ItemChecklist
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To
protectthemagainstdamage fromstaticelectricity,you shouldfollowsomeprecautionswhenever
you workon yourcomputer.
1.Unplug yourcomputerwhen working on the inside.
2.Useagrounded wriststrap beforehandling computercomponents.If you do nothave
one,touchbothofyourhandstoasafelygrounded objectortoametalobject, suchas
the powersupplycase.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,or
othercomponents.
4.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe
componentswheneverthe componentsareseparated fromthe system.
5.Ensurethatthe ATXpowersupplyisswitched off beforeyou plug inorremovethe ATX
owerconnectoron the motherboard.
If the motherboardhasmounting holes,buttheydon’tline up withthe holeson the baseand
thereareno slotstoattachthe spacers,do notbecomealarmed you can still attachthe spacersto
the mounting holes.Justcutthe bottomportion ofthe spacers(the spacermaybe alittlehardto
cutoff, sobe carefulofyourhands).Inthiswayyou can still attachthe motherboardtothe base
withoutworrying aboutshortcircuits.Sometimesyou mayneed tousetheplasticspringstoisolate
the screwfromthe motherboardPCBsurface,becausethecircuitwiremaybe nearbythehole.Be
careful,don’tletthe screwcontactanyprinted circuitwriteorpartson the PCBthatarenearthe
fixing hole,otherwiseitmaydamage the boardorcauseboardmalfunctioning.
Installing themotherboardtothechassis…
WARNING!
*ForGA-8IEX Only.** ForGA-8IEXP Only.
þTheGA-8IEXSeriesmotherboardo2PortUSB Cablex1
þIDE(ATA100)cablex1/Floppycablex1þ4PortUSB Cablex1
þIDE(ATA133)cablex2(**)þSPDIFKITx1(SPD-KIT)
þCD formotherboarddriver&utility(IUCD)þGA-8IEXSeriesuser’smanual
þIEEE 1394 Cablex1(**)þI/OShield
þQuickPCInstallationGuide þRAIDManual(**)
þMotherboardSettingsLabel

-4-GA-8IEX SeriesMotherboard
English
FormFactor—30.6cmx24.4cmATXsizeformfactor,4layersPCB.
Motherboard—GA-8IEX SeriesMotherboard:
GA-8IEX and GA-8IEXP
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—IntelPentium®4533MHz/400MHzFSB
—SupportIntel®Pentium®4(Northwood,0.13 m)processor
—2nd cache depend on CPU
Chipset—Chipset845EHOST/AGP/Controller
—ICH4I/OControllerHub
Memory—3184-pinDDR DIMM sockets
—SupportsPC2100 DDR orPC1600 DDR DIMM
—Supportsup to2GBDRAM(Max)
—Supportsonly2.5VDDR DIMM
I/OControl—IT8712
Slots—1CNR(Communication and Networking Riser) Slot(**)
—1AGPslot4X(1.5Vonly)devicesupport
—6PCIslotsupports33MHz&PCI2.2compliant
On-BoardIDE—2IDEcontrollerson the IntelICH4PCIchipset
providesIDEHDD/CD-ROM(IDE1,IDE2)withPIO,BusMaster
(UltraDMA33/ATA66/ATA100)operation modes.
—IDE3and IDE4CompatiblewithRAID,UltraATA133/100.(**)
On-BoardPeripherals—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M
and 2.88Mbytes.
—1ParallelportsupportsNormal/EPP/ECPmode
—2Serialports(COMA&COMB)
—6xUSB 2.0/1.1(2xRear,4xFrontbycable)
—1IrDAconnectorforIR/CIR
—1FrontAudioconnector
—1SerialIRQ(***)
—3IEEE1394 connector(**)
Chapter1Introduction
tobe continued......
Features Summary
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB 2.0Only.

