GENTRON GG3500D User manual

EEI
IDwn_P's ManuaJ
www. GentronUSA. corn

Owner's Manual
A
Carbon G onoxi e
Using a generator indoors WiLL KiLL YOU iN MINUTES.
Carbon Monoxide
Generator exhaust contains high levels of carbon monoxide (CO), a poisonous
gas you cannot see or smell. If you can smell the generator exhaust, you are
breathing CO. But even If you cannot smell the exhaust, you could be breathing
CO.
• NEVER use a generator inside homes, garages, crawlspaces, or other partly
enclosed areas. Deadly levels of carbon monoxide can build up in these areas.
Using a fan or opening windows and doors does NOT supply enough fresh air.
•ONLY use a generator outdoors and far away from open windows, doors, and
vents. These openings can pull in generator exhaust.
Even when you use a generator correctly, CO may leak into the home. ALWAYS
use a battery-powered or battery-backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator has been running,
move to fresh air RIGHT AWAY. See a doctor. You could have carbon
monoxide poisoning.

Owner's Manual
Preface
Thankyoufor usingour generator.
This manualincludesthe operationand maintenanceof theGG3500D
Allinformation inthis publication isbasedonthelatestproductinformation availableatthetime ofapprovalfor printing.We
reservethe rightto makechangesatanytime without noticeandwithout incurringandobligation.Thecopyrightofthis manual
belongsto our company.Nopartsofthis publicationmay bereproducedwithout written permission.
Thismanualshouldbeconsidereda permanentpartof thegeneratorandshouldremainwith itif it isresold.
Payspecialattentionto statementsprecededbythefollowingwords:
WARNING
It indicatesastrong possibilityofseverepersonalinjuryor deathif instructionsarenotfollowed.
CAUTION
It indicatesastrong possibilityofseverepersonalinjuryor deathif instructionisnot followed.
If aproblemshouldarise,or if youhaveanyquestionsaboutthe generator,consultanauthorizeddealer.
BECAREFUL
Thegeneratorisdesignedto givesafeanddependableserviceif operatedaccordingto instructions,readand understand
the Owner'smanualbeforeoperatingthegenerator.Failureto doso couldresultin personalinjuryor equipmentdamage.

Owner's Manual
Safety Instruction
/_ WARNING!
Thegeneratorisdesignedto givesafeanddependableserviceif operatedaccordingto instructions.
Readand understandthis manualcarefullybeforeoperatingthegeneratoror itmaycauseserious
injuryandequipmentdamage.
//_ WARNING!
Exhaustcontainspoisonouscarbonmonoxide.Do notoperategeneratorin confinedenvironmentor
with anaerator.Onlyuseoutdoors andfar from openwindows doorsandvents.
/_ WARNING!
Themufflerbecomesveryhot during operationand remainshot for awhileafterstoppingthe engine.
Becarefulnot to touchthe mufflerwhile it ishot.Letthe enginecool beforestoringthegenerator
indoor.Theengineexhaustsystemwill beheatedduring operationandremainshot immediatelyafter
stoppingtheengine.To preventscalding,paymoreattentionto thewaming marksattachedto the
generator.
/_ BECAREFUL!
Donotparallelconnectothercablesto receptacles,usespecialjack,or it maycauseanelectrical
shock.

