Giani CUCINA GCPC-001 User manual

InstructionManual
Model Reference: GCPC-001
IM-GCPC-00128102015
The Great British Breakfast
2 Slice Toaster with Egg and Bacon Cooker

Introduction
Thank you for choosing the Cucina by Giani 2 Slice Toaster with Egg and Bacon
Cooker. All products brought to you by Giani are manufactured to the highest
standards of performance and safety.
Before use, please read this manual. It gives important instructions about safety, use
and maintenance of your appliance.
Remove all packaging material. You may wish to keep the packaging for future use
or storage for your appliance. Alternatively, dispose of accordingly.
Index
Important Safety Instructions............................
Product Overview...............................................
Function Buttons................................................
Technical Information........................................
Before First Use.................................................
Using Your Toaster............................................
Toasting Hints and Tips.....................................
Using Your Cooker.............................................
Cooking Alternatives..........................................
Cooking Hints.....................................................
Cooking Guide...................................................
Cleaning and Maintenance................................
Storage...............................................................
After Sales Support............................................
Product Guarantee.............................................
1
02
04
05
06
06
07
07
08
09
09
10
10
10
11
11

Important Safety Instructions
Please read ALL instructions before using this appliance and keep safe for future
reference.
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. This appliance is for domestic use only. It should not be used for commercial
purposes.
2. Only use this appliance for its intended domestic use. Giani Ltd will not accept
any liability if the appliance is subject to improper use, or failure to comply with
these instructions.
3. Do not use outdoors or on wet surfaces.
4. Do not handle the plug or appliance with wet hands.
5. Do not immerse the main body in water. Avoid any liquids entering the appliance
as this will cause an electric shock or will short circuit the appliance.
6. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction concerning the use
of the appliance in a safe way and understand the hazards involved.
7. Children must not play with this appliance.
8. Cleaning and user maintenance must not be performed by children without
supervision.
9. This product is not a toy.
10. Do not use the appliance if any parts appear to be faulty, missing or damaged.
11. Do not use the appliance if it has been dropped or damaged in any way.
12. Do not leave the appliance unattended when connected to the mains supply or in
use.
13. Always unplug from the mains supply before carrying out any cleaning or
performing user maintenance.
14. Make sure the appliance has cooled down completely before cleaning or storing
away.
15. Check to ensure that your electricity supply matches that shown on the rating
plate.
16. If the supply cord is damaged, it must be replaced by a qualified service agent in
order to avoid a hazard.
17. Keep the appliance and its power supply cord away from heat or sharp edges
that could cause damage.
18. Make sure the power cord does not come into contact with areas of the appliance
that became hot during use.
19. Never touch the top of the appliance when in use as it becomes extremely hot.
20. Always use the appliance on a dry, level, stable, heat resistant surface.
21. Only use the attachments/accessories supplied with the product or
recommended by Giani.
22. Do not place the appliance against a wall or directly next to another appliance.
Leave at least 20cm of free space around the appliance when in use.
23. To avoid injury or possible fires, do not cover the appliance when in operation.
24. Do not move the appliance when it is in use.
25. Do not operate the Egg Cooker without water or oil (depending on what you are
cooking). 2

3
26. Always switch off the appliance when changing accessories or approaching parts
which move when in operation.
27. When removing the lid from the Egg Cooker after cooking, take extreme care as
the lids become hot and steam will release. ALWAYS use oven gloves.
28. Do not disconnect the appliance from the mains power supply by pulling the
cord, switch it off and remove the plug by hand.
29. Do not store in direct sunlight or high humidity conditions.
30. Use of an extension cord with this appliance is not recommended.
31. This appliance should not be operated by means of an external timer or separate
remote control system.
32. Keep the appliance away from flammable materials.
33. Do not insert metal objects or other utensils into the appliance as this will cause
an electric shock or may cause a fire.
34. Do not use metal utensils in the fry pan as this will damage the non-stick coating.
35. The measuring cup features an egg piercer at the bottom. Handle with care, the
piercer is extremely sharp.
CAUTION: If the bread carriage handle jams during use (eg. because the bread
slices are too thick) and the bread starts to burn, unplug the appliance immedi-
ately, allow to cool, then empty and clean the appliance.
CAUTION: Do not use this appliance for defrosting food other than bread slices,
bagels and baguettes.

