Glastender GT-24 User manual

© 2014 Glastender, Inc.Rev. 01-09-18
Operation Manual & Parts List
Glastender, Inc. · 5400 North Michigan Road · Saginaw, MI · 48604-9780
800.748.0423 · 989.752.4275 · Fax [phone] · www.glastender.com
GT-24, GT-30
Glasswashers
A Family Company Manufacturing In The USA Since 1969
(Manufactured after June 1, 1990 with digital temperature gauges)
GT-24-CW
GT-30-CCW

1Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
warranty statement
Glastender, Inc. warrants all products to be free of defects in mate-
rial and workmanship. One-year labor and parts warranty applies to
all glasswashers, self-contained refrigeration models, and BDS model
bottle disintegration units. In established areas, a start up is included
with GT-24 and GT-30 model glasswashers. Warranty is effective for
one year from the date of installation or up to 18 months from date of
factory shipment, whichever occurs sooner. Glastender, Inc. will replace
any part or assembly found defective under normal use and service.
For warranty labor claims beyond 15 months from the date of factory
shipment, proof of date of installation or occupancy must be provided.
Authorization for labor must be obtained from Glastender within the
warranty period and prior to the service being performed.
Labor warranty applies to the United States and Canada only.
Remote refrigeration models and beer line chillers include a one-year
parts warranty only. There is no labor warranty on these products.
Field replacement parts not covered under the original warranty include
a 90-day part warranty from the date of installation.
FOUR YEAR ADDITIONAL COMPRESSOR WARRANTY:
Glastender will warrant to the original user the compressor for all self-
contained refrigeration models for an additional four years following the
regular one-year warranty period. This plan applies to the compressor
only.
A completed warranty claim form MUST accompany all returned defec-
tive parts or assemblies. Upon request, a defective part or assembly must
be returned to Glastender, Inc., Saginaw, Michigan, with all transporta-
tion and delivery charges prepaid. Warranty repairs or replacements
will be shipped FOB factory in Saginaw, Michigan. Reimbursement for
applicable freight charges covers ground service only.
Glastender provides in-warranty repairs during a service company’s
regular working days and hours. There is no provision for payment
of a premium rate during “overtime” hours. When warranty service is
requested during other than normal working hours, the end user will be
charged the premium portion of the overtime rate.
The warranty covers substantiated travel expenses for up to 2 hours /
100 miles round trip up to a maximum of $150. Any additional costs
due to installations that require extra work, time, or travel to gain access
for service are the sole responsibility of the equipment purchaser. Any
exceptions to these travel and access limitations must be pre-approved
by a factory representative.
The warranty does not cover door gaskets, chemical tubing, pump
squeeze tubing, and/or any equipment subjected to accidents, freight
damage, alterations from the original design, improper power and/or
plumbing hookups, improper chemical use, general misuse, or lack
of routine required maintenance as determined by Glastender, Inc.
Installation, normal control adjustments, general maintenance, correct-
ing an installation error, or service calls that reveal the unit is function-
ing normally will not be reimbursed under warranty.
Condenser coils on self-contained refrigeration products must be
cleaned regularly. Failure to provide adequate air flow to a refrigeration
unit will void the warranty.
Glastender shall not be liable for loss of use, revenue, or profit, or for
any other indirect, incidental, special, or consequential damage includ-
ing, but not limited to, product spoilage or loss.
This warranty is conditioned upon Glastender receiving notice of any
defect subject to this warranty within sixty (60) days of its discovery
by the end user or dealer. All products are warranted only for the initial
place of installation. Removal of a product automatically terminates
this warranty.
SECOND YEAR EXTENDED PARTS & LABOR WARRANTY:
Glastender’s one-year parts and labor warranty on self-contained refrig-
eration units, excluding beer line chillers, can be extended to two years
with the purchase of a two year parts and labor warranty. Specify part
number EWR2 ($150 net price) when ordering.
EXPORT WARRANTY - One year parts only.
EXCLUSION OF WARRANTIES
EXCEPT AS PROVIDED ABOVE, GLASTENDER MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OR NON-INFRINGEMENT.
LIMITATION OF REMEDIES AND DAMAGES
If Buyer makes a valid and timely claim as outlined above, Glastender’s
liability and Buyer’s remedies under this agreement will be limited solely
to labor charges authorized and/or replacement or credit, at Glastender’s
option, with respect to Products returned at Buyer’s expense within thir-
ty (30) days after warranty repair. GLASTENDER’S LIABILITY WILL
IN NO EVENT BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE RETURNED PRODUCTS. GLASTENDER
WILL NOT BE LIABLE UNDER ANY CIRCUMSTANCE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, INCLUDING,
BUT NOT LIMITED TO, LABOR COSTS EXCEPT AS COVERED
UNDER OUR WARRANTY, LOST PROFITS OR THE LOSS OF
PERISHABLE PRODUCTS RESULTING FROM THE USE OF OR
INABILITY TO USE OUR PRODUCTS OR FROM OUR PRODUCTS’
INCORPORATION INTO OR BECOMING A COMPONENT OF
ANY OTHER PRODUCT. NEITHER PARTY WILL HAVE ANY
NEGLIGENCE OR OTHER TORT LIABILITY TO THE OTHER, OR
TO ANY THIRD PARTY, ARISING FROM ANY BREACH OF THIS
AGREEMENT.
GOVERNING LAW - JURISDICTION
The terms and conditions of an order are to be governed and construed
according to the laws of the State of Michigan, without regard to conflict
of laws principles. Buyer hereby consents to the jurisdiction and venue
of the courts located in Saginaw County, Michigan.
No representative, distributor, dealer, or any other person is authorized
to modify this warranty. This warranty replaces all other written or
verbal warranties.
NOTE: Glastender, Inc.’s policy of constant quality improvement
means that prices, specifications, and policies are subject to change
without notice. Questions regarding this warranty should be directed to
Glastender’s Warranty Administrator.
04-19-17
APPLICABLE TO ALL PRODUCTS SOLD WITHIN THE UNITED STATES AND CANADA
IMPORTANT!!
Attention Service Companies
Please review the important warranty information on this page. If you
believe a service call should be covered by the factory, please call
the factory for authorization between 8AM and 5PM EST, Monday
through Friday.

