USER’S GUIDE
Induction Cooker
GL 3076
Fry Milk Boiling Rice Soup
Power (w)
Voltage (w)
o
Temp.(C)
Hour/Minute
Power
Grill Steam

Fry Milk Boiling Rice Soup
Power (w)
Voltage(w)
o
Temp.(C)
Hour/Minute
Power
Grill Steam
Identify Your Induction Cooker
Ceramic Glass Plate
Operation &
Display Panel
How Induction Cooking Works
An electric voltage is applied on a conductor spool
beneath the ceramic glass.
This produces a high-frequency electromagnetic field.
The field penetrates the metal of the ferrous (magnetic -
material) cooking vessel and generates heat.
The heat generated in the cooking vessel is transferred
to the vessel's contents.
Nothing outside the vessel is affected by the field. As
soon as the vessel is removed heat generation stops.
Operation & Display Panel
FryStir FryHot Pot Milk
Water Soup
Rice
On/Off
Switch
Timer Pre-Set Functions Function
Selector
Switch
Digital Display

Induction Cooking Advantages
Setting up your Induction Cooker
Using your Induction Cooker
It is a powerful cooking medium, just like or even better than gas.
Instant & precise heat control, unlike electric cooking where the elements take
time to heat and cool, resulting in lack of proper control on the dishes being
cooked.
There is no heat wastage as the energy is supplied directly to the cooking vessel
unlike gas or conventional electric cookers where they end up heating your
kitchen and you, instead of heating up the food.
High safety no open flames, no fire hazards, no gas leakages. The glass top stays
cool that means no burnt fingers or hands.
Once you take the cookware off the hotplate, the device automatically switches to
standby mode.
The device detects whether suitable cookware is placed on the hotplate. If this is
not the case, no energy is transmitted.
As the hotplate is only heated up indirectly via the bottom of the cookware, over
spilling food cannot stick and burn.
Check the device for visible damage.
Place the device on a stable and level surface.
Never place the device on a flammable surface (e.g. table cloth, carpet, etc.).
Do not block the ventilation slots of the device. This may overheat the device.
Keep a minimum distance of 5 to 10 cm from the walls or other items.
Do not place the induction Cooker next to devices or objects which react
sensitively to magnetic field (e.g. radios, TVs, cassette recorders, etc.).
Do not place induction Cooker next to open fires, heater or other sources of heat.
Make sure that the mains connection cable is not damaged or squashed beneath
the device and does not came into contact with sharp edges and / or hot surface.
The device should be connected to a rolled-out extension cable with a maximum
length of 3m and a cross-section of 2mm. If an intermediate switch is used, it must
be rated at min. 16A.
After the device has been turned on, select the appropriate function for your cooking
using the function selector switch. You can choose from a selection of pre-set
functions.

Hot Pot This function is designed to boil water. During heating, you can adjust the
temperature and time as per your requirement. The timer can be adjusted anywhere
upto 99 minutes. In case of abnormally high heat, the cooker switches to standby
mode and starts re-heating after cooling down.
Stir Fry This is a function designed for cooking of vegetables etc. During cooking the
temperature and time can be adjusted as required.
Fry This is a function designed for frying vegetables etc. During cooking the
temperature and time can be adjusted as required.
Water This function is used for boiling or steaming. Select the water function.
Rice Cooking Take a cup of rice, soaked for half an hour. Put the rice along with 2 cups
of water into the pan. Switch on the cooker. Select the rice function. After the
stipulated time, the induction cooker will switch off to keep warm mode.
Milk This function is designed to keep the milk warm. In case you adjust the Power
level please supervise the boiling otherwise the milk may spill over.
S Take 4 cups of soup stock in a pan. Select the soup function. After the set time,oup
the cooker switches to keep warm status.
This is the default function and is selected automatically when the cooker is switched
ON, or if no other function is selected.
Note : The results may vary depending on the power supply, quality of ingredients
and the amount of water.
Timer The cooking can be set to a desired time with the help of the timer. Press the
timer button, and adjust the display to set the time with the help of (+) and (-) buttons.
Once set the display would flash the set time and then begin the countdown. After the
set time elapses the cooker will automatically switch to keep warm status.
Heat Adjustment The cooker automatically sets to the required temperature in case of
pre-set functions. However it is possible to manually adjust it as per requirement in
case of Hot-Pot, Fry and Stir Fry functions.
The temperature can be set manually to five levels P1 to P5 (from 60°C to 280°C)
using the (+) and (-) buttons. The set temperature level (P1 to P5) is displayed on the
digital screen.
240 minutes Timer, Temperature Range 60°C to 280°C
Function Power Level Setting
HOT POT Timer & power adjustable setting
0
STIR FRY Timer & temperature adjustable setting
FRY Timer & power adjustable setting
WATER Pre set / no adjustable setting
RICE Time preset 20 min after that it changes to keep warm mode
MILK
Pre set 8 min after that it changes to keep warm mode
/no adjustable setting
Pre set only on keep warm mode
SOUP
1400w
220 C
1800w
1000w
300w
1600w
2000w

