Glen EasyCook User manual

®
®
The pulse of modern kitchen
Glen Appliances Pvt. Ltd.
EPIP Phase II, Thana Baddi, Tehsil Nalagarh, Distt. Solan (H.P.)
I-34, DLF Industrial Area Phase-I, Faridabad
Customer Care No. : 0129-2254191 Fax [phone]
E-mail : [email protected] Website www.glenindia.com
Head Office
USER’S GUIDE

3
Know Your Induction Cooker
Operation & Display Panel
Induction Cooking Process
An electric voltage is applied on a conductor
spool beneath the ceramic glass.
T h i s p r o d u c e s a h i g h - f requency
electromagnetic field. The field penetrates
the metal of the ferrous (magnetic -material)
cooking vessel and generates heat.
The heat generated in the cooking vessel is
transferred to the vessel's contents.
Nothing outside the vessel is affected by the field.
As soon as the vessel is removed heat generation stops.
Milk Porridge Rice Hot Pot Kheer Stir Fry
+
-
Display
Panel
On/Off
Switch
Timer
6 Pre Set Functions
120
60 80
2000W
280°C
1800
240
1600
220
1400
200
1200
180
1000
160
800
140
600
120
300
MAX LOCK ELEC./VOLT. TIMER/PRE. FUNCTION ON.OFF
Milk Porridge Rice Hot Pot Kheer Stir Fry
+
-
120
60 80
2000W
280°C
1800
240
1600
220
1400
200
1200
180
1000
160
800
140
600
120
300
MAX LOCK ELEC./VOLT. TIMER/PRE. FUNCTION ON.OFF
Notice : The surface remains hot after use, please don’t touch !
warning : please turn off the unit to avoid the electric leakage if the surface broken.
!
2
Identify Your Easy Cook

5
Do not block the ventilation slots of the device. This may overheat
the device. Keep a minimum distance of 5 to 10 cm from the walls or
other items.
Do not place the EasyCook next to devices or objects which react
sensitively to magnetic field (e.g. radios, TVs, cassette recorders,
etc.).
Do not place EasyCook next to open fires, heater or other sources of
heat.
Make sure that the mains connection cable is not damaged or
squashed beneath the device and does not came into contact with
sharp edges and / or hot surface.
The device should be connected to a rolled-out extension cable with
a maximum length of 3m and a cross-section of 2mm. If an
intermediate switch is used, it must be rated at min. 16A.
How To Use
After the device has been turned on, select the appropriate function
for your cooking using the function selector switch. You can choose
from a selection of pre-set functions.
Milk : This function is designed to boil 1 kg of milk in a time of 7-8
minutes. after 7 minutes the cooker will switch off. turn on the
cooker, the default hot pot function would be activated. within 1-2
minutes the milk will boil. as the milk boils, immediately switch off
the power to prevent spillage of milk.
Rice : Take a cup of rice, soaked for half an hour. Put the rice along
with 2 cups of water into the pan. Switch on the cooker. Select the
rice function. After the stipulated time, the induction cooker will
switch off to keep warm mode.
Porridge : Take one cup of roasted porridge. Put it in the pan with
seven cups of water. Switch on the power. Press the porridge
function. After 15 mins. the temperature will come down to at 80°c.
Induction cooker will switch off automatically. Add 4 tbs. sugar (or
4
Induction Cooking Advantages
How To Set Up
Induction is the first technology that offers all of the
benefits of cooking with gas, with none of the drawbacks.
Induction cooking is :-
Faster : Energy is directly transferred to the pan metal, cooking on
an electric induction range is extremely fast - even faster than gas.
Safer : Much safer than gas or other electric surfaces, since there is
no open flame, red-hot coil or other radiant heat source to ignite
fumes or flammable materials.
Cleaner : With no grease catch to worry about, clean up is a breeze.
Just use a damp cloth and wipe over the flat, easy-to-clean surface.
Moreover no gas vapours mean cleaner kitchen.
Cooler : Traditional gas or electric range waste up to or more than
half heat the heat they generate. The waste heats the kitchen
instead of the food. With an electric induction range, almost no
ambient heat is produced, since all the heat is being generated in the
pan itself.
Cheaper : Induction cooking is far more energy efficient than gas or
traditional electric ranges. In induction cooktop, 90% of energy goes
right where u want it - in the pan! Gas delivers 50% to the pan and
traditional electric about 65%. In addition, when you remove the pan
the induction cooktop instantly goes into standby mode, using
almost no energy.
Check the device for visible damage.
Place the EasyCook on a stable and level surface.
Never place the EasyCook on a flammable surface (e.g. table cloth,
carpet, etc.).

