Glem GLINDPS User manual

Induction Cooktops
Instruction Book - GLINDPS and GLINDBG
Glem Gas After Sales Service 1 300 307 917

Contents
Page
2 Safety warnings
3 Safety warnings and Functions of an induction Cooktop
4 Control panel explanations and Power Share (GLINDPS)
5 Choosing the correct cookware
6 Using the induction cooktop and boost function (GLINDBG)
7 Using the timer and pause function
8 Care and cleaning - Quick reference guide
9 Error codes
9 -11 Installation of the cooktop
12 Electrical connection
A NOTE FROM GLEM GAS
Thank you for the purchase of one of our induction cooktops.
We have tried to include everything you need to know about the operation and
installation of your induction cooktop in this book. It is important that all installation
requirements are met. For example the cut out must be precise and the electrical
connection correct because we do not o󰀨er warranty for installations where these
requirements are not met.
If you are in any doubt about anything call After Sales Service on 1 300 307 917.

Glem Gas endorses a safe kitchen
At Glem Gas we are very safety conscious and we
have developed our cooktops with your safety as
the most important consideration. Please take time
to read through this manual and always take care
when using an electrical appliance. Keep these
instructions handy for future reference.
Remove all packaging and dispose of properly.
SAFETY WARNINGS
Installation
Model GLINDPS has the advantage of a simple
plug in connection but it still needs installation by a
qualied installer and electrician. Your home must
have the power capacity to power the induction
cooktop. An electrician will be able to determine
if the cooktop installation is appropriate. Warranty
will be void should this not be determined during
installation of the GLINDPS
Model GLINDBG must be connected by a qualied
electrician, and you will need to retain proof for
future service or warranty requirements.
Installation - Electrical shock hazard
• Disconnect the appliance from the main
electricity supply before carrying out work or
maintenance.
• Connection to a good earth wiring system is
essential and mandatory.
• Alterations to the domestic wiring system must
only be made by a qualied electrician.
• Failure to follow this advice may result in
electrical shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or
cuts.
Important Safeguards
• Read these instructions carefully before
installing or using this appliance.
• No combustible material or products should be
placed on this appliance at any time.
• Please make this information available to the
person responsible for installing the appliance
as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must
be installed according to these instructions for
installation.
• This appliance must be properly installed and
earthed by a suitably qualied person.
• This appliance should be connected to a circuit
which incorporates an isolating switch providing
full disconnection from the power supply.
• Failure to install the appliance correctly could
invalidate any warranty or liability claims.
Operation and Maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked hob. If the
hob surface is broken or cracked, switch the
appliance o󰀨 immediately at the mains power
supply (wall switch) and contact a qualied
technician.
• Switch the hob o󰀨 at the wall before cleaning or
maintenance.
• Failure to follow this advice may result in
electrical shock or death.
Health Hazard
• This appliance complies with electromagnetic
safety standards.
Hot Surface Hazard
• During use, accessible parts of this appliance
will become hot enough to cause burns.
• Do not let your body, clothing or any item other
than suitable cookware contact the ceramic
glass until the surface is cool.
• Metallic objects such as knives, forks, spoons
and lids should not be placed on the hob surface
since they can get extremely hot.
Keep children away.
• Handles of saucepans may be hot to touch.
Check that saucepan handles do not overhang
other cooking zones that are on. Keep handles
out of reach of children.
• Failure to follow this advice could result in burns
and scalds.
Cut Hazard
• The razor-sharp blade of a cooktop scraper is
exposed when the safety cover is retracted. Use
with extreme care and always store safely and
out of reach of children.
• Failure to use caution may result in injury..
Important safety instructions
• Never leave the appliance unattended when
in use. Boilover causes smoking and greasy
spillovers that may ignite.
• Danger of re -Do not store items on the cooking
surface.
• Never leave objects or utensils on the appliance.
• Never use your appliance for warming or heating
the room.
• After use, always turn o󰀨 the cooking zones and
cooktop as described in this manual.
• Do not allow children to play with the appliance
or sit, stand, or climb on it.
• Do not store items of interest to children in
cabinets above the appliance. Children climbing
on the hob could be seriously injured.

