Glidecam Industries Light-Force Battery Grip User manual

© GLIDECAM 2022. TM ® All trademarks and registered trademarks are the property of their respective owners.
USER MANUAL
glidecam.com
Light-Force Battery Grip

Introduction
Thank you for purchasing Glidecam Light-Force Battery Grip. This
product is a high-capacity power grip that can extend your video
camera run time up to 4 hours. Please read this User Manual
carefully and follow the safety guidelines strictly before using it.
WARNING:
• Do not dismantle, crush, puncture, and short circuit Battery
Grip or expose it to liquids, re, or environments where the
temperature is above 60°C (140°F).
• Do not open the casing to avoid cell damage or other hazards.
Checklist
q 1 x Glidecam Light-Force Battery Grip
q 1 x USB-C cable
q 1 x Dummy Battery
q 1 x User Manual
Names of Parts
a. mounting plate
Swichable mounting plate ts different cameras
b. anti-twist pin hole
ts Panasonic GH6. Pre-installed for GH6 version
c. anti-twist pin hole
ts Canon R5/R5c/R6. Pre-installed for Canon version
d. Arca-Swiss plate
Arca-Swiss standard plate,compatible with DJI gimbal’s
quick release system
Read all safety information below and operating instruc-
tions before using battery grip to avoid injury and damage
to your device.
d. Arca-Swiss plate e. LED
indicators
f. USB-C ports
g. 3/8 mounting hole
h. 1/4 mounting holes
a. mounting plate
d. Arca-Swiss plate
c. anti-twist
pin hole
b. anti-twist
pin hole
2

Names of Parts CONT.
e. LED indicators
During charging and discharging, the LED indicator will be on
and blinking to indicate the power level
f. USB-C ports
Dual USB-C input/output. Support USB PD protocol
g. 3/8 mounting hole
1x 3/8 mounting hole
h. 1/4 mounting holes
4x 1/4 mounting holes
Charging
Battery Grip supports charging with USB-C power adapter with
Power Delivery protocol. When charging with USB-A port adapter,
please use an additional USB-A to USB-C cable. The USB adapter is
easy to nd, such as those used by cell phones or smart devices.
Note: Ensure the USB adapter supports one or more of the following
output specications.
Voltage Maximum Current
5V 3A
9V 3A
12V 1.5A
15V 1.2A
20V 1A
When the output of the USB adapter is lower than 5V 3A, the
charging time may be extended.
The LED indicator shows charging conditions as follows:
Power level LED1 LED2 LED3 LED4
0-25% Blinking Off Off Off
25-50% On Blinking Off Off
50-75% On On Blinking Off
75-99% On On On Blinking
Fully Charged On On On On
Error Blinking Blinking Blinking Blinking
Note: Battery Grip can be charged while discharging, but a 9V3A or
15V/1.2A USB adapter is required to ensure sufcient power supply.
Mount to Camera Bottom
Glidecam Light-Force Battery Grip can be installed on a wide range
of cameras by simply replacing the mounting plate and dummy
battery. Visit glidecam.com/batterygrip for more information.
Panasonic GH6
The mounting plate for the GH6 has additional anti-deection locating
pins in front of the 1/4 screw. Before installing Battery Grip, install the
BLK22 Dummy Battery in the camera , and pass the cable through the
cord hole on the battery door. Then lock the battery door. Once the
Dummy Battery is installed, mount the Battery Grip on the bottom of
the GH6. Next, plug the USB-C connector of the Dummy Battery into
either of the two USB-C ports of the Battery Grip.
Once Battery Grip’s USB-C port is plugged into the cable, you can turn
on GH6. Battery Grip’s LED indicators will ash to show the remaining
battery capacity.
3

Mount to Camera Bottom CONT.
Canon R5/R5c/R6
Versions for the Canon R5/R5c/R6 include a pre-installed locating pin
on the left front of the Battery Grip that matches the locating hole on
the bottom of the camera. The locating pin works with the 1/4 screw to
prevent the rotation. Before installing the Battery Grip, install the LP-E6
Dummy Battery into the camera, and pass the cable through the cord
hole near the battery compartment cover. Then lock the compartment
cover. Once the Dummy Battery is installed, mount the Battery Grip
on the bottom of the camera. Next, plug the USB-C connector of the
Dummy Battery into either of the two USB-C ports of the Battery Grip.
Once Battery Grip’s USB-C port is plugged into the cable, you can
turn on camera. Battery Grip’s LED indicators will ash to show the
remaining battery capacity.
Powered by USB-C cable
directly
Battery Grip also supports powering directly to the camera’s USB-C
port using a USB-C cable. In addition, Battery Grip can also power
other devices such as Atomos Zato Connect or microphones, or
wireless transmitters.
The LED indicator shows charging conditions as follows:
Power level LED1 LED2 LED3 LED4
99-75% On On On On
75-50% On On On Off
50-25% On On Off Off
25-10% On Off Off Off
Less than 10% Blinking Off Off Off
Note
1. When using the camera’s USB-C port for power supply, the
camera’s battery compartment must have a battery installed. In
addition, the camera battery will be charged when the camera’s
USB-C port supplies power. Therefore, it is strictly prohibited to use
the Dummy Battery and the USB-C port to deliver power at the same
time.
2. Dummy Battery’s built-in system stabilizes the voltage at 8.4V,
so the camera cannot detect Battery Grip’s battery capacity by
measuring the battery voltage. Instead, please check the LED
indicator of the Battery Grip to know the remaining battery capacity.
3. When Battery Grip’s two USB-C ports are powered simultaneously,
both USB-C ports have a maximum output voltage of 9V. In
comparison, the single port can output up to 20V depending on the
device being powered.
4. When the Battery Grip is accidentally short-circuited, it will enter
protection mode. In this case, the Battery Grip can be restarted using
a USB-C cable connected to a USB adapter and charging for a few
seconds.
5. Even when the camera on/off switch is set to OFF thus turning
the camera off, it consumes power. Therefore, disconnect Battery
Grip from all connections when not in use to avoid further power
consumption.
4