7
Suitable and unsuitable cookware for induction cooking
Suitable Cookware
Unsuitable Cookware
Pots and pans with magnetic bottom, as stainless steel pots with iron
bottom, cast iron enameled pans.
Flat-bottom pans and pots with a diameter of 12 to 26 cm with
magnetic bottom.
Max. weight pot and content should not exceed 6 kg.
Pots/pans with a diameter of less than 12 cm.
Ceramic pots, heat-proof glass.
Copper pots and pans, aluminium pots and pans.
Cookware with feet.
Containers with a curved bottom.
temperature in case of pre-set functions. However it is possible to
manually adjust it as per requirement. there are total five levels,
ranging from 120 to 2000 w (60°C to 280°C) using the (+) and (-)
buttons. The set temperature is displayed on the LED Indicator.
Maximum : Through this option the max setting can be set for
function of Hot Pot & Stir Fry
Lock : This function is designed as safety provision & once it is set,
the setting of other functions can not be done/ changed. To again
make all the functions operational re set the lock function.
6
as per taste) and 1 tsp. ghee. Press the power and the default will be
at hot pot. Cook for 2-3 mins. or more for the right consistency. The
porridge is now ready.
Kheer : Soak half a cup of rice in water for an hour. Drain the water
from the soaked rice and put it in a pan alongwith one litre milk.
Switch on the power, press the kheer function. After 7 mins. the
temperature will come down at 60°c. The induction cooker will
switch off automatically. Add half a cup of sugar (or as per taste).
Press the power and the default will be at hot pot. Cook for 2-3 mins.
or more for the right consistency. The kheer is now ready.
Hot Pot : This function is designed to boil water. During heating, you
can adjust the temperature and time as per your requirement. The
timer can be adjusted anywhere upto 240 minutes. In case of
abnormally high heat, the cooker switches to standby mode and
starts re-heating after cooling down.
This is the default function and is selected automatically when the
cooker is switched ON, or if no other function is selected.
Stir Fry : This is a function designed for cooking of vegetables etc.
During cooking the temperature and time can be adjusted as
required.
Note : The results may vary depending on the power supply, quality
of ingredients and the amount of water & cookware.
Heat Adjustment : The cooker automatically sets to the required
Timer/Pre : 1 minute to 4 hours for function Hot Plate & Stir Fry.
The device will stop after the completion of set time.
This function is also designed to pre set the time, so thet at a decided
time the device will start ON the function. This can be set upto 24
hours durations. This can be set for functions other than Hot Pot &
Stir Fry.

