GEOSATpro DSR200c Troubleshooting guide

This manual contains operation and installation instructions for
the GEOSATpro DSR200c standard satellite receiver and the
GEOSATpro DVR1100c satellite receiver with digital video
recording capability.
The basic operation of both models are identical, but the DVR1100c
offers several digital recording features that are not found on the
basic DSR200c receive only model. The additional features of the
DVR1100c are noted in the menu features and operation guides.
DSR200c - Standard Receiver
DVR1100c - Digital Video Recorder Ready
Owners Manual
Installation Guide
Version 2010.07

www.geosatpro.com Toll Free 888-483-4673
1
DTV Transition Notice
After June 12th, 2009, a television receiver with only an analog broadcast tuner will
require a converter box to receive full power over-the-air broadcasts originating from a
United States broadcaster with an antenna because of the Nation’s transition to digital
broadcasting. Analog-only TVs should continue to work as before to receive low power,
Class A or translator television stations, cable, satellite TV services, gaming consoles,
VCRs, DVD players, and similar products.
Information about the DTV transition is available from www.DTV.gov or 1-888-CALL-
FCC, and from www.dtv2009.gov or 1-888-DTV-2009 for information about subsidized
coupons for digital-to-analog converter boxes.
This notice does not affect any programming received by this satellite set-top box. Your
digital satellite receiver will continue to receive the digital satellite signals and provide the
programming for display on both Analog Televisions and new DTV compatible monitors
with composite, Component YUV or S-Video input connections.
This notice complies with Parts 15 and 54 of Title 47 of the Code of Federal Regulations:
15.124 DTV Transition Notices by Manufacturers of Televisions and Related Devices.
Important Installation Notice: The Federal Communications
Commission (FCC) has ruled that local government zoning and
homeowner’s associations may not prevent the installation of
satellite antennas one meter (39”) or smaller in diameter within
a resident’s private use area, unless legitimate safety restrictions
such as re codes are in effect.
For More information: http://www.fcc.gov/cgb/satellite.html
Materials contained in this installation manual are the property of:
Satellite AV, LLC.
8801 Washington Blvd., Suite 101
Roseville, CA 95678
http://www.satelliteav.com ©2009 Satellite AV, LLC
Attention Glorystar Customers:
Please review the Glorystar instructions beginning on page 29
Note: Save all original boxes, manuals, accessories and packaging
materials in case it is necessary to return the merchandise.
Before unpacking or assembly of any item, review the warranty,
exchange and refund policies provided by your reseller.

B. Gohl © GEOSATpro
2
Page
Important Safeguards 3
DSR200c / DVR1100c Specications 5
Receiver Front / Rear Panel 6
Remote Control Layout 8
Basic Remote Operation 10
Receiver Operation Guide 11
Receiver Menu Items 15
DVR1100c Operation 25
Glorystar Installation Guide
Parts List 30
Site Survey 31
Dish Mounting Options 34
Dish Assembly 35
Universal Post Mount Assembly and Install 38
LNBF Bracket Assembly 39
Dish Aiming 42
Connect Receiver to a TV 44
Receiver Connection Examples 45
Activating the Glorystar Receiver 46
Locate and Peak Satellite Signal 48
Switch Installation - Single Room 50
LNBF Adjustments - (optional) 51
Updating Receiver and Channel List 52
Using Satellite Meters 57
Completing the Install and Grounding 58
FAQ - Frequently Asked Questions 59
Accessories 61
Satellite Elevation Finder 62
Table of Contents
29
Advanced / Hobbyist Installation 54

www.geosatpro.com Toll Free 888-483-4673
3
Important Safeguards

B. Gohl © GEOSATpro
4
Replacement Parts When replacement parts are required, be
sure the service technician has used replacement parts specied by
the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock,
or other hazards. Modication to the hardware or software without
authorization by the manufacturer the will result in voiding any
warranty. Service assistance may be arranged by contacting your
reseller.
Safety Check Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
NEC, ANSI/NFPA 70
Example of Antenna Grounding