Introduction
English
-5-
HardwareMonitor—CPU/Power/SystemFan Revolution detect
—CPU/Power/SystemFan Control
—CPUOverheatWarning
—SystemVoltage Detect
On-BoardSound —CreativeCT5880Sound Chipset+Sigmatel9708TCODEC
—Line Out/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn:Mic
—SPDIFout:bys/wswitch
—CD In/AUXIn/Gameport
On-BoardSound*** —RealtekALC650 CODEC
—LineOut/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn/center&subwoofer(bys/wswitch)
—SPDIFout/SPDIFIn(***)
—CD In/AUXIn/Gameport
On-BoardRAID(**)—OnboardPromisePDC20276
—Supportsdatastriping (RAID0)ormirroring(RAID1)
—SupportsconcurrentdualATA133IDEcontrolleroperation
—SupportATAPImode forCD ROM,DVDROM..etc.
—SupportsIDEbusmasteroperation
—SupportATA133/RAIDmode switchbyBIOS
—Mirroringsupportsautomaticbackgroundrebuilds
—FeaturesLBAandExtendedInterrupt13drivetranslationin
controlleronboardBIOS
On-BoardLAN—Intel82562ETLANPHY
On-BoardUSB 2.0—BuiltinICH4Chipset
On-Board1394(**)—BuiltinVT6306Chipset(**)
On-BoardMS(**),SC,—Winbond SMARTI/OChipset(MemoryStick ,SecurityDigitaland
SD(**)SCheader)
PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterace
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB 2.0Only.
tobe continued......

-6-GA-8IEX SeriesMotherboard
English
BIOS—Licensed AWARD BIOS,4Mbitx2FWH(**)
—Licensed AWARD BIOS,3Mbitx2FWH(*)
—SupportsDualBIOS
—SupportsMultiLanguage
—SupportsFaceWizard
—SupportsQ-Flash
AdditionalFeatures—PS/2Keyboardpoweron bypassword
—PS/2Mousepoweron
—ExternalModemwakeup
—STR(Suspend-To-RAM)
—WakeonLAN(WOL)
—ACRecovery
—Polyfuseforkeyboardover-currentprotection
—USB KB/Mousewakeup fromS3
—Supports@BIOS
—SupportsEasyTune 4
Overclocking —OverVoltage (DDR/AGP/CPU)byBIOS
—OverClock (DDR/AGP/CPU)byBIOS
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB 2.0Only.
Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor’sspecifications.
Wedon’trecommend you tosetthe systembusfrequency overthe CPU’sspecification
becausethesespecificbusfrequenciesarenotthe standardspecificationsforCPU,
chipsetand mostofthe peripherals.Whetheryoursystemcan run underthesespecific
busfrequenciesproperlywill depend on yourhardwareconfigurations,including CPU,
Chipsets,SDRAM,Cards….etc.

Introduction
English
-7-
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB2.0Only.
GA-8IEX Series MotherboardLayout
NB-FAN
SPDIF
DIMM_LED_CONN
SD** MS**
SC
GA-8IEX/8IEXP
KB_MS
COMA
COMB
GAME
LINE_IN
LINE_OUT
MIC_IN
USB
AUX_12V
CD_IN
F_AUDIO_I
AC97
WOL***
1394-2
IT8712
F_PANEL
BATTERY
BACKUP
BIOS
SYS_FAN
ICH4
Intel845E
SOCKET478
CPU_FAN
ATX
IR/CIR
FLOPPY
IDE1
IDE2
AGP
PCI1
PCI2
PCI3
PCI4
PCI5
PCI6
DDR3 DDR2
DDR1
CNR(**)
F_USB2
P4Titan533
PDC20276**
MAIN
BIOS
LPT1
LAN
F_USB1
VT6306**
82562ET
AUX_IN
IDE4**
IEEE1394**
CI
FrontUSB 2.0
1394-31394-1
CLR_CMOS
IDE3**
PWR_FAN
SPDIF_IN***
S_IRQ***
Buzzer***

-8-GA-8IEX SeriesMotherboard
English
Tosetup yourcomputer,you mustcompletethe following steps:
Step1-Installthe CentralProcessing Unit(CPU)
Step2-Install memorymodules
Step 3-Install expansion cards
Step 4-Connectribbon cables,cabinetwires,and powersupply
Step5-Setup BIOSsoftware
Step6-Installsupporting softwaretools
Chapter2HardwareInstallationProcess
Step4
Step4
Step2Step1Step4
Step3
Step4

