Ganz DIGIMASTER SERIES User manual

DIGIMASTER SERIES DVR
4 / 8 / 16 Channel Stand-Alone
DIGITAL VIDEO RECORDER
USER’S MANUAL

1
•INDEX
• CHAPTER 1. Specifications & System Organization
1. Specifications ------------------------------------------------------------ 3
2. Product Contents List -------------------------------------------------------- 5
3. System Organization --------------------------------------------------------- 6
•CHAPTER 2. Product Description
1. Front Panel(8&16CH) -------------------------------------------------------- 7
2. Rear Panel(8&16CH) --------------------------------------------------------- 8
3. Front Panel(4CH) ----------------------------------------------------------- 9
4. Rear Panel(4CH) ---------------------------------------------------------- 10
5. Remote Controller ------------------------------------------------------- 11
• CHAPTER 3. Display
1. System Power ON ---------------------------------------------------------- 12
2. Live View Display Mode Selection --------------------------------------------- 13
3.Display Mode ------------------------------------------------ 13
4. PTZ/FOCUS Control -------------------------------------------------------- 14
5. System Power OFF --------------------------------------------------------- 14
• CHAPTER 4. Search
⊙ Go to Search Mode --------------------------------------------------------- 15
1. Search by Time ----------------------------------------------------------- 15
2. Search by Event ----------------------------------------------------------- 16

2
•INDEX
• CHAPTER 5. MENU
⊙ Go to Menu -------------------------------------------------------------- 17
⊙ Go to System Setup -------------------------------------------------------- 17
1. Display ------------------------------------------------------------------ 18
2. Camera ----------------------------------------------------------------- 21
3. Sound ----------------------------------------------------------------- 24
4. System ------------------------------------------------------------------ 25
5. Event/Sensor ------------------------------------------------------------- 30
6. Disk Management ---------------------------------------------------------- 33
⊙ Go to Record Menu -------------------------------------------------------- 34
1. Recording Operations ------------------------------------------------------- 34
2. Continuous/Motion Record Schedule -------------------------------------------- 35
3. Alarm Recording Schedule --------------------------------------------------- 36
4. Panic Setup ---------------------------------------------------------- 37
⊙ Go to Archiving ----------------------------------------------------------- 38
1. CD-RW and USB Archiving/Back up ----------------------------------------- 38
•CHAPTER 6. CLIENT
⊙ DVR Remote Agent Installation Process --------------------------------------- 39
1. Introduction ------------------------------------------------------------ 41
2. Configuration ------------------------------------------------------------- 42
3. Monitoring --------------------------------------------------------------- 51
4. Search ------------------------------------------------------------------ 54
5. Web Client --------------------------------------------------------------- 61
• IMPORTANT SAFETY INSTRUCTIONS -------------------------------------- 63

3
1. Specifications & Organization
1. Specifications
AVI, JPG, BMPBack-up file formats
8 levelsNetwork Speed Control
16x16 grid, Sensitivity levels: 10Activity detection
TriplexSimplex/Duplex operation
4,8,16 x 1Vp-p, CVBS, 75ohms, BNC, looping outputsVideo inputs
1 x CVBS/S-VHS, VGAMonitor outputs
4(2) x 1Vp-p, CVBS, 75ohms, BNCSpot output
4 x line-in, RCA socketsAudio inputs
1 x line-out, RCA socketAudio output
352x240,704x240,704x480(NTSC), 352x288,704x288,704x576(PAL)Resolution
MPEG-4Compression standard
352x240 : 120/100 (NTSC/PAL) , 704x240 : 60/50 (NTSC/PAL)
704x480 : 30/25 (NTSC/PAL)
Recording speed
3-5 Kbyte (352x240, 352x288), 5-10 Kbyte (704x240, 704x288)
6-16 Kbyte (704x480, 704x576)
Image size
3 X HDD, No limit in capacityHard disk capacity
USB default (USB memory stick, USB HDD, ODD),DVD/CD-RW (option)Secondary Storage
4,8,16 x TTL, programmable as NC/NOAlarm inputs
4,8,16 x TTLAlarm outputs
For monitors with Multi Sync Function only(1024 X 768(60Hz))VGA
5 secs(Pre), 3 mins(Post), programmable per cameraPre/Post alarm recording
Up to 16Channel simultaneous playbackPlayback
TCP/IP, View, Search, Recording & Control by Client Program or I.E.Remote Access
Daily, Weekly adjust specific Hr per channelRecord Scheduling
Up to 1,000,000 for user login/out, config changes, remote access,
connects/disconnects
Event/Log search
ProgrammableCovert camera operation
Real time:25 Fps (PAL), 30Fps(NTSC) per cameraMonitor display
2-way Audio conferenceAudio
PAL/NTSCVideo standard

4
1. Specifications & Organization
Steel metal, Front Plastic MoldHousing
Up to 5 sec., programmable per cameraPre-alarm recording
English, Spanish, Chinese, Dutch, Portuguese, French, Russian,Japanese,
Polish, Romanian, German
OSD languages
10/100-Base-TX, RJ-45Ethernet interface
Live View, Live Recording, Search, Set-up, ArchivingRemote Function
RS-485 interfacePTZ Control
100VAC-240VAC, 60/50HzSupply voltage
5℃to 50℃Temperature range
4CH : 3.8KGS, 8&16CH : 7.3KGSWeight
4CH : 36cmX39cmX7cm, 8&16CH : 43cmX46cmX9cmDimensions (HxWxD)
BlackColor