Suitable and unsuitable cookware for induction cooking
Suitable Cookware
Unsuitable Cookware
Pots and pans with magnetic bottom, as stainless steel pots with iron bottom, cast
iron enameled pans.
Flat-bottom pans and pots with a diameter of 12 to 21 cm with magnetic bottom.
Max. weight pot and content should not exceed 6 kg.
Pots/pans with a diameter of less than 12 cm.
Ceramic pots, heat-proof glass.
Copper pots and pans, aluminium pots and pans.
Cookware with feet.
Containers with a curved bottom.
Possible Error Messages and their Solution
Solution
Error Code
E1
Reason
Plate surface temperature
sensor open
Please contact the supplier or go
to a qualified service center.
E2 IGBT temperature sensor
open.
Please contact the supplier or go
to a qualified service center.
E3 Abnormal supply voltage;
voltage too high.
Abnormal supply voltage;
voltage too low.
Please check power supply. Power on
after power supply is back to normal.
Please check power supply. Power on
after power supply is back to normal.
E4
E5 Plate surface temperature
sensor short-circuited:
empty pot/pan heating
leads to too high temperature
Please wait for some minutes until
the unit cools down. Please check
pot/pan.
E6 Fan failure: Air intake/
exhaust vent block.
Please contact the supplier or go to a
qualified service center. Clean the vent
after the unit cools down, then can restart.
E7 Coilpanel is not connected
well, circuit mal function.
Please contact the supplier or go to a
qualified service center.
E8 No pot/pan on the plate. Non-
usable pans on the plates
Put suitable cooking Utensils
on the plates.

The hotplate surface is made up of temperature-resistant toughened ceramic glass.
However necessary precautions in handling of glass are very important. The
breakage of glass due to any reason is not covered under guarantee.
In case of damage, even if this concern only a small tear, disconnect the device
from the power supply immediately and contact the customer service.
We recommend not placing any metal kitchen utensils, cookware or pan lids,
knives or other metal objects on the hotplate. These may heat up when the device
is turned on.
Place the hot pans in the hob area only. Never place them on the control panel or
the frame as this may result in melting of the plastic frame due to heat in the pan.
Do not place any magnetics objects like credit cards, cassettes etc. on the glass
surface while the device is in operation.
In order to avoid overheating, do not place any aluminium foil or metal plates on
the device.
Warning: Please do not put the induction cooker on an iron / steel board, while
operating. Due to electromagnetic reason, the iron / steel board may heat and
damage the bottom of the induction cooker.
Do not insert any objects like wires or tools into the ventilation slots. This may
cause electric shocks.
Do not touch the hot surface of the ceramic field. Please note the induction
hotplate does not heat up itself during cooking, but the temperature of the
cookware heats up the hotplate!
Do not heat up any unopened tins on the induction hotplate. A heated tin could
explode; therefore remove the lid under all circumstances beforehand.
If you do not use the device for an extended period, we recommend you
disconnect it from the electric outlet.
Never touch the device and the power plug with wet hands.
Do not connect the device to the same outlet with other devices. Connect the
device to a suitable outlet.
Never move the device by pulling on the power cable.
Do not move the induction hotplate during cooking or with hot cookware on top
of it.
Never use the device when it does not function properly, shows damage or in case
it was dropped.
Do not leave the device unsupervised during operation. Keep children and other
incompetent persons as well as persons under influence of drugs or alcohol away
from the device.
Safety Precautions

