Gilson Porta-Screen PS-3 User manual

Gilson Porta-Screen®
PS-3, PS-4
OPERATING MANUAL
Rev: 07/2022
PHONE: 800-444-1508 P.O. Box 200, Lewis Center, Ohio 43035-0200
740-548-7298 Email: customerservice@gilsonco.com Product Web Page: globalgilson.com
FAX: 800-255-5314
740-548-5314
PS-3 PS-4
VIDEO TUTORIALS AVAILABLE on globalgilson.com for Porta-Screen® maintenance and repair.

Gilson's Porta-Screen® 2
CONTENTS
Safety Instructions 3
1.0 Unpacking & Setup4
2.0 Operation Instructions 4
3.0 Sample Capacity5
4.0 Maintenance & Disassembly 5
5.0 Parts Diagram8
6.0 Parts List 9
7.0 Accessories 11
Gilson Porta-Screen®
PS-3, PS-4 Operating Manual
VIDEO TUTORIALS AVAILABLE AT GLOBALGILSON.COM
FOR PORTA-SCREEN® MAINTENANCE AND REPAIR.
See our Video Tutorials at globalgilson.com for more Porta-Screen® maintenance and repair
information.

Gilson's Porta-Screen® 3
WARNING: This machine operates on an electric
current. Improper operation could result in electric
shock, electrocution, or an explosion! Motors are NOT
explosion-proof! The electric motor on this machine
has internal thermal protection. If the motor shuts off
from overload, the machine may restart by itself after
cooling off unless the machine is unplugged during
cooldown.
WARNING:Do not wear loose clothing that might be
caught in the machine and keep all body parts away
from moving parts of the machine. ALWAYS wear
safety glasses, hearing protection, and other personal
protective equipment while operating, maintaining, or
repairing this machine. Take care not to pinch your
fingers between the clamp levers and the machine
frame.
WARNING:DO NOT operate the machine without
having all guards and covers in place.
WARNING:DO NOT perform tasks on the machine
other than those for which it was designed. Only use
the machine in the manner for which it was intended,
as described in this instruction manual.
WARNING: Only operate this machine in a properly
ventilated area. DO NOT use this machine in an ex-
plosive or hazardous atmosphere. It is NOT explo-
sion-proof or approved for operation in hazardous
locations.
WARNING: ALWAYS level the machine prior to op-
eration. Stop the machine immediately and re-level if
excessive vibration or machine movement occurs.
NOTE: These instructions are intended only as a
guide for general operation of this device and should
not be used in place of test protocol. Refer to current
specifications for complete and detailed test proce-
dures.
ALWAYS ensure the motor and other electrical com-
ponents are properly configured for your intended use
and available power source. The Gilson Porta-Screen®
comes with a 1/2hp motor wired for 115V,60Hz. It can
also be ordered with 230V,50Hz wiring.
ALWAYS use a properly-wired, three-pronged plug, or
otherwise ground the machine. Make sure the cord is
located where no one will trip or get tangled in it.
ALWAYS check electrical wiring for loose connections
and for pinched or frayed wiring.
ALWAYS disconnect and lock out power supply when
the machine is not in use, especially before performing
maintenance and repairs.
SAFETY INSTRUCTIONS
MOVINGPARTS Can Crush
and Cut. Operate Carefully.
WARNING
Wear safety glasses when using
equipment.
CAUTION

Gilson's Porta-Screen® 4
2.0 OPERATING INSTRUCTIONS
NOTE: Please read and understand all safety and operat-
ing instructions for the Gilson Porta-Screen® before put-
ting it into service.
2.1 TIMER SETUP & OPERATION
NOTE: The main device controlled by the timer may be
restricted to operating on a more limited electrical supply
range. Check the device carefully to ensure compatibility
with your electrical supply.
2.2 PROCEDURE
1.0 UNPACKING & SETUP
To extend a leg,
To contract a leg,
VIDEO TUTORIALS AVAILABLE AT
GLOBALGILSON.COM FOR PORTA-SCREEN®
MAINTENANCE AND REPAIR.

