Read me first
Introduction to EDR
Safety warnings and cautions before use
단원1시작하기
Section 1 Getting Started

EDR User’s Manual
4
Read me first
G e t t i n g S t a r t e d
Read me first
Thank you for purchasing the EDR(Event Data Recorder). Read the instructions thoroughly for proper
operation of your EDR(Event Data Recorder)
This Manual is copyrighted by Global Information Technology Co., Ltd. all rights reserved. No part of
this manual may be reproduced in any form without the prior written permission of Global Information
Technology Co., Ltd.
No patent liability is assumed with respect to the use of the information contained herein.
ⓒ2012 Global Information Technology Co., Ltd.All Right Reserved.
EDR specifications and manual are subject to change without notice. Global Information technology
Co., Ltd. assumes no liability for damage incurred directly or indirectly from error, omission or
discrepancies between the computer, VCI and the User Manual.
Introduction
Copyright
Disclaimer

EDR User’s Manual
5
Introduction to EDR
G e t t i n g S t a r t e d
Introduction to EDR
The Purpose of EDR (Event Data Recorder)
EDR is to confirm and analyze to collect the data when colliding with a vehicle.
Aim of EDR is below.
1. A detailed investigation of collision status
2. An accurate analysis of a safety device performance
(Relevant laws: part 563 of title 49, Code of Federal Regulations)
Composition of EDR
EDR(Event Data Recorder), is composed of VCI(Vehicle Communication Interface), ACU connector,
EDR software.
VCI : Module for vehicle Electronic Control Unit (ECU) communication.
EDR software : The program for reading and analyzing Event Data which communication with
airbag ECU.
ACU connector : Module for connect between ECU and VCI.
.

EDR User’s Manual
6
Safety warnings and cautions before use
G e t t i n g S t a r t e d
Safety warnings and cautions before use
This section contains WARNINGS and CAUTIONS for the safe use of your EDR. Please read the
following contents before use.
WARNING
This indicates items for which incorrect handling may result in a major accident involving serious
injury or death.
Set up the VCI module in a safe place in the vehicle. Avoid contact or disturbing other
equipment and parts during vehicle operation.
Do not use another High Power electrical supply device for power input on the VCI module
except the car battery (7~35VDC).
Be sure to tighten the link between the electric supply cable and the battery extension cable to
prevent detachment during use.
Install trigger module in a safe location to avoid disturbing normal vehicle operation.
Connection between VCI equipment, DLC main cable and adapter cable connections must
remain tight in order to avoid separation during normal vehicle operation.
Do not disassemble VCI module.

EDR User’s Manual
7
CAUTION
This indicates items for which incorrect handling may lead to injury or damage to property. Under
certain conditions more serious consequences may result.
Always use the VCI module in its rubber shield and keep inner VCI module away from liquids
and other contaminants.
Do not drop or shock the VCI module, damage may result.
Do not leave tools or heavy objects on the VCI module.
ALWAYS check positive and negative Battery cables before attaching the extension cable to the
power supply cable.
Beware of contacting any hot or moving engine parts or belts while using the extension cable
and power cable with the equipment.
Unplugging the DLC and USB cables from the VCI module must only be done after releasing the
cable connector lock tab(s).
USB cable must be connected to VCI module in order to upgrade VCI firmware.
Place all parts and supplies inside the storage case when not in use.
When plugging or unplugging any of the cable connectors on the VCI equipment, use the cable
connector handle and confirm the lock tab(s) are released.

EDR User’s Manual
8
EDR Components
단원1시작하기
Section 2 Components of EDR

EDR User’s Manual
9
Components of EDR
Components of EDR
Components of EDR
Part name
Part number
Description
Qty.
EDR program DVD
G1ZHDDM001 : Hyundai
G1ZKDDM001 : Kia
G1ZGDDM001 : General
G1ZLDDM001 : R&D
EDR program DVD
* HDD : 200 MB
* OS : Windows XP (Windows VISTA(32bit,
64bit), Windows 7(32bit, 64bit)
* CPU : 2 GHz
* USB : 1.1
* Memory : 1 GB RAM
1
Carrying Case
G1GKNHA001
Carrying Case for keeping or moving the EDR
products.
1
Assy.-VCI module
G1CHDMK050
VCI module for scan-tool functions.
1
Cable-Mini USB
G1MDDCA105
Cable for communication between VCI and
Information Terminal(Laptop).
Length 3.5m.
1
Cable-DLC [26pin -
16pin]
G1CDDCA001
DLC main cable for communication between
VCI module and (16pin) OBD-II diagnosis
connector on vehicle.
Length 2.0m.
1

EDR User’s Manual
10
Part name
Part number
Description
Qty.
AC/DC adapter
G1CDDPA011
Adapter for supplying power to the VCI main
module from AC power
1
AC power cable
G1CDKCA001
Cable for AC/DC adapter
Standard format: IEC 60320 C13
1
CFCI module
G1DDDME001
Used to communicate with CAN-FD applied
vehicles.
1
Adapter[36pin]
G1ZDDPA001
Adapter for communication with AM vehicle.
Length 0.4m.
Color: Yellow
1
Adapter[36pin]
G1ZDDPA002
Adapter for communication with SL vehicles.
Length 0.4m.
Color: Yellow
1

EDR User’s Manual
11
Part name
Part number
Description
Qty.
Adapter[34pin-40pin]
G1ZDDPA003
Adapter for communication with XM vehicle.
Length 0.4m.
Color: Yellow
1
Adapter[27pin-39pin]
G1ZDDPA004
Adapter for communication with TF HEV, QF,
TF vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[27pin-39pin]
G1ZDDPA006
Adapter for communication with YD vehicle.
Length 0.4m.
Color: Yellow
1
Adapter[27pin-39pin]
G1ZDDPA007
Adapter for communication with XM vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[27pin-39pin]
G1ZDDPA008
Adapter for communication with UB vehicles.
Length 0.4m.
Color: Yellow
1

