Gigabyte M28U Arm Edition User manual

- 2 -
Gaming Monitor User Guide
Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their
respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the
property of GIGABYTE.
Changes to the specications and features in this manual may be made
by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without
GIGABYTE’s prior written permission.
• In order to assist in the use of this monitor, carefully read the User
Guide.
• For more information, check on our website at:
https://www.gigabyte.com
The terms HDMI, HDMI High-Denition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc. in the United States and other countries.

- 3 -
Gaming Monitor User Guide
Safety Precautions
Read through the following Safety Precautions before using the monitor.
• Only use the accessories that are provided with the monitor or that
which are recommended by the manufacturer.
• Keep the plastic packaging bag for the product in a place that
cannot be reached by children.
• Before connecting the monitor to the power outlet, make sure that
the voltage rating of the power cable is compatible with the power
specication in the country where you are located.
• The power cord plug must be connected to a properly wired and
grounded power outlet.
• Do not touch the plug with wet hands, otherwise easily cause
electric shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric
radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not
cover or block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids.
Failure to do so may result in electric shock or damage to the
monitor.
• Make sure to unplug the monitor from the power outlet before
cleaning.
• As the screen surface is easy to be scratched, avoid touching the
surface with any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen. You
may use a glass cleaner to clean the monitor if required. However,
never spray the cleaner directly onto the screen.
• Disconnect the power cable if the monitor is not being used for a
long period of time.
• Do not attempt to disassemble or repair the monitor yourself.

- 4 -
Gaming Monitor User Guide
Stability Hazard Precautions
The product may fall, causing serious personal injury or death. To
prevent injury, this product must be securely attached to the oor/wall in
accordance with the installation instructions.
Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
• ALWAYS use stands or installation methods recommended by the
manufacturer of the product set.
• ALWAYS use furniture that can safely support the product.
• ALWAYS ensure the product is not overhanging the edge of the
supporting furniture.
• ALWAYS educate children about the dangers of climbing on furniture
to reach the product or its controls.
• ALWAYS route cords and cables connected to your product so they
cannot be tripped over, pulled or grabbed.
• NEVER place a product in an unstable location.
• NEVER place the product on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the product to
a suitable support.
• NEVER place the product on cloth or other materials that may be
located between the product and supporting furniture.
• NEVER place items that might tempt children to climb, such as toys
and remote controls, on the top of the product or furniture on which
the product is placed.
• If the existing product is going to be retained and relocated, the
same considerations as above should be applied.
• To prevent personal injury or damage to the product caused by
tipping over due to earthquakes or other shocks, make sure to install
the product in a stable location and take measures to prevent falling.

- 5 -
Gaming Monitor User Guide
CONTENTS
Safety Precautions............................................................................................................3
Stability Hazard Precautions.........................................................................................4
Introduction .................................................................................................................................6
Unpacking...........................................................................................................................6
Package Contents.............................................................................................................8
Product Overview.............................................................................................................9
Getting Started.........................................................................................................................11
Installing the Monitor Arm.........................................................................................11
Adjusting the Viewing Angle.....................................................................................14
Installing a Wall-Mount Bracket (Optional) ..........................................................21
Making Connections ....................................................................................................22
Using the Device......................................................................................................................23
Turning the Power On/O..........................................................................................23
User Comfort Recommendations............................................................................24
Selecting the Input Source.........................................................................................24
Operations .................................................................................................................................25
Quick Menu......................................................................................................................25
Congure the Device Settings..................................................................................33
Appendices................................................................................................................................43
Specications..................................................................................................................43
Supported Timing List..................................................................................................44
Troubleshooting............................................................................................................. 45
Basic Care..........................................................................................................................46
Notes on USB Charging...............................................................................................46
GIGABYTE Service Information................................................................................. 46
Safety Information ..................................................................................................................47
Regulatory Notices........................................................................................................47

- 6 -
Gaming Monitor User Guide
INTRODUCTION
Unpacking
1. Making sure the box is in the correct orientation, carefully lay the
box on the stable surface. Then open the cover.
UP
2. Remove the items from the upper EPS foam.

