image or video and visualize more details without over-exposing
already light areas.
You can adjust different values for different circumstances and
environment
Turn on the backlight compensation to improve the image quality
when you have a scene where the background has a high
illumination level (for instance when you are sitting in front of a
bright light).

English
-8-
-Camera control
Item Description
Enable Auto Focus function provides real-time sharp and clear
image quality. No matter how far you sit from the screen, you
always bring in focus. Use the slider to find manual focus setting.

English
-9-
2. Picture Mode
Take a picture right away and share with your friends.
Item Mode Description
Shot Still image capture mode.
Multi-Snapshot Capture continuous still images based
on multi-snapshot number.
Mail Send photo by email.

English
-10-
Item Mode Description
Adding Frame Select photo frame to add inside still
image. (*)
Tracking Face
Click this button, and the screen will
auto appear in the center of the frame.
When you are watching the display,
your face should appear in the acquired
image. In an auto stereoscopic display,
the image will auto digital zoom.
Rotate Rotate still image 45 degrees counter-
clockwise. (*)
Center Rotate still image to center. (*)
Rotate Rotate still image 45 degrees
anti-clockwise. (*)
Multi-shot
number Select multi-shot number from 2 to 10.
Full Screen
Mode
Display your web camera over the
entire screen. Press ESC to exit full
screen mode or click left mouse to
return to normal mode.
Refresh Refresh web camera.

English
-11-
Item Mode Description
Device
Delete File Delete the selected files.
Rotate Image Rotate the selected image file 90
degrees in title list display.
Email file Attach the selected image file to an
email.
Print Picture Print the selected image file.
Remark:
* This function must use the resolution of 640x480 or 320x240. Please make
sure the resolution is correct before executing this function.

English
-12-
3. Video Mode
You can record real-time video in this section.
Item Mode Description
Recording
Start/Stop
To begin recording video from your web
camera. Click to stop recording
video.

English
-13-
Item Mode Description
Audio Setting
Setting the audio device.
Recording
time display
Displays recording time.
“00:00:00” mean hours, minutes,
seconds.
4. Security Mode
Using motion detection function, it records any movements that appear
in front of your monitor automatically. It can also record anytime until
the HD is full. If there’s no movement, it will shut down automatically
after four seconds or otherwise it will be active when detecting new
movement.

English
-14-
Item Mode Description
Recording
Start/Stop
To begin recording monitor video from
your web camera. Click to stop
recording video.
Audio
Setting Setting the audio device.

English
-15-
Item Mode Description
Schedule
Recording
Set up time for the security monitoring
system.
Email Alert
When this button is enabled, it will send
out an email if an alert happens during
recording.

English
-16-
Item Mode Description
Sensitive
adjustable
Set up the degree of variance for every
second of recording video. When the
differences are over the setup degree,
the system will alert you.
Warning
sound
selection
Set up the different alerting sound
effects.
Recording
time
display
Displays monitor recording time.
“00:00:00” mean hours, minutes,
seconds.

English
-17-
MSN Messenger
a. For live video function, you’ll need MSN Messenger version 6 or
later. If you don’t have it, please refer to the website:
http://messenger.msn.com to download.
b. Sign onto MSN Messenger service.
c. Choose a friend on the contact list and Click “OK” to confirm.
d. Double-click on your friends, who are available to chat. Click on
the webcam icon.
e. Your friend will then receive an invitation message. When your
friend confirms to talk, the video chat will start.
f. For the further information, please refer to the website at
http://messenger.msn.com
Yahoo Messenger
a. Download Yahoo Messenger at http://messenger.yahoo.com and
finish the registration, if you don’t have it.
b. Sign onto Yahoo Messenger.
c. From the main window, click Tools menu, then select “Start My
Webcam”.
d. Right-click on a name in your Messenger List and choose “View
Webcam”.
e. Your friend will then receive an invitation message. When your
friend clicks YES, the video chat will start.
f. For the further information, please refer to the website at
http://messenger.yahoo.com
Using MSN Messenger, Yahoo Messenger, AOL

English
-18-
AOL Instant Messenger
a. You can download AOL Instant Messenger free at
http://www.aim.com and finish the registration, if you don’t have it.
b. Sign onto AOL Instant Messenger.
c. Click on “Show Messenger Lists” and choose the friend you want
to start with video chat.
d. Your friend will then receive an invitation message. When your
friend confirms to talk, the video chat will start.
e. For the further information, please refer to the website at
http://www.aim.com
NOTE
Please make sure you already connected the camera to the computer
before running video conferencing or video chat programs.
Please make sure you close other webcam programs before running
the video conferencing or video chat program.

English
-19-
Overview
CrazyTalk Avatar Creator is an innovative and easy-to-use software tool for
creating animated talking characters and digital hosts for video files and
greeting cards from your own photograph or digital image collection.
Animate any person, animal, or illustration with CrazyTalk Avatar Creator's
easy-to-use professional editing tools.
Your photos are brought to life in amazing animation by fitting them with
CrazyTalk Avatar Creator's proprietary Facetrix, facial morphing
technology.
CrazyTalk Avatar Creator's then gives a voice to your photos by allowing
them to lipsync with audio recordings and spoken text messages using the
exclusive Expressix speech animation technology.
Once your project is complete. CrazyTalk Avatar Creator offers all new
support for popular video editing and greeting cards.
You can send your talking messenger or card image in a variety of formats
including .cab, .mht file or an .AVI movie.
CrazyTalk Avatar Creator IntroductionCrazyTalk Avatar Creator Introduction
