Giant GP8055-Brine User manual

Contents:
Installation Instructions: page 2
Pump Specications: page 3-5
Exploded View/Parts List: pages 6-7
Repair Kits/Tool List: page 8
Torque Specications: page 8
Troubleshooting Chart: page 8
Repair Instructions: pages 9-11
Dimensions: back page
Warranty Information back page
Triplex Ceramic
Plunger Pump
Models Manual
Models
GP8055-Brine
GP8060-Brine
GP8065-Brine
Updated 10/20

2
INSTALLATION INSTRUCTIONS
Cooling the Gear Oil
Important! The water input pressure must not
exceed 2 bar when using the integrated system for
cooling the gear oil (standard version).
If a separate cooling circuit (maximum 29 PSI [2
bar]) is installed, it is then possible to have an input
pressure of up to maximum 145 PSI (10 bar) on the
suction side.
Make sure that suction pulsation is su󰀩ciently
dampened - water column resonance must be
avoided.
Important! The pumps can be run without gear
oil cooling in continuous operation up to a power
rating of 107 hp (80 kW) or with major intermittent
operation).
If operation power exceeds 107 hp (80 kW) or if
continuous operation is the case, the pump must
be run with the integrated oil cooling system. The
maximum temperature of the water being pumped
and which is also fed through the cooling system
must not exceed 86 °F (30°C). The amount which
is fed into the cooling system depends on the pump
speed and is approximately 1.85 GPM (7.0 L/min) at
580 RPM. The cooling water is sucked in by one of
the pumping chambers and pumped away.
The stated gures are for maximum pressure and
maximum speed (RPM) and apply for interval
operation with cold water.
Required NPSH refers to water (specic weight 1kg/
dm3, viscosity 1°E) at maximum permissible pump
revolutions.
Fluid medium: Clean water lter with 50µm.
Operation and Maintenance
Check oil level prior to starting and ensure trouble-
free water supply.
Important! If there is a danger of frost, the water
in the pump and in the pump ttings (particularly
the unloader valve) must be emptied. The second
discharge port can also be used and the pump run
“dry” for 1-2 minutes for this purpose.
Oil: Use only 3.3 Gallons (12.5 liters) of ISO VG 220
GL4 (e.g. Aral Degol BG220) or SAE 90 GL4 gear oil
(Giant p/n 01154). Initial change after 50 operating
hours and then every 1000 operating hours after one
year at the latest.
Important! When operating in damp places or with
high temperature uctuations, oil must be changed
immediately should condensate (frothy oil) occur in
the gear box.
NPSH values must be observed.

U.S. (Metric)
Volume...................................................... Up to 75.3 GPM ............................(285 LPM)
Discharge Pressure .................................. Up to 3000 PSI ...............................(200 bar)
Power Consumption ................................. 145 BHP ............................................ 108 kW
Speed ....................................................... Up to 580 RPM ............................... 580 RPM
Inlet Pressure............................................ Up to 29 PSI ....................................(2.0 bar)
Plunger Diameter...................................... 2.17”..................................................... 55mm
Plunger Stroke.......................................... 2.83”..................................................... 72mm
Crankshaft Diameter................................. 2.76”..................................................... 70mm
Key Width ................................................. 0.55”..................................................... 14mm
Crankshaft Mounting........................................................................................ Either side
Shaft Rotation...................................................................Top of pulley towards manifold
Temperature of Pumped Fluids................. Up to 86o F*........................................ (30o C)*
Inlet Ports..........................................................................................................(2) 3” BSP
Discharge Ports ......................................................................................... (2) 1-1/4” BSP
Weight....................................................... 767 lbs. ............................................. (348kg)
Crankcase Oil Capacity ............................ 3.3 Gal. ....................................... (12.5 liters)
Fluid End Material...................................................................... Nickle Aluminum Bronze
NPSHR ..................................................... 23.0 ft-head...................................... 7.0 mWs
*Higher water temperatures possible with separate crankcase cooling system; the manufacturer
is to be contacted in this case.
