GLI 55-0000CY-BK User manual

PREMIUM
RESIN REEL SYSTEM
FOR INGROUND POOL
55-0000CY-BK
INSTRUCTIONS
Youngstown, Ohio 44510 • www.glipoolproducts.com
REGISTER WARRANTY ONLINE AT WWW.GLIPOOLPRODUCTS.COM.
PLEASE REGISTER WITHIN 10 DAYS OF PURCHASE.
IF YOU WISH TO MAKE A CLAIM, CALL TOLL FREE 1-800-448-2343
FOR REPLACEMENT PARTS FOR YOUR REEL SYSTEM PLEASE VISIT, WWW.GLIPROMOTIONS.COM.
PARTS BREAKDOWN
PART NUMBER DESCRIPTION QUANTITY
1 99-55-4395026 Off-set triangular base with built in
casters
2
2 99-55-4395002 Crank handle 2
3 99-55-4395003 Resin roller bearings - Installed 2
4 99-55-4395004 3” Resin insert adaptor 2
5 99-55-4395013 2.83” Axle bolt (In Hardware Bag) 2
6 99-55-4395015 Strap Kit/Hardware Bag 1
INSTALLATION INSTRUCTIONS
1. CONGRATULATIONS on your purchase of our Premium Resin Solar Reel for Inground Pools. Please follow the instructions carefully so as to not void
warranty.
2. Please use your solar blanket and reel assembly in the manner it was intended for:
a. Your solar blanket is not a safety cover
b. Remove the solar blanket and solar reel assembly from the pool completely before swimming use.
c. Do not store the solar blanket on the ground in direct sunlight, as it will burn the lawn
3. Preparation & Assembly: Check inventory of all items and assemble as illustrated below:
Resin
Insert
Adaptor
1
RETRACTABLE WHEEL FEATURE:
To expose wheels, tilt the reel stand in one
direction to remove weight from the stand.
Raise locking tooth and rotate thumbwheel
clockwise. Lower the locking tooth to
re-lock. To hide wheels, raise locking tooth
and rotate thumbwheel counter clockwise.
Lower locking tooth to re-lock.
2
3
4
6
4. Depending upon the size of your pool you will also require one of the following Storage Kits: (Storage Kit assembly is detailed below.)
5. Positioning Your Solar Reel:
For Rectangular pools, place Wheels at either end of pool. (See Fig. A)
For Irregular shaped pools, place Stands at some convenient midway point. You will need to fold Blanket and allow Blanket to unwind in two
directions. (See Fig. B)
RECTANGULAR IRREGULAR
Unroll Unroll Unroll
Fig. A Fig. B
6. Trimming Your Solar Blanket:
• Lay your Solar Blanket (not provided) on top of water. IMPORTANT! Irregular Shaped Pools will need to have their solar covers folded at point
of placement of Stands! The cover will unroll left and right of stands & cross pole. Please allow 6 inches more material on length to allow for a
fold where straps will be attached to wind onto reel system. (See Fig. B above)
• With scissors trim blanket to t shape of pool. Be sure to clear pool edge coping.
7. Assembling The Storage Kit:
All Storage Kits consist of 6 sided Hexagon shaped tubing. There are two diameters of tubing, the smaller size nesting into the larger size. All Stor-
age Kits begin and end with small tubes. The resin insert adaptor requires CAREFUL ALIGNMENT!
a. All storage kits consist of hexagon shaped tubing. There are two diameters of tubing; the smaller diameter
will insert into the larger diameter.
b. Determine length of tube required for your installation. Maximum nished length per storage kit size listed
above (in Step 4).
Please Note: The smaller diameter tube will be used on both ends of the reel and will connect to the base
unit. Two of the smaller diameter tubes will have pre-drilled axle bolt holes on one end. The pre-drilled end
will be connected to the base unit.
(Image 1)
c. Loosely assemble tubes together to match the desired length for your installation, evenly dividing the excess
at each connection. Note that the smaller diameter tube must be inserted a minimum of 9” into the larger
diameter tube at each connection. Tip: Measure in 9” from end of smaller diameter tube and make a mark
with a pencil. (Image 2) The tube must be inserted at least to your pencil mark. It is ok if tube is inserted
more than 9”, but not less.
d. Once you determine length and have proper spacing of tubes, mark each tube at the connection point for
reference. (Image 3) This will eliminate the need to re-measure if your tubes get moved during the remain-
der of the installation process.
e. Each connection will be fastened together with the through bolts supplied in your Storage Kit. Use the
pre-drilled holes in the larger diameter tube as a guide to drill the smaller inner tube. (Image 4) Twist tubing
to remove excess play prior to drilling holes. (Image 5 - Before Twisting, Image 6 - After Twisting) (Fig. C on