Owner's Manual
Safety Instruction
WARNING!
•Gasolineisextremelyflammableandis explosiveundercertainconditions.Refuelinaventilatedareawith enginestopped.
• Keepawayfrom cigarette,smokeandsparkswhen refuelingthegenerator.Alwaysrefuelin awellwentilatedlocation.
WARNING!
•Connectionfor standbypowerto abuildingelectricalsystemmust bemadeby aqualifiedelectrician.Theconnection must
isolatethegeneratorfrom utilitypower,and must complywith all applicablelawsandelectricalcodes.Improperconnections
to a buildingelectricalsystemcanallowelectricalcurrentfrom thegeneratorto backfeedintotheutilitylines. Suchbackfeed
mayelectrocuteutility companyworkers orotherswho contactlinesduring apoweroutageandthe generatormayexplode,
or causefireswhen utility powerisrestored.
WARNING!
To avoidaccidentsandequipmentdamage,checkgeneratorsystemeverytime beforestartingengine.
• Keepthegeneratoradistanceof atleast1meterfrom otherequipmentduring operation.
• Keepthegeneratorhorizontalwhen running.If generatortilts, it maycausefuel spillage.
• Generatoroperatorsmust betrained,must know howto stopthe generatorquicklyandunderstandtheoperationof all
controllableparts.Untrainedoperatorsshouldnotbeallowedto usethisequipment.
• Keepchildrenandpetawayfrom operationarea.
• Keepawayfrom rotatingpartsduringoperation.
• Thegeneratorisa potentialsourceof electricalshockwhen misused.Do notoperateitwith wet handsor in anywet location.
Donot operatethegeneratorin rainor snow.Do not allowunit togetwet.

Owner's Manual
Content
1.COMPONENTIDENTIFICATION 6
2.SAFETYINSTRUCTIONS 6
3.SAFETYLABELLOCATIONS 7
4.PRE-OPERATIONCHECK
4.1Checkthe engineoillevel
4.2Checkthe fuellevel
4.3Checkthe aircleaner
8
8
8
9
5.GENERATORUSE
5.1Startingthe engine
5.2Highaltitudeoperation
5.3Generatoruse
5.4ACapplications
5.5OutputandOverloadindicators
5.6DOapplications
5.7Startthe engine
5.8Oilalarmsystem
5.9Stoptheengine
6.MAINTENANCE
6.1Changingoil
6.2Aircleanerservice
6.3Sparkplug service
6.4Sparkarresterservice
7.TRANSPORTATIONANDSTORAGE
7.1Whentransportinggeneratorsets
7.2 Beforestoringtheunitsfor anextendedperiod
10
10
11
12
12
13
14
16
16
16
18
19
21
21
23
24
24
24
8.TROUBLESHOOTING 25
9.TECHNICALDATA 27
9.1Sizeandweight 27
9.2Engine 27
9.3Generator 27
10.Wiring diagram 28
11.Partsdiagram 29
12Partslist 30

Owner's Manual
Digital Inverter Generator
WARNING!
Readthis manualcarefullybeforeusingthemachine,for your own safety.
1COMPONENTIDENTIFICATION
1.Fuelcap
2.Air ventknob
3. Chokeknob
4. Controlpanel
5. Startinggrip
6. Fuelvalvegrip
7. Maintenancecovers
8.ACsocket
9.Overloadindicatorlight
10.Outputindicatorlight
11.Oilalertindicatorlight
12.Ecothrottleswitch
13.Engineswitch
14.DCsocket
15.DOcircuitbreaker
16.Groundingterminal
Fuelleveldisp
Starting grip

Owner's Manual
Control panel
DO circuit breaker
Eco throttle switch 'X ,:.k, Output indicator light
O_ Oil ale_ indicator light
AC socket
-- Grounding terminal
DC socket Engine switch
SMARTTHROTTLE
Enginespeediskeptat idleautomaticallywhen the electricalapplianceisdisconnectedandit retumsto the properspeedto
power ofthe electricalloadwhen electricalapplianceisconnected.Thispositionisrecommendedto minimizethefuel
consumption while in operation.
2. SAFETYINSTRUCTIONS.
• Thegeneratorisdesignedto givesafeanddependableserviceifoperatedaccordingtoinstructions..
• Readand understandtheOwner'sManualbeforeoperatingthe generator.Failureto do socould resultin personalinjuryor
equipmentdamage.
• Exhaustgascontainspoisonouscarton monoxide.Neverrun thegeneratorin anenclosedarea.Besureto provideadequate
ventilation.
• Themufflerbecomesvery hot duringoperationandremainshotfor awhileafterstoppingthe engine.Becarefulnot totouch
the mufflerwhile it is hot. Lettheenginecoolbeforestoringthegeneratorindoors.
• Theengineexhaustsystemwill beheatedduring operationandremainshot immediatelyafterstoppingtheengine.Toprevent
scalding,payattentionto thewaming marks.
• Gasolineisextremelyflammableandexplosiveundercertainconditions.Refuelin awell-ventilatedareawith the enginestopped.
• Keepawayfrom cigarettesmokeandsparkswhenre-fuelingthegenerator,Alwaysrefuelinawellventilatedlocation.
• Wipe upspilledgasolineatonce.
• Connectionsfor standbypowerto a building'selectricalsystemmust bemadebyaqualifiedelectricianandmust complywith all
applicablelawsandelectricalcodes.Improperconnectionscanallowelectricalcurrentfrom thegeneratorto backfeedintothe
utilitylines.