-9-HardwareInstallation Process
English
Step1:Install theCentralProcessing Unit(CPU)
Step1-1:CPUInstallation
MPlease make suretheCPUtypeissupportedbythemotherboard.
Pin1indicator
3.CPUTop View
2.Pulltherodtothe90-degreedirectly.
4.LocatePin1inthesocketandlook
fora(golden)cutedgeon theCPU
uppercorner.TheninserttheCPU
intothesocket.
MIfyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill cause
improperinstallation.Please changetheinsertorientation.
Therearetwotypes forCPUsocket,please take noteofinstalling.
Type1Type2
Angling the
rod to650
Socket
Actuation
Lever
Pin1indicator
1.Anglingtherodto65-degreemaybefeela
kindoftight,andthencontinuepulltherod
to90-degreewhen anoise“cough”made.

-10 -GA-8IEX SeriesMotherboard
English
Step1-2:CPUHeatSinkInstallation
MPleaseuseIntelapprovedcoolingfan.
MWerecommendyoutoapplythethermaltapetoprovidebetterheatconductionbetween
yourCPUandheatsink.
(TheCPUcooling fanmightsticktotheCPUduetothehardeningofthethermalpaste.
Duringthisconditionifyoutrytoremovethecoolingfan,youmightpulltheprocessorout
oftheCPUsocketalonewiththecooling fan,andmightdamagetheprocessor.Toavoid
thisfromhappening,wesuggestyoutoeitherusethermaltapeinsteadofthermalpaste,or
removethecoolingfanwithextremecaution.)
MMakesuretheCPUfanpowercableispluggedintotheCPUfanconnector,thiscompletes
theinstallation.
MPleaserefertoCPUheatsinkuser’smanualformoredetailinstallation procedure.
2.Makesurethe CPUfan isplugged to
the CPUfan connector,than install
complete.
1.Fasten the heatsinksupporting-base
ontothe CPUsocketon the main-
board.

-11 -HardwareInstallation Process
English
Step2:Install memorymodules
The motherboardhas3dualinline memorymodule(DIMM)sockets,butitcan onlysupporta
maximumof4banks ofDDR memory.DDR socket1uses2banks,DDR socket2&3sharethe
remaining2banks.Pleaserefertothefollowingtablesforpossiblememoryconfigurationssupported.The
BIOSwill automaticallydetectsmemorytype and size.Toinstall the memorymodule,justpushit
verticallyintothe DIMM Slot.The DIMM modulecan onlyfitinone direction due tothe notch.
Memorysizecan varybetween sockets.
DDR
1.TheDIMMsockethasanotch,sotheDIMMmemory
modulecanonlyfitinonedirection.
2. InserttheDIMM memorymoduleverticallyintothe
DIMM socket. Then pushitdown.
3.Closethe plasticclipatbothedgesoftheDIMM
socketstolockthe DIMM module.
Reversethe installationstepswhenyou wishto
removethe DIMM module.
MWhenSTR/DIMM LEDisON,do notinstall/remove DIMM fromsocket.
MPlease notethattheDIMM modulecanonlyfitinonedirection dueto
thetwonotches.Wrong orientation will cause improperinstallation.
Please changetheinsertorientation.
D:DoubleSided DIMM S:SingleSided DIMM
X:NotUse
DDR1DDR2DDR3
S S S
DS S
D D X
DXD
SDX
S X D
Notes:Double-sided x16 DDR memorydevicesarenotsupportbyIntel845E/Gchipset.
SupportUnbuffered DDR DIMM Sizestype:
64 Mbit(2Mx8x4banks)64 Mbit(1Mx16x4banks)128 Mbit(4Mx8x4banks)
128Mbit(2Mx16x4banks)256 Mbit(8Mx8x4banks)256 Mbit(4Mx16x4banks)
512Mbit(16Mx8x4banks)512 Mbit(8Mx16x4banks)
TotalSystemMemory(Max2GB)