www.geosatpro.com Toll Free 888-483-4673
5
DSR200c / DVR1100c Specications
MPEG Transport Stream & AV Decoding
Transport Stream MPEG-2 ISOIIEC 13818 / Transport Stream Specification
Profile Level MPEG-2 MP@ML
Input Rate Max. 90 MbiU
Video Resolution 720 x 480 (NTSC)
Audio Decoding MPEG / Musicam Layer I & II
Audio Mode Single channel / Dual channel Joint Stereo / Stereo
Teletext VBI & OSD / Closed Captioning pass through, EIA-608 compliant
Sampling Rate 32, 44.1 and 48KHz
Conditional Access Module Interface
SMART CARD 1 SLOT, ISO 7816, GSM11.11 and EMV (payment systems) compatibility
Tuner & Channel
Input Connector F-type (Output loop-through), IEC 169-24, Female
Signal Level -25 to -65 dBm
LNB Power / Polarization Vertical: +13.5 ±5
Horizontal: +18.5Vdc ±5% Current : Max. 500mA. Overload protected
22KHz Tone Frequency: 22KHz ±2KHz
DiSEqC Control Amplitude: 0.8 ±0.2V Version 1.0, 1.1, 1.2, USALS Compatible
Demodulation QPSK
Input Symbol Rate 2-45 Ms/s Convolution Code Rate 112, 2/3, 3/4, 5/6, 7/8 with Constraint Length K=7
AV & Data Input/Output
RCA Output CVBS (Yellow), L, R Output (White, Red) w/Volume, YUV Component, S-VHS (Y/C) Video
SPDIF Dolby Digital Bitstream Out (Optical)
Data Interface RS-232, Transfer rate 115Kbps, 9 pin D-Sub Male Type
USB: USB 2.0, Type A Connector 5V 1500mA / DVR1100c - Digital Video Record Function
RF Modulator
TV Standard NTSC
RF Connector 75 Ohms, F-type, Loop - through
Frequency Range VHF - CH3, CH4
System Resources
Main Processor ARM946 RiscProcessor
Flash Memory 4 Mbyte
Program DRAM DSR200c - 16 Mbyte
DVR1100c - 32 Mbyte
Channel Capacity Digital Channel: 5,000
Front VFD Display (3 Icon, 5 digit Alphanumeric)
Power Supply
Input Voltage AC 90 to 240V, 50 - 60Hz
Power Consumption Max. 30W
Protection Separate Internal Fuse
Type SMPS
Physical Specification
Size (W x H x D) DSR200c - 260 x 50 x 210mm
DVR1100c - 290 x 50 x 220mm
Net Weight 2.0Kg

B. Gohl © GEOSATpro
6
Power Switch the receiver between Standby and Operation mode
Increase or Decrease the Volume
Change Channel Up / Down
Connects USB memory device for Firmware / Channel List upgrade
CAS Slot - Subscription card insertion with foil contacts facing down
DSR200c
Front Panel
Power Switch the receiver between Standby and Operation mode
Display the Main Menu screens
Display the Channel List or enter an item in a menu
Change Channel Up / Down or move the cursor within a Menu
Increase or Decrease the Volume or move the cursor within a Menu
CAS Slot - Subscription card insertion with foil contacts facing up
DVR1100c
Front Panel
1
2
3
4
5
1
2
3
4
5
6

www.geosatpro.com Toll Free 888-483-4673
7
Connects to the satellite dish coax cable
Loops the satellite signal to another satellite receiver
Connects composite VIDEO to TV or other equipment
Connects AUDIO Left / Right channels to TV or other equipment
Connects Component Video YUV to TV
Connects Optical Digital Audio to a digital audio amplier
Connects S-VHS (Y/C) video to TV or other equipment
Connects to television antenna input (tune TV to channel 3 or 4)
Connects to an outdoor TV antenna or cable
Null Modem RS232 type computer connection for upgrade or repair
Connects USB 2.0 memory device for DVR / multi-media / upgrade of
Firmware or Channel List 5V/500ma (DVR1100c Model only)
AC power plug connection (90 - 250VAC / 60Hz, 30W)
Master Power Switch disconnects receiver from external power
Rear Panel
1
2
3
4
5
6
7
8
9
10
11
12
13
The GEOSATpro DSR200c & DVR1100c digital satellite
receivers are Glorystar Approved.

B. Gohl © GEOSATpro
8
Remote Control Unit