Owner's Manual
3. SAFETYLABELLOCATIONS
Theselabelswam youfor potentialhazardsthat cancauseseriousinjury.Readthe labelsandsafetynotesandprecautions
describedinthemanualcarefully.Ifa labelcomesoff or becomeshardto read,contactyourdealerfor areplacement.
_:be!

Owner's Manual
_lf theoil levelis belowtheendof thedipstick,refilltherecommendedoil upto thetop ofthe oilfiler neck.
TheOilAlertSystemwill automaticallystopthe enginebeforethe oil levelfalls belowthesafelimit. However,to avoidthe
inconvenienceofanunexpectedshutdown,it isstilladvisableto visuallyinspectthe oil levelregularly.
4.1 Checkengineoil level
iU__lowed
Oil fi[|er hole
4.2 Checkthefuellevel
Tightenthefuelcapbeforetransporting.
Useautomotivefuel(Unleadedor lowleadedispreferredto minimizecombustionchamberdeposits).
!! Don'tusefuel-containingalcohol:Fuelsystemdamageor engineperformanceproblemsresultingfrom theuseof fuelsthat
containalcoholarenot coveredunderthewarranty.

Owner's Manual
Fue! _evel disp|ay
Neveruseanoil/gasolinemixtureor dirty gasoline.
Avoid gettingdirt, dustor waterin thefueltank.
Afterrefueling,tightenthefuelfiller capsecurely.
Gasolineisextremelyflammableand isexplosiveundercertainconditions.
Refuelin awell=ventilatedareawith theenginestopped.
Do notsmokeor allowflamesor sparksinthe areawheretheengineisrefueledor wheregasolineis stored.
Do notoverfillthefuel tank.After refueling,makesurethetank capis closedproperlyandsecurely.
Becarefulnotto spillfuelwhenrefueling.Spilledfuelorfuelvapor mayignite.If anyfuelisspilled,makesuretheareaisdry
beforestartingthe engine.
Avoidrepeatedor prolongedcontactwith skinor breathing ofvapor.KEEPOUTOFREACHOFCHILDREN
4.3Checkthe aircleaner.
Checktheaircleanerelementto besureit iscleanandin goodcondition.
1.Loosenthe coverscrewandremovetheleftsidemaintenancecover.
2.Pressthe latchtabonthe top ofthe aircleanerbody,removethe aircleanercartridge,andchecktheelement.
3.Cleanor replacetheelementif necessary.
Neverrunthe enginewithout theaircleaner.Rapidenginewearwill resultfrom contaminants.Suchasdust anddirt, being
drawn through the carburetor, into the engine.
It isnormalfor a littleoilto appearundertheairfilterboxif thegeneratoris runningfor a long periodof time,or alot ofoil isinthe
engine.Wipeupexcessoil aftereachuseandafterstoppingthegenerator.

