GILES OVH-10-C Installation and operating instructions

Giles Enterprises, Inc.
An ISO 9001-2008 Registere Company • Committe to Quality
2750 Gunter P rk Drive West • Montgomery, AL 36109 USA
Phone: [phone] • F x: 334.239.4117 • Website: www.gfse.com
Toll Free: 800.554.4537 (USA & Cana a Only)
OVH-10-C
Operations & Service Manual
Item No. 65906 (Rele se D te 8/27/12: Rev. A)

LIMITED WARRANTY
• Subject to the terms and conditions of this Limited Warranty as herein stated, a Gi es Enterprises,
Inc., Foodservice Equipment and parts purchased new from an authorized Gi es Enterprises, Inc.,
representative are warranted as to defects in materia or workmanship for a period of 24 months
from the date of insta ation, provided, however, that with regard to abor costs in connection with
this warranty, see be ow. A insta ations must be made by a qua ified insta ing agency in accor-
dance with a app icab e codes and/or regu ations in the jurisdiction in which insta ed. Limited war-
ranty coverage is extended to the origina owner on y and is void if the unit is reso d.
• During the Limited Warranty period, Gi es Enterprises, Inc. wi rep ace or recondition, at its factory,
any part or parts of this unit which Gi es Enterprises, Inc. inspectors judge defective, provided the
unit has been subjected to norma usage, proper y insta ed, operated and serviced. This Limited
Warranty does not cover cosmetic damage, and damage due to acts of God, accident, misuse, a ter-
ation, neg igence, abuse of the Gi es Foodservice Equipment or the use of unorthodox repair meth-
ods. A parts rep aced under this Limited Warranty carry on y the unexpired term of this Limited
Warranty. Limited Warranty service may be furnished on y by an authorized Gi es Enterprises, Inc.,
representative.
• If Limited Warranty service is requested, Gi es Enterprises, Inc., wi send factory-authorized serv-
ice representatives to repair, recondition, rep ace or inspect units of its manufacture with such abor
being rendered without cost to owner for 24 months from the date of insta ation. Otherwise, serv-
ice, inc uding abor and transportation charges or other expenses, in connection with the remova or
insta ation of any part or parts supp ied under this Limited Warranty, are specified on the origina
sa es contract between the purchaser and the authorized Gi es Enterprises, Inc., representative.
• Gi es Enterprises, Inc. reserves the right to change or improve its equipment and parts in any way
without ob igation to a ter such equipment or parts previous y manufactured.
• Gi es Enterprises, Inc. makes no further warranties, express or imp ied inc uding imp ied warranties
of merchantabi ity or fitness for a particu ar purpose, and has no other ob igation or iabi ity not
specifica y stated herein.
• Repair or rep acement as provided under this imited warranty is the exc usive remedy. Gi es
Enterprises, Inc., sha not be iab e for any incidenta or consequentia damages for breach of any
express or imp ied warranty on this product, except to the extent prohibited by app icab e aw. Any
imp ied warranty of merchantabi ity or fitness for a particu ar purpose on this product is imited in
duration to the duration of this imited warranty.
• Used Gi es Enterprises, Inc., Foodservice Equipment or parts or Gi es Enterprises, Inc., Foodservice
Equipment or parts not purchased from an authorized Gi es Enterprises, Inc., representative, carry
no warranties, express or imp ied.

iii
Model: OVH-10-CTable Of Contents
Safety ........................................................v
SafetyOverview....................................................................v
SpecificSafetyPrecautions...........................................................vi
1. I troductio ..............................................1
1-01. Construction..............................................................1
1-02. StandardFeatures..........................................................1
1-03. OptionalFeatures..........................................................1
1-04. Specifications.............................................................2
1-04.1. OverallDimensions.........................................................2
1-04.2. egulatoryListings.........................................................3
1-04.3. HoodWeights.............................................................3
2. I stallatio ...............................................4
2-01. Unpacking................................................................4
2-02. Location .................................................................5
2-02.1. ClearancetoCombustibles ..................................................6
2-03. Cooking Appliance Limitations & Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2-04. Electrical equirements.....................................................8
2-04.1. ElectricalConnections ......................................................9
2-04.2 Hood & Appliance Wiring Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2-04.2.1. Connection w/Hood & Appliance on same Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2-04.2.2. Connection w/ 380-480V Appliance Power Separate from 208-240V Hood Power . . . . . . . 11
2-04.2.3. Connection w/120V to 480V Appliance Power Separate from 208-240V Hood Power
using emoteShuntTripDevice..............................................12
2-05. AirBaffleInstallation.......................................................13
2-06. FinalCountertopInstallation.................................................14
3. Overview...............................................15
3-01. ControlPanel ............................................................16
3-02. HoodFront&FilterChamber................................................18
3-03. Accessories(Standard).....................................................20
3-04. Accessories(Optional).....................................................21

