Gigabyte M32U User manual

LCD Monitor User's Manual
- 2 -
Copyright
© 2020 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective
owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of
GIGABYTE.
Changes to the specications and features in this manual may be made by
GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted,
or published in any form or by any meanswithout GIGABYTE’s prior written
permission.
• In order to assist in the use of this monitor, carefully read theUser Guide.
• For more information, check on our website at:
https://www.gigabyte.com
The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.

LCD Monitor User's Manual
- 3 -
Safety Precautions
Read through the following Safety Precautions before using the monitor.
• Only use the accessories that are provided with the monitor or that which are
recommended by themanufacturer.
• Keep the plastic packaging bag for the product in a place that cannot be
reached by children.
• Before connecting the monitor to the power outlet, make sure that the voltage
rating of the power cable is compatible with the power specification in the
country where you arelocated.
• The power cord plug must be connected to a properly wiredand grounded
power outlet.
• Do not touch the plug with wet hands, otherwise easily cause electric
shock.
• Place the monitor in a stable and well-ventilatedplace.
• Do not place the monitor near any heat sources such as electric radiators or
direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not cover or
block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids. Failure to do
so may result in electric shock or damage to the monitor.
• Make sure to unplug the monitor from the power outletbefore cleaning.
• As the screen surface is easy to be scratched, avoid touchingthe surface with
any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen.You may use a
glass cleaner to clean the monitor if required. However, never spray the cleaner
directly onto the screen.
• Disconnect the power cable if the monitor is not being used for a long period
of time.
• Do not attempt to disassemble or repair the monitoryourself.

LCD Monitor User's Manual
- 4 -
Stability Hazard Precautions
The product may fall, causing serious personal injury or death. To prevent injury, this
product must be securely attached to the oor/wall in accordance with the installa-
tion instructions.
Many injuries, particularly to children, can be avoided by taking simple precautions
such as:
• ALWAYS use stands or installation methods recommended by the
manufacturer of the product set.
• ALWAYS use furniture that can safely support the product.
• ALWAYS ensure the product is not overhanging the edge of the supporting
furniture.
• ALWAYS educate children about the dangers of climbing on furniture to reach
the product or its controls.
• ALWAYS route cords and cables connected to your product so they cannot be
tripped over, pulled or grabbed.
• NEVER place a product in an unstable location.
• NEVER place the product on tall furniture (for example, cupboards or
bookcases) without
• anchoring both the furniture and the product to a suitable support.
• NEVER place the product on cloth or other materials that may be located
between the product and supporting furniture.
• NEVER place items that might tempt children to climb, such as toys and
remote controls, on the top of the product or furniture on which the product
is placed.
• If the existing product is going to be retained and relocated, the same
considerations as above should be applied.
• To prevent personal injury or damage to the product caused by tipping over
due to earthquakes or other shocks, make sure to install the product in a
stable location and take measures to prevent falling.

LCD Monitor User's Manual
- 5 -
Contents
INTRODUCTION............................................................................................. 6
Unpacking..........................................................................................................................6
Package Contents ...........................................................................................................8
Product Overview ...........................................................................................................9
GETTING STARTED ........................................................................................ 11
Installing the Stand Base ..............................................................................................11
Lift the monitor................................................................................................................12
Adjusting the Viewing Angle ......................................................................................13
Installing a Wall-Mount Bracket (Optional)............................................................15
Making Connections......................................................................................................17
USING THE DEVICE........................................................................................ 18
Turning the Power On/O............................................................................................18
User Comfort Recommendations..............................................................................19
Selecting the Input Source ..........................................................................................20
OPERATIONS.................................................................................................. 21
Quick Menu ................................................................................................... 21
Function Key Guide ........................................................................................................23
Congure the Device Settings....................................................................................28
APPENDICES.................................................................................................. 39
Specications....................................................................................................................39
Supported Timing List...................................................................................................40
Troubleshooting..............................................................................................................41
Basic Care ...........................................................................................................................42
Notes on USB Charging.................................................................................................42
GIGABYTE Service Information...................................................................................42
SAFETY INFORMATION ................................................................................. 43
Regulatory Notices .........................................................................................................43

LCD Monitor User's Manual
- 6 -
INTRODUCTION
Unpacking
1. Open the upper cover of the packaging box. Then observethe unpacking
instruction attached on the inner cover. Making sure the box is in the
correct orientation, carefully lay the box on the stable surfacepen.
2. Remove the items from the upper EPS foam.