2
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Index
Exterior Components ..........................................3-4
Glass Stops, Curtains, Rinse Tank Guides
and Conveyors ....................................................5-6
Spray Boxes, Gaskets, Inlet Screens
and Level Controls..............................................7-8
Electrical Components......................................9-10
terms and CondItIons
Drive Assembly Components .........................11-12
Recirculating Pump Components ...................13-16
Chemical Tubing, Level Sensor Tubing
and Related Parts ...........................................17-18
Peristaltic Pump Components.........................19-22
Plumbing Components....................................23-24
PrICes:
All prices are LIST. Applicable taxes will be added.
QuotatIons:
Unless otherwise stated, quotations are effective for 30 days only.
aCCePtanCe:
All orders are subject to acceptance by Glastender, Inc.’s headquarters in
Saginaw, Michigan. Possession of the Product Directory and Price List
is not an offer to sell.
shIPments:
F.O.B. factory in Saginaw, Michigan. Freight terms are Third Party or
Collect if shipped directly to you. Prepay and Add to Invoice freight
terms are available upon request. The approximate shipping weights of
all products are listed with the prices. Partial shipments will be made
unless otherwise specified by the customer. Surface freight classifica-
tions are:
• GT-24/GT-30/GW24 Glasswashers - Class 175
• GT-18 Glasswashers - Class 250
• All Underbar Equipment - Class 175
• Bar Die Orders – Class 250
• Portable Bars - Class 175
• Remote refrigerators (i.e., no compressor) or dry storage back bar
equipment - Class 175
• Self-contained refrigeration equipment - Class 150
• Ice Display Units (IDU and GDU) - Class 85
• Lighted Liquor Displays - Class 85
• Beer line chillers and beer towers (beverage dispensing equipment)
- Class 92.5
• Bottle Disintegration System - Class 150
• Ice Cream Freezers - Class 77.5
All small items are evaluated to see the most cost effective means for
shipment. Many small items ship via UPS or FedEx; however, when
dimensional weight is excessive, LTL carriers are the most cost effective
choice. Spare parts orders received before 1:00 PM EST can usually be
shipped the same day.
The order department is happy to assist with routing or shipping questions.
Payment terms:
Cash should be included with all orders unless credit terms have been
arranged. To establish credit, banking and trade references are required.
A convenient credit application is available upon request. Payment via
credit card is not our normal means of receiving payment. Visa and
MasterCard will be accepted, but must be charged at the time of ship-
ment. In addition, a payment via credit card for orders totaling more than
$500 will incur a 3% convenience fee on the total transaction amount.
delIvery:
The majority of equipment is manufactured to order and typically ships
within three to six weeks after complete order information is received by
the factory. In-stock equipment typically ships within two to three days
of the factory receiving complete order information.
returns:
Items specified as “Manufactured to Order” are NOT returnable.
A Return Authorization number must be issued by the factory in
advance for any items that are returnable. The number MUST be noted
on the outside of the returned package. Returns must be received within
90 days of the issue date. Shipping charges must be prepaid. A mini-
mum 20% restocking charge will be applied to all authorized returns if
received in new, unused condition in the original packaging.
The above conditions apply to spare part returns, except spare part
returns must be received within 30 days of original shipment for elec-
tronic or electrical parts or within 90 days for all other parts.
loss or damaGe:
For customer routed shipments, Glastender, Inc. is not responsible for
any loss, damage, or delay of merchandise during shipment. Such transit
claims must be filed with the carrier. Merchandise must be examined on
arrival. If shortages occur, Glastender, Inc. must be notified in writing
within five (5) days of delivery to honor any shortage claim. Glastender
will assume responsibility for freight claims on Prepay and Add ship-
ments but the customer must inspect freight and note any damage upon
receipt. Failure to do so may result in losses at the customer’s expense.
Custom orders:
Custom orders must be paid in advance and are not subject to cancellation.
lamInates:
Some products include common, readily available plastic laminates of
the customer’s selection. There may be an additional charge if uncom-
mon varieties are ordered.
12/14/17

3Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Front View 13
8
9
7
9
4
5
6
10
3
1
16
Rear View
4
5
Counterclockwise Model Shown
Counterclockwise Model Shown
15
11
12
214
exterIor ComPonents

4
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
exterIor ComPonents
Part no. desCrIPtIon PrICe
1. 04000111 Leg, stainless steel, 7″ (4 required) $39.00
00000041 Bolt, leg, 1/4″-20 x 5/8″ (4 required per leg) .50
2. 01000701 Floor, GT-24, clockwise 278.00
01000702 Floor, GT-24, counterclockwise 278.00
01000703 Floor, GT-30, clockwise 328.00
01000704 Floor, GT-30, counterclockwise 328.00
3. 00000031 Screw, exterior, 10-24 x 1/2″, PPH, SMS, 410 SS 1.00
4. 01000715 Skin top, GT-24 76.00
01000718 Skin top, GT-30 102.00
5. 01000716 Top, GT-24, clockwise 749.00
01000717 Top, GT-24, counterclockwise 749.00
01000719 Top, GT-30, clockwise 942.00
01000720 Top, GT-30, counterclockwise 942.00
6. 01000713 Front shield, GT-24 (decal not included) 140.00
01000714 Front shield, GT-30 (decal not included) 167.00
7. 01000628 Panel, switch, GT-24 and GT-30 (decal not included) 89.00
8. 01000629 Panel, back, GT-24 89.00
01000634 Panel, back, GT-30 106.00
9. 01000630 Panel, side, GT-24 (2 required) 83.00
01000635 Panel, side, GT-30 (2 required) 101.00
10. 01000631 Panel, front, GT-24 (15-1/2″) 76.00
01000636 Panel, front, GT-30 (21-1/2″) 104.00
11. 01000632 Panel, split front, TOP, GT-24 48.00
01000637 Panel, split front, TOP, GT-30 60.00
12. 01000633 Panel, split front, BOTTOM, GT-24 48.00
01000638 Panel, split front, BOTTOM, GT-30 60.00
13. 01000487 Decal, cleaning instructions, clockwise 26.00
14. 01000488 Decal, cleaning instructions, counterclockwise 25.00
15. 01000494 Decal, switch panel 12.00
16. 01000678 Tank complete, GT-24, clockwise (includes all welded components) 2,260.00
01000679 Tank complete, GT-24, counterclockwise (includes all welded components) 2,260.00
01000680 Tank complete, GT-30, clockwise (includes all welded components) 2,625.00
01000681 Tank complete, GT-30, clockwise (includes all welded components) 2,625.00

5Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Glass stoPs, CurtaIns, rInse tank GuIdes, and Conveyors
3
2
8
7
1
6
5
4
Clockwise Model Shown
9

