Glideware Not-So-Lazy Susan User manual

Use the provided template to center the
(B) pivot bracket on the top
and bottom of the cabinet
A(Qty 8)
D
(1) F
(12)
G (7)
Mount the pivot bracket
Top & bottom center of the cabinet
2
A 4x
B 1x
1
B(2)
C(2)
E(3)
Not-So-Lazy SusanTM
Installation Instructions
Assemble the Arrestor assembly
Drop in (E) nut, then attach the
(L) pole bracket to the (I) arrestor
4
F 4x
L 1x
E 1x
I
Note the v-notch
Assemble the Bottom Shelf
Attach the (L) pole bracket to the
under side of the (J) bottom shelf
5
F 4x
L 1x
J
Note the v-notch
3
F 4x
L 1x
H
Note the v-notch
Attach the (L) pole bracket to the underside
of (H) top plate. Mount bracket to the
pre-drilled holes. PAGE 1

1 Raise the Top Plate assembly up,
install the (E) Nut and (C) Bolt.
2 Raise the Arrestor assembly up (2),
install the (D) Screw and adjust height,
then tighten
10
Install the (G) Hooks into the slots above,
Adjust to your preference
and press to fit
9
C 1x
E 1x
D 41x
1
2
G 7x
8
1 Pull down on the top pin,
2 locate the pole below the pin
3 Release the pin to lock into position
1
2
3
Add (J) Shelf then (C) bolt & (E) nut to secure
the shelf to the (K) pole. Tighten firmly
Slide the (I) assembly and the
(H) assembly onto the pole. Do not fasten.
6
7
Insert the pole assembly into the cabinet
8
Place the pole assembly onto the bottom pin
J
H
I
E 1x C 1x
K
TIP!!
1. Do the final adjustment of the (I) arrestor
after the pans are in place.
2. Recommend installing in a 36" x 36" cabinet PAGE 2
