Gigabyte W733-W30 User manual

W733-W30
Intel® Core™ W7 GPU Workstation
User Manual
Rev. 1.0

Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Warnings and Cautions
Before installing, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug all the power cords from the power supplies to disconnect power to the equipment.
• Shock Hazard! Disconnect all power supply cords before servicing.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives
and the internal system components to cool before touching them.
CAUTION!
• Do not operate the system for long periods with the access panel open or removed. Operat-
ing the system in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/o󰀨: To remove power from system, you must remove the system from
rack. Make sure the system is removed from the rack before opening the chassis, adding, or
removing any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the system and discon-nect
the cables attached to the system before servicing it. Otherwise, personal injury or equipment
damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives,
boards, and other parts. We recommend that you perform all procedures in this chapter only at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic
wrist strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensi-tive to electrostatic discharge (ESD). Hold boards only by their edges. After removing a
board from its protective wrapper or from the system, place the board component side up on a
grounded, static free surface. Use a conductive foam pad if available but not the board wrapper.
Do not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips
or with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the
jumper, causing intermittent problems with the function con-trolled by that jumper. Take care to
grip with, but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the
board may bend or break.

CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

Regulatory Notices
WEEE Symbol Statement
The symbol shown below is on the product or on its packaging, which indicates that this
product must be disposed of with other waste. Instead, the device should be taken to the
waste collection centers for activation of the treatment, collection, recycling and disposal
procedure. The separate collection and recycling of your waste equipment at the time of
disposal will help to conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment.
For more information about where you can drop off your waste equipment for recycling,
please contact your local government ofce, your household waste disposal service or where you purchased
the product for details of environmentally safe recycling.
●When your electrical or electronic equipment is no longer useful to you, "take it back" to your local or
regional waste collection administration for recycling.
Restriction of Hazardous Substances (RoHS) Directive Statement
GIGABYTE products have not intended to add and safe from hazardous substances (Cd, Pb, Hg, Cr+6,
PBDE and PBB). The parts and components have been carefully selected to meet RoHS requirement. More-
over, we at GIGABYTE are continuing our efforts to develop products that do not use internationally banned
toxic chemicals.
California Proposition 65 Warning
WARNING!
This product can expose you to chemicals including Lead, which is known to the State
of California to cause cancer, and Bisphenol A (BPA), which is known to the State of
California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
Battery WARNING!
This product can expose you to chemicals including Lead, which is known to the State
of California to cause cancer, and Bisphenol A (BPA), which is known to the State of
California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.

ႝᏔೕϷ٬Ҕྕࡋ;!ୖԵаΠ኱Ң
Rang)ҬࢬᒡΕ*
Operang Temperature
Non-operang temperature
Operang humidity
Non-operang humidity
10°C to 35°C
100-240V~, 12-6A, 50-60Hz
-40°C to 60°C
8%-80% (non-condensing)
20%-95% (non-condensing)
伺服器相關警告與注意事項
警告
為了避免電擊危險或損壞設備請注意:
• 不要切斷電源線的接地端子，接地端子是一個很重要的安全防護。
• 將電源線接到有接地功能的插座，此插座需位於使用者容易使用的範圍。
• 電源線的配線要避免被踩到，被絆到或被過度彎折，重壓。
警告
• 本設備關機後內部仍存在電源，須拔掉電源線才能完全切掉設備內部的電源。
• 更換零件前請確定電源已經完全切斷。
• 電源線,電話線，網路線可能帶電，維修前除了移除電源線外也請移除所有連接線，避
免電擊傷害或是設備損壞。
• 維修非支援熱插拔的零件時須將伺服器從機櫃取下才能維修。
警告
• 避免人員燙傷，觸摸磁碟機或是內部零件前請確保該零件已經冷卻。
警告
• 伺服器中有高速風扇，維修時請遠離風扇避免受傷。
警告
• 本設備不能用在有兒童出現的區域。

警告
• 如果更換錯誤電池會產生爆炸，請以相同或同型號電池更換使用。
• 廢電池請回收。
᝾֋Ǻӵ݀׳ඤᒱᇤႝԣ཮ౢғᛈࣆ!!ፎа࣬ӕ܈ӕࠠႝԣ׳ඤ٬Ҕ
注意
• 伺服器開機時不要長時間移除蓋子，長時間移除蓋子會造成散熱功能失效造成損壞。
注意
• 靜電會損害電子產品，建議您在符合靜電防護的工作環境操作伺服器，如果無法確定
環境的靜電防護。請穿上靜電手環並且將手環接到有接地的金屬表面如機櫃或機殼。
• 拿取電路板時僅觸碰板子的邊緣，不要觸碰連接器。板子從防靜電包裝取出後只能放
置在無靜電的桌面，零件面朝上。如果可以, 請使用防靜電泡棉. 避免使用靜電袋. 避免
電路板與任何表面摩擦產生靜電。