iv
Model: OVH-10-C Table Of Contents
5. Hood Clea i g a d Mai te a ce . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.01. MonthlyInterlockCheck....................................................31
5-02. HoodCleaning ...........................................................32
5-02.1. WeeklyCleaning..........................................................32
5-02.2. QuarterlyCleaning ........................................................32
5-03. MaintenanceandServiceLog ...............................................33
6. Troubleshooti g .........................................35
6-01. TroubleshootingProcedures.................................................35
7. PartsList ...............................................37
7-01. Parts Ordering and Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7-02. earElectricalComponents.................................................38
7-03. HoodFront,Filter&FanCompartment ........................................40
4. Operatio & Filter Mai te a ce . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4-01. HoodOperation ..........................................................23
4-01.1. StartingtheHood( egular) .................................................23
4-01.2 StartingtheHood(ILSModel) ...............................................23
4-02. HoodFilterSystem........................................................24
4-02.1. VentlessHoodFilterTable ..................................................24
4-02.2. Filter emoval, Baffle, EAC, Charcoal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4-02.3. Filter Installation, Baffle, EAC, Charcoal Filter Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4-02.4. CharcoalorBaffleFilterMissing..............................................26
4-02.5. EACFilterMissing ........................................................26
4-02.6. EACFilterStatus..........................................................27
4-03. FilterMaintenance........................................................27
4-03.1. BaffleFilterCleaning.......................................................27
4-03.2. EACFilterCleaning........................................................28
4-03.3. CharcoalFilterMaintenance.................................................28
4-04. FilterAlarmChart.........................................................29

v
Model: OVH-10-CSafety
Safety Overview
Safety
The instructions contained in this manual have been prepared to aid you in learning the proper procedures
for installing and servicing the OVH-10-C Counter-Top Hood.
Throughout this manual, safety precautions are identified through the use of safety alert symbols and
three key words: DANGER, WARNING and CAU ION. All safety alert information will precede the
step(s) to which it applies. Suggested, recommended, or otherwise noteworthy information is identified
through the use of NO ES. Additionally, certain words are used to indicate a specific meaning or to add
emphasis.
The following words are used as indicated throughout the manual:
Shall: understood to be mandatory.
Should: understood to be advisory.
May: understood to be permissive.
Will: indicates a future event or condition is highly likely to occur.
or
(Safety Alert Symbol)
sed in conjunction with key words DANGER, WARNING, or CAU ION to alert you of potential personal
injury hazards and to highlight precautionary measures that pertain to subsequent step(s). Adhere to all
safety messages following these symbols to avoid possible injury or death. Failure to comply with safety
precautions identified by a safety alert symbol may also void the equipment’s warranty.
!!
•Indicates an imminently hazardous situation which, if not avoided, will result in serious injury, or even
death. se of this is limited to the most extreme situations.
!DANGER
•Indicates a potentially hazardous situation which, if not avoided, may result in serious injury, or even
death.
!WARNING
•Indicates a potentially hazardous situation which, if not avoided, may result in minor to moderate injury.
Also alerts against unsafe practices.
!CAUTION
•When used without the safety alert symbol, CAU ION indicates a potentially hazardous situation
which, if not avoided, may result in damage to the equipment or property, and void the warranty.
CAUTION
NO E:
•Identifies suggested, recommended, or otherwise noteworthy information.

vi
Model: OVH-10-C Safety
Specific Safety Precautions
For your safety, please observe the following precautions when operating or servicing the OVH-10-C
Ventless Hood. Read the following important safety information to avoid personal injury and/or damage to
the equipment or property.
•Always disconnect the source of main power before removing any service panel or cover.
•Failure to ensure that the Power Switch is in the OFF position during servicing or when replacing filters
could result in damage to the equipment, electrical shock or other serious personal injury.
•Failure to comply with these DANGER notices will result in serious injury or even death, equipment or
property damage, and void the warranty.
!DANGER
•DO NO use or store flammable liquids or materials that produce flammable vapors in the vicinity of
this or any other appliance!
•Consult a qualified electrician to ensure that all electrical requirements are met and that the unit is prop-
erly grounded.
•Before installing or servicing this equipment, read the contents of this manual thoroughly.
•Improper installation, adjustments or alterations, or improper service/maintenance could result in seri-
ous injury or even death, damage to equipment or property, and void the warranty.
•Failure to comply with these WARNING notices could result in serious injury or even death, and equip-
ment or property damage.
!WARNING
UV MODEL ONLY
•An internal ultraviolet radiation source is present on these models during operation.
•Keep protective covers and panels in place during normal operation. Replace any removed after servic-
ing.
•An interlock circuit in the hood reduces potential for exposure to excessive ultraviolet radiation. DO
NO attempt to disconnect or bypass this interlock.
•Looking directly at a V light source without proper eye protection can cause serious eye injury.
!WARNING

