GIGAIPC iTXL-1135G7A User manual

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
1www.gigaipc.com
iTXL-1135G7A
iTXL-1115G4EA
Thin Mini-ITX Motherboard
User’s Manual 1st Ed

2
www.gigaipc.com
Copyright Notice
This document is copyrighted, 2022. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for any
infringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy,
GIGAIPC assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
GIGAIPC reserves the right to make changes in the product design
without notice to its users.

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
3www.gigaipc.com
Acknowledgement
All other products’ name or trademarks are properties of their
respective owners.
• AMD® is trademark of Advanced Micro Devices.
• Microsoft Windows is a registered trademark of Microsoft Corp.
• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel
Corporation
• Core, Atom are trademarks of Intel Corporation
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

4
www.gigaipc.com
Packing List
Before setting up your product, please make sure the following items
have been shipped:
Item Quantity
iTXL-1135G7A or iTXL-1115G4EA MB 1
SATA power cable 2
I/O Bracket 1
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
5www.gigaipc.com
About this Document
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware
and software features (if any), its specifications, dimensions, jumper/
connector settings/definitions, and driver installation instructions (if
any), to facilitate users in setting up their product.
Users may refer to the GIGAIPC.com for the latest version of this
document.

6
www.gigaipc.com
Safety Precautions
Please read the following safety instructions carefully. It is advised that
you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the
device.
3. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
4. Always completely disconnect the power before working on the
system’s hardware.
5. No connections should be made when the system is powered
as a sudden rush of power may damage sensitive electronic
components.
6. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before
cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray
detergents.
9. Make sure the device is installed near a power outlet and is
easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent
falls
12. Do not cover the openings on the device to ensure optimal heat
dissipation.

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
7www.gigaipc.com
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is
running
15. Never pour any liquid into the openings. This could cause fire or
electric shock.
16. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge
when installing the internal components. Use a grounding
wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please the contact our
service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S
PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO
PREVENT DAMAGE.

8
www.gigaipc.com
FCC Statement
This device complies with Part 15 FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device
must accept any interference received including
interference that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant
et les directives gouvernementales de recyclage.

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
9www.gigaipc.com
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
GIGAIPC Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电
子组件
○ ○ ○ ○ ○ ○
外部信号
连接器
及线材
○ ○ ○ ○ ○ ○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此 产 品 所 标 示 之 环 保 使 用 期 限，系 指 在 一 般 正 常 使 用 状 况下。

10
www.gigaipc.com
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
GIGAIPC Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components O O O O O ○
Wires &
Connectors
for External
Connections
O O O O O O
O：The quantity of poisonous or hazardous substances or elements found in each
of the component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least
one of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this
product is applicable under normal usage only

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
11 www.gigaipc.com
Table Contents
Thin Mini-ITX Motherboard 1
User’s Manual 1st Ed
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List................................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement.............................................................................. 8
China RoHS Requirements (CN).................................................... 9
China RoHS Requirement (EN) ................................................... 10
Chapter 1 - Product Specifications 13
1.1 Specifications ............................................................... 15
Chapter 2 – Hardware Information 17
2.1 Jumpers and Connectors ............................................. 18
2.1.1 Rear I/O Connector ...................................................... 21
2.2.1 DC_IN1 (DC In Jack)....................................................... 22
2.2.2 HDMI_21, HDMI_43 (HDMI connector) ....................... 23
2.2.3 USB3 (USB 3.2 Gen 1 connector).................................. 24
2.2.4 USB31 (USB 3.2 Gen 2x1 connector) ............................ 25
2.2.5 LAN1 (GbE LAN connector)........................................... 26
2.2.6 LAN2 (2.5GbE LAN connector)...................................... 27
2.2.7 DC_IN2 (ATX 2x2 pin power connector)....................... 28
2.2.8 SYS_FAN (System fan connector) ................................. 29

12
www.gigaipc.com
2.2.9 CPU_FAN (CPU fan connector) ..................................... 30
2.2.10 BKL_EDP (Backlight control header for EDP) ................ 31
2.2.11 JCOM4, JCOM3, JCOM2, JCOM1 (RI# pin RI#/5V/12V
Select for COM1, COM2, COM3, COM4 port) ............ 32
2.2.12 COM1~4 (COM header (RS-232/422/485 & RI/5V/12V)
...................................................................................... 33
2.2.13 GPIO_CNT (General Propose input/output header) ..... 34
2.2.14 AT_CN (AT/ATX mode select jumper) ......................... 35
2.2.15 LVDS (LVDS connector)................................................ 36
2.2.16 SO-DIMM1, SO-DIMM2 (2 x DDR4 SO-DIMM Slot) .... 37
2.2.17 SYS_PANEL (Front panel header) .................................. 38
2.2.18 F_USB2_1, F_USB2_2 (USB 2.0 header) ........................ 39
2.2.19 TPM_SPI (Trusted Platform Module Connector).......... 40
2.2.20 SATAPW0 (SATA power connector) ................................41
2.2.21 SATA0 (SATA 6Gb/s connector) ..................................... 42
2.2.22 F_USB3 (USB 3.2 Gen 1 header).................................... 43
2.2.23 SPKR (Speaker out connector) ...................................... 44
2.2.24 FP_AUDIO (Front panel audio header).......................... 45
2.2.25 MPCIE (Mini PCIE connector)...................................... 46
2.2.26 M2E (M.2 Slot, E-key, Support NGFF-2230) ................. 47
2.2.27 EDP (Embedded Display Port Connector)................... 48
2.2.28 M2M (M.2 Slot, M-key, Support NGFF-2280) .............. 49
2.2.29 LSW (LVDS resolution jumper) ...................................... 50
2.2.30 BKL_LVDS (Backlight Control header for LVDS)............. 51
2.2.31 ME (ME Enable Jumper) ............................................... 52