• Do not leave children alone or unattended in the
area where the appliance is in use.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience or knowledge, unless they have
been given supervised or instruction concerning
use of the appliance by a responsible person for
their safety.
• Do not repair or replace any part of the
appliance unless specically recommended in
the manual. All other servicing should be done
by a qualied technician.
• Do not use a steam cleaner to clean.
• Do not place or drop heavy objects on cooktop.
• Do not stand on the cooktop.
• Do not use pans with jagged edges or drag pans
across the glass surface as this can scratch the
glass.
• Do not use scourers or any other harsh abrasive
cleaning agents to clean your cooktop, as these
can scratch the ceramic glass.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid a
hazard.
• The appliance is not intended to be operated
by means of external timer or seperate remote
control system.
This appliance is intended to be used in
a domestic household environment only!
Commercial use of any kind is not covered
under the manufacturer’s warranty!
WARNING: The appliance and its accessible
parts become hot during use.
Care should be taken to avoid touching the heating
elements. Children under 8 years of age should be
kept away unless constantly supervised.
Children shall not play with the appliance. Cleaning
and user maintenance should not be made by
children without supervision.
CAUTION - The cooking process has to be
supervised. A short term cooking process has to be
supervised continuously.
WARNING: Unattended cooking on a hob with fat
or oil can be dangerous and may result in re.
NEVER try to extinguish a re with water, but switch
o󰀨 the appliance and then cover ame e.g. with a lid
or a re blanket.
WARNING: Danger of re: do not store items on
the cooking surfaces.
WARNING: If the surface is cracked, switch o󰀨 the
appliance to avoid the possibility of electric shock
• A steam cleaner is not to be used to clean the
cooktop.
• The appliance is not intended to be operated by
means of an external timer or separate remote-
control system.
EXPLANATION ON THE FUNCTIONS OF AN
INDUCTION COOKTOP
Cooktop Preparation
Remove and discard any protective lm or labels
that may be attached to the surface of your cooktop.
Wipe the cooktop down with a damp cloth to remove
any builder’s debris or marks.
What is induction cooking?
Induction cooking is a safe, advanced, and e󰀩cient
cooking technology. It works by electromagnetic
vibrations generating heat directly into the pan,
rather than indirectly through heating the glass
surface. The glass becomes hot only because the
pan eventually warms it up.
It is fast and responsive to turn dhown. On the lower
power settings the cooktop cycles on and o󰀨 to
control the heat making it very good for simmering.
Diagram of induction heating
A - Magnetic conductive cooking vessel
B - Ceramic cooktop surface provides insulation and
the cooking surface.
C - Magnetic coil
D - Coil
E - Vortex. Relying on an electromagnetic eddy
current the internal molecules of the pot are
vigorously rubbed together creating heat.
A
B
DC
E

MODEL GLINDBG
Full boost 60cm induction cooktop
This is a high powered (7200W) induction cooktop
with boost function on all 4 cooking zones. The
cooking zones have di󰀨erent power levels to provide
exibility in heat rates and cooking styles.
Heat Zones
Model GLINDBG
Power of zone - 1 1800 / 2200W
Power of zone - 2 1200 / 1500W
Power of zone - 3 1800 / 2200W
Power of zone - 4 1200 / 1500W
Total Power 7200W
Control Panel Explained Model GLINDBG
SYMBOL FUNCTION SYMBOL FUNCTION
ON/OFF TIMER
MINUS ZONE SELECTION
PLUS CHILD LOCK
PAUSE BOOST
MODEL GLINDPS
“Plug and Play” 2200W 60cm induction cooktop
This is a new concept in induction cooktops where
for the rst time a Glem Gas induction cooktop can
be plugged into a standard power outlet. The power
is shared between the 3 cooking zones providing
cooking performance similar to a gas cooktop.
The induction cooktop GLINDPS has been designed
with a power limiter. This is to ensure the cooktop
does not exceed 2200W, allowing it to be plugged
into a 10amp power socket where the maximum
supply is 2400W.
When more zones are turned on the power level will
change for each zone. The power is shared when
more than one zone is used at a time.
Power Sharing - Model GLINDPS
1. Use any one zone at full power (level 9)
2. Use any two zones in conjunction at max power
level 7 for both zones (eg. zone 1 & 2, Zone 1 &
3 etc.)
3. Use any three zones in conjunction and the max
power level will be as follows:
Zone 1 – power level 3
Zone 2 – power level 4
Zone 3 – power level 5
Model GLINDPS
Power of zone - 1 1800W
Power of zone - 2 1200W
Power of zone - 3 2000W
Total Power 2200W
1
3
2
1
23
4