vii
Model: OVH-10-CSafety
•Maintain a minimum clearance of 18” (457.2mm) between the hood’s exhaust outlet and the ceiling, or
other overhead obstruction.
•Exercise care when lifting or moving the unit. See Section 1-4.4, Hood Weights.
•Exercise care when removing the unit from the shipping skid.
!CAUTION
•DO NO operate the unit unless you fully understand its components and their intended function.
•DO NO bend the collection fins or break the ionizer wires of the Electrostatic Air Cleaner (EAC).
Doing so will prevent it from working properly and cause a shutdown of power to the appliance being
operated under the hood.
• Failure to comply with these CAU ION notices may result in minor to moderate injury, damage
to equipment or property, and void the warranty.
!CAUTION
•The electronic components of the Control Panel are somewhat impact-sensitive. Exercise care when
performing tasks near the unit’s Control Panel to prevent possible unintentional damage.
•After cleaning the EAC, DO NO attempt to dry the EAC cell by installing it in the hood and running the
fan to force air dry, or by running the appliance under the hood to heat dry. This could potentially dam-
age the EAC power system, leading to failure and voiding the warranty. The EAC filter must air dry at
ambient room temperature, preferably overnight.
•When cleaning the Hood, Hood Skirt or Stand ...
•• DO NO steam clean.
•• DO NO spray with water from a hose.
•• DO NO use products containing chlorine.
•• DO NO use abrasive products, steel wool or scouring pads.
•Failure to comply with these CAU ION notices may result in damage to equipment or property, and
void the warranty.
CAUTION

viii
Model: OVH-10-C Safety
NO E:
•The approximate sound level of the hood while operating is 65 dB.
NO E:
•Giles’ responsibility for the damage to the unit ends once the freight shipment is loaded onto the carri-
er’s truck. pon delivery, if the palletized unit showed any signs of damage, the entire load, including
the supplied accessories, should have been inspected immediately and any damage to the equipment
should have been promptly reported to the freight company.
•As an aid for electricians and installers, an electrical wiring diagram is provided with the unit. Refer to
the wiring diagram during installation or while servicing.
•Comply with all appropriate state and/or local heath regulations regarding cleaning and sanitation of
foodservice equipment.
•Giles recommends the use of mild, bio-degradable, non-toxic degreasers, such as Clear Magic or
Simple Green, for cleaning parts of the hood where excessive grease film accumulation is present.
•Always ensure the unit is installed and electrically grounded in accordance with local codes, or in the
absence of local codes, in accordance with the National Electrical Code ANSI/NFPA No. 70-1984.
NO E:
•For some installations, it may be necessary to consult a HVAC specialist to con-
firm that proper room air exchange is occurring and that the on-site A/C system is
capable of handling the anticipated heat load.
•Exhaust ventilation is recommended for areas in which recirculating hoods are operated. Giles recom-
mends 50 CFM per linear foot of hood space. his amount could vary based on local codes and
site-specific situations.