Owner's Manual
5.GENERATORUSE
5.1Startingthe engine
Beforestartingtheengine,disconnectanyloadfrom the DCreceptacle.
1)Turnthefuelvalveto "ON" position.
SL#n _he _Ue_
1_ _ON _
2) Putthe electricstartkeyintothe engineswitch,andturn it tothe "ON" position.
3) Tumtheelectdcstartkeyto "START"positionuntiltheenginehas
started.

Owner's Manual
Thefirst time youstartthe engine,or restartthe engineafteralongperiodoftime using theelectricstartandiftheenginedoesnot
start.Checkthebattery.Thebatterymight bedrained.Youcanstartthegeneratorusingthe manualpullstart.
Usingthe recoilstart
1)Turnthefuelvalveto the"ON" position.
2)Putthe electricstartkeyintothe engineswitch,andturn it tothe "ON" position.
3) Pullthe startinggrip lightly untilresistanceisfelt,then pullbackbrisklyto startthe engine
.<,. ............
.............[%&,,
/_' _ _::l ::'-_'..........................
.........................:::2,IL....
5.2Highaltitudeoperation
At highaltitude,thestandardcarburetorair-fuel mixturewill beexcessivelyrich.
Performancewill decrease,andfuelconsumption will increase.
Evenwith suitablecarburetorjetting,enginehorsepowerwill decreaseapproximately3.5% for each300m (1,000feet)increasein
altitude.

Owner's Manual
_ Operationofthegeneratorat loweraltitudethanthecarburetorisjettedfor mayresultinreducedperformance,
overheating,andseriousenginedamagecausedbyan excessivelyleanair/fuelmixture.
5.3Generatoruse
5.3.1WARNING!
•To preventelectricalshockfrom faulty appliances,thegeneratorshouldbegrounded. Connectanelectricconductor (cable)of
atleast1.5mmto 2mm betweenthegenerator'sgroundterminalandanextemalground source.
• Connectionsfor standbypowerto a building'selectricalsystemmust bemadebyaqualifiedelectricianandmust complywith all
applicablelawsandelectricalcodes.Improperconnectionscanallowelectricalcurrentfrom thegeneratorto backfeedintothe
utilitylines.Suchbackfeedcancausedamageor evenelectrocuteonceutilitypoweris restored.
• Donot exceedthe currentlimit specifiedfor any onereceptacle
• Donot connectthe generatorto a householdcircuit. This couldcausedamageto thegeneratororto electricalappliancesin
thehouse.
• Donot modifyor usethe generatorfor other purposethanit is intendedfor. Alsoobservethefollowingwhen usingthe generator.
• Donot connectgeneratorsin parallel.--Do not connectanextensionto exhaustpipe.
Whenanextensioncableisrequired,besureto usea shieldedflexiblecable,
Limitlengthofextensioncables;60mfor cablesof 1.5mm2 and100mfor cablesof 2.5mm2.
Keepthegeneratorawayfrom otherelectriccablesor wiressuchasdistributionnetwork.
TheDCreceptaclecan beusedwhiletheAC powerisin use.Ifyou usebothatthe sametime,besurenotto exceedthetotal
powerfor ACand DO.
Most appliancemotors requiremorethantheir ratedwattagefor start-up.
5.4ACapplications
1.Startthe engineandmakesuretheoutput indicatorlight(green)illuminates.
2.Confirmthatthe applianceto beusedisswitchedoff, andplug intheappliance.
Ovedoad _ndP_or Out,put _r
Substantialoverloadingthatcontinuously lightsthe overloadindicatorlight(red)maydamagethegenerator.Marginaloverloading
thattemporarilylightstheoverloadindicatorlight (red)mayshortenthe servicelifeofthegenerator.
Besurethat allappliancesarein goodworking orderbeforeconnectingthemto thegenerator,ifanappliancebeginsto operate
abnormally, becomessluggish,or stopssuddenly,tum off thegeneratorengineswitch immediately.Thendisconnectthe
appliance,andexamineitfor signsof malfunction.