Specications
Model GP8055-Brine
Consult the factory for special requirements that must be met if the pump
is to operate beyond one or more of the limits specied above.
HORSEPOWER RATINGS:
The rating shown are the power
requirements for the pump. Gas
engine power outputs must be
approximately twice the pump
power requirements shown above.
We recommend a 1.15 service
factor be specied when select-
ing an electric motor as the power
source. To compute specic pump
horsepower requirements, use the
following formula:
SPECIAL NOTE:
The theoretical gallons per revolution (gal/rev)
is 0.130. To nd specic outputs at various RPM,
use the formula:
GPM = 0.130 x RPM
GPM x PSI = HP
1450
3
GP8055 HORSEPOWER
REQUIREMENTS
RPM GPM 500 PSI 1000 PSI 2000 PSI 3000 PSI
300 39 13.9 27.9 55.7 83.6
400 52 18.6 37.1 74.3 111.4
500 65 23.2 46.4 92.9 139.3
580 75.5 27.0 53.9 107.9 161.8

U.S. (Metric)
Volume...................................................... Up to 89.0 GPM ..............................(340 LPM)
Discharge Pressure .................................. Up to 2465 PSI ................................. (170 bar)
Power Consumption ................................. 142 BHP .............................................. 106 kW
Speed ....................................................... Up to 580 RPM ..................................580 RPM
Inlet Pressure............................................ Up to 29 PSI ...................................... (2.0 bar)
Plunger Diameter...................................... 2.36”........................................................60mm
Plunger Stroke.......................................... 2.83”........................................................72mm
Crankshaft Diameter................................. 2.76”........................................................70mm
Key Width ................................................. 0.55”........................................................14mm
Crankshaft Mounting...........................................................................................Either side
Shaft Rotation..................................................................... Top of pulley towards manifold
Temperature of Pumped Fluids................. Up to 86o F*...........................................(30o C)*
Inlet Ports..........................................................................................................(2) 3” BSPP
Discharge Ports ......................................................................................... (2) 1-1/4” BSPP
Weight....................................................... 767 lbs. ................................................ (348kg)
Crankcase Oil Capacity ............................ 3.3 Gal. ..........................................(12.5 liters)
Fluid End Material.........................................................................Nickle Aluminum Bronze
NPSHR ..................................................... 26.2 ft-head........................................ 8.0 mWs
*Higher water temperatures possible with separate crankcase cooling system; the manufacturer
is to be contacted in this case.
Specications
Model GP8060-Brine
Consult the factory for special requirements that must be met if the pump
is to operate beyond one or more of the limits specied above.
HORSEPOWER RATINGS:
The rating shown are the power
requirements for the pump. Gas
engine power outputs must be
approximately twice the pump
power requirements shown above.
