KING CANOPY G10208 User manual

10’X20’ Dome Garage
ITEM #: G10208
Dimensions:
10ft. Wide x 20ft. Deep x 8ft. Center Height
WARNING:
Keep all ame and heat
sources away from this tent
fabric. It is not re proof
The fabric will burn if left in
continuous contact with any
ame source.
Distributed by: PIC America, LTD.
8009 Purfoy Road • Fuquay-Varina, NC 27526
1-800-800-6296 • www.kingcanopy.com

FOOT15PC-T (4) 2-way Corner Foot Pads
FOOT15PC-X (6) 3-way Center Foot Pads
3W13PC-T (10) 3-way Connectors (ends)
4W13PC-X (15) 4-way Connectors (centers)
4X10-15PC (28) 58” Pipe
2X10-15PC (10) 21.5” Pipe
3X9-15PC-C (20) 45” Curved Pipe
BALL (50) Ball Bungee Straps
AC-G1020 (5) Assembly Cables
ROPE60 (60´) Rope for Assembly
STAKE-GAR (10) Stakes
A15-CC (6) Screw-in Ground Anchors
G102008-EWWZ (1) Front Wall with Zippers
G102008-EWWW (1) Back Wall with Window
G10208-C (1) Cover
TB-GAR (4) Corner Turnbuckles
A15-CC
3W13PC-T
4W13PC-X
3X9-15PC-C
TB-GAR
PARTS
FOOT15PC-T FOOT15PC-T
FOOT15PC-X
G102008-EWWZ
G102008-EWWW
BALL
STAKE-GAR
AC-G1020
ROPE60
4X10-15PC
2X10-15PC
G10208-C

3-way Connectors
are for each end
4-way Connectors
are for center
connections
Note: Longest part of 3-way
is used to form the length. Note: The two longest parts
of the 4-way are used to
form the length.
FRAME ASSEMBLY
1) Start by laying out all of the parts and pieces to your King Canopy. Please refer to the
parts list to ensure that your kit is complete. When all the parts have been accounted for,
begin to layout your frame according to the photo above. The 3X9-15PC-C curved pipes
form the dome part of the canopy. The 4X10-15PC pipes form the length of the canopy.
Each 3-way tting (3W13PC-T) should be placed at all the end connections and the 4-way
(4W13PC-X) ttings are placed in the 3 center sections.
3X9-15PC-C 3X9-15PC-C
3X9-15PC-C
3X9-15PC-C 4X10-15PC 4X10-15PC
4X10-15PC
4X10-15PC 4X10-15PC
4W13PC-X
2X10-15PC
FOOT15PC-T FOOT15PC-T
FOOT15PC-X
FOOT15PC-X
2X10-15PC
FOR FASTER AND EASIER SETUP,
WE RECOMMEND ASSEMBLY BY TWO OR MORE PEOPLE.
4X10-15PC
3W13PC-T

FRAME ASSEMBLY
2) Assemble the center section of frame using the 3X9-15PC-C curved pipe and the
4X10-15PC 58´´ straight pipe. (See photo above) Make sure longest part of the 3-ways and
4-ways are used to form length. Continue assembly until you have four sections complete,
which is the full length of the unit.
2) After assembling the first full length
section of roof, use the rope enclosed to hold
frame together by tying the frame from end
to end down the center (See Photo Above
and on Right).

4) Once you have completely assembled all the curved sections of the canopy, (See Photo
Above) you are now ready to put the cover on. Put the cover on before assembling the last
section with feet. See next step.
3) Continue assembly by completing the next curved section on each side of the top
section. (See Photo Above) Hold frame together by tying frame from end to end like in
step 2 before.
NOTE: PUSH FRAME INWARD FROM EACH SIDE TO KEEP CURVE SHAPE.
FRAME ASSEMBLY

7) Once you have secured the cover to the curved section
of frame, you may now nish frame assembly. Assemble the
remaining frame on each side using the 2X10-15PC pipe,
foot sections, and 4X10-15PC pipe as shown in Diagram
K. Make sure hooks on the feet are on the inside of frame.
Push in on leg sections and make sure the legs are securely
set on ground before assembling nal side and standing
canopy up. This will keep the canopy from sliding.
10.
COVER & LEG ASSEMBLY
5) Remove the cover from plastic bag and unfold. Next fold half
the cover over the other half with the white side out. Match the
corners (See Diagram F) and mark the top center of cover at the
grommet line at both ends. (See Diagram G).
6) Once centers have been marked at both ends, pull cover
over frame with white side down. (See Diagram H) Position the
center mark with the top center pipe of frame. (See Diagram I)
Attach cover to each end of top curved frame by running ball
bungee straps through each grommet hole, around pipe and
hook back over ball. (See Diagrams J and K)
Diagram K
Diagram G
Diagram H
Diagram F
Diagram I
Diagram J

8) Now that you have completed the frame assembly and your
canopy is standing, take the cables provided and hook one end
to each foot (See Diagram L) over to the foot on the opposite
side. You may have to push out or pull in to get cables hooked.
Make sure cables are tight across. These cables keep the canopy
frame with the designed curved shape.
(NOTE: Be careful NOT to trip over cables.)
Diagram L
9) With the canopy standing and cables in place, anchor the canopy using the foot stakes
provided (See Diagram M). Driving the stakes in at an angle will help anchor the canopy
more securely. Once stakes are in place, you may remove the cables.
SEE “ANCHORING YOUR CANOPY”
Diagram M
COVER & LEG ASSEMBLY

10) To complete your canopy, secure the top down each side on the bottom pipe and
around each end with ball bungee straps. (See Diagram N)
11) Add the canopy endwalls using the hook
& loop straps by attaching around pipe. Next,
tighten and secure the drawstrings at each corner
foot. You have successfully set up your canopy
(See Diagram O). Now that the canopy is set up,
you may remove the ropes used for assembly.
COVER & END WALL ASSEMBLY
Diagram N
Diagram N

COVER & END WALL ASSEMBLY
Diagram O
NOTE: Your canopy sidewalls
and rear endwall are long
enough to be buried in the
ground.This will help prevent
water from running inside.