Owner's Manual
5.5OutputandOverloadindicators.
Theoutputindicatorlight(green)will remainlightedduring normaloperatingconditions.
If thegeneratorisoverloadedor if thereisashort inthe connectedappliance,the output indicatorlight (green)will go OFF,the
overloadindicatorlight(red)will goONandcurrentto the connectedappliancewill beshut off.
Stoptheengineiftheoverloadindicatorlight (red)switchesONandinvestigatetheoverloadsource.
_, Beforeconnecting anappliancetothe generator,checkthatit isingood order,andthat itselectricalratingdoesnot exceed
that ofthe generator.Thenconnectthepowercordof theappliance,andstartthe engine.
Besureallequipmentistumed off beforeplugginginthe powercord.
_edoa_ indicator (red)
,Output indicator (green)
Whenan electricmotor is started,boththeoverloadindicatorlights(red)andthe output indicatorlight(green) maygo on
simultaneously.Thisis normaliftheoverloadindicatorlight (red)goesoffafteraboutfour seconds.
If theoverloadindicatorlight(red)stayson, consultyour dealer.
Connectthe groundterminal.
Startengineaccordingto"STARTINGTHEENGINE"section.

Owner's Manual
_When theoutput indicatorlight(green)doesnot lightandtheoverloadindicatorlight(red) lightsinstead,setthe engine
switchto STOP,stop theengineatonceandthenstarttheengineagain.
3.Confirmthatthe equipmentto beusedisswitchedoff,andinsertthe plugof theequipmentto beusedintotheACreceptacle
unitA.
_ Checkthattheequipmenttobeconnectedisswitchoff. Whenthe equipmentto be usedis switchedon, it will operate
suddenly,andinjuriesor accidentsmaybecaused.
4. Switchon the equipment,output indicatorlightwill beON.Incaseof overloadoperationor whentrouble occursfor the
equipmentbeingused,theoutput indicatorlight(green)will goout,theoverloadindicatorlight(red)will lightcontinuously, and
nopowerwill beputout.Atthis time,the enginewillnotstop,so thattheenginemust bestoppedbysettingthe respectiveengine
switchto STOP.
_When equipmentrequiresa largestartingpower,the overloadindicatorlights(red)andtheoutput indicatorlight(green)
maylighttogetherfor ashorttime, butthis is noabnormality.Afterstartof the equipment,theoverloadindicatorlight (red)will go
out andthe output indicatorlight (green)will staylit.
AC
Powerfactor
GG3500D
Electriclamps Powertools Electromotor DCbattery
1 0.8-0.9 0.4-0.7(efficiency0.86)
0-3000W 0-2400W 0-1800w Ratedvoltage12v
Ratedcurrent6A(Canada)
8.3A(exceptCanada)
5.6DOapplications
Forcharging12Vautomotivebatteries:
Thegeneratorcannotsenseasensibilityloadwith thesamepower,whichthe manualindicates.Itonlycansense40%-70%
power,which themanualindicates.

