Geppetto-Eis 180P User manual

Operation Manual
Ice Cream Spaghetti - Press
180P

Table of Contents:
Contents
1Preface........................................................................................................................................... 4
1.1 Introduction............................................................................................................................ 4
2Safety Instructions........................................................................................................................ 5
2.1 Symbols and Notes.............................................................................................................. 5
2.2 Basic Security Instructions.................................................................................................. 6
2.3 Intended Use......................................................................................................................... 6
3Device Description........................................................................................................................ 7
3.1 General Terms...................................................................................................................... 7
3.2 Technical Specifications * ................................................................................................... 7
4Assembly Instructions.................................................................................................................. 8
4.1 Spaghetti- Press Instalation................................................................................................ 8
4.2 Compressed Air Connection............................................................................................... 8
4.3 Power Supply........................................................................................................................ 8
5Instructions for Use ...................................................................................................................... 9
5.1 Normal Operation................................................................................................................. 9
5.2 Setting the speed................................................................................................................ 10
6Maintenance Guidelines............................................................................................................ 10
6.1 Cleaning............................................................................................................................... 10
6.2 Routine Maintenance......................................................................................................... 10
6.3 Troubleshooting and Debugging...................................................................................... 11
6.4 Wear and Spare Parts....................................................................................................... 12
7Fittings.......................................................................................................................................... 13
7.1 Accesories (optional).......................................................................................................... 13
8Declaration of incorporation of partly completed machinery according to Machinery
Directive 2006/42/EG Annex II 1B................................................................................................... 14

Seite 4
GEPPETTO ICE CREAM PRESS Model 180P
1 Preface
1.1 Introduction
We thank you for your confidence and congratulate you on the purchase of your new Ice
Cream Spaghetti-Press 180P.
In order to achieve the maximum hygiene during its use, we have made special efforts to
ensure that all parts that come into contact with the food products, are easy to dissemble and
to clean.
The design of the Ice Cream Press 180P ensures the maximum hygiene with ease. It
therefore achieves 100% the HACCP hygiene guidelines.
Please read this manual with all the information and instructions carefully and keep it for
future references. We are sure that if you follow all the instructions contended in this manual,
you will have much enjoyment and success with your new Ice Cream Spaghetti-Press 180P.

Seite 5
2 Safety Instructions
2.1 Symbols and Notes
Please observe the meaning of the following symbol and note explanations. These are
classified according to ISO 3864-2.
CAUTION
Indicates a potentially dangerous situation.
Failure to follow the instructions will result in
property damage and minor or moderate personal
injury.
WARNING
Indicates a possible dangerous situation. Failure
to follow the instructions will result in death or
serious bodily injury (disability).
ADVICE
Indicates general instructions, useful user tips
and working recommendations, which have no
influence on the safety and health of the
operator.

Seite 6
2.2 Basic Security Instructions
These operating instructions serve as a basis for the safe use and operation of the ice
cream press. These operating instructions, in particular the safety instructions, must be
observed by all persons working on or with the ice cream press. In addition, the
applicable rules and regulations for accident prevention at the place of use must be
observed. The operating instructions must always be kept at the place of use of the ice
cream press.
The company GEPPETTO-EIS is not liable for accidents that occur during the
operation, cleaning and maintenance of the machine, if the safety instructions in
this manual are not followed!
2.3 Intended Use
The ice cream press is intended for pressing ice cream. The ice cream must not
contain large pieces of fruit, nut, chocolate or other hard pieces to prevent damage of
the press stamp.
For optimal operation, the ice cream should have a temperature of -14 to -17 ° C /
-57,2 to -62,6 F.
CAUTION
Do not misuse the ice cream press for other
purposes!
Any misuse can lead to device damage!