- 7 -
Gaming Monitor User Guide
3. Remove the upper EPS foam from the box. Then you can remove the
monitor from the lower EPS foam.

- 8 -
Gaming Monitor User Guide
Package Contents
The following items come with your packaging box. If any of them is
missing, please contact your local dealer.
Monitor Arm Clamp
Screws Pack Power Cable HDMI Cable
Multilingual
Installation
Guide
M28U Arm Edition
USB Cable DP Cable Quick Start Guide
Warranty Card
Warranty Card
Note: Please keep the packaging box and packing materials for future
transportation of the monitor.

- 9 -
Gaming Monitor User Guide
Product Overview
Front View
GAMING
1
1Power LED

- 10 -
Gaming Monitor User Guide
Rear View
DPHDMI-2TYPE-C USB 3.0
HDMI-1
DP TYPE-CHDMI-1 HDMI-2 USB 3.0
6 8 954 107
1 2 3
1Control button
2KVM button
3Kensington lock
4AC IN jack
5Headphone jack
6HDMI ports (x2)
7DisplayPort
8USB Type-C port
9USB upstream port
10 USB 3.0 ports (x3)
Note:
HDMI, the HDMI logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.

- 11 -
Gaming Monitor User Guide
GETTING STARTED
Installing the Monitor Arm
1. Align and install the bottom of the arm onto the clamp. Then secure
them with the screws.
2. Place the clamp to the table. Then tighten the knob to secure the
arm assembly.
15~30mm
30~70mm

- 12 -
Gaming Monitor User Guide
The Desk Mount kit attaches the monitor to surfaces up to 70mm
thick. Before starting, make sure you have enough room to t the
entire clamp and the surface is sturdy and at.
15~70mm
3. Align and slide the upper hooks on the arm into the mounting slots
on the rear of the monitor. Push the locking latch and then release
to secure the lower hooks on the arm into the mounting slots on the
rear of the monitor.

- 13 -
Gaming Monitor User Guide
CAUTION!
The C-clamp accessory is designed to be used with this monitor only.
Using this accessory with any other product may result in damage and/
or injury.
Make sure the mounting surface is at and strong enough to handle the
monitor. Do not install on glass surfaces.
Improper installation may cause property damage and/or personal
injury.

- 14 -
Gaming Monitor User Guide
Adjusting the Viewing Angle
Adjusting the Arm Tilt Angle
Tilt the arm forward or backward to the desired viewing angle (60˚).
60°
Adjusting the Screen Height
Lower or raise the screen to the desired height (0 to 50mm).
GAMING 50m
m

- 15 -
Gaming Monitor User Guide
Adjusting the Tilt Angle
Tilt the screen forward or backward to the desired viewing angle
(-5˚ to 25˚).
25°
-5°
Adjusting the Swivel Angle
Swivel the screen to the left or right for the desired viewing angle (100˚).
100°100°

- 16 -
Gaming Monitor User Guide
Swivel the stand to the left or right for the desired viewing angle
(±170˚).
±170°

- 17 -
Gaming Monitor User Guide
Changing the Screen Orientation
You can do one of the following:
• Rotate the monitor (0˚ to 5˚ counter-clockwise) to portrait
orientation.
GAMING
0°~5°
• Rotate the monitor (90˚ clockwise) to portrait orientation.
GAMING
90°
90°

- 18 -
Gaming Monitor User Guide
When placing the device, ensure that there is sucient space for
ventilation. The increasing internal temperature can lead to re and
damage the device.
A: Above 100mm
A
A
A
When adjusting the stand, please be careful not to put your hands/
thumb on the joints or moving parts of the stand.

- 19 -
Gaming Monitor User Guide
When adjusting the stand, please be careful not to turn the monitor
away from the desktop to avoid safety hazards.

- 20 -
Gaming Monitor User Guide
Using the cable management ring:
1. Release the cable management ring and route the cables.
2. Lock the cable management ring to secure the cables in place.