6
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Glass stoPs, CurtaIns, rInse tank GuIdes, and Conveyors
Part no. desCrIPtIon PrICe
1. 01000727 Glass stop arm assembly, GT-24 (consists of: 01000728, 01000729, 01000730, and
01000731)
$78.00
01000733 Glass stop arm assembly, GT-30 (consists of: 01000732, 01000729, 01000730, and
01000731)
80.00
2. 01000728 Glass stop arm with ag, GT-24 50.00
01000732 Glass stop arm with ag, GT-30 52.00
3. 01001592 Kit, gears, glass stop arm actuator (consists of 01000730, 01000729, 01000731) 30.00
4. 01000653 Curtain, front, GT-24 40.00
01000654 Curtain, front, GT-30 50.00
5. 01000655 Curtain, wash or rinse, GT-24, 13-1/2″ (2 required) 25.00
01000656 Curtain, wash or rinse, GT-30, 17″ (2 required) 31.00
6. 01000684 Curtain set, GT-24 (consists of: two 01000653 and two 01000655) 130.00
01000685 Curtain set, GT-30 (consists of: two 01000654 and two 01000656) 160.00
7. 01000659 Rinse tank guide, GT-24, clockwise 64.00
01000660 Rinse tank guide, GT-24, counterclockwise 64.00
01000661 Rinse tank guide, GT-30, clockwise 74.00
01000662 Rinse tank guide, GT-30, counterclockwise 74.00
8. 01000563 Conveyor, GT-24 460.00
01000565 Conveyor, GT-30 574.00
9. 01000534 Stemware rack for GT-24 295.00
01000535 Stemware rack for GT-30 385.00

7Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
sPray Boxes, Gaskets, Inlet sCreens, and level Controls
3
8
5
14 1
6
4
2
12
11
7
10
9
13

8
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
sPray Boxes, Gaskets, Inlet sCreens, and level Controls
Part no. desCrIPtIon PrICe
1. 01000663 Spray box, wash, GT-24 $454.00
2. 01000664 Spray box, wash, GT-30 479.00
3. 01000665 Spray box, rinse, clockwise, GT-24 227.00
01000668 Spray box, rinse, counterclockwise, GT-24 227.00
4. 01000666 Spray box, rinse, GT-30 240.00
5. 01000470 Gasket, wash or rinse spray box (GT-24 and GT-30) 5.00
01000471 Gasket set, spray box (consists of: (2) 01000470) 10.00
6. 01000675 Screen, pump inlet (GT-24 and GT-30) 70.00
7. 01000520 Pickup tube, liquid level 16.00
8. 01000521 Tubing, liquid level, GT-24 (36″ long) 6.00
01000522 Tubing, liquid level, GT-30 (42″ long) 8.00
9. 01000550 Switch, liquid level and low level air 35.00
10. 00000022 Screw, air switch mounting, #6 x 1/2″ .50
11. 00000001 Clamp, cable, white nylon, 5/8″ ID .50
12. 00000025 Screw, water inlet straps, pickup tube straps, and water inlet cover, 8-32 x 5/8″ .50
13. 01000644* Cover, pickup tube and water inlet, wash 48.00
14. 01000645* Cover, pickup tube and water inlet, rinse 48.00
*NOTE: For these parts, you must specify if the unit is clockwise or counterclockwise when ordering.

9Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
eleCtrICal ComPonents
19
2
25
21
433
20
336
37
38
35
32
1
16
34
14
5
15
27
17 13 12
18
6
31
22
26
29
23
9
8
10
7
11
30
28
208 Volt Shown
24

