Girard Systems GC116I Operating instructions

12v ANEMOMETER
GC116I
INSTALLATION AND PROGRAMING GUIDE
REV.12302015
RV AWNING PRODUCTS
1361 CALLE AVANZADO, SAN CLEMENTE, CA 92673(800) 382-8442 FAX [phone]
www.girardrv.com

Page 2of 10
Girard Systems awnings may be operated in light wind and rain
conditions. When periods of heavy rain and or high wind are expected
the awning must be closed. Never leave the awning open and
unattended.
Damage caused by wind and rain is not covered by warranty.
All awnings must be closed prior to moving the vehicle for any reason.
As an extra safety precaution a visual check that every awning is fully
closed is required.
Damage caused by failure to comply with these instructions is
not covered by warranty.
Before using your awning, ensure that the area into which the awning
will be deployed is free of obstructions (Trees, walls, pillars, posts,
other vehicles etc.)
Damage caused by collisions with any of the above or similar is
not covered by warranty.
Before using your awning make sure that all of your electrical circuits
are operating correctly. Recreational Vehicles can generate AC power
from three separate sources. The electrical system transfer switch in
your vehicle will select power for the awning as follows:
Shore Power – if connected;
Generator Power – if the generator is running;
Inverter Power – batteries must be charged for inverter operation.
Girard Systems awnings are supplied with an electric motor appropriate to the
product.

Page 3of 10
CONTENTS
The G-Link System ………………………………………………………………………….. 3
Product Description …………………………………………………………………………. 4
Installation …………………………………………………………………………………….. 4
Set up and Programming …………………………………………………………………. 5
Pairing with a GC136 or GC154 ………………………………………………………… 5
Pairing with a GC274A …………………………………………………………………….. 6
Pairing with a GC274B …………………………………………………………………….. 7
Pairing with a GC732G …………………………………………………………………….. 8
Pairing with a GC1146C ………………….……………………………………………….. 9
Pairing with a 98GC74 ……………………………………………………………………. 10
THE G–LINK SYSTEM
The G-Link motors and control modules provided by Girard Systems communicate by
use of RF signals on a frequency of 433.92 MHZ. This eliminates the need for wiring
and the drilling of holes in the vehicle. These components must be electronically
matched, programmed or paired before use. This is usually done at the Girard Systems
factory. Should the need arise for the user to pair a device with the motor controller
they must refer to the appropriate manual for the devices applicable to their particular
installation.

Page 4of 10
PRODUCT DESCRIPTION
The GC116I Anemometer is a 12v DC Remote module designed to operate in
conjunction with all Girard Systems G-Link motor controllers. This device will send an All
Channels Retract signal whenever the wind speed exceeds a pre-set value for longer
than 3 seconds. This feature is intended to protect the awning from potential damage
caused by strong or gusting winds and can be programmed to control up 20 Receivers
anywhere on the coach.
The GC116I offers three ranges of wind speed sensitivity;
•0 to 1 Wind Speed between 0 and 10 mph
•1 to2 Wind Speed between 10 and 18 mph
•2 to 3 Wind Speed between 18 and 30 mph
INSTALLATION
The Anemometer should be mounted securely in an unobstructed area on the roof of
the vehicle or structure and connected to a 12v DC supply Red wire (+) White wire (-).
LED
P2 BUTTON
UP BUTTON
WIND SPEED ADJUSTMENT

Page 5of 10
SET UP AND PROGRAMMING
The GC116I Anemometer must be programmed/matched/paired with whichever device
controls the motor of the awning or awnings to be retracted in windy conditions.
First ensure that there is power to the motor controller, and then fully extend the
awning. If more than one awning is to be controlled by the anemometer then they must
be programmed one at a time.
PAIRING WITH A GC136 OR GC154
Locate and ensure access to the program button of the motor controller. In this case a
small screwdriver or toothpick will be required to press the program button.
Note; when carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press the PROGRAM button on the motor controller (The green LED will start to
blink )
4) Press the STOP button on the motor controller (The green LED will stop blinking
and remain illuminated)
5) Press the up button on the Anemometer to retract the awning.
PROGRAM BUTTON
STOP BUTTON

Page 6of 10
PAIRING WITH A GC274A
Locate and ensure access to the program button of the motor controller. In this case the
lid of the 274A must be removed to gain access to the program button.
Note; when carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press the PROGRAM button on the motor controller (The green LED will start to
blink )
4) Press the STOP button on the motor controller (The green LED will stop blinking
and remain illuminated)
5) Press the up button on the Anemometer to retract the awning.
PROGRAM BUTTON
STOP BUTTON

Page 7of 10
PAIRING WITH A GC274B
Locate and ensure access to the program button of the motor controller. In this case the
middle and right buttons must be pressed and held untill the Green LED begins to flash.
Note; when carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press and hold the middle and right buttons on the motor controller (The green
LED will start to blink )
4) Press the STOP button on the motor controller (The green LED will stop blinking
and remain illuminated)
5) Press the up button on the Anemometer to retract the awning.
PROGRAM
STOP

Page 8of 10
PAIRING WITH A GC732G
Locate and ensure access to the program button of the motor controller. In this case the
program button is easily accessed on the side of the box.
Note; when carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press the PROGRAM button on the motor controller (The red LED will start to
blink )
4) Press the STOP button on the motor controller (The red LED will stop blinking
and remain illuminated)
5) Press the up button on the Anemometer to retract the awning.
PROGRAM BUTTON

Page 9of 10
PAIRING WITH A GC1146C
Locate and ensure access to the P2 button for the motor controller. In this case the
program button is found on the back of the primary handset and a toothpick or similar
tool will be required to press it.
Note; when carrying out this part of the procedure each step must be
executed within 6 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press the P2 button on the Primary handset TWICE (The Control unit will beep
with each press)
4) Press the P2 button on the ANEMOMETER ONCE (The motor controller will beep
several times to indicate that the program has been accepted)
5) Press the up button on the Anemometer to retract the awning.
P2 BUTTON

Page 10 of 10
PAIRING WITH A 98GC74
Locate and ensure access to the P2 button for the motor controller. In this case the
program button is found on the back of the primary handset and a toothpick or similar
tool will be required to press it.
Note; when carrying out this part of the procedure each step must be
executed within 6 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the wind speed adjustment dial to between 1 and 2.
2) Connect the Anemometer to a 12V DC Power source. (The Red LED will flash
once when power is connected)
3) Press the P2 button on the back of the Primary remote TWICE (The Motor
controller will beep with each press)
4) Press the P2 button on the Anemometer ONCE (The motor controller will beep
several times to indicate that the program has been accepted)
5) Press the up button on the Anemometer or physically activate it by spinning the
cups to retract the awning.
For queries or assistance with programming any of your G-Link devices
please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am
and 3:30pm P.S.T.
P2 BUTTON