We recommend a 1.15
service factor be specied when
selecting an electric motor as the
power source. To compute spe-
cic pump horsepower require-
ments, use the following formula:
GPM X PSI
= HP
1450
4
GP8060 HORSEPOWER
REQUIREMENTS
RPM GPM 500 PSI 1000 PSI 2000 PSI 2500 PSI
300 47 16.8 33.6 67.1 83.9
400 62 22.1 44.3 88.6 110.7
500 78 27.9 55.7 111.4 139.3
580 90 32.1 64.3 128.6 160.7
SPECIAL NOTE:
The theoretical gallons per revolution (gal/rev) is
0.155. To nd specic outputs at various RPM, use
the formula:
GPM = 0.155 x RPM
89

U.S. (Metric)
Volume......................................................Up to 105.7 GPM ............................(400 LPM)
Discharge Pressure ..................................Up to 2000 PSI .................................(140 bar)
Power Consumption .................................147 BHP ...............................................110 kW
Speed .......................................................Up to 580 RPM................................. 580 RPM
Inlet Pressure............................................Up to 29 PSI ......................................(2.0 bar)
Plunger Diameter......................................2.55” ...................................................... 65mm
Plunger Stroke..........................................2.83” ...................................................... 72mm
Crankshaft Diameter.................................2.76” ...................................................... 70mm
Key Width .................................................0.55” ...................................................... 14mm
Crankshaft Mounting......................................................................................... Either side
Shaft Rotation.................................................................... Top of pulley towards manifold
Temperature of Pumped Fluids.................Up to 86o F*.......................................... (30o C)*
Inlet Ports........................................................................................................ (2) 3” BSPP
Discharge Ports ........................................................................................ (2) 1-1/4” BSPP
Weight.......................................................767 lbs. ............................................... (348kg)
Crankcase Oil Capacity ............................3.3 Gal. ......................................... (12.5 liters)
Fluid End Material....................................................................... Nickle Aluminum Bronze
NPSHR .....................................................23.6 ft-head ....................................... 7.2 mWs
*Higher water temperatures possible with separate crankcase cooling system; the manufacturer
is to be contacted in this case.
Specications
Model GP8065-Brine
Consult the factory for special requirements that must be met if the
pump is to operate beyond one or more of the limits specied above.
HORSEPOWER RATINGS:
The rating shown are the power
requirements for the pump. Gas
engine power outputs must be
approximately twice the pump
power requirements shown above.
We recommend a 1.15
service factor be specied when
selecting an electric motor as the
power source. To compute spe-
cic pump horsepower require-
ments, use the following formula:
GPM X PSI
= HP
1450
5
SPECIAL NOTE:
The theoretical gallons per revolution (gal/rev) is
0.181. To nd specic outputs at various RPM, use
the formula:
GPM = 0.181 x RPM
GP8065 HORSEPOWER
REQUIREMENTS
RPM GPM 500 PSI 750 PSI 1000 PSI 2000 PSI
300 54 19.3 28.9 38.6 77.1
400 72 25.7 38.6 51.4 102.9
500 91 32.5 48.8 65.0 130.0