Control Panel Explained - GLINDPS
SYMBOL FUNCTION SYMBOL FUNCTION
ON/OFF TIMER
MINUS ZONE SELECTION
PLUS CHILD LOCK
BEFORE FIRST USE
Remove and discard all labelling and packaging.
Ensure you have removed all parts and accessories
before disposing of the packaging.
Read this manual and please take note of the
SAFETY WARNINGS section. You will only have to
read it once and it is well worth doing. The thing to
remember about induction cooktops is that they rely
on magnetism to work so if something magnetic is
left on a zone it could get really hot.
Using touch controls
The controls respond to touch, so you don’t need to
apply any pressure but you have to use it properly
so it activates. Use the ball of your nger, not its tip.
The cooktop will beep each time a touch is
registered.
NOTE:
Make sure the control panel is always clean, dry,
and that there is no object (e.g., a utensil or a cloth)
covering them. Even a thin lm of water may make
the controls di󰀩cult to operate.
If you think that the cooktop is switching on and o󰀨
when it shouldn’t then for sure there will be water or
some moisture over the control area.
Choosing the correct cookware
Only use cookware with a base suitable for
induction cooking. Look for the induction symbol on
the packaging or on the bottom of the pan. You can
check if it is okay by using a magnet to nd if the
cookware is magnetic. If it is, then it is suitable.
Cookware made from aluminium, ceramic, pure
stainless steel or copper without a magnetic base,
glass or earthenware will not be suitable. One way
to check if a vessel is suitable:
1. Put some water in the pan you want to check.
2. Follow the steps under ‘To start cooking’.
3. If does not ash in the display and the water
is heating, the pan is suitable.
Use pans that are wide enough to completely cover
the cooking area. If it is slightly wider then the
energy will be used at its maximum e󰀩ciency. There
are some minimum diameter requirements and
cookware diameters smaller than shown in the table
will probably not work.
Size of zone mm Min pot diameter mm
160 120
180 140
210 160
280 220
The cooktop is ceramic glass, so any sharp metal
edge has the potential to damage the surface. Do
not use cookware with jagged edges or a base that
is not at.
Make sure that the base of your pan is smooth,
sits at against the glass, and is the same size as
the cooking zone. Always centre your pan on the
cooking zone.
To further protect the glass always lift the pans on
and o󰀨 the cooktop, don’t slide them or they may
scratch the glass.