Safety Instructions
Using Glidecam Light-Force Battery Grip Safely:
█Always make sure that your Battery Grip is
mounted securely and is unable to fall onto anyone
nearby. This is especially important when there are
children present who might be tempted to pull on
cables.
█Always ensure that cables that run to Battery Grip
are clearly visible and do not present a trip hazard.
█Do not expose to strong electrical or magnetic
elds.
█Do not dismantle, crush, puncture and short
circuit Battery Grip, or expose it to liquids, re or
environments where the temperature is above 60°C
(140°F).
█Do not dispose of Battery Grip in municipal
waste and do not incinerate it, always follow local
regulations for safe disposal.
█When Battery Grip is malfunctioning, it is
forbidden to open it for repair without permission.
█Do not let the electrodes of the Dummy Battery
connected to the Battery Grip come into contact
with metal or conductive liquids. Failure to do so
may result in a short circuit.
5

Specifications
Physical Specications
Battery Grip Dimensions (W x
H x D mm)
138*79*57(mm)
Battery Grip Weight (without
dummy battery)
464g/16oz
Dummy battery length 10cm/3.9inch
Mount points Top: 1/4-20 Screw x1
Bottom: Arca-swiss standard
plate x1 with 1/4-20 x3, 3/8-16 x1"
Environmental
Operating temperature (C/F) -10℃—60℃ 14°F—140°F
Construction
Body Aluminum alloy CNC Unibody
Dummy battery ABS Polycarbonate Ultrasonic
Welding
Power
Battery Chemistry Lithium-ion
Battery Capacity 5000mAh 7.4V/ 36Wh
I/O 2xUSB Typc-C, Input/Output
Input Voltage 5V 3A, 9V/3A, 12V/2A, 15V/1.5A,
20V/1A
Output Voltage 5V 3A, 9V/3A, 12V/2A, 15V/1.5A,
20V/1A
Fast Chargeing Technology USB Power Delivery
Dual USB-C maxium output
Voltage
9V/3A
Dynamic Power Management
System
Dynamic charge-discharge path
Trickle charging
Overheating protection
Short circuit protection
Overcharge protection
LED Indicator 4x LEDs
Run Time GH6 4K 60p High Bitrate:3.2Hours
R5C: 3-4 Hours
Charging Time approx. 3hours(9V3A)
approx. 5.5 hours(5V2A)
Warrenty One Year
6

Regulators
Hereby,declares that this equipment is in compliance
with the Electromagnetic Compatibility Directive 2014/30
EU.
Test standards:
EN 55032:2015+A11:2020+A1:2020
0EN 55035:2017+A11:2020
EN IEC 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A1:2019+A2:2021
It is herewith conrmed and found to comply with
the requirements set up by regulationfor the evaluation
of electromagnetic compatibility.This device complies
with part 15 of the FCC rules.
Identication of regulation: 47 CFR Part 15 Subpart B,
Measurement Procedure:ANSI C63.4: 2014
It is only valid in connection with the test report number:
TCT220706E004.
The products have been tested with listed
standards and found in compliance with UK
Electromagnetic Compatibility Regulations (SI
2016/1091). It is possible to use UKCA marking to
demonstrate the compliance with this EMC.
Test standars:
BS EN 55032:2015+A11:2020+A1:2020
BS EN 55035:2017+A11:2020BS EN IEC
61000-3-2:2019+A1:2021 BS EN
61000-3-3:2013+A1:2019+A2:2021
The products have been tested with listed standards
and found in compliance with the Directive
(EU) 2015/863 - Amendment of EU RoHS Directive
2011/65/EU Annex II. It is possible to use CE marking to
demonstrate the compliance with this RoHS.
Test standars:
IEC 62321-3-1:2013 / IEC 62321-4:2013+AMD1:2017
IEC 62321-5:2013 / IEC 62321-6:2015
IEC 62321-7-1:2015 / IEC 62321-7-2:2017
IEC 62321-8:2017
7

For further information, please visit gliecam.com
Light-Force Battery Grip
Designed by Glidecam
Assembled in China
42 Winter St. Suite 10. Pembroke, MA 02359
United States