EDR User’s Manual
12
Part name
Part number
Description
Qty
Adapter[24pin]
G1ZDDPA010
Adapter for communication with TD, VQ
vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[44pin]
G1ZDDPA011
Adapter for communication with KH vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[44pin]
G1ZDDPA012
Adapter for communication with PS, PS EV,
YP, YPM, YD vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[44pin-44pin]
G1ZDDPA013
Adapter for communication with UMA, QL, YG
vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[44pin-44pin]
G1ZDDPA014
Adapter for communication with JFA, JF
vehicles.
Length 0.4m.
Color: Yellow
1

EDR User’s Manual
13
Part name
Part number
Description
Qty
Adapter[34pin-40pin]
G1ZDDPA019
Adapter for communication with VG vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[27pin-39pin]
G1ZDDPA021
Adapter for communication with DE HEV, SC,
CK, DE PHEV, DE EV, RJ, BDM vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[44pin-44pin]
G1ZDDPA023
Adapter for communication with JF HEV, JF
PHEV vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[36pin-52pin]
G1ZDDPA025
Adapter for communication with ON vehicles.
Length 0.4m.
Color: Yellow
1
Adapter[36pin-52pin]
G1ZDDPA026
Adapter for communication with SK3, SK3
EV, DL3A, DL3 HEV vehicles.
Length 0.4m.
Color: Yellow
1

EDR User’s Manual
14
Part name
Part number
Description
Qty
Adapter[27pin-39pin]
G1ZDDPA028
Adapter for communication with SP2 vehicles.
Length 0.4m.
Color: Yellow
1

EDR User’s Manual
15
단원1시작하기
Specifications and features
Power On/off method and switch operation
Installation of VCI module and DLC main cable
Section 3 B a s i c F e a t u r e s

EDR User’s Manual
16
Specifications and features
Ba sic Featu re s
Specifications and features
Specification of VCI
General features
Item
Specifications
Micro Controller
ARM9 (S3C2410A) @ 208MHz
Memory
RAM 32MByte
ROM 32MByte
Operating Voltage
7~35VDC
Operating Temperature
14℉~158℉(-10℃~ 70℃) : USB Mode
14℉~131℉(-10℃~ 55℃) : Wireless LAN Mode
Operating Mode
Diagnosis Function / Flight Record Function
Current Consumption
Typical 350mA @12V
Housing
ABS & Rubber Shroud
Dimension
170 × 105 × 33 mm
Weigh
350g
PC Interface
Item
Specifications
Wire protocol
USB 1.1
Wireless protocol
Wireless LAN IEEE 802.11b

EDR User’s Manual
17
Figure 1. Main Components of VCI module
VCI (Vehicle Communication Interface)
Item
Specifications
CAN
CAN 2.0B
K-Line/L-Line
ISO-9141, ISO-9141-CARB, KWP-2000
Commercial Veh.
SAE-J1708, RS-232C
Data/Control Line
Melco Pull-Down UART
Added Interface
Item
Specifications
1. VSS
Vehicle speed simulation
2. Voltage Output
5 ~20 VDC
Main Components
Trigger Module Connector
Mini USB Connector
DLC Connector
VCI Status Display
Power Switch

EDR User’s Manual
18
Power On/off method and switch operation
Ba sic Featu re s
Power On/off method and switch operation
To turn on the VCI module, first connect the main DLC cable from the vehicle to the VCI module and
depress the main power switch.
If the vehicle DLC diagnosis connector does not use a 16-pin connector, or if battery power cannot be
supplied to the VCI module, the AC/DC power cable must be connected to supply battery power to the
VCI module.
Figure 1. VCI module display
Turning on the VCI module

EDR User’s Manual
19
The VCI equipment has a display for checking VCI operating conditions. This display shows the
current condition of each VCI function with a colored LED.
Figure 2. LED status on the VCI module display
POWER
LED will illuminate with the VCI module on. Sub LED’s show which function is currently operating on
the VCI module.
Green: refers to Normal(diagnosis) mode
VEH. COMM
The current condition of Vehicle communication to the VCI module can be monitored using this LED.
This LED is Green.
PC COMM
Displays communication mode between the VCI and PC, it also displays by LED color.
Red color refers to wireless LAN and Green for USB cable.
To turn off the VCI module, depress the power switch for 2-3 seconds or disconnect the power supply
cable. The VCI module automatically turns off in case of a disconnected power supply cable.
VCI Display Operation
Turning off the VCI module

EDR User’s Manual
20
Installation of VCI module and DLC main cable
Ba sic Featu re s
Installation of VCI module and DLC main cable
First locate the Data Link Connector (DLC), to communicate between the ECU and the EDR.
The location of the Data Link Connector (DLC) may vary depending on the type of vehicle.
Usually located on the lower instrument panel, on the driver’s side.
DLC may be installed in the engine room. Check for the proper location on each vehicle.
Some older model vehicles, which do not use a 16-pin (OBD II diagnosis -SAE J1962) connector,
must use a 16-pin suitable adapter. The SCSI connector is on the other side of this 16-pin
diagnosis connector.
The SCSI connector must be connected properly at the VCI module. And the user must check the
connection condition once complete.
Figure 1. Connect the DLC main Cable to the OBD-II Connector
Installation of main DLC cable
