GKOLED GKOCP03 Series User manual

M4 Screws
Mounting Plate
Clip
Pressing Plate
Connect the wires according
to the wiring diagram
M4 Screws
CIRCULAR CANOPY
Installation Guide
Series GKOCP03
®
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
— To prevent personal injury or product damage only licensed electricians should install.
— To avoid electric shock or component damage disconnect power before attempting installation or servicing.
— This product must be installed in accordance with the national electric code (NEC) and all applicable federal, state, and local electric codes and safety standards.
— Disconnect product and allow cooling prior to servicing.
— Any alteration or modification of this product is expressly forbidden as it may cause serious personal injury, death, property damage, and/or product malfunction.
— To prevent product malfunction and/or electrical shock this product must be properly grounded.
— This luminaire is designed to operate in ambient temperatures ranging from -40°F to 113 °F and to be horizontally mounted with the LEDs facing down.
— This product is not available for several special enviroments, such as places with corrosive gas liquids or gas stations.
Surface Mounting With J-Box
1. Loosen and remove the M4 Screws used to attach the mounting plate to the
fixture.
Ceiling
Spindle
Suspension Loop
2. Attach the mounting plate to the ceiling using M16 Expansion Bolts or M6
stainless steel screws with plastic anchors (not included).
3. Connect the clip of the fixture to the spindle of the mounting plate to ensure
the fixture will not slip and fall. Complete wiring using the wiring diagram, then
push the pressing plate into the suspension loop on the mounting plate.
4. Reattach the mounting plate to the fixture using the previously removed M4
Screws.
Wiring Diagram
Remove the screw plug on the side of the light, adjust the dial switch to the
desired power level and color temperature to match the application
requirements, then reinstall the screw plug as demonstrated below:
NOTE: Power values indicated in diagram are based on tested values and may
slightly vary.
WITHOUT EMERGENCY BATTERY WITH EMERGENCY BATTERY
CCT POWER
5000K 100%
80%
60%
40%
60W
46W
34W
22W
4000K
3/4 Inch Threaded Hole
3/4 Inch Conduit
Ceiling
Pendant Mounting With 3/4 Inch Conduit
1. Complete wiring using the wiring diagram.
2. Screw the fixture onto the 3/4 inch conduit (not included) to complete the
installation.
Power & CCT Adjustment Controls
LED FIXTURES LED FIXTURES
Black Line Red
Black
White
Green/Yellow Green
Purple
AC Line (24/7)
AC Line Switch
Neutral
Ground
DIM+
Neutral
Ground
DIM+
DIM-
White
Purple
Pink DIM-
Pink
Green/Yellow Green
Note: Two dimming wires in the the driver box.

Motion Sensor Dimensions & Specifications
(For Sensor Factory Settings, See Last Page)
3.5in. (90mm.)
1.6in. (41mm.)
1.4in. (35.97mm.)
3.2in. (81.16mm.)
2.4in. (60.98mm.)
32.9mm.
G1
1.7in. (42.3mm.)
(18.8imm.)
0.7in.
(12.7imm.)
0.5in.
Specifications
Power Supply: 120/277VAC, 50/60Hz
Dimming Control Output: 0-10V, default 10V
Detection Radius & Angle: 30'@ 40' Mounting Height, 360°
Mounting Height: Max. 40'
Humidity: 20-90%
Operating Temperature: -40°F to 158°F (-40°C to 70°C)
Important
•Sensor warm up time is 40 seconds. After the sensor connects
to input power the first time, the light fixture will stay on for 40
seconds, then dim for normal operation.
•Factory Default Settings: Sensor Detection Range 100%, Sensor
Hold Time 10 Seconds, Light Threshold 30 Lux, Stand-By Light
Level 30%, Stand-By Time: 60 Minutes.
•When any setting is changed using the dip switches or remote
control, the light fixture that the sensor is connected to will turn
on and off to confirm the change.
Coverage Side View Coverage Top View
360° Coverage
Ø2.4in. (61mm.)
Ø0.8in.
19.2mm.
Multi-Level Function
The motion sensor includes the capability for tri-level control functionality, for areas which require a preliminary notification consisting of a change
in the brightness of the light before the light switches off completely. When the sensor is installed, there are 3 lighting modes: 100% --> dimmed
(under reduced natural lighting conditions) --> off, with 2 periods of selectable waiting time: sensor hold time and sensor stand-by time. Additional
configurable options include light threshold for sensor operation, and sensor sensitivity/detection area.
When natural lighting conditions
are sufficient, the motion sensor
does not turn on the fixture even
when motion is detected.
When natural lighting conditions
fall below a selected threshold,
the motion sensor turns on the
fixture when motion is detected.
After sensor hold time elapses,
the motion sensor dims the
fixture to the stand-by light level
if the natural light conditions are
below the selected threshold.
After the stand-by time period
elapses, the motion sensor
switches the fixture off
automatically.
Optional - Multi-Level Motion Sensor
Sensor Coverage