This canopy is designed for use as a temporary structure. After assembly, the canopy
MUST BE securely anchored to the ground to prevent damage from winds. Your canopy
will act like a kite in the wind if not properly and securely anchored to the ground. Severe
winds will cause the frame to twist and unanchored legs will fall, thereby collapsing the
canopy. If severe winds are expected, you must remove the cover from the frame to
prevent damage.
We recommend anchoring your canopy at each corner
foot and center foot on each side. Screw anchor into
ground next to canopy foot using a large screw driver
as seen in Diagram A. Looping the cable through the
anchor eye will keep it out of the way while turning.
Tilting the anchor slightly will help the anchor to cut into
the ground. Apply downward pressure while turning
the anchor into the ground. Leave approximately three
inches of anchor out of the ground.
Unloop the cable from the anchor eye and slide the
clamp onto cable. Run cable around the pipe, (See
Diagram B) and then back through the clamp as seen
in Diagram C. Pull the cable as tight as possible through
the clamp. Hold the cable and tighten clamp with a 5/8
inch wrench or some type of adjustable wrench.
When you have tightened the clamp and satised that
the cable will not slip, you may tighten the cable more
by turning the anchor further in the ground as seen in
Diagram D.
If you have further questions call our customer service
department toll free at 1-800-800-6296
Diagram A
Diagram B
Diagram C
Diagram D
1.
2.
3.
Parts Enclosed> 6-screw-in anchors with cable and clamp attached
(Tools needed = 5/8 inch wrench and large heavy-duty screw driver)
ANCHORING YOUR UNIT

We are condent that you will be completely satised with your King Canopy unit. Please take a moment
to read the very important information below, and call us with any questions you may have.
King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and
we are in no way responsible for any damage caused by the canopy or to the canopy. We suggest you contact
your insurance carrier just as you would for any other outside structure.
OTHER PRECAUTIONS WHICH MUST BE FOLLOWED:
Keep all ame and heat sources away from this tent fabric. The tent fabric will burn if left in continuous
contact with any ame source.
DO NOT cook underneath or near canopy.
DO NOT store or use ammable liquids underneath or near canopy.
DO NOT ignite or store reworks underneath or near canopy.
DO NOT use bleach to clean cover.
DO NOT dry clean cover.
DO NOT wash cover in washing machine or dry in dryer. Hand wash with mild soap and water only.
DO NOT allow rain water, snow or ice to accumulate on top of cover.
DO NOT hang or suspend anything from the frame, grommets, truss system or ball straps of the unit.
REMOVE canopy cover before a storm, or disassemble entire canopy unit if possible.
REMOVE rain water, snow and ice from canopy cover.
This is a temporary structure and is not recommended for use as a permanent structure.
IMPORTANT NOTICE: PLEASE READ CAREFULLY

Defective Parts
We try our best to eliminate any defective parts that are shipped with our products. If, however, you should nd
a defective part, we will replace – free of charge – any part which is defective. You will need to provide proof
of purchase showing date of purchase and provide us with detailed description of the defective component.
Your replacement will be shipped by ground shipping, freight prepaid. Next day or express shipping will
require freight collect and paid for by you, the consumer. Damages from improper anchoring, strong winds,
snow, ice or rain are not considered defects.
Improper Anchoring, Strong Winds, Rain Snow, or Ice
King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These
canopies are designed to protect against damages caused by sun, rain, tree sap, birds, etc. They are not designed
to hold roof loads that accompany snow, ice or heavy rains. If your canopy is not anchored securely, it can be
lifted by the wind and will y away. If your canopy takes ight, we are not responsible for any replacement. If
you know strong weather is predicted, remove the cover or take down the canopy unit completely. The cover
is designed to be quickly and easily removed.
Warranty
All components of this canopy feature a 1-year limited warranty and are warranted to be free from defects in
material and workmanship for a period of 1-year. You must complete and return the enclosed warranty card
promptly after purchase. Please retain your proof of purchase receipt; you will be asked to provide this receipt
in order to obtain warranty service.
Non-Warranty Replacement Parts
If after expiration of the warranty period, you require replacement parts please contact us at 1-800-800-6296.
We stock replacement parts and make them available to you at discounted prices. Our customer service
department will be pleased to assist you in any way possible.
Certain regions of the country are extremely hard on covers of any kind. Normal wear and tear is not covered
under the warranty, and should be expected.
In order to receive a discounted or free replacement part, you may be asked to return the part, freight prepaid,
to our warehouse for inspection before we will send a replacement. You must, in all cases, provide a copy of
your receipt showing the date of purchase, model number and price.
For missing parts, replacement parts or any questions:
Please Call 8:00am – 5:00pm EST, Monday – Friday
1-800-800-6296 or 1-919-552-2977
Or you can fax us at: 1-919-552-5069
Replacement parts and customer service is also available through our website.
Please visit us at www.kingcanopy.com
WARRANTY INFORMATION