Owner's Manual
Loadingvoltage(V) Loadingvoltage(V) Loadingcurrent(A)
Openingthesmartthrottle 22 12 6
Closingthesmart throttle 27 13 8.5
DOMax.Outputpower 37 13.5 8.5
Thegeneratorcannotsenseasensibilityloadwith thesamepowerwhich the manualindicates°£It onlycansense40%-70%
powerwhich the manualindicates.
Example:
Model
Generatorratedoutput
Frequency Powerfactor
1.0
0.4-0.75
DO
GG3500D
3.0KVA
3500W
0-1400W~-2625W
100W(12V/8.3A)
•When usingthe DCoutput,tum SmartThrottleto theOFFposition.TheDCcurrent will bebelow5A if tuming onthe Smart
ThrottlewithoutACcurrentoutput.
•Whenchargingbatteries,personmust bepresentto monitor thevoltage.Stopchargingwhenthe voltageof thebatteriesis
above16V.Or itmaycause batteryexplosion,resultinginseriousinjuryordeath.
*To preventthepossibilityof creatingasparknearthebattery,connectchargingcablefirst tothe generator,thento the battery.
Disconnectcablefirst atthebattery.
. Beforeconnectingchargingcablesto a batterythat isinstalledina vehicle,disconnectthevehiclesgroundedbatterycable.
Reconnectthevehicle'sgroundedbatterycableafterthe chargingcablesareremoved.Thisprocedurewill preventthepossibility
of shortcircuitandsparksifyoumakeaccidentalcontactbetweena batteryterminalandthe vehicle'sframeor body.
. Donot attemptto startanautomobileenginewhilethegeneratorstill connectedto the battery.Thegeneratormaybedamaged.
. Connectthepositivebatteryterminaltothe positivechargingcord. Donot reversethechargingcables,orseriousdamageto the
generatorand/orthe batterymayoccur.
. Thebatterygivesoff explosivegases;Keepspark,flamesandcigarettesaway.Provideadequateventilationwhen charging.
. Thebatterycontainsacid(electrolyte).Contactwith skin or eyesmaycauseseverebums.Wearprotectiveclothingand
afaceshield.
If batteryacidgetsonyour skin,flushwith water.
If batteryacidgetsin youreyes,flush with waterfor at least15minutesandcalla physician.
If swallowed,drink largequantitiesof wateror milkandfollow with milkof magnesiaor vegetableoil andcalla physician.
. KEEPOUTOFTHEREACHOFCHILDREN,PETSANDUNTRAINEDPEOPLE.

Owner's Manual
5.7Startthe engine
•TheDCreceptaclemaybeusedwhilethe ACpowerisin use.
•An overloadedDCcircuit will trip theDCcircuit protector.Ifthis happens,disconnectthe DCloadbeforeresetingcircuit
protectorto resumeoperation.
OC circuit breaker
5.8Oilalertsystem
•Theoil alertsystemis designedto preventenginedamagecausedbyinsufficientamountof oilin alertsystemwill
automaticallyshut down theengine(theengineswitchwill remainin theONposition).
• Ifthe oil alertsystemshutsdownthe engine,theoil alertindicatorlight (red)will comeonwhen youoperatethestarter,andthe
enginewill notrun.Ifthis occurs,addengineoil.
Oil alarm indicator (r_)
5.9Stoppingthe engine
To stopthe enginein anemergency,tum theengineswitchto theOFFposition.
In normaluse:
1.Switchoff the connectedequipmentandpullthe insertedplugout.

Owner's Manual
2.Tum theengineswitch to theOFFposition
//
Eie_r;ic stad key
3.Turnthefuelvalveto "OFF"position.
T_rt_ the {_
va|ve kl_Ob
the OFF
posiUOn.
Besuretotightenthe fuelcapandtheengineswitch is inthe "OFF"position
whenstopping, transportingand/orstoringthegenerator.

Owner's Manual
6 MAINTENANCE
•Thepurposeofthe maintenanceandadjustmentscheduleisto keepthegeneratorinthe bestoperatingcondition.
• Inspector serviceasscheduledinthe tablebelow.
Shutoffthe enginebeforeperforminganymaintenance,If theenginemust berunning,makesurethe areaiswell
ventilated.Theexhaustcontainspoisonouscarbonmonoxidegas.
Useauthorizedpartsor theirequivalent.Theuseof replacementpartswhicharenot of equivalentqualitymaydamage
thegenerator.
Maintenanceschedule
Sparkplug
Combustionchamber
Valveclearance
Fueltankandfiltertank
Fuelline
Check
Replace
Check
Replace
Clean&
Adjust
Clean
Check&
Adjust
Clean
Eachmonth Each3 months Each6 months Eachyear
Eachuse or 20Hrs. or 50Hrs. or 100 Hrs. or 200
Hr_
Check Every2 years(replaceifnecessaryas(3)
NOTE:(1)Log hours ofoperationto determineproper maintenance.