-12 -GA-8IEX SeriesMotherboard
English
Issues To BewareOfWhenInstalling CNR
PleaseusestandardCNR cardlikethe one inordertoavoidmechanicalproblem.
StandardCNR Card
Step3:Install expansion cards
1.Readtherelatedexpansioncard’sinstructiondocumentbeforeinstalltheexpansioncardinto
thecomputer.
2.Removeyourcomputer’schassiscover,necessaryscrewsand slotbracketfromthe computer.
3.Presstheexpansioncardfirmlyintoexpansionslotinmotherboard.
4.Besurethemetalcontactsonthecardareindeedseatedintheslot.
5.Replacethescrewtosecuretheslotbracketoftheexpansioncard.
6.Replaceyourcomputer’schassiscover.
7.Poweron thecomputer,ifnecessary,setupBIOSutilityofexpansioncardfromBIOS.
8. Installrelateddriverfromtheoperatingsystem.
AGPCard
Pleasecarefullypull outthe small white-
drawablebaratthe end ofthe AGPslot
when you trytoinstall/Uninstall the AGP
card.Pleasealign the AGPcardtothe
onboardAGPslotand press firmlydownon
the slot.MakesureyourAGPcardislocked
bythe small white-drawablebar.
MPlease note:
If M/Bhashardwareaudio(CT5880),yourmodemriser
hasbeen setto"Primary"automatically

-13 -HardwareInstallation Process
English
Step4:Connectribbon cables,cabinetwires,and power
supply
Step4-1:I/OBack PanelIntroduction
u PS/2Keyboardand PS/2Mouse Connector
PS/2MouseConnector
(6pinFemale)
PS/2KeyboardConnector
(6pinFemale)
ØThisconnectorsupportsstandardPS/2
keyboardand PS/2mouse.
u v w
x
y
v ParallelPortand SerialPorts(COMA/COMB)
ØThisconnectorsupports2standardCOMports
and 1Parallelport. Devicelikeprintercan be
connected toParallelport;mouseand modem
etccan be connected toSerialports.
ParallelPort
(25 pinFemale)
COMACOMB
SerialPorts(9pinMale)

-14 -GA-8IEX SeriesMotherboard
English
wGame/MIDIPorts
Joystick/MIDI(15 pinFemale)
ØThisconnectorsupportsjoystick,MIDIkeyboard
and otherrelateaudiodevices.
yUSB/LANConnectorØBeforeyou connectyourdevice(s)intoUSB
connector(s),pleasemakesureyourdevice(s)
suchasUSB keyboard,mouse,scanner,zip,
speaker..etc.HaveastandardUSBinterface.
AlsomakesureyourOS(Win95 withUSB
supplement,Win98,Windows2000,Windows
ME,WinNTwithSP 6)supportsUSBcontroller.
If yourOSdoesnotsupportUSBcontroller,
pleasecontactOSvendorforpossiblepatchor
driverupgrade.Formoreinformationplease
contactyourOSordevice(s)vendors.
USB 0
USB 1
LAN
yAudioConnectorsØAfterinstallonboardaudiodriver,youmayconnect
speakertoLine Outjack,microphone toMICInjack.
DevicelikeCD-ROM,walkman etccan be connected
toLine-Injack.
Pleasenote:
Youareabletouse2-/4-/6-channelaudiofeatureby
S/Wselection.
Ifyouwanttoenable6-channelfunction,youhave2
chooseforhardwareconnection.
Method1:
Connect“FrontSpeaker”to“LineOut”
Connect“RearSpeaker”to“LineIn”
Connect“Centerand Subwooferr”to“MICOut“.
Method2:
Youcanrefertopage18,andcontactyournearestdealer
foroptionalSUR_CENcable.
MICIn
(Centerand Subwoofer)
Line Out
(Front
Speaker)
LineIn
(RearSpeaker)
Ifyou wantthedetail information for2-/4-/6-channelaudiosetup
installation,pleasedownload8IE(CompleteVersion)manualfromGigabyte
web.