9
Do not heat up any unopened tins on the induction hotplate. A
heated tin could explode; therefore remove the lid under all
circumstances beforehand.
If you do not use the device for an extended period, we recommend
you disconnect it from the electric outlet.
Never touch the device and the power plug with wet hands.
Do not connect the device to the same outlet with other devices,
connect the device to a suitable outlet.
Never move the device by pulling on the power cable.
Do not move the induction hotplate during cooking or with hot
cookware on top of it.
Never use the device when it does not function properly, shows
damage or in case it was dropped.
Do not leave the device unsupervised during operation. Keep
children and other incompetent persons as well as persons under
influence of drugs or alcohol away from the device.
Warning: This appliance is not intended for use by persons (including
children) with limited physical, sensory or metal abilities or who lack
the necessary experience and / or skills unless these persons act
under the supervision of a person responsible for their safety or they
were instructed by such a person on how to use the appliance.
Do not submerge the device in water or other liquids.
Only qualified experts may perform repair and maintenance work on
the device using original replacement and accessory parts. Never
attempt to repair the device yourself!
8
The hotplate surface is made up of temperature-resistant toughened
ceramic glass. However necessary precautions in handling of glass
are very important. The breakage of glass due to any reason is not
covered under guarantee.
In case of damage, even if this concern only a small tear, disconnect
the device from the power supply immediately and contact the
customer service.
We recommend not placing any metal kitchen utensils, cookware or
pan lids, knives or other metal objects on the hotplate. These may
heat up when the device is turned on.
Place the hot pans in the hob area only. Never place them on
the control panel or the frame as this may result in melting
of the plastic frame due to heat in the pan.
Do not place any magnetics objects like credit cards, cassettes etc.
on the glass surface while the device is in operation.
In order to avoid overheating, do not place any aluminium foil or
metal plates on the device.
Warning: Please do not put the cooktop on an iron / steel
board, while operating. Due to electromagnetic reason, the
iron / steel board may heat and damage the bottom of the
induction cooker.
Do not insert any objects like wires or tools into the ventilation slots.
This may cause electric shocks.
Do not touch the hot surface of the ceramic field. Please note the
induction hotplate does not heat up itself during cooking, but the
temperature of the cookware heats up the hotplate!
Safety Precautions

11
Trouble Shooting
Please contact the supplier
or send it to a qualified
service center.
Please contact the supplier
or send it to a qualified
service center.
Check power supply.
Power on after power
supply is back to normal.
Please check power supply.
Power on after power
supply is back to normal.
Wait for a few minutes until
the unit cools down and
check pot / pan.
Please contact the supplier
or send it to a qualified
service center. Clean the
vent after the unit cools
down, and then restart.
Please contact the supplier
or send it to a qualified
service center.
Put suitable cooking
pot / pan on the plates.
Plate surface
temperature sensor
malfunction.
IGBT
Temperature sensor
malfunction.
Abnormal supply
voltage; Voltage too
high.
Abnormal supply
voltage; Voltage too
low.
Plate surface
temperature sensor
short-circuited because
of empty pot / pan.
Fan failure; Air
intake/exhaust vent
blocked.
Coil panel is not
well connected, circuit
malfunction.
No pot/pan on the plate.
Non-usable pans on the
plates.
Trouble
Code Possible Reasons Solution
E1
E2
E3
E4
E5
E6
E7
E8
10
Scientific tests have proven that induction hotplates do not pose a
risk. However, persons with a pacemaker should clear with their
doctor weather to take care of some special handling advises.
‘‘Only use flat bottom pan, bottom size should be between 12cms to
22cms and weight less than 6kg. Any damage due to higher weight
or size will not be covered under warranty.’’
Cleaning and Maintenance
Unplug the power prior to cleaning the device. Do not use any caustic
cleaning agents and make sure that no water penetrates the device.
To protect yourself from electric shock, never immerse the device, its
cables and the plug in water or other liquids.
Wipe off the ceramic field with a damp cloth or use a mild, non-
abrasive soap solution.
Wipe off the casing and the operating panel with a soft cloth or a mild
detergent.
Do not use any petrol products as they may damage the plastic parts
and the casing/operating panel.
Do not use any flammable, acid or alkaline materials near the device,
as this may reduce the service life of the device and lead to
deflagration when the device is turned on.
Make sure that the bottom of the cookware does not scrape across
the surface of the ceramic field, although a scratched surface does
not impair the use of the device.
Make sure that the device was properly cleaned before storing it in a
dry place.