1
Model: OVH-10-C
Introduction
Thank You! for purchasing the OVH-10-C Ventless Hood System manufactured by Giles Enterprises, Inc.,
Montgomery, Alabama, SA. The OVH-10-C is a Limited Type-1 Hood designed specifically for use on
counter-top spaces and is listed for use with a variety of small commercial appliances ... Toasters,
Conveyor Ovens, Ovens and Rotisseries.
With proper care and maintenance, this unit will provide years of trouble-free service. To help protect your
investment in this equipment, we recommend taking a few moments to familiarize yourself with the
installation, operation, cleaning, and maintenance procedures described in this manual. We urge you to
read this manual before installing or operating the hood. Adherence to these recommended procedures
will minimize future potential for costly downtime and equipment repairs. Please retain this manual for
later reference.
Control Panel
•LED light cluster indicates the status and condition of the Electronic Air Cleaner (EAC) cell.
•Appl ance Powered light indicates that power is being supplied to the interlocked appliance(s)
operating under the hood.
•F lter M ss ng light indicates that the Baffle Filter and/or the Charcoal Filter is missing or not properly
installed.
•F lter Clogged light indicates that the Baffle Filter and/or the Charcoal Filter is possibly clogged and
requires attention.
F lters
• Baffle Filter - captures and collects large particulate entrained in the air stream.
• Electronic Air Cleaner (EAC) - captures and collects fine particulate air contaminates.
• Charcoal Filter - activated carbon filter helps to eliminate cooking odors.
1. Introduction
1-1. Construct on
1-2. Standard Features
The OVH-10-C Hood is constructed of 16-Ga to 20-Ga Stainless Steel.
1-3. Opt onal Features
Inter-Locked Start (ILS)
• This system prevents the hood and the served appliance(s) from restarting after a power interruption
without being attended by an operator. This optional provision is required by code in certain cities and/or
states.

2
Model: OVH-10-C Introduction
1-4. Spec f cat ons
1-4.1. Overall D mens ons
27 1/8
688.24 INSIDE
28 1/16 712.41
26 11/16
677.49
45 5/16 1151.59
29 15/16
760.4
27 5/16
693.9
1 1/16 26.62
91/2
241.8
513/16
147.57
4 3/8 111.25
7 3/8 187.38
POWER
CONNECTION
20 5/16
516.69

3
Model: OVH-10-CIntroduction
1-4.2. Regulatory L st ngs
1-4.3. Hood We ght
Hood Crated We ght Uncrated We ght
OVH-10-C 245 lbs [111 kg] 175 lbs [79 kg]

4
Model: OVH-10-C Installation
2. Installation
This section summarizes the procedures necessary to install your new OVH-10-C Countertop Hood.
Before installing and attempting to operate, please read the contents of this manual thoroughly. Following
these procedures will help ensure safe and proper installation.
The unit is shipped on a wooden skid with protective framing, secured to the skid by high-tensile plastic
strapping and wrapped with machine applied stretch-wrap. Perform the following steps to unpack the
unit:
1. Position the palletized unit in an area with sufficient space for unpacking.
2. Cut and remove stretch-wrap and all strapping.
3. Use appropriate tools to remove the wooden crate from around the unit.
3. Remove any packed accessories and/or parts from the skid and set aside.
4. The unit is extremely heavy. Using suitable lifting equipment or adequate manpower, lift the unit and
remove it from the shipping skid. See Section 1-4.3, Hood Weights.
5. Properly dispose of all shipping materials.
2-01. Unpacking
!! IMPORTANT NOTE:
•If the palletized unit showed any signs of damage, you should have immediately inspected the
equipment and any other packed accessories, and promptly notified the freight company of any and all
damages. Typically, it is the customer’s responsibility to claim freight damage.
•The unit is extremely heavy and somewhat top-heavy! Exercise due caution when handling to avoid
personal injury or damage to the equipment. Take precautions not to damage the hood’s Base or
Skirting.
•Exercise care when removing the wooden framing from around the unit to avoid any exposed nails or
staples.
•Failure to comply with these CAUTION notices may result in minor to moderate injury, damage to
equipment or property, and void the warranty.
!CAUTION

5
Model: OVH-10-C
1. Do not obstruct the exhaust air outlet. Maintain a minimum clearance of 18 inches (457.2 mm)
between the air outlet and the ceiling, or any other overhead obstruction.
2. The OVH-10-C Hood model is designed to sit atop a counter space. Ensure that the intended site is
structurally sound and capable of supporting the hood’s weight plus that of the appliance(s) to be
placed under it. See Section 1-4.3, Hood Weight.
2-02. Location
NOTE:
•The sound level of the hood while operating will be approximately 65 dB.
•DO NOT MODIFY OR ALTER THIS EQUIPMENT, OR ADD ATTACHMENTS OF ANY IND.
!CAUTION
NOTE:
•For some installations, it may be necessary to consult a HVAC specialist to
confirm that proper room air exchange is occurring and that the on-site A/C
system is capable of handling the anticipated heat load.
•Exhaust ventilation is recommended for areas in which recirculating hoods are operated. Giles
recommends 50 CFM per linear foot of hood space. This amount could vary based on local codes
and site-specific situations.
Model: OVH-10-C