LCD Monitor User's Manual
- 7 -
3. Remove the upper EPS foam.Then you can remove the stand from the lower EPS
foam.

LCD Monitor User's Manual
- 8 -
Package Contents
The following items come with your packaging box. If any of them is missing, please
contact your local dealer.
Monitor Monitor Base Power Cable
HDMI Cable
USB CableStand DP Cable
Multilingual
Installation
Guide
Warranty Card
Quick Start Guide Warranty Card
Note: Please keep the packaging box and packing materials for future transporta-
tion of the monitor.

LCD Monitor User's Manual
- 9 -
Product Overview
Front View
1
1Control button

LCD Monitor User's Manual
- 10 -
Rear View
9
76541 2 3 8
1AC IN jack
2AC power switch
3Kengsington lock
4HDMI ports (x2)
5DisplayPort
6Type-C port
7USB upstream port
8USB 3.0 ports (x3)
9Headphone jack

LCD Monitor User's Manual
- 11 -
GETTING STARTED
Installing the Stand Base
1. Align the Stand base with the stand o underneath the stand.Then attach the
base onto the stand. Tighten the screw to secure the monitor base inplace.
Note: You can either use a coin or a small athead screwdriver to tighten the screw.

LCD Monitor User's Manual
- 12 -
Lift the monitor
Take the monitor out of the box by holding the stand arm. Carefully lift the
monitor, turn it over and place it upright on its stand on a at even surface.
Remove the foam wrap from the monitor.
Note: Consider keeping the box and packaging in storage for use in the future when you may
need to transport the monitor. The tted foam packing is ideal for protecting the monitor
during transport.

LCD Monitor User's Manual
- 13 -
Adjusting the Viewing Angle
Note: Hold the monitor base so that the screen does not topple when you make the
adjustment.
Adjusting the Tilt Angle
Tilt the screen forward or backward to the desired viewing angle (-5˚ to 20˚).
20

LCD Monitor User's Manual
- 14 -
Changing the Screen Orientation
Raise the screen to the highest position (130mm).
Note: Before making the height adjustment, make sure you have removed the safety plate
from the stand.

LCD Monitor User's Manual
- 15 -
Installing a Wall-Mount Bracket (Optional)
Use only the 100 x 100 mm wall mount kit recommended by the
manufacturer.
1. Place the monitor on a at surface, with the screen facing down.
Note: We recommend that you cover the table surface with soft cloth to prevent damage
to the monitor.
2. Push the locking clips inward to detach the stand from themonitor.
3. Remove the stand.

LCD Monitor User's Manual
- 16 -
4. Attach the mounting bracket to the mounting holes at the rear of the monitor.
Then use the screws to secure the bracket in place.
100 mm
100 mm
Note: To mount the monitor on the wall, refer to the installation guide that is included in the
wall-mount bracket kit. VESA Mounting Screw M4 x 8mm minimum.

LCD Monitor User's Manual
- 17 -
Making Connections
1
124
35
USB 3.0PDHDMI-1 HDMI-2
6
7
1Power cable
2HDMI cable
3DisplayPort cable
4Type-C cable
5USB (A-Male to B-Male) cable
6USB cable
7Headphone cable

LCD Monitor User's Manual
- 18 -
USING THE DEVICE
Turning the Power On/O
Make sure the power switch next to the AC power input jack is switched to ON.
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor.The Power LED will light in
white, indicating the monitor is ready touse.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the monitor by
moving the Control button down ( ). Refer to page 23.

LCD Monitor User's Manual
- 19 -
User Comfort Recommendations
The following are some tips for comfortable viewing of your monitor:
• Optimal viewing distances for monitors range fromapproximately 510 mm to
760 mm (20”to30”).
• A general guideline is to position the monitor such that the top of the screen
is at or slightly below your eye-height when you are comfortably seated.
• Use adequate lighting for the type of work you areperforming.
• Take regular and frequent breaks (at least for 10 minutes) every half- hour.
• Be sure to periodically look away from your monitor screen and focus on a far
object for at least 20 seconds during the breaks.
• Eye exercise can help reduce eye strain. Repeat these exercises frequently: (1)
look up and down (2) slowly roll your eye (3)move your eyes diagonally.

LCD Monitor User's Manual
- 20 -
Selecting the Input Source
1.
2.
Move the Control button right
( ) to enter the Input menu.
Select Exit
Input
DisplayPort
HDMI 1
HDMI 2
Move the Control button center
( ) to select the desired
input source. Then press the
Control
Type-C