USING YOUR NEW INDUCTION COOKTOP
Switching the hob on and o󰀨 - Switch the hob on
and o󰀨 by using the main power switch.
1. Touch the ON/OFF symbol.
All the indicators show “- “.
2. Place a suitable pan on the
cooking zone that you wish to use.
Make sure the bottom of the pan
and the surface of the glass are
clean and dry.
3. Press the zone selection symbol and
an indicator next to the key will ash.
4. Select power level by touching the
MINUS or PLUS symbol to increase
or decrease power.
Maximum power is
NOTE:
• The power can be increased or decreased at
any time.
• If you don’t choose a heat setting within 1
minute, the hob will automatically switch o. You
will need to start again from step 1.
When you have nished cooking
1. Select the heating zone
you wish to switch o󰀨.
2. Turn the zone o󰀨 by touching the MINUS key
until it the power reads .
3. To turn the whole cooktop o󰀨
press the ON/OFF symbol
Warning - Beware of hot surfaces
When is displayed the cooking zone is hot to
touch. It will disappear once the zone cools down to
a safer temperature.
Using a Boost function – Model GLINDBG
This gives the selected zone a boost of extra energy
Activating the Boost function
1. Select the heating zone
you wish to use.
2. Touch the boost symbol P.
3. The power Indicator will show P.
4. The Boost function will operate for 5 minutes
and then go to level
Cancelling the Boost function
1. Select the zone under Boost mode.
2. Touch the minus symbol to power down and
then select the power you want.
CHILD LOCK FUNCTION
You can lock the controls to prevent unintended
use (for example children accidentally turning the
cooking zones on). When the controls are locked, all
the controls except the ON/OFF are disabled.
To lock the controls
Touch the lock symbol
until the indicator shows (locked)
To unlock the controls
1. Make sure the cooktop is turned on.
2. Touch and hold the lock symbol
for 5 seconds.
3. You can now use the cooktop.
When the cooktop is in Child lock mode all the
controls are disabled except the main ON/OFF.
NOTE:
You can always switch the cooktop o󰀨 with the ON/
OFF key in an emergency, but you will need to
unlock the cooktop for the next time you use it.
Residual heat warning
When the cooktop has been operating for some
time there will be some residual heat. The power
indicator of a hot zone will appear as to warn you
to keep away from it until it cools down.
Auto Shutdown
Another safety feature of the cooktop is the auto
shut down. This occurs when you forget to switch
o󰀨 a cooking zone. The default shutdown times are
shown in the table below:
Power
level 1 2 3 4 5 6 7 8 9
Default
working
time (hour)
8 8 8 4 4 4 2 2 2

USING THE TIMER
There are two ways to use the timer. You can use it
as a minute minder where the timer does not switch
o󰀨 any cooking zone when the time is up. You can
use it as a cut o󰀨 timer to turn one or more cooking
zones o󰀨 when the time is up.
Using the timer as a minute minder
1. Make sure the hob is turned on, and no cooking
zone has been activated. NOTE: you can set the
minute minder while the cooking zone is on as
long as the power level indicator is not ashing.
2. Touch timer symbol
3. will show in the timer display and single digit
ashes.
4. Set the desired minutes by touching or
5. Touch timer key again and the number to
represent tens will ash.
6. Set the desired minutes by touching or
7. When the time is set, it will begin to count down
and the display will show the remaining time.
8. A signal sound will beep for 10 seconds, and
the timer indicator shows when the set time is
nished.
Setting timer to turn one or more cooking zones o󰀨
If the timer is set on one zone:
1. Select the heating zone
where you want to set a timer.
2. Touch timer the digits will show
in the timer display and single digit ashes
3. Set the desired minutes by touching or
4. Touch timer key again, then the number to
represent tens will ash.
5. set the desired dozens of minutes
by touching or
6. When the time is set, it will begin to count down
immediately. The display will show the remaining
time.
NOTE: The red dot next to power level indicator
lluminates indicating that zone is in timer mode.
7. When cooking timer expires, the corresponding
cooking zone will be switch o󰀨 automatically.
NOTE: Other cooking zones will keep operating if
they are turned on previously.
If the timer is set on more than one zone:
1. When you set the time for several cooking zones
simultaneously, decimal dots of the relevant
cooking zones are displayed. The minute display
shows the remaining time and the dot of the
corresponding zone ashes.
2. Once the countdown timer expires, the
corresponding zone will switch o󰀨. Then it will
show the remaining time for another zone and
the dot of corresponding zone will ash.
3. To check the remaining time set on a particular
zone, touch the zone and the corresponding
timer will be shown in the timer indicator.
Cancel the timer
1. Select the zone where you want to cancel the
timer.
2. Touch the timer symbol and the indicator will
ash
3. Set the timer to and the timer is cancelled.
PAUSE FUNCTION GLINDBG model only
The pause function stops all heating but retains
all the settings you set. You can revert all settings
easily with this function.
To use Pause function
Touch the pause function
and all the heating zones
stop working and indicate
To cancel Pause function
Touch the pause function again, all the heating
zones will revert to its original setting.
NOTE: The function is available when either one or
multiple heating zones are working.
NOTE: If you don`t cancel the Pause mode within
30 minutes, the cooktop will automatically switch o󰀨.
COOKING GUIDELINES
Take care when frying as oils and fats heat up
rapidly, particularly if you’re using the Power Boost
function. At extremely high temperatures oil and fat
can ignite spontaneously and present a re risk.
Cooking Tips
• When food comes to the boil, reduce the power
setting.
• Using a lid will reduce cooking times and save
energy by retaining the heat.
• Minimise the amount of liquid or fat used to
reduce cooking times.
• Start cooking on a high power and reduce it
when the food has been well heated.