Daylight Sensor Function
Select the daylight sensor function by pushing
Settings In This Demonstration:
Hold-Time: 30 Minutes
Setpoint On: 50 Lux
Setpoint Off: 300 Lux
Stand-By Dimming Level: 10%
Stand-By Period: +∞
(The +∞ Stand-By Period option is only available
when the Daylight Sensor is activated.)
when the remote control is in setting mode.
Power On
Check
OFF
Dim
Every
30 Min.
No
Motion
Motion
Hold-Time
Ends
100%
On
When movement is
detected, the light
switches on to 100%
brightness.
After sensor hold-time
elapses, the light dims
to the stand-by level.
The light remains
dimmed to the
stand-by level at
night.
When the natural light
level exceeds the
“setpoint off” light
level, the fixture will
remain off even when
the space is occupied.
The light stays on at
10% brightness when
motion is not detected
and natural light
conditions are
insufficient.
goes in a cycle
at night, 100% brightness
when motion is detected,
and dims to 10% after no
motion is detected for a
long time.

Instructions for Sensor Parameter Adjustment Using Remote Are Included with the Remote
Dip Switch Parameter Settings
SENSOR DETECTION RANGE: 100%
SENSOR HOLD TIME: 5 MINUTES
LIGHT THRESHOLD: DISABLED
STAND-BY LIGHT LEVEL: 30%
STAND-BY TIME: 30 MINUTES
Dip Switch 1 & 2: Sensor Detection Range (Sensitivity) Settings
The operating parameters of the motion sensor may be adjusted directly from the sensor or remotely using an optional remote control.
Adjustments made directly to the sensor are done using a set of dip switches on the sensor body, in the locations indicated in the above image.
Each motion sensor parameter may be adjusted by using a set of two adjacent dip switches. Dip switches 1 & 2 set sensor sensitivity, dip switches
3 & 4 set sensor hold time, dip switches 5 & 6 set the level of lux for sensor activation, dip switches 7 & 8 set sensor stand-by light level, and dip
switches 9 & 10 set sensor stand-by time.
Sensor detection range, describes the radius of the circular detection zone on the ground below a sensor installed on a fixture (maximum ceiling
height 40ft). To adjust sensor detection range, put the dip switches to either an ON position ( ) or an OFF position ( ) as indicated in the guide
below.
Dip Switch 3 & 4: Sensor Hold Time Settings
Upon detecting motion, the fixture light can be set to stay on for any
period of time indicated in the options below. Any additional motion
detected before the selected amount of time elapses will restart the
timer. While adjusting the sensor detection zone and performing walk
tests, it is recommended to select the shortest possible hold time. To
adjust sensor hold time, put the dip switches to either an ON position
( ) or an OFF position ( ) as indicated in the guide below.
Dip Switch 7 & 8: Stand-By Light Level Settings
The stand-by light level determines the brightness of the fixture while
the sensor is not detecting motion. To adjust stand-by light level, put
the dip switches to either an ON position ( ) or an OFF position ( )
as indicated in the guide below.
ON
ON
1 2
100%
75%
50%
20%
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
SENSOR SENSITIVITY
SETTINGS
3 4
15 Min.
5 Min.
1 Min.
10 Sec.
SENSOR HOLD TIME
SETTINGS
7 8
50%
30%
10%
0%
STAND-BY LIGHT LEVEL
SETTINGS
5 6
50 Lux
30 Lux
10 Lux
Light Sensor Disabled
SENSOR LIGHT
THRESHOLD SETTINGS
Dip Switch 5 & 6: Light Threshold Settings
The sensor light threshold indicates the ambient light level at which
the sensor will begin to control the fixture. To adjust light threshold,
put the dip switches to either an ON position ( ) or an OFF position
( ) as indicated in the guide below.
Dip Switch 9 & 10: Stand-By Time Settings
The stand-by time determines the length of time the fixture stays on
while the sensor is not detecting motion. To adjust stand-by time, put
the dip switches to either an ON position ( ) or an OFF position ( )
as indicated in the guide below.
9 10
60 Min.
30 Min.
1 Min.
+∞
STAND-BY LIGHT LEVEL
SETTINGS
Motion Sensor Dip Switch Settings
Dip Switch Factory Settings