10
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
eleCtrICal ComPonents
Part no. desCrIPtIon PrICe
01000608 Wire harness, GT-24 and GT-30 $165.00
1. 01000549 Switch, conveyor and ll (2 required) 18.00
2. 07000257 Switch, prime, momentary (2 required) 20.00
3. 01000591 Light, power, green, 240VAC 11.00
4. 01000593 Light, check chemicals, asher, 125VAC 20.00
5. 01000550 Switch, liquid level and low level air 35.00
6. 01000866 Screw, air switch mounting, 4-40 x 3/4″ phillips (2 required) 1.00
7. 01000551 Switch, glass stop with roller 56.00
8. 01000859 Spring, 18-1/2 ounce 10.00
9. 07000259 Switch insulator 1.50
10. 00000032 Screw, switch retaining, 6-32 x 1″, HH, MS, zinc (2 required) .50
11. 01000641 Washer, switch retaining screw, star, #6 (2 required) .50
12. 01000554 Relay, 120V 80.00
13. 00000050 Screw, relay mounting, 10-32 x 1-1/4″ PPH, MS, SS (2 required) .50
14. 01000545 Thermostat 110.00
15. 00000022 Screw, thermostat mounting, #6 x 1/2″ (2 required) .50
16. 01000484 Bracket, thermostat mounting 5.00
17. 01000740 Grommet, thermostat mounting bracket, relay mounting 1.00
18. 00000044 Screw, thermostat mounting bracket, 10 x 5/8″, PPH, zinc (2 required) .50
19. 01000606 Gauge, digital temperature with probe 145.00
20. 00000023 Screw, temperature gauge mounting, at head, 4-40 x 1″ .50
21. 01000618 Nut, temperature gauge mounting, 4-40 .50
22. 01000741 Retaining plate, rinse tank sensor bulb 2.00
23. 01000738 Cover, thermometer 4.00
24. 00000026 Nut, sensor and thermostat bulb, retaining plate, electrical box mounting, 8-32 .50
01000641 Washer, sensor and thermostat bulb, retaining plate, star, #6 .50
25. 01001586 Heater kit, perimeter style, 240 volt (replaces 01000583) 265.00
01001587 Heater kit, perimeter style, 208 volt (replaces 01000584) 265.00
26. 01000555
Transformer, low level sensor and temperature gauges (primary - 120VAC, secondary - 24VAC) 53.00
27. 00000039 Screw, transformer mounting, 10-32 x 3/8″ phillips, TH, MS, SS .50
28. 01000669 Plug, three wire 1.00
29. 06001537 Plug, six wire 1.50
30. 01000547 Receptacle, three wire 1.00
31. 06001634 Receptacle, six wire 1.50
32. 01000670 Plug, solderless terminal .50
33. 01000548 Receptacle, solderless terminal .50
34. 06001584 Cover, electrical box 1.50
35. 00000168 Electrical box 4.00
36. 01000474 Bracket, electrical box 17.00
37. 06001552 Grommet, electrical box 3.50
38. 00000076 Bolt, electrical box, 8-32 x 1/2″, hex head (2 required) .50
01000642 Lockwasher, large, star, #10 .50

11 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
drIve assemBly ComPonents
CW View
CCW View
5
15 4
8
3
12
11
10
14
267
9
1
13
67
15

12
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
drIve assemBly ComPonents
Part no. desCrIPtIon PrICe
1. 01000801 Drive shaft $111.00
2. 01000847 Washer, drive shaft, nylon (3 required) .50
3. 01000671 Flange bearing (2 required) 3.00
4. 01000475 Mount, motor, clockwise rotation 26.00
5. 01000476 Mount, motor, counterclockwise rotation 26.00
6. 01000855 Screw, drive motor mounting, 10-32 x 5/8″ (4 required) .50
7. 01000642 Lockwasher, #10, drive motor mounting screw (4 required) .50
8. 00000041 Bolt, motor mounting to tank, hex, washer head, 1/4″-20 x 5/8″ (4 required) .50
9. 01000467 Pulley, 3″, with set screw and machined center, drive shaft 20.00
10. 01000466 Pulley, 2″, with set screw and sleeve, drive motor 14.00
11. 00000024 Screw, set, drive shaft or drive motor pulley, 5/16″-18 x 1/2″ .50
12. 01000735 Sleeve, drive motor pulley, 3/8″ to 1/2″ 6.00
13. 01000587 Belt, 27″, GT-24 20.00
01000588 Belt, 33″, GT-30 20.00
14. 01000594 Motor, drive, 1/2 RPM (Merkle-Korff) 225.00
15. 01000531 Fan blade, drive motor 3.00
01001590 Fan blade, drive motor, black, REX 3.00

13 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
reCIrCulatInG PumP ComPonents
manufaCtured PrIor to novemBer 2004
3
2
6
5
7
8
4
1
Recirculating Pump Kit
Curtain not pictured
9
10