-15 -HardwareInstallation Process
English
Step4-2:Connectors&JumperSetting Introduction
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB2.0Only.
3 24 1 11
17
16
26
10
25
7
8
5
13
18
91415
19
23
22
21
6
2
4
20
12
24
16
1)ATXPower
2)AUX_12V
3)CPU_FAN
4)SYS_FAN
5)PWR_FAN
6)NB_FAN
7)FDD
8)IDE1/IDE2
9)IDE3/IDE4(**)
10)F_PANEL
11)DIMM_LED
12)IR/CIR
13)F_USB1/F_USB2
14)1394-1/1394-2/1394-3(**)
15)WOL(**,***)
16)S_IRQ(***)
17)SD(**)
18)SC
19)MS(**)
20)SPDIF
21)SPDIF_IN(***)
22)F_AUDIO_I
23)CD_IN
24)AUX_IN
25)SUR_CEN(***)
26)CI
27)CLR_CMOS
28)BATTERY

-16 -GA-8IEX SeriesMotherboard
English
3)CPU_FAN (CPUFanConnector)ØPleasenote,aproperinstallation ofthe CPU
coolerisessentialtopreventthe CPUfrom
running underabnormalcondition or
damaged byoverheating.The CPUfan
connectorsupportsMax.currentup to600mA.
ØThisconnector(ATX+12V)is
used onlyforCPUCoreVoltage.
1)AUX_12V(+12VPowerConnector)
4)SYS_FAN (SystemFanConnector)
1+12V/Control
Sense
GND
1
+12V/Control
SenseGND
1
2
3
4
+12V
GND +12V
GND
5)PWR_FAN (PowerFanConnector)
ØTheseconnectorallowyou tolinkwiththe
coolingfanon thesystemcasetolowerthe
systemtemperature.
2)ATX(ATXPowerConnector)ØACpowercordshouldonlybe connectedto
yourpowersupplyunitafterATXpower
cableand otherrelated devicesarefirmly
connected tothe mainboard.
PS-ON(SoftOn/Off)
3.3V
3.3V
GND
GND
VCC
+12V
5VSB (Stand by+5V)
PowerGood
3.3V
GND
GND
GND
GND
VCC
VCC
-12V
1
20
-5V
VCC
GND
1
+12V/Control
Sense
GND

-17 -HardwareInstallation Process
English
7,8)Floppy/IDE1/IDE2Connector
(Primary/Secondary]
9)IDE3/IDE4Connector
(RAID/ATA133,GreenConnector)(**)
ØImportantNotice:
Pleaseconnectfirstharddisk toIDE1
and connectCD_ROMtoIDE2.
Theredstripeoftheribboncablemustbethe
samesidewiththePin1.
1
FDD
IDE1
1
IDE2
IDE3
1
IDE4
ImportantNotice:
1.Theradstripeoftheribbncablemustbethe
samesidewiththePin1.
2. If you wishtouseIDE3and IDE4,pleaseuse
itinunitywithBIOS(eitherRAIDorATA133).
Then,installthecorrectdrivertohaveproper
operation.Fordetails,pleasereferto
theRAIDmanual.
Ifyou wantthedetail information for“RAID“
setup ,please download8IEX Series manual
(CompleteVersion)fromGigabyteweb.
http://www.gigabyte.com.tw.
1
6)NB_FAN ØIfyouinstalledwrong direction,theChipFan
willnotwork.SometimeswilldamagetheChip
Fan.(Usuallyblack cableisGND)
VCC
1
GND