last page) Drill from each side with the drill bit supplied. (Image 7)
f. Fasten with 2 bolts and nuts at each connection. (Image 8, Image 9, Image 10)
g. For off-season storage of Solar Blanket - Install wood screw hooks into fence, wall or even hang from
garage or shed ceiling. Be sure to install hooks into solid wood posts or studs. Roll solar blanket onto the
storage system and suspend from hooks using the enclosed storage straps.
STORAGE KIT ASSEMBLY:
Image 1 Image 2
Image 3 Image 4
Image 5 Image 6
Image 7 Image 8
Image 9 Image 10
PART # 55-1203IG-TK
12’ X 3” IGR STORAGE KIT
(2) 59.5” x 2.75” Dia. Inner Tube
(1) 59.5” x 2.95” Dia. Outer Tube
(4) 3” Through Bolt with Nut
(1) Drill Bit
(2) 24” Storage Straps
(2) Wood Screw Storage Hooks
Max. Finished length = 13’3/8”
PART # 55-1603IG-TK
16’ X 3” IGR STORAGE KIT
(2) 72” x 2.75” Dia. Inner Tube
(1) 72” x 2.95” Dia. Outer Tube
(4) 3” Through Bolt with Nut
(1) Drill Bit
(2) 24” Storage Straps
(2) Wood Screw Storage Hooks
Max. Finished length = 16’ 1/2”
PART # 55-2003IG-TK
20’ X 3” IGR STORAGE KIT
(3) 59.5” x 2.75” Dia. Inner Tube
(2) 59.5” x 2.95” Dia. Outer Tube
(8) 3” Through Bolt with Nut
(1) Drill Bit
(2) 24” Storage Straps
(2) Wood Screw Storage Hooks
Max. Finished length = 21’ 3/4”
PART # 55-2004IG-TK
20’ X 4” IGR STORAGE KIT
(3) 59.5” x 3.75” Dia. Inner Tube
(2) 59.5” x 4.0” Dia. Outer Tube
(8) 4” Through Bolt with Nut
(2) 3.75” Axel Bolt with Nut
(2) 4” metal insert adaptor
(2) 4” resin insert adaptor
(1) Drill Bit
(2) 24” Storage Straps
(2) Wood Screw Storage Hooks
Max. Finished length = 21’ 3/4”
PART # 55-2404IG-TK
24’ X 4” IGR STORAGE KIT
(4) 68” x 3.75” Dia. Inner Tube
(3) 68” x 4.0” Dia. Outer Tube
(12) 4” Through Bolt with Nut
(2) 3.75” Axel Bolt with Nut
(2) 4” metal insert adaptor
(2) 4” resin insert adaptor
(1) Drill Bit
(2) 24” Storage Straps
(2) Wood Screw Storage Hooks
Max. Finished length = 25’ 3/8”
3” DIAMETER STORAGE KITS:
(If you purchased a 4” diameter storage kit, go to 4” diameter storage kit instructions below.)
a. Attach tube assembly to base unit.
b. The resin insert adaptor must be inserted into the end of the tube. (Image 11)
c. Insert Crank handle through the base unit and into the resin insert adaptor. (Image 12) Be sure to align the
axle hole.
d. Fasten tube to base unit using the 2.83” axle bolt that is packaged with your base kit. (Image 13)
e. Repeat same procedure on opposite end.
4” DIAMETER STORAGE KITS:
Note: The 4” storage kit is packaged with two metal insert adaptors and two resin insert adaptors. See pictures
of each. (Image 14) You will use the large resin insert adaptors for your installation.
a. The small resin insert adaptors that were packaged with the base kit and the large metal insert adaptors that
were packaged with the storage kit can now be discarded as they will not be used.
These can be seen in
Image 14, and are noted to be discarded.
b. The resin insert adaptor must be inserted into the end of the tube. (Image 15)
c. Insert Crank handle through the base unit and into the resin insert adaptor. Be sure to align axle hole. (Image
16)
d. Fasten tube to base unit using the 3.75” axle bolt that is packaged with your storage kit. (Image 17) Note:
the 2.83” axle bolt that is packaged with your base kit can be discarded as it will not be used.
e. Repeat same procedure on opposite end.
Image 11 Image 12
Image 13
Image 14 Image 15
Image 16 Image 17
Youngstown, Ohio 44510 • www.glipoolproducts.com
8. Attach Straps to Tubes:
Come in 6 inches from each tube end and attach a strap plate to the tube assembly. Use the self drilling screws on the drill line to attach the
plate. Look at the holes that were pre-drilled at the factory and use the same drill line. There are 6 lines on each tube. Take the remaining strap
plates and connect them evenly along the length of the tube assembly. Attach straps to strap plate. (Fig. D)
9. Attach Solar Blanket to Straps:
If reel is to be placed at the end of the pool, attach cover to strap plate with plastic screw. (Fig. E) If reel is to be placed in offset position, then
attach cover to strap plate forming a fold to act like a hinge and the plastic screw will go through two layers of the solar blanket. (Fig. F)
Bubbles should face down.
Twist
Tubing To
Remove Excess
Play Prior
To Screwing
Together.
Fig. C
Thread
Strap
as Shown
Fig. D Solar Blanket
Strap & Bracket
Plastic Screw
Fig. E
Fig. F
Solar Blanket Folded
Plastic Screw
Strap & Bracket
DISCARD