5
2. Product Contents List
Please confirm that all product contents are present after opening the package.
1. Specifications & Organization
①Basic Contents
Remote Controller
User’s Manual Remote Agent
Installation CD AAA Battery x 2
AC Power Cable
② Optional Contents
Internal Hard Disk Drive Internal CD-RW Drive USB Thumb Drive
DR8N or DR16N Unit
DR4N 12V Adaptor

6
3. System Organization
1. Specifications & Organization
NETWORK
Camera #1-16
Alarm Sensor #1-16 Relay Out
VCR VGA
Monitor A/V Monitor
Remote Client PC Image Printer
Video In
Video Out
TCP/IP
Alarm Input/Out
Remote
Controller
CD-RW
Backup
AVI Backup
WEB Client
USB

7
① Power : System Power On/Off
② DISPLAY : Select Screen Division Mode or Rotation Mode
③ SEQUENCE : Select Sequence Screen Mode
④ PANIC : Trigger Panic Recording Mode and Panic Relay Output
⑤ ZOOM : Digital Zoom on Live Image
⑥ LOCK : Front Panel Lock Button
⑦ ARCHIVE : Go to Archiving Menu
⑧ PTZ : Go to Camera PTZ Control
⑨ SETUP : Go to System Setup Menu
⑩SEARCH : Go to Search Menu
⑪ USB PORT: USB Port for use of a USB Memory Stick and/or USB HDDBackup.
⑫ RETURN : Cancel / Deselect / Return to Previous Screen
⑬ ENTER : Confirm / Select / Next Screen
⑭ LED Indicator : Indicates Present System Status. (POWER, REC, NETWORK)
⑮ Channel Selection Buttons (1~8/16) : Select Channel or Input Password
- Directional / Navigation Buttons (UP, DOWN, LEFT, RIGHT, ENTER)
- Remote Controller Input Sensor (IR)
- EJECT : Eject CD-ROM (Optional)
-◀◀/ ◀ : Focus Adjust (Near/Far) or Reverse Play / Rewind
- Ⅱ: Pause Playback
-▶/ ▶ ▶ : Iris Adjust (Open / Close) or Forward Play / Fast Forward
- JOG / SHUTTLE : Outer wheel – variable REW or FF; Inner wheel – scroll frame-by frame while PAUSED.
- HOLD : Hold Current JOG / SHUTTLE Position
1. Front Panel(8&16CH)
2. Product Description
• If the Remote Control IR Sensor is blocked, the Remote Controller will NOT function
properly.
• When a button is pressed on the Front Panel or on the Remote Controller, the DVR
will beep, unless this feature is disabled from : System Setup ÆAudio ÆBuzzer
Tip
123
4
5 6
7
8
910 11
12
13
14
15

8
• When System Installation, Please Install under System Power OffStatus.
• Please Use Specific Adaptor when Power Supply.
2. Rear Panel(8&16CH)
2. Product Description
Tip
12
98 10 13
1 2 3
476 511
①Video IN / Loop: BNC Video Input Port (1 ~ 8/16), BNC Video Loop Output (1 ~ 8/16)
② Monitor out : BNC Main Monitor Output
SVHS : Output Video by Connected SVHS.
③ Spot #1 ~ #4 : 4/2(8CH) x BNC Output to Individually-Sequenced Spot Monitors
④Audio In : 4 x RCA Audio Line Input Terminal
⑤ Audio Out : RCA Audio Line Out Terminal
⑥ Alarm : 8/16 x Input TTL Alarm/Sensor Input Terminal
⑦ Relay : 8/16 x Relay Output Terminal
⑧ USB PORT: USB Port for use of a USB Memory Stick and/or USB HDD Backup
⑨ VGA OUT : VGA Main Monitor Output (to a Computer Monitor)
⑩ RS-232C : Serial Configuration Port for Program Debugging
⑪ RS-485 : Serial Interface for PTZ device connection and control
⑫ RJ-45 jack : 10/100 Ethernet LAN/WAN connection (for Remote Access and Configuration)
⑬ AC Power Input

9
3. Front Panel(4CH)
• Power Button is Soft Style to Prevent System Failure by Wrong Operation.
• Channel Selection Button is Prior to SCR Mode.
• When Remote Controller Sensor Input is Blocked by Something, it Cause
1Remote Controller do NOT Work Properly.
• When Press any Button, it Operate with Beep Sound.
•In Case of CD-RW, the Real Appearance will be Differ from the above Picture
1Depends on its Model.
Tip
1 2 3 4
7
65
11 1298 10 13
14
15
CD-RW : CD-RW Device for Backup.
Channel Selection Button : Select Channel or Input Password.
Led Indicator : Indicate Present System Status Information.
( PWR: System On/Off, REC: Record On/Off,
ALARM: Alarm Sensor Detection Status, NET: Client Network Connection Status, )
Search Controller : Searching Recorded Data or Control Menu & PTZ/FOCUS.
HOLD : Hold Jog dial.
JOG dial
Eject : Eject CD
DISPLAY : Select Screen Division Mode or Rotation Mode.
SEARCH : Go to Search Mode for Searching Data.
SETUP : Go to System Menu.
PTZ/FOCUS : Go to Camera PTZ/FOCUS Control.
RETURN : Cancel Setup or Return to Previous Mode.
ENTER : Apply Changing Setup.
Remote Controller Sensor Input.
USB Port: USB port for use the USB memory stick and USB HDD Backup
1
2
3
4
7
6
5
11
12
9
8
10
13
14
15
2. Product Description