580 105 37.5 56.3 75.0 150.0
106

6
Exploded View - GP8055/GP8060/GP8065 - Brine

7
Part List - GP8055/GP8060/GP8065 - Brine
Item Part Description Qty
1 05380 Crankcase 1
2 06893 Oil Filler Plug Assembly with Vent 1
5 22929 Copper Washer 2
6 12256 Plug, 3/8” BSP 1
7 05656 Plug for Oil Dipstick 1
8 05035 Oil Dipstick Assembly 1
9 06225 O-Ring 1
12 07109 Plug, 1/2” BSP 2
13 07182 Seal 2
14 05036 Bearing Cover Closed 1
14A 05298 Bearing Cover Open 1
15 05112 Radial Shaft Seal 1
16 05037 O-Ring 2
17 05038 Hexagon Socket Screw 16
18 05039 Spring Ring 16
21 05044 Tapered Roller Bearing 2
21A 05042 Fitting Disc 1-5
21B 05043 Fitting Disc 1-5
21C 05113 Fitting Disc 1-5
22 05299 Crankshaft 1
23 05300 Fitting Key 1
24 05047 Connecting Rod Assembly 3
25 05048 Crosshead c/w Plunger 3
28 05049 Crosshead Pin 3
29 05051 Hexagon Screw 5
29A 05381 Bracket 1 for Cooling Hose 2
29B 05383 Bracket 2 for Cooling Hose 2
30 05052 Cover Plate 1
30A 07225-0100 Hexagon Screw 5
30B 13136 Grommet 5
30C 08280 Washer 10
30D 05050 Splash Cover 1
31 07623 Eye Bolt 4
32 05058 Radial Shaft Seal 3
32A 03118 Oil Scraper 3
33 03119 Seal Retainer 3
33A 05056 O-Ring 3
33B 05054 Clip Ring 3
33C 05059 Fitting Disc 3
34 05060 Oil Shield 3
36A 05063 Cover for Plunger Pipe
(GP8060/GP8065) 3
36B 05280 Plunger Pipe (GP8055) 3
36B 05061 Plunger Pipe (GP8060) 3
36B 05115 Plunger Pipe (GP8065) 3
36C 05062 Tension Screw 3
36D 07665 Copper Washer 3
36E 06900 Centering Sleeve 3
38 05283 Seal Case (GP8055) 3
38 05064 Seal Case (GP8060/GP8065) 3
38A 13286-0001 O-Ring, Viton (GP8055) 6
38A 06667-0001 O-Ring, Viton (GP8060/GP8065) 6
39 05275 Seal Sleeve (GP8055) 3
39 05065 Seal Sleeve (GP8060) 3
39 05116 Seal Sleeve (GP8065) 3
39A 05066 O-Ring 3
40 07723 Seal Ring (GP8055) 3
40 05067 Seal Ring (GP8060) 3
Item Part Description Qty
40 06996 Seal Ring (GP8065) 3
41 05276 Pressure Ring (GP8055) 3
41 05068 Pressure Ring (GP8060) 3
41 05117 Pressure Ring (GP8065) 3
42 05277 V Sleeve (GP8055) 9
42 05069 V Sleeve (GP8060) 9
42 06997 V Sleeve (GP8065) 9
43 05278 Sleeve Support Ring (GP8055) 3
43 05070 Sleeve Support Ring (GP8060) 3
43 05118 Sleeve Support Ring (GP8065) 3
45 05279 Seal Tension Spring (GP8055) 3
45 05071 Seal Tension Spring (GP8060) 3
45 05119 Seal Tension Spring (GP8065) 3
49 05072 Stud Bolt 8
49A 05073 Hexagon Nut 8
50 05074-3000 Inlet Valve Casing 1
50A 13162 Centering Stud 2
50B 05075-3000 Discharge Valve Casing 1
51 05076-0100 Suction Valve Assembly 3
51A 04166 Spring Tension Cap 3
51B 05078-0100 Suction Valve Seat 3
51C 05079-0100 Valve Plate 3
51D 07658-0001 O-Ring, Viton 3
51E 05080 Valve Spring 3
52 05082-0100 Discharge Valve Assembly 3
52A 04166 Spring Tension Cap 3
52B 05084-0100 Discharge Valve Seat 3
52C 05079-0100 Valve Plate 3
52D 05613 O-Ring 6
52E 05080 Valve Spring 3
56 05085-0100 Discharge Valve Adaptor 3
56A 05613 O-Ring 3
57 05086 Pressure Spring 3
57A 07210-0100 Pressure Spring 3
58 05087-0010 Hexagon Socket Screw 12
60 06909 Plug, 1 1/4” BSP 1
61 05088 Plug, 3” BSP 1
66 05303 Disc for Crankshaft 1
67 13358 Hexagon Screw 1
K1 05026-0100 Cooling Vane Plate 1
K2 05027 Seal for Gear Cover 2
K3 05028 Gear Cover 1
K4 05029 Hexagon Head Countersunk
Screw 4
K5 07381 Hexagon Socket Screw 8
K6 08041 Washer 8
K7 05030 Connection for Oil Cooler 1
K8 07661 Copper Seal 6
K9 07109 Plug, 1/2” BSP 2
K10 05031 Connecting Branch 3
K11 05032 Hose Adaptor 3
K12 05033 Tube for Cooler 2
K13 05402 Hose Clamp 4
K14 05403 Hose Guard 2
K15 05404 Hose Coupling Nut 1
K16 05405 Flat Gasket 4
K18 04158 Hexagon Socket Screw 4
K19 05053 Washer 4

Pump Repair Kits - GP8055/GP8060/GP8065 - Brine
Plunger Packing Kits
GP8055 - #09616
Item Part # Description Qty.