Seite 7
3 Device Description
3.1 General Terms
The ice press is a device with which frozen ice cream can be pressed through a form
disposer. The ice cream can be processed with different shapes of form disposers, i.e.
spaghetti ice cream, lasagna ice cream and other forms.
The ice cream press consists of the following elements:
•Base plate with suction feet
•Head part with pneumatic pressure unit
•Drip tray (upper and lower part)
•Control tube
•Form disposer (different shapes are available, see 7.1 Accesories)
3.2 Technical Specifications *
•Dimensions (L x W x H): 255 x 150 x 590 mm / 10 x 5,91 x 23,23 inches
•Material: High quality stainless steel
•Operating mode: pneumatic
•Pressure performance up to 280 kg/cm² at 10 bar pressure
•Weight: 11 kg /24,25 lbs
*Subject to change

Seite 8
4 Assembly Instructions
4.1 Spaghetti- Press Instalation
•Carefully remove the ice-press from its packaging.
•Do not use utility knives to open the packaging to avoid possible damage to the
machine!
•Place the machine at the intended location. It can be set up freely or screwed firmly to
the substructure. For this purpose there is an 0,31 inches / 8 mm threaded hole, in the
bottom plate. Make sure that the machine is set up on a horizontal, firm and stable
ground.
4.2 Compressed Air Connection
•To connect the ice press to an existing compressor, a hose of 6 mm diameter is
required..
•Connect the other end of the hose assembly to the connector of the Spaghetti ice
cream press. Insert hose as far as it will go. By briefly retracting the hose this is
locked.
•When installing the cable, please make sure that it is laid without kinks.
•Switch on the compressor.
•Set the working pressure at the pressure reducer to 58 - 87 psi / 4 - 6 bar. Please
also refer to the operating instructions of the manufacturer.
4.3 Power Supply
The ice cream press itself requires no electricity. It is exclusively operated with
compressed air.

Seite 9
5 Instructions for Use
CAUTION
The ice cream press may only be operated by
persons instructed in its handling.
ADVICE
Before putting your new ice press into operation,
all parts
in contact with food products must be
thoroughly cleaned in order to eliminate any
manufacturing residues!
5.1 Normal Operation
•Fill the cooled form disposer with the appropriate amount of ice cream.
•Insert the form disposer from below into the guide tube.
•Lock the former by turning it counterclockwise.
•Turn further until it stops. In this case, the roller valve is actuated whereby the press
stamp moves into the former and presses the ice located therein through the mold.
•Wait until the press stamp reaches the bottom of the form disposer and the entire ice
cream has been pressed out.
•By turning the form disposer clockwise until it stops, the press stamp automatically
returns to its original position and the form disposer is unlocked.
•Remove the form disposer downwards.
It is recommended to keep the form disposer refrigerated when not in use.

Seite 10
5.2 Setting the speed
Under the top cover of the ice press a valve with choke is installed, this serves to
regulate the speed of the pressure piston. The power of the ice press always
remains the same!
By screwing in the adjusting screw on the choke valve, the working speed is reduced
by unscrewing the adjusting screw the speed is increased.
6 Maintenance Guidelines
6.1 Cleaning
CAUTION
Before any maintenance and
cleaning work, the machine
must be set without pressure
to avoid any injury!
•Put the compressor out of operation.
•Depressurize the ice cream press to avoid injury. To do this, move the ball valve in the
compressed air connection line of the ice cream press or disconnect the compressed
air connection line at the connector from the compressed air supply.
•Check if the ice cream press is depressurized.
•Loose the release screw on the front and unscrew approx. 0,20 inches /5 mm.
•Turn the guide tube clockwise as far as it will go and then pull it downwards.
•Unscrew the polyamide press stamp from the piston rod.
ATTENTION: The press stamp is screwed with left hand thread!
•The form disposer can be cleaned occasionally when changing types of ice cream.
•Clean the removed parts (all parts are dishwasher safe).
•Reassemble in reverse order.
6.2 Routine Maintenance
•Lightly grease the seal of the press stamp for smooth running and long life after
cleaning.
•Regularly check the oil level of the compressor on the sight glass.
•Regularly check the oil level of the compressor at least once a month to prevent
corrosion in the compressor and to prevent contamination of the compressed air lines
and the pressure cylinder (see also operating instructions of the compressor
manufacturer)!
•The condensed water must be disposed properly.