CARE AND CLEANING
What? How?
Dirty stu󰀨 on glass
(ngerprints, marks, residual
stains, or non-sugary spill
overs onto the glass).
1. Switch o󰀨 the power of the cooktop.
2. Apply a cooktop cleaner while the glass is still warm (but not hot!)
3. Rinse and wipe dry with a clean cloth or paper towel.
4. Switch the power to the cooktop back on.
Boil overs, melts, and hot
sugary spills on the glass
Remove these immediately with a razor blade scraper suitable for ceramic glass
cooktops but beware of hot cooking zone surfaces. Sugar can etch the glass.
1. Switch the power to the hob o󰀨 at the wall.
2. Hold the blade at a 30° angle and scrape the spill to a cool area of the cooktop.
3. Clean the spill up with a clean cloth or paper towel.
Spill overs onto the touch
controls
1. Switch o󰀨 the power of the cooktop.
2. Remove the spill overs
3. Wipe the touch control area with a clean damp cloth, then dry with a paper towel.
4. Switch the power to the cooktop back on.
Important!
• When the cooktop is switched o󰀨, there will
be no ‘hot surface’ indication, but the cooking
zone may still be hot! Take extreme care!
• Heavy-duty scourers, some nylon scourers
and harsh/abrasive cleaning agents may
scratch the glass. Always read the label
to check that your cleaner or scourer is
suitable, if you are in doubt don’t use it.
• Never leave cleaning residue on the cooktop:
the glass may become stained.
QUESTIONS AND QUICK REFERENCE CHECK
Problem Possible causes and What to do
The cooktop wont turn on.
No power.
1. Check the connection to the power supply and make sure it is switched on.
2. Check whether there is a power outage in your home or area.
3. If you’ve checked everything and the problem persists, call a qualied technician.
The touch controls are
unresponsive.
The control panel is locked by Child lock function.
Unlock the controls. See section ‘Using your cooktop’ for instructions.
The touch controls are
di󰀩cult to operate.
There may be a slight lm of water over the controls, or you may be using the tip of your nger
when touching the controls.
Make sure the touch control area is dry and use the ball of your nger when touching the controls.
The glass is being scratched.
Rough-edged cookware. Unsuitable, abrasive scourer or cleaning products being used.
Use cookware with at and smooth bases.
See ‘Choosing the right cookware’. See ‘Care and cleaning’.
Some pans make crackling
or clicking noises.
This may be caused by the material of your cookware
(layers of di󰀨erent metals vibrating di󰀨erently).
This is normal for cookware and does not indicate a fault.
The induction hob makes a
low humming noise at some
certain power setting.
This is caused by the technology of induction cooking.
This is normal, but the noise may quiet down or disappear completely when you change the
power level setting.
Fan noise coming from the
induction hob.
A cooling fan is built in your induction hob which prevent the electronics from overheating. It may
continue to run even after you’ve turned the induction hob o󰀨. This is normal and needs no action.
Do not switch the power to the induction hob o󰀨 at the wall while the fan is running.
Pans do not become hot and
appears in the display.
The induction hob cannot detect the pan. Check the pan base size, if it is too small for the cooking
zone or not properly centred. Use cookware suitable for induction cooking.
See section ‘Choosing the right cookware’. Centre the pan and make sure that its base matches
the size of the cooking zone.
The cooktop or a zone turns
itself o󰀨 unexpectedly. A tone
sounds and error code is
displayed.
Technical fault.
Please note down the error code (typically alternating with one or two digits in the cooking timer
display)., switch the power to the cooktop o󰀨 at the wall, and contact a qualied technician.
Glem Gas After Sales Service 1 300 307 917
• Remove stains left by melts and sugary food
or spill overs as soon as possible. If left to cool
on the glass, they may be di󰀩cult to remove or
even permanently damage the glass surface.
• Cut hazard: when the safety cover is retracted,
the blade in a scraper is razor-sharp. Use with
extreme care and always store safely and out of
reach of children.
• The cooktop may beep and turn itself o󰀨, and
the touch controls may not function while there
is liquid on them. Make sure you wipe the touch
control area dry before turning the cooktop back
on.