38A 13286 O-Ring 6
38B 05281 Support Ring 6
39A 05066 O-Ring 3
40 07723 Seal Ring 3
42 05277 V-Sleeve 9
GP8060 - #09617
Item Part # Description Qty.
38A 06667 O-Ring 6
39A 05066 O-Ring 3
40 05067 Seal Ring 3
42 05069 V-Sleeve 9
GP8065 - #09586
Item Part # Description Qty.
38A 06667 O-Ring 6
39A 05066 O-Ring 3
40 06996 Seal Ring 3
42 06997 V-Sleeve 9
Oil Seal Kit - #09584
Item Part # Description Qty.
32 05058 Radial Shaft Seal 3
33A 05056 O-Ring 3
Inlet Valve Kit - #09587-0100
Item Part # Description Qty.
51 05076-0100 Inlet Valve Assembly 3
56A 05613 O-Ring 3
Discharge Valve Kit - #09588-0100
Item Part # Description Qty.
52 05082-0100 Discharge Valve Assembly 3
56A 05613 O-Ring 3
8
Problem Cause Solution
Pressure drops, water leaks V-sleeves leak
Replace V-sleeves, examine surface of
plunger
Discharge or suction valve leaks Replace valve
Steam formation (cavitation)
Reduce suction height, reduce flow resistance
in inlet line, clean inlet filter, lower water
temperature
Worn valves Examine valves
O-Ring on the valves or inlet valve
adapter leaks
Examine O-ring, examine valve casing for
unevenness on the sealing surfaces
Oil leaks at visible part of
plunger
Gear sealing is leaky Examine seals and running surface of plunger
Dirty mile-colored frothy oil Oil has mixed with water Replace oil immediately, find and fix the cause
Oil leakage on the crankshaft Shaft seal ring leaks Check seal and shaft
Noise increases without loss of
pressure
Worn bearing
Dismantle gear, examine all parts, replace
worn parts, check oil level. If service life was
too short, check for excess strain or whether
lubrication intervals were too long. Only
specified lubricants are to be used
Pressure drops, pump
becomes loud
Irregular pressure
GP8055/GP8060/GP8065 - Brine
Troubleshooting
GP8055/GP8060/GP8065 - Brine
TOOL LIST AND TORQUE SPECIFICATIONS
ITEM PART # DESCRIPTION
TORQUE
Ft-lbs (NM) TOOL NEEDED
17 05038 Hexagon Socket Screw 64 (87) 10mm allen wrench
24 05047 Connecting Rod Hexagon Socket Screw 37 (50) 8mm allen wrench
33B 05054 Clip Ring n/a Industrial Snap ring pliers
36C 05062 Tension Screw 30 (40) 16mm socket
49A 05073 Hexagon Nut (manifold) 265 (360) 30mm socket
51 05076-0100 Valve Assemblies n/a Valve puller (p/n 07662) - included with pump
52 05082-0100 Valve Assemblies n/a Valve puller (p/n 07662) - included with pump
58 05087 Hexagon Socket Screw 132 (180) 12mm allen wrench
K5 07381 Hexagon Socket Screw n/a 8mm allen wrench

Pump Repair Instructions - GP8055/GP8060/GP8065 - Brine
6) Remove tension screw (36C) and take
seal sleeve (39) together with all mounted
parts out of the drive. Pull plunger pipe
out of the seal assembly and check for any
damage. Carefully, remove seal rings (40)
and sleeves (42) with a screw driver.
4) The spring tension cap (51A, 52A) is
screwed together with the valve seat (51B or
52B). Screw o󰀨 spring tension cap. Takeout
springs (51E, 52E) and valve plate (51C,
52C). Check sealing surfaces and O-rings
(51D, 52D). Replace worn parts. Coat threads
of valve seat with silicon grease or molycote
anti-seize Cu-7439 when reassembling. Be-
fore retting the valves, clean the sealing sur-
faces in the casing and check for any damage.