Product Overview
1. Transparent Lid
2. Steam Tray
3. Poaching Tray
4. Egg steam Tray
5. Fry Pan
6. Plastic Spatula
7. Measuring Cup
8. Control Panel
9. Crumb Tray
10. Carriage Handle
11. Toasting Slots
Note: The measuring cup features an egg piercer at the bottom. This is used to
prick the egg to prevent cracking when cooking the egg in the shell.
Take extreme care, the piercer is very sharp.
Note: The crumb tray has a ‘press – release’ system. Simply press and the
crumb tray will release automatically.
4
1
2
3
4
6
7
8
11
9
10
5

Function Buttons
Note: The Green LED light indicator illuminates
when the appliance is plugged into the mains
supply
5
Function
A
B
C
D
E
Toaster – Browning Control Dial. The browning setting required will vary
according to the moisture content and thickness of the bread.
Toaster – Defrost Button. Select your required browning setting and press
DEFROST (the defrost button will illuminate blue), the toasting time will
automatically adjust to first defrost and then toast to your chosen browning
setting.
Toaster – Reheat Button. Will re-heat your toast without adding any further
browning. (The reheat button will illuminate blue when selected). Ideal for
when your toast has completed its cycle but you are not ready to use,
simply re-heat when required
Toaster – Stop Button. (Always illuminated blue when in operation) The Stop
button will immediately stop the toasting cycle. During operation, if you think
the bread is toasted enough or you require to stop the cycle, you can cancel
the process by pressing the STOP button
Egg Cooker Control Dial. (On / Off) When turning the control dial to Heat the
red LED light will illuminate. The Egg Cooker is now switched on.
A B C D E

Technical Information
Before First Use
1. Remove all packaging materials, stickers and labels.
2. Check that all parts are enclosed and that the unit is not damaged.
3. Check that the toasting slots are empty.
4. Wash the Cooker accessories in warm soapy water, rinse and dry thoroughly.
5. Wipe down the appliance with a soft damp cloth and dry thoroughly.
Warning: Do not immerse the main body in water. Avoid any liquids entering the
appliance as this will cause an electric shock and damage the appliance.
NOTE: The Toaster and Egg Cooker are operated independently. You can use
separately or both at the same time.
6
Volatage
Rated Power - Toaster
Rated Power - Egg Cooker
220-240V
850W
400W

Using Your Toaster
1. Place your toaster on a level, stable, heat resistant surface.
2. Check the crumb tray is locked in position.
3. Plug the appliance into the mains socket and switch on.
4. Select the required browning setting (A).
5. Place the bread slices into the toasting slots.
6. Press down the bread carriage handle until it clicks (The bread will be lowered and
centred as the lever moves down).
7. Release the pressure and the handle will stay in the lowered position. The heating
process has begun.
Note: If the handle comes up immediately, check the appliance is plugged in,
as the bread carriage cannot lock if the toaster is not connected to the
electricity supply.
8. The Stop button (D) will illuminate blue while the toaster is in operation.
9. When toasting is complete the toast will pop up and the Stop button light will go
out.
10. To lift the toast further out of the slot, lift the carriage handle to the highest
position.
11. Switch off at the mains socket, unplug and allow to cool.
CAUTION: The toaster surface will get hot during use, especially near the toast-
ing slots. ALWAYS allow the appliance to cool down before touching it.
NEVER use utensils to release trapped toast. This is extremely dangerous. Turn
off the appliance at the mains socket, unplug, allow to cool, then turn the
toaster upside down and gently shake to release the trapped toast.
Toasting Hints and Tips
• When toasting, use slices of similar size, thickness and freshness.
• Old (yesterdays) bread contains less moisture, so makes crispier toast.
• Old or thin bread cooks faster than fresh or thick bread – use a lighter setting.
• Sweet bread products (tea cakes, fruit loaf, etc) brown much more quickly than
ordinary bread, so should be toasted on a lighter setting.
7

Using Your Cooker
The Cooker and Toaster are operated independently. You can use separately or both
at the same time.
NOTE: You MUST ALWAYS use the Fry Pan for any cooking process.
To Fry Eggs
1. Lightly spray or brush oil onto the Fry Pan (5).
2. Break your egg (maximum 1) into the Fry Pan.
3. Plug the appliance into the mains supply.
4. Turn the Cooker control dial (E) to the Heat position. The red LED light will
illuminate.
5. Do not leave the appliance unattended whilst using the cooker.
6. When your egg is cooked and reached your preferred consistency, remove the Egg
using the plastic spatula (6).
7. Turn the control dial to the ‘off’ position and unplug from the mains supply and
allow the unit to cool.
Note: Fat can splash from the Pan whilst frying, take extreme care.
To Steam Eggs
1. Pour cold water into the Fry Pan (5) using the measuring cup. Do not exceed the
maximum water level as indicated on the measuring cup. You can adjust the
amount of water used according to your taste.
2. Pierce the large rounded end of your egg with the egg piercer on the underside of
the measuring cup.
3. Place your eggs (maximum 5) into the Egg Stream tray (4), small end down (pierced
side up).
4. Fit the Steam Tray (2) and cover with the transparent lid (1).
5. Plug the appliance into the mains supply.
6. Turn the Cooker control dial (E) to the Heat position. The red LED light will
illuminate.
7. Do not leave the appliance unattended whilst using the cooker.
8. The eggs are ready when there is no more water left in the Fry Pan.
Note: Depending on your preferred consistency (soft or hard) it may take a few
cooking processes for you to gauge the required cooking time.
CAUTION: Take extreme care when removing the lid, Steam will be released,
use oven gloves to avoid scalding.
8