- 11 -
Table of Contents
Chapter 1 Hardware Installation ...................................................................................13
1-1 Installation Precautions.................................................................................. 13
1-2 Product Specications.................................................................................... 14
1-3 System Block Diagram................................................................................... 17
Chapter 2 System Appearance.....................................................................................18
2-1 Front View...................................................................................................... 18
2-2 Rear View....................................................................................................... 19
2-3 Rear Panel System LAN LEDs ...................................................................... 20
Chapter 3 System Hardware Installation ......................................................................21
3-1 Removing and Installing the Chassis Cover .................................................. 22
3-2 Installing the CPU .......................................................................................... 23
3-3 Installing the Memory..................................................................................... 24
3-3-1 Dual Channel Memory Conguration .....................................................................24
3-3-2 Installing the Memory ............................................................................................25
3-4 Installing the PCI Expansion Card ................................................................. 26
3-5 Installing the Hard Disk Drive......................................................................... 27
3-6 Installing and Removing the M.2 SSD Module............................................... 28
3-7 Installing and Removing the M.2 WiFi Module............................................... 28
3-8 Peripheral Devices Connection...................................................................... 29
Chapter 4 Motherboard Components ...........................................................................30
4-1 Motherboard Components ............................................................................. 30
4-2 Jumper Setting .............................................................................................. 32
Chapter 5 BIOS Setup ..................................................................................................33
5-1 The Main Menu .............................................................................................. 35
5-2 Advanced Menu ............................................................................................. 38
5-2-1 CPU Conguration..................................................................................................39
5-2-2 ME Conguration....................................................................................................40
5-2-3 Trusted Computing .................................................................................................41
5-2-4 Runtime Error Logging Settings .............................................................................42
5-2-5 S5 RTC Wake Settings...........................................................................................43
5-2-6 Serial Port Console Redirection .............................................................................44
5-2-7 SIO Conguration...................................................................................................48
5-2-8 USB Conguration..................................................................................................49

- 12 -
5-2-9 Network Stack Conguration ..................................................................................50
5-2-10 CSM Conguration .................................................................................................51
5-2-11 Offboard SATA Controller Conguration .................................................................52
5-2-12 WHEA Conguration...............................................................................................53
5-2-13 Chipset Conguration.............................................................................................54
5-2-14 Tls Auth Conguration ............................................................................................55
5-2-15 iSCSI Conguration................................................................................................56
5-2-16 Intel(R) Ethernet Controller I225-V ........................................................................57
5-2-17 Driver Health...........................................................................................................58
5-3 Chipset Menu................................................................................................. 59
5-3-1 System Agent (SA) Conguration...........................................................................60
5-3-2 PCH-IO Conguration.............................................................................................63
5-4 Server Management Menu............................................................................. 64
5-4-1 System Event Log ..................................................................................................66
5-4-2 View FRU Information ............................................................................................67
5-4-3 BMC Network Conguration ...................................................................................68
5-4-4 IPv6 BMC Network Conguration...........................................................................69
5-5 Security Menu ................................................................................................ 70
5-5-1 Secure Boot ...........................................................................................................71
5-6 Boot Menu...................................................................................................... 74
5-7 Save & Exit Menu........................................................................................... 76
5-8 BIOS Recovery .............................................................................................. 77
5-9 BIOS POST Beep code (AMI standard)......................................................... 78
5-9-1 PEI Beep Codes.....................................................................................................78
5-9-2 DXE Beep Codes ...................................................................................................78

- 13 -
Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the user manual and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