6
Model: OVH-10-C Installation
2-02.1 Clearance to Combustibles
27 1/8
688.24 INSIDE
28 1/16 712.41
26 11/16
677.49
45 5/16 1151.59
29 15/16
760.4
27 5/16
693.9
1 1/16 26.62
20 5/16
516.69
0" CLEARANCE
TO COMBUSTIBLES
0" CLEARANCE
TO COMBUSTIBLES
18" CLEARANCE
TO COMBUSTIBLES
18
457.2 MIN.
EXHAUST CLEARANCE 0" CLEARANCE
TO COMBUSTIBLES
0" CLEARANCE
TO COMBUSTIBLES

7
Model: OVH-10-CInstallation
HEATING
AREA HEATING
AREA
27 1/8
688.24 INSIDE
28 1/16 712.41
26 11/16
677.49
45 5/16 1151.59
29 15/16
760.4
27 5/16
693.9
1 1/16 26.62
20 5/16
516.69
18
457.2 MIN.
EXHAUST CLEARANCE
A
MAX.
4
101.6
MIN. 4
101.6
MIN.
4
101.6
MIN.
APPLIANCE RESTRICTIONS
APPLIANCE TYPE MAX. ELECTRIC
INPUT, kW (WATTS) A
CONVEYOR OVENS 11.5 (11,500) 19* [482.6]
OVENS 6.2 (6200) 6[152.4]
ROTISSERIE 6.2 (6200) 6[152.4]
CONVEYOR TOASTERS (VERTICAL AND
HORIZONTAL) 11.5 (11,500) 19* [482.6]
FLAT TOASTERS 11.5 (11,500) 19 [482.6]
* - MEASURED TO TOP OF CONVEYOR BELT
2-03. Cooking Appliance Limitations & Clearances
Hood is listed for Electric Appliances ONLY.
* Appliance(s) exceeding 50 Amps must have a separate circuit from the Hood, but be intelocked
through the Hood contactor coil.

8
Model: InstallationInstallation
2-04. Electrical Requirements
Power Rating for Hood Only, if Appliance is on Separate Circuit & Interlocked
Through Separate Contactor
Voltage Hz Phase Hood Power
(Amps) Breaker
208-240 60 1 1.5 15
•Consult a qualified electrician to ensure that all electrical specifications have been met and that the
unit is properly grounded.
• I mproper installation, adjustment, alteration, service or maintenance could result in serious injury or
even death, damage to equipment or property, and void the warranty.
!WARNING
Power Rating for Hood & Appliance** on Same 208-240V Circuit
Voltage Hz Phase Field Provided Appliance
Power (Amps)
Hood Power
(Amps)
Branch Circuit Protector
(Amps) if Connecting
Hood & Appliance on
Same Circuit
208-240 60 1 or 3 0 - 10.5 1.5 15
10.6 - 14.5 1.5 20
14.6 - 22.5 1.5 30
22.6 - 38.5 1.5 50
38.6 - 46.5 1.5 60
46.7 - 50*1.5 70
*Appliance(s) exceeding 50A must have a separate circuit from the Hood, but be intelocked through the
Hood contactor coil.
** Appliance provided and rated separately from Hood.

9
Model: OVH-10-C
2-04.1. Electrical Connections
1. Install appropriate circuit breaker in Main breaker box.
2. Remove Hood Back Panel.
3. Connect appropriately sized wire (supplied by customer) from breaker box to Hood. Allow sufficient
cord length to allow moving hood, if necessary, for future service or maintenance.
4. Connect Hood and Appliance wiring to Hood terminal blocks. Several different wiring configuration
options are possible depending on specific installation situations and appliance choices. See Section
2-04.2 for specific details of these options.
5. Replace all panels and covers.
6. Turn on Main Breaker.
7. Place the Hood Power Switch in the ON position; Hood fan will start. For ILS model hood, press and
hold the “Push to Start” button on the Control Panel for approximately 5 seconds to start fan.
•All electrical installation should be performed by a qualified electrician or technician.
• I mproper installation or poor work practices could result in serious injury or even death, damage to
equipment or property, and void the warranty.
• If using a remote contactor (Section 2-04.2.4), the contactor must be a U isted, definite purpose
AC resistive air heating type, suitable for the appliance load. Installation and connections shall be in
accordance with the National Electric Code NFPA 70.
Model: OVH-10-C

10
Model: InstallationInstallation
2-04.2.1 Electrical Connection, Hood & Appliance on same Circuit
2-04.2. Hood & Appliance Wiring Configurations
USE LIQUID-
TIGHT CONDUIT
AND FITTINGS
HOOD & APP IANCE
POWER
