Glastender GW24 User manual

Parts Directory
Glastender, Inc. · 5400 North Michigan Road · Saginaw, MI · 48604-9780
800.748.0423 · 989.752.4275 · Fax [phone] · www.glastender.com
GW24 GlassWasher
© 2011 Glastender, Inc.
Rev. 07-01-14
A Family Company Manufacturing In The USA Since 1969
Conforms to ANSI/UL STD 921
Certied to CSA STD
C22.2 No. 168

1
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax [phone] • www.glastender.com
Index
Warranty.................................................2
Terms and Conditions ......................................3
Covers and Drainboard Tops .................................4
Interior and Exterior Components ........................... 5-6
Electrical Components.................................... 7-8
Recirculating Pump and Related Parts ...................... 9-10
Peristaltic Pump, Chemical Tubing, and Related Parts......... 11-12
Drive Assembly Components ............................ 13-14
Accessories .............................................14
Plumbing Components.................................. 15-16
Recommended Spare Parts Inventory .........................17
Parts Order Form .........................................18