Tighten caps (58) at 133 Ft-lbs; check torque
tension after 8-10 operating hours.
5) Remove hexagon nuts (49A) and
valve casing together with seal case
(38) from crankcase (1). If neces-
sary, carefully tap the valve casing
(50) past the centering stud (50A)
using a rubber hammer.
IMPORTANT! If necessary, sup-
port the valve casing by resting it on
wooden blocks or by using a pulley.
Valve Inspection and Repair
1) Remove bolts (58). 2) Remove discharge
casing (50B) up and away.
3) Take out pressure springs
(57A). Pull out assembled
valves (51 & 52) with tting tool.
To Check Seals and Plunger Pipe
9

8) Take out the seal case (38) from the valve (if
necessary secure 2 screwdrivers in the front O-ring
groove to extract seal casing from valve casing).
Coat seals with silicon grease before installing.
Mounting surfaces of the crankcase
and the valve casing must be clean and free of
damage. The components must lie exactly and
evenly on one another. The same exactness ap-
plies for all centering positions in the crankcase,
pressure and valve casing.
Pump Repair Instructions - GP8055/GP8060/GP8065 - Brine
7) Be careful not to damage the seal
sleeve (39) and pressure ring (41). Check the inner
diameter of the pressure ring for wear and if neces-
sary replace together with seals (40) and (42). Clean
all parts. New parts should be lightly coated with
silicon grease before installation. Inert the seal unit
(40, 41, 42 43) into the sleeve. Push the ceramic
plunger carefully through the seals from the crank-
case side. If necessary, the seals can be held tightly
using a suitable pipe support held on the other side
of the seal sleeve.
9) Coat the seal sleeve lightly with anti-corrosive
grease (e.g. molycote no. Cu-7439) in its tted area
towards the crankcase. Insert the seal sleeves in to
their crankcase ttings. Coat the threads of the ten-
sion screw (36C) lightly with thread glue and insert
it together with a new copper ring (36D) through
the ceramic pipe. Turn the pump per hand until the
plunger (25) rests against the plunger pipe. Tighten
the tension screw at 30 Ft-lbs.
Thread glue must never come between
the plunger pipe (36B) and centering sleeve (36E).
Overtensioning of the plunger pipe by excessive
tightening of the tension screw and/or dirt or damage
on the mounting surfaces can lead to plunger pipe
breakage. Insert the seal tension spring (45) and O-
ring (39A) in to the seal sleeve (39).
Replacing Valve Casing:
10) Put seal cases (38) in the centering holes of the
valve casing, then push valve casing carefully on to
centering studs (50A). Tighten hexagon screws (49A)
evenly and crosswise at 266 Ft.-lbs.
The torque tension on the screws
(49A) must be checked after 8-10 operating hours;
the pump must be at zero pressure. Thereafter,
the tension is to be checked every 200 operating
hours.
10

Pump Repair Instructions - GP8055/GP8060/GP8065 - Brine
12) Remove the connecting rod screws (24).
Connecting rods are marked 1 to
3 for identication. Do not twist connecting rod
halves or interchange them. When reassembling,
the connecting rod must be tted in their exact
original position on the crankshaft journals.
13) Push connecting rod halves together with the
crosshead as far as possible into the crosshead guide.
Take out bearing cover (14/14A) and push out crank-
shaft taking particular care that the con rod doesn’t
get bent. Check surfaces on the connecting rods (24),
crankshaft (22) and crossheads (25). Check the sur-
faces of the crosshead guides in the crankcase for any
unevenness.
