Glamox MAX LED Series User manual

Glamox MAX LED
User manual

2
English
For further installation and maintenance
guidance, please see the document
“Installation and maintenance manual”
enclosed with your product or on our
website.
Norsk
For ytterligere installasjons- og
vedlikeholdsveiledning kan du lese
dokumentet “Installation and maintenance
manual” som følger med produktet, eller
finnes på våre nettsider.
Svenska
För övriga installation och underhålls
uppgifter, var vänlig se vårt dokument
“Installation and maintenance manual”
bifogat med er produkt, eller på vår
hemsida.
Deutsch
Weitere Installations- und Wartungsweise
finden Sie in dem Dokument “Installation
and maintenance manual” zusammen mit
ihrem Produkt auf unsere Webseite.
Suomi
Tarkemmat asennus- ja huolto-ohjeet löytyvät
tuotteen mukana toimitetusta ohjeesta sekä
internetsivuiltamme.
Eesti
Lisainformatsiooni saamiseks vaata palun
“Installation and maintenance manual”, mis
on kaasas valgustiga ning leitav ka meie
koduleheküljelt.
Nederlands
Voor verdere installatie en onderhoud, zie
het document “Installation and maintenance
manual” dat bij uw product is bijgesloten of
kijk op onze website.
Dansk
For yderlig information om installation og
vedligeholdelse, se venligst dokumenterne
på vores hjemmeside på det pågældende
produkt.
Polski
Dalsze wskazówki dotyczące instalacji i
konserwacji znajdują się w dokumencie
„Instrukcja instalacji i konserwacji”
dołączonym do produktu lub na naszej
stronie internetowej.

3
English
The light source contained in this luminaire
shall only be replaced by the manufacturer
or his service agent or a similar qualified
person. Live parts inside – RISK OF
ELECTRIC SHOCK
Norsk
Lyskilden i denne armaturen skal kun byttes
av Glamox, Glamox sin serviceansvarlig
eller en tilsvarende kvalifisert person.
Strømførende deler på innsiden– FARE FOR
ELEKTRISK STØT
Svenska
Ljuskällan i denna armatur får endast
bytas ut i Glamox fabriker, av Glamox
servicetekniker eller motsvarande
kvalificerad personal. Strömförande delar
på insidan- RISK FÖR ELSTÖTAR
English
Do not connect to a temporary power
supply source. This may damage the
electronics.
Norsk
Tilslutt ikke armaturen til midlertidig
byggestrøm. Dette kan skade elektronikken.
Svenska
Anslut inte armaturen till tillfällig byggström.
Detta kan skada elektroniken.
Deutsch
Nicht an unsauberes Netz (Baustrom)
anschliessen. Die elektronischen Bauteile
können dadurch beschädigt werden.
Suomi
Älä kytke väliaikaiseen virtalähteeseen.
Tämä voi vioittaa elektroniikkaa.
Eesti
Ära kasuta ajutist toiteahelat. See võib
põhjustada vigastusi elektroonikale.
Nederlands
Sluit niet aan op een tijdelijke
elektriciteitsvoorziening. Dit kan de
elektronica beschadigen.
Dansk
Tilslut ikke armaturet til midlertidig
byggestrøm. Dette kan skade elektronikken.
Polski
Nie podłączać do tymczasowego źródła
zasilania. Może to uszkodzić elektronikę.
Deutsch
Die enthaltene Lichtquelle in dieser Leuchte
darf nur durch den Hersteller, seinen
Kundendienst oder eine ähnlich qualifizierte
Person ersetzt werden. Stromführende Teile
im Innern – GEFAHR EINES ELEKTRISCHEN
SCHLAGS
Suomi
Tämän valaisimen valonlähteen saa vaihtaa
ainoastaan valaisimen valmistaja, valtuutettu
huoltoliike tai vastaava pätevöity henkilö.
Jännitteisiä osia – SÄHKÖISKUVAARA
Eesti
Selle valgusti valgusallikat võib
asendada ainult tootja, tema lepinguline
hoolduspartner või sarnane kvalifitseeritud
personal. Sisaldab pingestatud komponente
– ELEKTRILÖÖGI OHT
Nederlands
De lichtbron in dit armatuur mag alleen
vervangen worden door de fabrikant,
zijn servicedienst of een soortgelijk
gekwalificeerd persoon. Stroomvoerende
delen binnenin – GEVAAR VAN
ELEKTRISCHE SCHOK
Dansk
Lyskilden i dette armatur må kun udskiftes
af Glamox, Glamox servicepartner eller
tilsvarende kvalificeret person. Invendige
strømførende dele – FARE FOR ELEKTRISK
STØD
Polski
Źródło światła w tej oprawie może zostać
wymienione wyłącznie przez producenta,
jego przedstawiciela serwisowego lub
inną wykwalifikowaną osobę. Wewnątrz
znajdują się części pod napięciem –
RYZYKO PORAŻENIA PRĄDEM

II 2G Ex eb mb op is IIC T4 Gb
II 2D Ex tb IIIC T81°C Db
PRESAFE 15ATEX 7402X
IECEx PRE 15.0068X
Description:
Surface mounted with LED modules for normal operation HF and
with a battery in external Battery box for emergency operation HF-E
Temperature limits (ta): HF: -30°C to 50°C
HF-E: -20°C to 50°C
Protection: IP67/66
Line voltage: 110 - 254V AC 50/60Hz and 220 - 250VDC
Supplied current (mains mode): 0.11 - 0.56A
Power factor: 0.92 - 0.96
Light modules: LED
For more information, please see www.glamox.com
0470
Types L1 C1 L C = Hood nuts M8 distance
MAX-600 LED 724 704 687 400 430 500
MAX-1200 LED 1334 1314 1296 500 700 950
X: Special conditions for safe use:
Potential electrostatic charging hazard – For cleaning use moist cloth only! No solvent.
WARNING:
Do not open when an explosive atmosphere is present!
Live parts behind cover – Do not contact!
4
MAX LED