Popular Cables And Connectors manuals by other brands

Etherma ICESTOP Installation and usage instructions

Etherma

Etherma ICESTOP Installation and usage instructions

Philips SWN1116 Specifications

Philips

Philips SWN1116 Specifications

FasTest FasMate Series operating instructions

FasTest

FasTest FasMate Series operating instructions

Hubbell GAI-TRONICS 400-005 manual

Hubbell

Hubbell GAI-TRONICS 400-005 manual

Atlona AT-HDMI-210 Specifications

Atlona

Atlona AT-HDMI-210 Specifications

Zamel GPRN Manual instruction

Zamel

Zamel GPRN Manual instruction

CYP CPLUS-V8PT Operation manual

CYP

CYP CPLUS-V8PT Operation manual

Eagle E250DH product manual

Eagle

Eagle E250DH product manual

Stihl Smart Connector instruction manual

Stihl

Stihl Smart Connector instruction manual

Comprehensive CDA-VGA108A user manual

Comprehensive

Comprehensive CDA-VGA108A user manual

OUNEVA VA03-0057 installation guide

OUNEVA

OUNEVA VA03-0057 installation guide

Philips SWV6414 Specifications

Philips

Philips SWV6414 Specifications

Axioma OG-1-USB user manual

Axioma

Axioma OG-1-USB user manual

OUNEVA VC02-0071 installation guide

OUNEVA

OUNEVA VC02-0071 installation guide

Philips SWV2300 Specifications

Philips

Philips SWV2300 Specifications

Spectech T991 user manual