-18 -GA-8IEX SeriesMotherboard
English
10)F_PANEL(2x7 pinsconnector)
ØPleaseconnectthepowerLED,PCspeaker,resetswitchand powerswitchetcofyourchassis
frontpaneltotheF_PANELconnectoraccordingtothepinassignmentabove.
HD+
PD_Y-
2 14
113
PD+
PW-
PW+
RST-
SPK+
SPK-1
1
RST+
HD-
PD_G-
HD (IDEHardDisk ActiveLED)Pin1:LEDanode(+)
Pin2:LEDcathode(-)
SPK (SpeakerConnector) Pin1:VCC(+)
Pin2-Pin3:NC
Pin4:Data(-)
RST(ResetSwitch)Open:NormalOperation
Close:ResetHardwareSystem
PD+/PD_G-/PD_Y-(PowerLED)Pin1:LEDanode(+)
Pin2:LEDcathode(-)
Pin3:LEDcathode(-)
PW(Soft PowerConnector) Open:NormalOperation
Close:PowerOn/Off
11)RAM_LED
+
-
ØDonotremovememorymoduleswhile
DIMM LEDison.It mightcauseshortor
otherunexpecteddamagesduetothe
2.5Vstand byvoltage.Removememory
modulesonlywhenACPowercordis
disconnected.

-19 -HardwareInstallation Process
English
12)IR/CIR(IR/CIR)ØMakesurethe pin1on the IRdeviceis
aling withpinone the connector.To
enablethe IR/CIRfunction on the board,
you arerequired topurchasean option IR/
CIRmodule.Fordetail information please
contactyourautherized Giga-Byte
distributor.
TouseIRfunction only,pleaseconnectIR
moduletoPin1 toPin5.
VCC
NC
IRRX
GND
IRTX
NC
VCC
GND
NC
CIRRX
1
14)1394-1/1394-2/1394-3(IEEE1394 Connector,Grey Connector)(**)
1
1394-1
GND GND
GND
VCCVCC
TPA0-
TPA0+
TPB0-
TPB0+
1
1394-2
GND GND
GND
VCC
TPA1-
TPA1+
TPB1-
TPB1+
1
1394-3
GND GND
GND
VCC
TPA2-
TPA2+
TPB2-
TPB2+
VCC
VCC
ØPleaseNote:Serialinterface
standardsetbyInstituteof
ElectricalandElectronics
Engineers,whichhasfea
tureslikehighspeed,high
bandwidthandhotplug.
13)F_USB1/F_USB2
(FrontUSBConnector,YellowConnector)
ØBecarefulwiththe polarityofthe front
panelUSB connector.Check the pin
assignmentwhileyou connectthe front
panelUSB cable.Pleasecontactyour
nearestdealerforoptionalfrontpanel
USB cable.
USB Dy-
Power
USB Dx-
USB Dx+
1
USB Dy+ USB Over Current
Power
GND
GND
USB2
USB Dy-
Power
USB Dx-
USB Dx+
1
USB Dy+
USB Over Current Power
GND
GND
USB1

-20 -GA-8IEX SeriesMotherboard
English
15)WOL(Wake on LAN)(**,***)
*ForGA-8IEX Only.** ForGA-8IEXP Only.*** ForPCB2.0Only.
ØThisconnectorallowsthe removeserversto
managethesystemthatinstalledthis
mainboardviayournetworkadapterwhich
alsosupportsWOL.
+5VSB
GND
Signal
1
16)S_IRQ(***)
VCC
1
GND
ØSerialIRQ(Forspecialdesign,forexample:
PCMCIAadd on card)
17)SD(SecureDigitalMemoryCardInterface,RedexideConnector)(**)
18)SC(SmartCardInterface,Black Connector)
19)MS(MemoryStick Interface,WhiteConnector)(**)
SD
1GND
SD1
VCC3
SD3
SD4
SD5
SDCLK
SDLED
SD2
SDPWCTL-
SC
1
5SCACLK
SCAPWCTL-
VCC
SCAC4
SCAIO
SCARST-
SCALED
GND
SCAC8
SCAPSNT
MS
1GND
MS1
VCC3
MS3
MS4
MS5
MSCLK
MSLED
MS2
MSPWCTL-
ØThedevicecouldbeexpandedforreadingFlash
Memory,suchasSD(SecurityDigital),
MS(MemoryStick)and SmartCardReader
Connector.The SmartICCardcould
increasesecurityinauthenticatingonline
transactions;thecardreaderdevice(inquire
localdistributor)madebyThirdPartycould
bepurchasedbyusers.