ERROR CODES
If an abnormality comes up, the hob will automatically enter a protective state and display corresponding
protective codes:
AFTER SALES SERVICE 1300 307 917
Problem Possible causes What to do
E1 Signal lost (PCB failure) Please contact after sales service
E2/E3 Abnormal High/Low input voltage Stop cooking and wait until input voltage back to normal. If
not, please contact after sales service.
E4/E5/E6 Thermistor failure. Please contact after sales service to repair.
E7 Abnormal high temperature
(dry burning)
Cut o󰀨 power, wait for 30min and switch on.
If still not working, please contact after sales service.
E8/E9 Failure of IGBT sensor Please contact after sales service to repair.
E0 IGBT Overheat Check if the fan is still working. If not, please contact after
sales service.
EE Display PCB failure. Please contact after sales service.
The above are the judgment and inspection of common failures.
ATTENTION! To avoid danger, please do not disassemble the unit by yourself!
INSTALLATION
Preparation of the kitchen bench
1. Be sure the thickness of the kitchen bench is at least 30mm.
2. A suitable heat-resistant kitchen bench material must be used to avoid deformation caused by the heat
radiation from the cooktop.
3. When installing a minimum clearance of 50mm must be preserved around the hole in the bench.
4. Cut out the work surface according to the sizes shown in the drawing. Be accurate!!
Model L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
GLINDBG 590 520 62 58 560 490 50 mini.
GLINDPS 590 520 62 58 560 490 50 mini.
ATTENTION: Ensure that the cooktop is well ventilated underneath, and the air inlet and outlet are not
blocked. Ensure that the cooktop works well. It is the installer’s responsibility to ensure that that the cooktop
is adequately sealed. No warranty claims will be accepted for benches damaged because of moisture
leaking through the seal or insu󰀩cient ventilation.
The distance between the cooktop surface and the cupboards above should not be less than 760mm - refer
to diagram on the next page.

Clearance requirements above cooktop and ventilation that must be provided underneath
A (mm) 550 minimum*
B (mm) 50 minimum
C (mm) 20 minimum
D Air intake
E Air exit 5mm
*prevously shown as 750mm min
Under bench clearance requirements
Under bench clearance requirements
X(mm) 100 minimum
Y(mm) 50 minimum
Before you install the cooktop, make sure that
• The kitchen bench is square and level, and no structural members interfere with space requirements.
• The kitchen bench is made of a heat-resistant material.
• If the cooktop is installed above an oven, that the oven has a built-in cooling fan.
• The installation will comply with all clearance requirements and applicable standards and regulations.
• A suitable isolating switch providing full disconnection from the mains power supply is incorporated in
the permanent wiring, mounted, and positioned to comply with the local wiring rules and regulations.
• The isolating switch must be of an approved type and provide a 3mm air gap contact separation
in all poles (or in all active [phase] conductors if the local wiring rules allow for this variation of the
requirements). The isolating switch will be easily accessible to the customer with the hob installed.
• You consult local building authorities and by-laws if in doubt regarding installation.
• You use heat-resistant and easy-to-clean nishes (such as ceramic tiles) for the wall surfaces
surrounding the hob.