15) Mount bearing cover (14A) and tighten screws (17) to 64 Ft-lbs. Adjust axial play (clearance) on the
crankshaft to minimum 0.1 mm / max. 0.15 mm using shims (21A/21B). The shaft should turn easily with little
clearance. Connecting rod must sit exactly in the middle of each crank pin. Fit the bearing cover (14) and
tighten the screws (17) at 64 Ft-lbs. Seal (32A) must always be installed so that the seal lip on the inside
diameter faces the oil. Possible axial oat of the seal adaptor (33) to be compensated with shims (33C).
Mount cooling plate (K1) and gear cover (K3) with their respective seals (K2). When assembling the cooling
circuit line, make sure that the oil cooler connection (K7) is always joined to the upper connection (K3) of the
gear cover.
14) Reassemble in reverse order. Thread the
long end of the crankshaft together with the inner
bearing rings into the crankcase; then mount
outer bearing ring (20) and spacer ring (22A).
Mount connecting rod halves in their exact origi-
nal position and tighten at 37 Ft-lbs.
Connecting rods must be able to
move slightly sideways on the stroke journals.
To Dismantle Crankcase Gear
11) Take out plungers and seal sleeves as described
above. Drain the oil by taking o󰀨 the plug (12). After
removing the clip ring (33B), lever out the seal retainer
(33) with a screwdriver. Open hose adaptor (K11) and
remove gear cover (K3). Remove the cooling vane
plate (K1) by removing the screws (K4)
11

GIANT INDUSTRIES LIMITED WARRANTY
Giant Industries, Inc. pumps and accessories are warranted by the manufacturer to be free from defects in
workmanship and material as follows:
1. Five (5) years from the date of shipment for all pumps used in portable pressure
washers with NON-SALINE, clean water applications.
2. Two (2) years from the date of shipment for Giant pumps used in car wash
applications.
3. One (1) year from the date of shipment for all other Giant industrial and consumer
pumps.
4. Six (6) months from the date of shipment for all rebuilt pumps
5. Ninety (90) days from the date of shipment for all Giant accessories.
This warranty is limited to repair or replacement of pumps and accessories of which the manufacturer’s
evaluation shows were defective at the time of shipment by the manufacturer. The following items are NOT
covered or will void the warranty:
1. Defects caused by negligence or fault of the buyer or third party.
2. Normal wear and tear to standard wear parts.
3. Use of repair parts other than those manufactured or authorized by Giant.
4. Improper use of the product as a component part.
5. Changes or modications made by the customer or third party.
6. The operation of pumps and or accessories exceeding the specications set forth
in the Operations Manuals provided by Giant Industries, Inc.
Liability under this warranty is on all non-wear parts and limited to the replacement or repair of those products
returned freight prepaid to Giant Industries which are deemed to be defective due to workmanship or failure of
material. A Returned Goods Authorization (R.G.A.) number and completed warranty evaluation form is required
prior to the return to Giant Industries of all products under warranty consideration. Call (419)-531-4600 or fax
(419)-531-6836 to obtain an R.G.A. number.
Repair or replacement of defective products as provided is the sole and exclusive remedy provided hereunder
and the MANUFACTURER SHALL NOT BE LIABLE FOR FURTHER LOSS, DAMAGES, OR EXPENSES,
INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES DIRECTLY OR INDIRECTLY ARISING FROM
THE SALE OR USE OF THIS PRODUCT.
THE LIMITED WARRANTY SET FORTH HEREIN IS IN LIEU OF ALL OTHER WARRANTIES OR
REPRESENTATION, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY WARRANTIES
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE AND ALL SUCH WARRANTIES
ARE HEREBY DISCLAIMED AND EXCLUDED BY THE MANUFACTURER.
WARNING: This product might contain a chemical known to the State of California to cause cancer,
and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
10/20 GP8055_60_65-Brine.indd
GIANT INDUSTRIES, INC.
900 N. Westwood Ave.
Toledo, Ohio 43607
[phone]
FAX [phone]
www.giantpumps.com
© Copyright 2020 Giant Industries, Inc.
Pump Dimensions (mm) - GP8055/GP8060/GP8065 - Brine