Gilson's Porta-Screen® 5
3.0 SAMPLE CAPACITY
3.1 COARSE AGGREGATE
3.2 FINE AGGREGATES
4.0 MAINTENANCE & DISASSEMBLY
NOTE: Please read and understand all safety and main-
tenance instructions for the Gilson Porta-Screen® before
performing maintenance on it.
WARNING
Always disconnect and lock out electric power
before performing maintenance!
4.1 CLAMPING SYSTEM
4.2 LUBRICATION
Connection Rod Bearing:
Normal Maximum Minimum
Size of Particle Sample Weight
mm (in) kg (lb)
9.5 (3/8) 1 (2)
12.5 (1/2) 2 (4)
19.0 (3/4) 5 (11)
25.0 (1) 10 (22)
38.0 (1.5) 15 (33)
50 (2) 20 (44)
63.5 (2.5) 35 (77)

Gilson's Porta-Screen® 6
Shaft Bearings:
Motor Bearings:
Idler Pulley Bearings:
4.3 BELTS
Access to Belts
Drive Belt:
Timing Belt:
To tighten:
To replace:
making certain
DO NOT PLUG IN THE PORTA-SCREEN® UNTIL YOU ARE
READY TO USE IT.
4.4 BEARING REPLACEMENT
Guide Bearing Assemblies:
Upper:
Lower:

Gilson's Porta-Screen® 7
DO NOT PLUG IN THE PORTA-SCREEN® UNTIL YOU ARE
READY TO USE IT.
Connecting Rod & Drive Shaft Bearings:
DO NOT PLUG IN THE PORTA-SCREEN® UNTIL YOU ARE
READY TO USE IT.
Counterweight Shaft Bearings:
DO NOT PLUG IN THE PORTA-SCREEN® UNTIL YOU ARE
READY TO USE IT.
Wire Cloth:

Gilson's Porta-Screen® 8
PS-3 & PS-4 Parts Diagram
5.0 PARTS DIAGRAM

Gilson's Porta-Screen® 9
6.0 REPLACEMENT PARTS
Item
No. Part No. Description
No.
Req.
OUTER CASE & FRAME PARTS
1RPPS-3KEY1 Top Frame Cross Bar 1
2RPPS-3KEY2 Top Frame Screw & Lock Washer 4
31 RPPS-3KEY31 Bullseye Level with Cushion Washer 1
36 RPPS-3KEY36 Bullseye Level Adjusting Screws 3
27 RPPS-3KEY27 Leg Lock Tab 3
33 RPPS-3KEY33 Leg Lock Tab Spring 3
65,
28
RPPS-3KEY65/28 Leveling Leg (65), with Adjusting Screw Pad,
Nut, & Washer
3
29 RPPS-3KEY29 Main Frame for PS-3, PS-3F 1
RPPS-4KEY29 Main Frame for PS-4, PS-4F
30 RPPS-3KEY30 Vibrating Unit Assembly for PS-3, PS-3F 1
RPPS-4KEY30 Vibrating Unit Assembly for PS-4, PS-4F
RPPS-3KEY10 Upper Case Cover 2
11A RPPS-3KEY11A Lower Case Cover, Front 1
RPPS-3KEY11B Lower Case Cover, Rear 1
UPPER GUIDE BEARING ASSEMBLY PARTS
34 RPPS-3KEY34 Upper Guide Bearing Housing with Guide
Bushing
35 RPPS-3KEY35 Upper Guide Bearing Mounting Screw & Lock
Washer
4RPPS-3KEY4 Upper Guide Bearing Pin & Setscrew
CLAMPING ASSEMBLY PARTS, RIGHT & LEFT
5A RPPS-3KEY5A Clamp Lever with Mounting Bracket (6F), Left
Side, PS-3, PS-3F
1
RPPS-4KEY5A Clamp Lever with Mounting Bracket (6F), Left
Side, PS-4, PS-4F
5B RPPS-3KEY5B Clamp Lever with Mounting Bracket (6F),
Right Side, PS-3, PS-3F
1
RPPS-4KEY5B Clamp Lever with Mounting Bracket (6F),
Right Side, PS-4, PS-4F
38 RPPS-3KEY38 Clamp Lever Handle Grip 2
6R RPPS-3KEY6R Rear Clamp Lever Mounting Bracket 2
39 RPPS-3KEY39 Clamp Lever Mounting Bracket Screw & Lock
Washer
8
7RPPS-3KEY7 Clamp Tension Rod for PS-3, PS-3F 4
RPPS-4KEY7 Clamp Tension Rod for PS-4, PS-4F
40 RPPS-3KEY40 Clamp Tension Rod Retainer Clip, Screw, &
Lock Washer
4
8RPPS-3KEY8 Clamp Bar 1
9RPPS-3KEY9 Clamp Adjusting Nut & Spacer 4
COUNTERWEIGHT ASSEMBLY PARTS
12 RPPS-3KEY12 Left Counterweight Shaft (Short) 1
13 RPPS-3KEY13 Right Counterweight Shaft (Long) 1
41 RPPS-3KEY41 Counterweight Shaft Bearing 4
42 RPPS-3KEY42 Counterweight Shaft Bearing Mounting Screw
& Lock Washer
8
14 RPPS-3KEY14 Counterweight for PS-3, PS-3F 4
RPPS-4KEY14 Counterweight for PS-4, PS-4F
43 RPPS-3KEY43 Counterweight Clamp Bracket for PS-3,
PS-3F
4
Item
No. Part No. Description
No.
Req.
RPPS-4KEY43 Counterweight Clamp Bracket for PS-4,
PS-4F
44 RPPS-3KEY44 Counterweight Clamp Bracket Bolt & Lock
Washer
8
15 RPPS-3KEY15 Counterweight Shaft Pulley & Setscrew 2
16 RPPS-3KEY16 Timing Belt 1
17 RPPS-3KEY17 Idler Bracket 1
45 RPPS-3KEY45 Idler Bracket Mounting Screw with Lock & Flat
Washers
2
46 RPPS-3KEY46 Idler Bracket Adjusting Screw with Locking
Nut
1
18 RPPS-3KEY18 Idler Pulley Mounting Screw & Lock Washer 1
19 RPPS-3KEY19 Idler Pulley with Bearing Set 1
62 RPPS-3KEY62 Bearing Set Only 1
DRIVE SHAFT ASSEMBLY PARTS
20 RPPS-3KEY20 Drive Shaft with Eccentric & Roll Pin 1
47 RPPS-3KEY47 Drive Shaft Bearing 2
42 RPPS-3KEY42 Drive Shaft Bearing Mounting Screw & Lock
Washer
4
49 RPPS-3KEY49 Timing Pulley & Setscrew 1
21 RPPS-3KEY21 Drive Pulley with Setscrew 1
22 RPPS-3KEY22 Drive Belt 1
CONNECTING ROD ASSEMBLY PARTS
RPPS-3KEY23 Connecting Rod Assembly (50, 51, 52) 1
50 RPPS-3KEY50 Connecting Rod with Grease Fitting 1
51 RPPS-3KEY51 Connecting Rod Rubber Bushing 1
52 RPPS-4KEY52 Connecting Rod Bearing with Inner Race 1
24 RPPS-3KEY24 Connecting Rod Mounting Bolt with Lock Nut 1
54 RPPS-3KEY 54 Connecting Rod Mounting Bolt Spacer 2
LOWER GUIDE BEARING ASSEMBLY PARTS
59 RPPS-3KEY59 Lower Guide Bearing Housing with Guide
Bushing
1
56 RPPS-3KEY56 Lower Guide Bearing Mounting Screw & Lock
Washer
2
26 RPPS-3KEY26 Lower Guide Bearing Pin 1
64 RPPS-3KEY64 Lower Guide Bearing Pin Clamp Bolt with
Lock Nut
1
ELECTRIC & DRIVE PARTS
63 RPPS-3KEY63 Motor 115V,60Hz for PS-3, PS-4 1
RPPS-3KEY63-1 Motor 230V,50Hz for PS-3F, PS-4F
60 RPPS-3KEY60 Motor Pulley & Setscrew 1
61 RPPS-3KEY61 Motor Mounting Bolt with Lock & Flat Washer 4
RPPS-3-ECA-
MOTOR
Electric Cord Assembly with Plug, 6ft Cord 1
RP-TIMER-ART Timer, Digital, for S/N 3520 & Higher 1
6.1 PS-3 AND PS-4 PARTS LIST

Gilson's Porta-Screen® 10
6.2 REPLACEMENT TRAYS, WIRE CLOTH, & PARTS
GILSON PORTA-SCREEN REPLACEMENT TRAYS, WIRE CLOTH, & PARTS
Model Description GILSON PORTA-SCREEN® REPLACEMENT TRAYS,IRE

Gilson's Porta-Screen® 11
PSA-312 Porta Cover
PSA-114
PSA-114 Porta-Wheels
PSA-312 on PS-3
7.0 ACCESSORIES
PSA-367 Porta Sample Pan
PSA-367
PSA-356 Porta-Screen Tray Rack
PSA-356
VISIT GLOBALGILSON.COM TO SHOP PORTA-SCREEN
®
ACCESSORIES, TO SEE PRODUCT INFORMATION,
AND TO WATCH PRODUCT MAINTENANCE AND REPAIR VIDEOS.