14
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Part no. desCrIPtIon PrICe
1. 00000076 Bolt, water recirculating pump mounting, 8-32 x 1/2″, hex head (4 required per pump) .50
01000642 Lockwasher, water recirculating pump mounting, large, star, #10 .50
00000026 Nut, water recirculating pump mounting, 8-32 .50
2. 00000000 Clamp, water recirculating pump hose (6 required per pump) 1.00
3. 01000612 Hose, bottom, long, wash pump, GT-24 5.00
01000614 Hose, bottom, long, wash pump, GT-30 5.00
4. 01000613 Hose, bottom, short, rinse pump, GT-24 4.00
01000615 Hose, bottom, short, rinse pump, GT-30 4.00
5. 01000616 Hose, top (2 required per pump) 5.00
06001468 Hose, 1″ ID x 1-1/4″ OD x 1/8″ (per foot) 5.00
6. 01000598 Pipe, PVC, 3/4″ x 4″ 4.00
7. 01000599 Tee, PVC, 3/4″ 10.00
01000604 Pipe, PVC, 3/4″ x 6″ (GT-30 wash pump only) 4.00
8. 01000562 Valve, drain (2 required) 13.00
9. 01000826* Mounting kit, MP water pump (pump not included) 92.00
10. 01000415 Pump, water recirculating, wash pump 660.00
reCIrCulatInG PumP ComPonents
manufaCtured PrIor to novemBer 2004
* These kits are needed to only when replacing Hartell Pumps, installed in Glasswashers prior to November 2004.

15 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
reCIrCulatInG PumP ComPonents
manufaCtured novemBer 2004 and later
7
5
3
14
6
2

16
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Part no. desCrIPtIon PrICe
1. 01000415 Pump, water recirculating, all stainless construction with impellers, 115, (this pump is
the larger of the two pumps)
660.00
2. 01001270 Pump, water recirculating, GT-24 and GT-30 rinse, 115V, 1/10 hp - for use in all GT-24
SN 24008346 and after and GT-30 SN 30005302 and after (built after May 1, 2008)
(this pump is the smaller of the two pumps)
575.00
3. 01000612 Hose, bottom, long, wash pump, GT-24 5.00
01000614 Hose, bottom, long, wash pump, GT-30 5.00
4. 01000613 Hose, bottom, short, rinse pump, GT-24 4.00
01000615 Hose, bottom, short, rinse pump, GT-30 4.00
5. 01000616 Hose, top (2 required per pump) 5.00
6. 01000599 Tee, PVC, 3/4″ 10.00
7. 01000562 Valve, drain (2 required) 13.00
01000851 Shaft seal, for wash pump 01000415 50.00
01000854 O-Ring, for wash pump 01000415 5.00
01000852 Impeller, for wash pump 01000415 42.00
01000853 Acorn nut, for wash pump 01000415 3.00
reCIrCulatInG PumP ComPonents
manufaCtured novemBer 2004 and later

17 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
ChemICal tuBInG, level sensor tuBInG, and related Parts
6
7
10
10
8
9
4
5
11
12
2
1
13 14
Clockwise Model Shown
3

18
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Part no. desCrIPtIon PrICe
1. 01000517 Tubing, clear, 1/8″ ID x 1/4″ OD (per foot) $3.00
2. 01000527 Tubing, clear, 1/16″ ID x 1/8″ OD (per foot) 1.00
3. 01000526 Tubing support, detergent 6.00
4. 01000858 Tubing support, sanitizer 6.00
5. 01000518 Pickup tube, low level sensor, PVC 25.00
6. 01000485 Decal, detergent 1.00
7. 01000486 Decal, sanitizer 1.00
8. 01000696 Tubing, assembly, lower, detergent (consists of: 01000517 [6′ length], 01000601, and
01000526)
20.00
9. 01000694 Tubing, assembly, lower, sanitizer (consists of: 01000527 [6′ length], 01000858, and
(2) 01000603)
20.00
10. 01000687 Tubing, assembly, liquid low level sensor (consists of: 01000517 [6′ length], and
01000518)
37.00
11. 01000601 Fitting, chemical pickup, detergent, 1/8″ 2.00
12. 01000603 Connector with nut, sanitizer feedline, 1/8″ (2 required) 2.50
13. 01000697 Tubing, assembly, upper, detergent, 1/8″ ID (6′ length) (pump to tank) 12.00
14. 01000695 Tubing, assembly, upper, sanitizer, 1/16″ ID (6′ length) (pump to tank) 6.00
ChemICal tuBInG, level sensor tuBInG, and related Parts

19 Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
eleCtronIC PerIstaltIC PumP ComPonents
manufaCtured PrIor to January 2003
14
9
8
10
17
16
5
7
13
1
3
6
2
12
15
18
4
19
20
11
21
22