13
with enamelled steel cover for faster cooking.
Before igniting the triple ring burner ensure that the burner
and cover are properly placed in position. If they are not
kept properly the burner might get deformed. (Such
deformation is not covered under guarantee).
In case of leakage of gas or any other defect, report to your gas
dealer and get the checked/rectified by an authorised
person only.
Use a damp cloth to clean your .
EasyCook
EasyCook
EasyCook
EasyCook
Make sure that there are no inflammables near the .
When the is in use check from time to time that it burns
normally.
While using a lighter to ignite the burner, keep a distance of
atleast 0.5 cm between them to prevent gas from burning in
the Gas pipe. In case this happens, immediately switch off
the burner
Do not close the lid when burners or electric plates are hot.
Make sure that when the glass is hot, there should not be
any dripping of cold water or liquid on glass as it may
damage the glass.
The breakage of glass due to any reason is not covered
under guarantee.
and re-ignite
12
Your Gas Cooktop
Installation
The gas cylinder should be placed vertically and should not tilt.
The should be placed at a convenient working height
against a wall. It should be kept away from shelves and curtains
Windows should be closed and the use of fans should be avoided
during its operation.
The flexible tube connecting the cylinder to the should be
gas resistant and of an approved brand. It should not be longer than
a meter and should be kept away from any source of heat. The tube
should not be subjected to external pressure, twisted or sharply
looped
When the is not in operation ensure that the regulating
knobs on the are in the ‘OFF’ position and the regulating
valve on the cylinder is ‘CLOSED’
Push the rubber hose onto the inlet nozzle as far as it will go.
EasyCook
EasyCook
EasyCook
EasyCook
To light the , open the regulating valve, light a match stick
and hold it close to the burner port. Now press the corresponding
regulating knob and turn it anticlockwise to the ‘ON’ position.
The Auto Ignition models are provided with India’s first one touch
multi-spark battery operated auto ignition (no electric connection
required). Just turn the knob to put on the flame.
In case the Auto ignition does not work replace the battery.
In some models, separate push button switch is provided for ignition.
Turn the knob ‘ON’, simultaneously press the switch to put on the
flame.
To turn off the flame, turn the regulating knob to the ‘OFF’ position.
During cooking, ensure that the ingredients being cooked do not
overflow, which may extinguish the flame or choke the burner ports.
The Glen (TR models) has a high energy triple ring burner
EasyCook
EasyCook
How To Use

14
The company warrantees to get the EasyCook or any part thereof
repaired free of charge for a period of one year from the date of
purchase, should any defect develop due to faulty or defective
workmanship or material. However, the plastic parts, glass, buttons and
items subject to normal wear and tear due to operation are not covered
under warranty
The aluminum alloy burner carry a five year replacement
guarantee. In case any burner gets deformed or melted or has any
manufacturing defect, it will be replaced free of cost within 60 months
from the production date inscribed on them.
The company accepts no responsibility for any consequential losses
arising out of misuse or negligence on the part of the user.
Warranty
Technical Specifications
Subject to change without prior notice
For Use with Commercial L.P.G. at 2.942 kN/m² (30gf/cm²)
C. OVERALL DIMENSION (mm)
840 450 125
Width Depth Height
12.00
Gross
Wt.
App. (kg.)
A. BURNER RATINGS
Model
Small
Burner
Big
Burner
Total Gas
Rating
g/h kcal/h g/h kcal/h g/h kcal/h
GL 1037 320 3485 177 1930143 1555
1 x 1 x
B. INDUCTION RATING
Supply Power Temp.
Range
230V AC/50Hz 2000 W 60°c to 280°c
The is not used according to the direction given in the
instruction manual.
Defects are caused by improper or reckless use.
The repair work is carried out by persons not authorised by the
company.
The serial no. has been deleted, defaced or altered.
The breakage of glass due to any reason whatsoever is not covered
under guarantee.
The Bill/cash memo is not presented .
Any modification or alteration of any nature is made in the .
The manufacturer is not responsible for any consequential losses
arising out of misuse of the appliance or due to non-observance of
necessary precautions in using L.P. Gas/Electric power.
EasyCook
EasyCook
Terms of Warranty
PRODUCT : EASY COOK GL1037
DATE OF PURCHASE & BILL NO.
SERIAL NUMBER
NAME OF OWNER
ADDRESS
DEALER’S STAMP & SIGNATURE