Before tting the xing brackets
The cooktop should be placed on a stable, smooth surface (use the packaging).
Stretch out and stick the supplied tape [02] along the underside edge of the hob, ensure the ends overlap.
Trim o󰀨 any excess tape and dispose of it. When installing the cooktop ensure that the tape is providing a
moisture resistant seal.
Installing the xing brackets
Fix the cooktop brackets by securing the two brackets on the bottom of cooktop (see picture).
Then install the hob into the cut-out of the kitchen bench. Apply gentle downwards pressure onto the
cooktop to push it into the bench.
When you have installed the hob, make sure that
• the power supply cable is not accessible through cupboard doors or drawers.
• there is adequate ow of air from outside the cabinetry to the base of the cooktop.
• if the cooktop is installed above a drawer or cupboard space, a thermal protection barrier is installed
below the base of the cooktop.
• the isolating switch is easily accessible by the customer.

Caution – FAILURE TO MEET THESE FOLLOWING REQUIREMENTS WILL VOID WARRANTY
1. The hob MUST be installed by qualied personnel or technician.
2. The hob shall not be mounted to cooling equipment, dishwashers, and rotary dryers.
3. The hob shall be installed such that better heat radiation can be ensured to enhance its reliability.
4. The wall and induced heating zone above the work surface shall withstand heat.
5. To avoid any damage, the sandwich layer and adhesive must be resistant to heat.
6. If the electircal supply is restricted, means of all pole disconnection must be accessible and
incorporated in the xed wiring in accordance with the wiring rules
Connecting the cooktop the mains power supply
This cooktop must be connected to the mains power supply only by a suitably qualied person. Before
connecting the cooktop to the mains power supply, check that:
• The domestic wiring system is suitable for the power drawn by the hob.
• The voltage corresponds to the value given in the rating plate
• The power supply cable sections can withstand the load specied on the rating plate.
To connect the cooktop to the mains power supply, do not use adapters, reducers, or branching devices, as
they can cause overheating and re.
The power supply cable must not touch any hot parts and must be positioned so that its temperature will
not exceed 75˚C at any point.
Check with an electrician whether the domestic wiring system is suitable without alterations. Any alterations
must only be made by a qualied electrician.
If connecting the cable directly to the mains, install a suitable isolating switch with a minimum contact
opening of 3mm between the appliance and the mains. The isolating switch should be sized according to
the load on the cooktop rating label and should comply with current regulations. (the earth wire should not
be interrupted by the circuit breaker)
Connection to the electricity supply must be made by an authorised person in accordance with the wiring
rules AS/NZS3000. Ensure the supply power cable cannot contact any hot surfaces.
Immediately after installation, carry out a thorough inspection and test of the cooktop. If the cooktop fails
to operate correctly, after checking that you have followed the user instructions correctly, disconnect the
cooktop and contact the Glem Gas service department. Never attempt to repair the cooktop.
PE
NOTE
• If the cable is damaged or needs replacing, this should be done by an after-sales technician using the
proper tools, to avoid any accidents.
• The installer must ensure that the correct electrical connection has been made and that it complies with
safety regulations.
• The cable must not be bent or compressed.
• The cable must be checked regularly and only replaced by a proper qualied person.
!
PE

DISPOSAL: Do not dispose
this product as unsorted
municipal waste. Collection
of such waste separately
for special treatment is
necessary.
This appliance is labelled in compliance with European
directive 2002/96/EC for Waste Electrical and Electronic
Equipment (WEEE). By ensuring that this appliance is
disposed of correctly, you will help prevent any possible
damage to the environment and to human health, which
might otherwise be caused if it were disposed of in the
wrong way.
The symbol on the product indicates that it may not be
treated as normal household waste. It should be taken to
a collection point for the recycling of electrical and elec-
tronic goods.
This appliance requires specialist waste disposal. For
further information regarding the treatment, recovery and
recycling of this product please contact your local council,
your household waste disposal service, or the shop where
you purchased it.
For more detailed information about treatment, recovery,
and recycling of this product, please contact your local city
o󰀩ce, your household waste disposal service or the shop
where you purchased the product.
AFTER SALES SERVICE 1300 307 917