5
Connection of MAX to the mains
When the MAX is connected to other luminaires as shows in the diagrams, the
switch will switch off/on all the luminaires. The light in both tubes of the MAX
can be switched while the battery will be charged uninterruptedly.
• Wiring without switch for main light
• Wiring with 1-poled switch for main light
Mains
L
N
L4
3
N
L1
2
L4
3
N
L1
2
MAX HF-E
Emergency
L4
3
N
L1
2
MAX HF
Not emergency
MAX HF-E
Emergency
Mains
L
N
L4
3
N
L1
2
L4
3
N
L1
2
L4
3
N
L1
2
MAX HF-E
Emergency
MAX HF
Not emergency
MAX HF-E
Emergency
Installation and operation MAX LED
Terminal block
Torque value for screws: 1.8Nm
Type and size of wires that can be used:
Solid wire: From 1.0mm² to 6.0mm²
Stranded wire with or without ferrule: From 0.75mm² to 6.0mm²
There can only be connected one wire on each side of the screw on each
side of each terminal. (totally max 4 wires at each terminal).
Earthing the luminaire
The luminaire must be earthed in the terminal block.
Armored cable must be earthed as described in the drawing.
For external bonding, see picture.
Connection of MAX LED
L1 - N for not emergency (main light)
L4 - N for emergency (charging)
Power supply must be from same line (fuse) for both normal light and emergency.
Earth terminal
Earth lug for
armored cable
Terminal wire
For external bonding

Mains
L
N
L4
3
N
L1
2
L4
3
N
L1
2
L4
3
N
L1
2
MAX HF-E
Emergency
MAX HF
Not emergency
MAX HF-E
Emergency
• Wiring with 2-poled switch for main light
M20 M25
Polyamid 5.0 Nm
8-13mm 7.5 Nm 12-18 mm Torque Cabel diameter
Brass 7.5 Nm
4-12mm 10.0 Nm 12-18mm Torque Cabel diameter
MAX LED-E MAX LED MAX LED-E
6
Installation and operation

85 mm
7
MAX LED mounting
12 3
4
With plastic folio at diffuser
5 6
7 8 9
10 11 12
Remove plastic folio before powering
1.8 Nm

Cables
Mains supply cable must be approved for fixed installation. The external diameter can be 4–12 mm (M20 gland) or
10–18 mm (M25 gland) as main choice, but different glands sizes can be supplied. Cross sectional area of the wires
can be between 1.5 and 6.0 mm2. The cable must have an earth wire and shielded cable is recommended to be
used.
Operation of MAX LED in emergency mode
MAX 600 LED 2200 give 16% light level at E1 and 9% at E3. MAX 1200 LED 4500 give 13% light
level at E1 and 6% at E3. When mains voltage is switched on the charging indicator (green LED) will light, indicating
charging of the battery. If the connection to the battery is disrupted or the battery is defect, the indicator will not light.
Reset fault indication by switching off/on power supply. A new or discharged battery must be charged for at least 24
hours in order to be full charged.
Battery pack replacement
When the battery pack is defect or need to be replaced, use only original battery pack from Glamox
• 4.8V 4.0Ah Item no: PA140818001 for MAX 600/1200 LED 3500/6500
• 7.2V 4.0Ah Item no: PM161012000 for MAX 600/1200 LED 2200/4500
Battery type is marked inside MAX LED.
Do not replace the battery when an explosive atmosphere is present.
Control and inspection
General inspection and main function control to be carried out once a month. Fully emergency duration test by
switching off power supply should be performed at least once a year and the specified emergency light time shall be
observed.
Maintenance
The MAX LED is designed to operate many years with a minimum need for maintenance. However it may be
necessary to clean the diffuser if it gets dirty. Do never use any solvents for cleaning polycarbonate diffuser due to risk
of generating static charge. Use moist cloth only, no solvent. If battery and other components need to be replaced, it
is important to use only original Glamox components.
Cycling of battery
To have best lifetime of batteries, cycle the batteries at least 2 times by charging for 24 h and discharge until the
emergency light turns off. To cycle, just switch the circuit breaker on/off.
MAX LED operation, inspection and maintenance
8

9
Battery change
Battery pack
Spareparts item no:
PA140818001, 4.8V, 4.0Ah
PM161012000 7.2V, 4.0Ah
1.2 Nm

10

• LED lamp do not light:
- Check that the mains voltage is in the voltage range of the luminaire.
- Check that the cover of the luminaire is mounted and that the screws are tightened.
- Open the luminaire and check the following:
Check the wires, the contacts, the HFX/HFXE LED.
Change with new one if damaged.
• The charging indicator (LED) do not light:
- Switch off/on to reset charging.
- Open the luminaire and check the following:
The connection of L4 - N, the battery and the charging unit.
Check if battery is connected and OK.
- The HFXE LED or battery might be defect.
• Emergency illuminance level is too low:
- Clean the cover of the luminaire
- Change the battery
• Emergency lighting time is under the specified time (1.5 or 3.0 hours for standard luminaire):
- Change the battery
Manufacturer:
Glamox AS
Birger Hatlebakks veg 15
NO-6405 Molde, Norway
Service contact:
Glamox AS
Tel.: [phone]
Fax: [phone]
or nearest Glamox sales office
11
What to do if....

Please visit our web site for contact information
www.glamox.com
Please refer to our websit
e
for information about
our 5-year warranty.
© Glamox August 2020
Item no: 72596948