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
13 www.gigaipc.com
Chapter 3 – BIOS 53
3.1 Introduction .................................................................. 54
3.2 The Main Menu............................................................. 55
3.3 Advanced ...................................................................... 56
3.3.1 TPM Configuration........................................................ 57
3.3.2 SATA And RST Configuration......................................... 59
3.3.3 CPU Configuration ........................................................ 60
3.3.4 IT8786 Super IO Configuration ..................................... 61
3.3.5 Hardware Monitor ........................................................ 62
3.3.6 S5 RTC Wake Settings ................................................... 63
3.3.7 Network Stack Configuration........................................ 64
3.3.8 NVMe Configuration..................................................... 65
3.3.9 Offboard SATA Controller Configuration ...................... 66
3.3.10 Digital IO Port Configuration ........................................ 67
3.4 Chipset .......................................................................... 68
3.5 Security ......................................................................... 70
3.6 Boot............................................................................... 73
3.7 Save & Exit .....................................................................74

Thin Mini-ITX Motherboard iTXL-1135G7A/ 1115G4EA
14 www.gigaipc.com
Chapter 1
Chapter 1 - Product Specifications

15
www.gigaipc.com
157.486.35
170
4.9 132.08
154.94
170
1.
6 18.05
10.1

Thin Mini-ITX Motherboard iTXL-1135G7A/ 1115G4EA
16 www.gigaipc.com
1.1 Specifications
Motherboard iTXL-1135G7A
(MTGU5AT)
iTXL-1115G4EA
(MTGU3AT)
Form Factor Thin Mini-ITX form factor
170W x 170D (mm)
CPU
Intel® Core™ i5-1135G7
Processor
10nm SuperFin, 4 cores, 8
threads, up to 4.2 GHz
TDP 28W
8 MB Smart Cache
Intel® Core™ i3-1115G4E
Processor
10nm SuperFin, 2 cores, 4
threads, up to 3.90 GHz
TDP 28W
6 MB Smart Cache
Socket 1 x FCBGA1449
Chipset —
Memory 2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual Channel DDR4 3200 MHz memory modules
Ethernet 1 x GbE LAN Port (Intel® I219V)
1 x 2.5GbE LAN Port (Intel® I226V)
Video
Integrated Graphics Processor - Intel® Iris® Xᵉ Graphics:
4 x HDMI 2.0 ports, supporting a maximum resolution of
4096x2304 @60Hz
1 x LVDS port, supporting a maximum resolution of 1920x1080
@60Hz
1 x eDP port, supporting a maximum resolution of 4096x2304
@60Hz
(4 independent display outputs)
Audio Realtek® Audio Codec
Storage 1 x SATA 6Gb/s Port
Raid RAID 0/1
Expansion Slots
1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x Full-size Mini PCIe with SIM slot
1 x 2230 M.2 E-key

17
www.gigaipc.com
Motherboard iTXL-1135G7A
(MTGU5AT)
iTXL-1115G4EA
(MTGU3AT)
Internal I/O
1 x 4-pin ATX main power connector
1 x SATA Power connector
1 x CPU fan header
1 x System fan header
1 x Front panel header
1 x Front panel audio header
4 x USB 2.0 headers
2 x USB 3.2 Gen 1 headers
4 x COM headers (RS-232/422/485 & RI/5V/12V)
1 x 2W Speaker out header
1 x Backlight Control header for eDP
1 x Backlight Control header for LVDS
1 x GPIO (8 bits) & SMBus header
1 x Buzzer
1 x AT/ATX mode select jumper
Rear I/O
2 x Audio Jacks (Line out, Mic in)
4 x HDMI
2 x RJ45 LAN Ports
2 x USB 3.2 Gen 2x1
2 x USB 3.2 Gen 1
1 x DC Jack (+12~24VDC)
TPM 1 x TPM Header (SPI)
OS Compatibility Windows 10/11 (x64)
Operating
Properties
Operating temperature: 0°C to 60°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-condensing)

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
18 www.gigaipc.com
Chapter 2
Chapter 2 – Hardware Information

2.1 Jumpers and Connectors
19
www.gigaipc.com
1
8
20
32 4 5 6
10
11
13
14
15
1618
19
21
22
23
24
25
26
27
28
29
30
7
9
12
17
31
32

Thin Mini-ITX Motherboard iTXL-1135G7A / 1115G4EA
20 www.gigaipc.com
No Code Description
1DC_IN1 DC In Jack
2HDMI_21
HDMI_43 HDMI connector
3USB3 USB 3.2 Gen 1 connector
4USB31 USB 3.2 Gen 2x1 connector
5LAN1
LAN2 2 x RJ45 LAN Ports
6HP_OUT 1 x Audio jack (Line out)
7MIC 1 x Audio jack (Mic in)
8DC_IN2 ATX 2x2 pin power connector
9SYS_FAN System fan connector
10 CPU_FAN CPU fan connector
11 BKL_EDP Backlight Control header for EDP
12
JCOM4
JCOM3
JCOM2
JCOM1
RI# pin RI#/5V/12V Select for COM1, COM2,
COM3, COM4 ports
13
COM4
COM3
COM2
COM1
COM header (RS-232/422/485 & RI/5V/12V)
14 GPIO_CNT General Purpose input/output header
15 AT_CN AT/ATX mode select jumper
16 LVDS LVDS connector
17 SODIMM1
SODIMM2 2 x DDR4 SO-DIMM Sockets