To Poach Eggs
1. Pour cold water into the Fry Pan (5) using the measuring cup. Do not exceed the
maximum water level as indicated on the measuring cup. You can adjust the
amount of water used according to your taste.
2. Lightly spray or brush oil onto the Poaching Tray (3), covering all compartments.
3. Break your eggs in to the Poach Tray (maximum 3 – 1 per compartment).
4. Place the Egg Steam Tray (4) on to the Fry Pan.
5. Place the Poach Egg Tray on to the Steam Egg Tray; fit the Steam Tray (2) & Cover
(1).
6. Plug the appliance into the mains supply.
7. Turn the Cooker control dial (E) to the Heat position. The red LED light will
illuminate.
8. Do not leave the appliance unattended whilst using the cooker.
9. The eggs are ready when there is no more water left in the Fry Pan.
Note: Depending on your preferred consistency (soft or hard) it may take a few
cooking processes for you to gauge the required cooking time.
Cooking Alternatives
The Fry pan can also be used to cook bacon (1 piece at a time), black pudding and
mushrooms, simply follow the Fry procedure.
The Steam Tray can be used to steam vegetables. Pour cold water into the Fry Pan.
Place your vegetables into the Steam Tray, cover and cook.
The Poach Tray can also be used to heat Baked Beans (tinned), chopped or plum
tomatoes (tinned), simply follow the Poach procedure.
It is recommended to monitor the above alternatives closely when cooking for the
first time as the cooking process varies dependent upon type of cooking and
required cooking time.
Cooking Hints
When the appliance is switched on the red LED light will illuminate and extinguish as
the thermostat regulates the temperature.
The egg cooker timing is controlled by the amount of water placed in the Fry Pan. The
more water added, the longer the appliance will cook.
When steaming eggs, there is still possibility the eggs may expand and leak, this is
normal.
9

Cooking Guide
Note: The timings are indications only as adjustments will be required depend-
ing on the size of eggs used and your preferred taste.
Cleaning & Maintenance
1. Make sure the toaster is unplugged from the mains supply and fully cooled down.
2. To remove breadcrumbs, release the crumb tray and slide out.
CAUTION: It is very important to empty the crumb tray regularly. This avoids a
build-up of crumbs and prevents a fire hazard.
3. Empty the tray, wipe with a soft damp cloth, dry thoroughly and replace it in the
toaster.
Ensure the raised sides of the crumb tray are facing upwards before sliding back
into the toaster.
NOTE: Do not use the toaster unless the crumb tray is fitted and in position.
4. The Fry Pan must only be wiped with a soft damp cloth or sponge that has been
soaked in warm soapy water. DO NOT immerse the Fry Pan in water, this will
damage the heating elements.
5. The Egg Steam Tray, Poaching Tray, Steam Tray, Transparent Lid and Spatula
must be cleaned with warm soapy water only. Do not use abrasive solutions or
materials as this will damage them.
6. Wipe the outer surface with a soft damp cloth. DO NOT use abrasive solutions or
materials as this will damage the appearance.
Storage
1. Never wrap the power cable around the toaster.
2. Wrap the cable neatly around the cord storage provided on the underside of the
toaster.
3. When not in use, remove the plug from the mains supply and store the toaster in a
dry, safe place and out of reach of children.
10
Fried Eggs
Steamed Eggs - Medium (soft yolk)
Steamed Eggs - Hard (solid yolk)
Poached Eggs
Light Spray / Brush of Oil
65ml Water
75ml Water
80ml Water
Required Water / Oil in Fry Pan Cooking time
4min
9min 20 seconds
12min 18 seconds
9min 50 seconds

After Sales Support
If the power cord is damaged, it MUST be replaced by a qualified electrician.
If you need help using your 2 Slice Toaster with Egg and Bacon Cooker, please
contact Giani Ltd:-
Telephone: [phone]
Email: [email protected]
Website: www.gianiuk.co.uk
(replacement instruction manuals are available to download).
11
Product Guarantee (UK Only)
If your appliance ceases to function within 1 year from the date of purchase, the retailer
will replace it free of charge, provided:
This guarantee does not affect your statutory rights.
You have not misused, neglected or damaged it
It has not been modified (except by Giani Ltd)
It was not purchased second hand
It has not been used commercially
You have not fitted a plug incorrectly
You can supply proof of purchase, indicating the price you paid and where and when
the appliance was purchased.
2011/65/EU
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE APPLIANCE IN ACCORDANCE WITH
EC DIRECTIVE 2002/96/EC
At the end of its working life, the appliance must NOT be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer providing
this service.
Disposing of a household appliance separately avoids possible negative consequences for the
environment and health deriving from inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of
ousehold appliances separately, the product is marked with a crossed-out wheeled dustbin.