- 14 -
Hardware Installation
1-2 Product Specications
System
Dimension
Pedestal
726.3 x 218 x 455 mm
Motherboard MW34-SP0
CPU 13th Intel® Core™ Desktop Processor
Sigle Processor
up to 24-core, 32 threads
Socket LGA 1700 Socket
Chipset Intel® W680
Memory 4 x DIMM slots
DDR4 memory module supported only
2 channel memory architecture
Support for 3200/2933/2666/2400/2133 MHz; ECC & non-ECC; buffered &
unbuffered; UDIMM module
Total up to 128GB of system memory (32GB single UDIMM capacity)
LAN 1 x 2.5GbE LAN (Intel® i225)
1 x 10/100/1000 management LAN (Realtek® RTL8211FD)
Video Integrated in Aspeed® AST2600:
- 1 x VGA port
Audio Realtek® ALC897 controller
Supports 2/4/5.1/7.1 channel congurations
3 ports Audio Jack (Audio in/Audio out/Mic)
Storage 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays
Additional 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays (Option)
4 x M.2 slot for storage (M-Key; NGFF-2280 or 22110; PCIe Gen4 x4)
NOTE: SAS card is required for SAS devices support Storage adapter is required
for 2.5" NVMe SSD installed
RAID intel® RAID 0, RAID 1, RAID 5 and RAID 10
Peripheral
Drives 5.25" space reserved for ODD device
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 15 -
Hardware Installation
Expansion Slot Slot_6: 1 x PCIe x16 (Gen5 x16 or Gen5 x8) slot
Slot_3: 1 x PCIe x16 (Gen5 x0 or Gen5 x8) slot
Slot_1: 1 x PCIe x4 (Gen3 x4) slot
1 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 from CPU
- Supports NGFF-2280/22110 card
3 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 from chipset
- Supports NGFF-2280 cards
Internal I/O
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
8 x SATA III 6Gb/s ports
1 x USB3.2 gen2x2 Type-C® header
1 x USB3.2 gen1 header for 2 ports
2 x USB2.0 headers for 2 ports
1 x Front panel header
1 x TPM header
1 x M.2 slot for Wi-Fi
1 x CPU fan header
6 x System fan headers
Front I/O 2 x USB 3.2 Gen1 Type-A
1 x Power Button
1 x Reset Button
1 x Audio and MIC Jack
1 x Power LED
1 x HDD LED
1 x Alert LED
Rear I/O 1 x VGA
1 x COM
1 x HDMI
1 x DP
1 x USB 3.2 gen2x2 Type-C®)
3 x USB 3.2 gen1 Type-A
1 x MLAN
1 x 2.5G LAN
1 x ID Button
1 x 3 in 1 Audio jack
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

- 16 -
Hardware Installation
Power Supply 1 x 850W ATX PSU
80 PLUS Gold
AC Input:
- 100-240V~/ 12-6A, 50-60Hz
DC Output:
- Max 850W/ 100-240V
+12V / 70.8A
+5V / 20A
+5Vsb / 3A
+3.3V / 20A
System
Management
ASPEED® AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Operating
Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

- 17 -
Hardware Installation
1-3 System Block Diagram

- 18 -
System Appearance
Chapter 2 System Appearance
2-1 Front View
5
6
1
34
2
7 8
No. Description No. Description
1. USB 3.2 Gen1 5. Reset
2. System LED 6. Power Button
3. HDD LED 7. Earphone
4. Power LED 8. MIC

- 19 -
System Appearance
2-2 Rear View
3
1
2
8
7
12
6
4
9
5
10
13
14
11
No. Description No. Description
1. VGA/COM Port 8. Sever Management LAN Port
2. HDMI 2.1 Port 9. ID Button with LED
3. Display Port 10. MIC-IN (Pink)
4. USB 3.2 Type C Port 11. LINE-OUT (Green)
5USB 3.2 Type A Port 12. LINE-IN (Blue)
6. 2.5GbE LAN Port 13. PCIe Card Bay
7. USB 3.0 Ports 14. PSU (AC 220V)
The HDMI port is HDCP 2.3 compliant and supports Dolby TrueHD and DTS HD Master Audio formats.
It also supports up to 192KHz/24bit 7.1-channel LPCM audio output. You can use this port to connect
your HDMI-supported monitor. The maximum supported resolution is 4096x2160@60Hz, but the actual
resolutions supported are dependent on the monitor being used.

- 20 -
System Appearance
2-3 Rear Panel System LAN LEDs
No. Name Color Status Description
1. 2.5GbE
Speed LED
Yellow On 1 Gbps data rate
Green On 2.5 Gbps data rate
N/A Off 100 Mbps data rate
2. 1GbE Link /
Activity LED
Green On Link between system and network or no access
Blink Data transmission or reception is occurring.
N/A Off No data transmission or reception is occurring.
3. 1GbE
Speed LED
Yellow On 1 Gbps data rate
Green On 100 Mbps data rate
N/A Off 10 Mbps data rate
1
23
2

- 21 -
System Hardware Installation
Pre-installation Instructions
Computer components and electronic circuit boards can be damaged by electrostatic discharge.
Working on computers that are still connected to a power supply can be extremely
dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to
yourself.
• Always disconnect the computer from the power outlet whenever you are working inside the
computer case.
• If possible, wear a grounded wrist strap when you are working inside the computer case.
Alternatively, discharge any static electricity by touching the bare metal system of the computer
case, or the bare metal body of any other grounded appliance.
• Hold electronic circuit boards by the edges only. Do not touch the components on the board
unless it is necessary to do so. Do not ex or stress the circuit board.
• Leave all components inside the static-proof packaging until you are ready to use the component
for the installation.
Chapter 3 System Hardware Installation