Warning: This appliance is not intended for use by persons (including children) with
limited physical, sensory or metal abilities or who lack the necessary experience
and / or skills unless these persons act under the supervision of a person responsible
for their safety or they were instructed by such a person on how to use the appliance.
Do not submerge the device in water or other liquids and do not wash it in the
dishwasher.
Only qualified experts may perform repair and maintenance work on the device
using original replacement and accessory parts. Never attempt to repair the device
yourself!
Scientific tests have proven that induction hotplates do not pose a risk. However,
persons with a pacemaker should clear with their doctor weather to take care of
some special handling advises.
Unplug the power prior to cleaning the device. Do not use any caustic cleaning
agents and make sure that no water penetrates the device.
To protect yourself from electric shock, never immerse the device, its cables and the
plug in water or other liquids.
Wipe off the ceramic field with a damp cloth or use a mild, non-abrasive soap
solution.
Wipe off the casing and the operating panel with a soft cloth or a mild detergent.
Do not use any petrol products as they may damage the plastic parts and the
casing/operating panel.
Do not use any flammable, acid or alkaline materials near the device, as this may
reduce the service life of the device and lead to deflagration when the device is
turned on.
Make sure that the bottom of the cookware does not scrape across the surface of the
ceramic field, although a scratched surface does not impair the use of the device.
Make sure that the device was properly cleaned before storing it in a dry place.
Cleaning and Maintenance
Specifications
Model No. : GL3076 Temperature Range : 60°C TO 280°C
Power : 2000 Watt Connection : 220-240V AC 50 Hz
Dimensions L x W x H : External Dimensions - 330 x 280 x 59 mm
Your Induction Cooker is provided with a cooling fan which keeps the internal
temperature under control. Once the cooking is over the fan is still running so
don't switch off the mains till the time the fan is running.

PRODUCT : INDUCTION COOKER GL 3076
SERIAL NO :
BILL NO. & DATE :
NAME OF OWNER :
ADDRESS :
DEALER’S STAMP & SIGNATURE
Under no circumstances, whether based on limited warranty or otherwise shall the
company be liable for incidental, special or consequential damages. Use of product
indicates acceptance by you of the aforesaid terms and conditions.
WARRANTY
This GLEN Induction Cooker is fully warranted against any defect arising out of
defective materials or faulty workmanship for a period of one year from the date of
purchase. Should any defect develop in this product, the customer should bring the
product to the nearest authorised service centre, where the company undertakes to get
the product repaired free of charge.
This warranty is not valid if :
The use and care instructions have not been followed.
Defects are caused by accident, misuse, abuse or commercial use.
The repair work is carried out by persons not authorised by the company.
The serial no. Has been deleted, defaced or altered.
Any modification or alteration of any nature is made in the product.
Normal wear & tear of the product is not covered under warranty
The bill/cash memo and copy of warranty card is not presented.
The breakage of glass due to any reason whatsoever is not covered under warranty.
Glen Appliances Pvt. Ltd.
EPIP Phase II, Thana Baddi, Tehsil Nalagarh, Distt. Solan (H.P.)
Customer Care & H.O.
I-34, DLF Industrial Area Phase-I, Faridabad - 121 003, INDIA
E-mail : [email protected] Website : www.glenindia.com
Helpline : 9548-130-131 Fax : [phone]
