DECORATIVE FUEL EFFECT GAS FIRE

User Instructions

These instructions should be read by the user before operating the

appliance and retained for future reference

Model o. GRDC**R & GRDP**R is only for use on atural Gas

(G20) at a supply pressure of 20 mbar in G.B. / I.E.

** denotes trim/fret variant

I STALLATIO I FORMATIO

CO DITIO S OF I STALLATIO

It is the law that all gas appliances are installed in accordance with the rules in

force only by a competent (e.g. GAS SAFE Registered) Installer in G.B, and in

accordance with the installation instructions and the Gas Safety (Installation and

Use) Regulations 1998. Failure to install appliances correctly could lead to

prosecution. It is in your own interest and that of safety to comply with the law.

The fire may be fitted below a combustible shelf provided that the shelf is at least

200mm above the top of the appliance and the depth of the shelf does not exceed

150mm.

The fire may be installed below combustible shelves which exceed 150mm deep

providing that the clearance above the fire is increased by 15mm for each 25mm

of additional overhang in excess of 150mm.

o purpose made additional ventilation is normally required for this

appliance when installed in G.B. When installed I.E. please consult

document I.S. 813 : 1996 Domestic Gas Installation which is issued by the

ational Standards Authority of Ireland. Any purpose made ventilation

should be checked periodically to ensure that it is free from obstruction.

If this appliance is fitted directly on to a wall without the use of a fireplace or

surround, soft wall coverings such as wallpaper, blown vinyl etc. could be affected

by the heat and hot air and may discolour or scorch. This should be considered

when installing or decorating.

The Model number of this appliance is as stated on the rating plate affixed to the

base panel of the fire and the appliance is manufactured by:-

BFM Europe Ltd

Trentham Lakes

Stoke on Trent

ST4 4TJ

Please No e : The life span of he ba eries in he burner uni is dependen upon

use and herefore he ba ery life will vary accordingly. If he burner uni fails o

opera e, please check he 6 off AA ba eries before calling he service cen re for

engineer assis ance.

ABOUT YOUR EW FA TASY PEBBLE GAS FIRE

The Fantasy range of pebble fuel-bed gas fires incorporates a unique and highly

developed fuel bed which gives the realism of a loose pebble layout

combined with realistic flames and glow. The use of durable ceramic material in

the construction of the fuel-bed components ensures long and trouble free

operation.

When first using the new fire a slight smell may be noticed. This is due to starch

used in the manufacture of the soft ceramic pebbles, it is non-toxic and will soon

disappear.

Discolouration to both the pebble fuelbed and fibreboards will occur when

first lighting the appliance, this is normal and these components will return

to their normal colour when the fire has fully warmed up.

Please take the time to fully read these instructions as you will then be able to

obtain the most effective and safe operation of your fire.

ABOUT YOUR EW FA TASY COAL GAS FIRE

The Fantasy coal effect gas fire incorporates a unique and highly

developed fuel bed which gives the realism of a loose coal layout combined with

realistic flames and glow. The use of durable ceramic material in the construction

of the fuelbed components ensures long and trouble free operation.

When first using the new fire a slight smell may be noticed. This is due to starch

used in the manufacture of the soft ceramic coals, it is non-toxic and will soon

disappear.

Please take the time to fully read these instructions as you will then be able to

obtain the most effective and safe operation of your fire.

IMPORTA T SAFETY I FORMATIO

WAR I G

This appliance has a naked flame and as with all heating appliances a

fireguard should be used for the protection of children, the elderly and

infirm. Fireguards should conform to B.S. 8423 : 2002 should be fitted.

(Fireguards for use with gas heating appliances).

It is important that this appliance is serviced at least once a year by a GAS SAFE

registered gas installer ( in G.B.) and that during the service the fire is removed

from the fire opening and the flue pipe visually checked for debris or blockages

which must be removed. We recommend that during the annual service,

replacement of the Oxypilot is carried out. These are conditions of the

manufacturers guarantee. After installation or during servicing a spillage

test must always be carried out.

Rubbish of any type must EVER be thrown onto the fuel-bed, this could affect

safe operation and damage the fire.

Any debris or deposits should be removed from the fuel-bed from time to time.

This may be carried out by referring to the cleaning section as described later in

this book.

Only the correct number and type of pebbles or coals must be used and only

complete and genuine replacement sets can be sourced from BFM Europe.

Always keep furniture and combustible materials well clear of the fire and never

dry clothing or items either on or near to the fire. ever use aerosols or

flammable cleaning products near to the fire when it is in use.

The ceramic fuel-bed remains hot for a considerable period after use and

sufficient time should be allowed for the fire to cool before cleaning etc.

SPILLAGE MO ITORI G SYSTEM

This appliance is fitted with a spillage monitoring system which shuts down the fire

if the evacuation of combustion products from the fire is affected by a partially or

fully blocked flue pipe. If this system operates the fire will go out. If this occurs,

leave the fire for at least three minutes then follow the lighting procedure as

described in the previous section. In the event of repeated operation a GAS

SAFE registered gas installer must be called to investigate and rectify the

cause.

OPERATI G THE FIRE USI G THE REMOTE CO TROL HA DSET

a) The Remote control handset generates an infrared signal, which will be

received by the sensor situated at the front right of your fire, behind the

ashpan cover. This infrared signal requires direct line of sight from the

handset to the sensor on the fire to ensure good operation.

b) To light the appliance using the handset, point the handset at the fire

and press the 2 left hand buttons together. The fire will emit a “beep”

sound, the buttons can now be released. After a few seconds an

audible clicking can be heard and then the fire will light the pilot and

then light the main burner. The ignition cycle will take approximately 20

seconds.

c) To reduce the level of heat input on the fire, point the handset at the fire

and press the small flame button. (An audible beep will be heard)

d) To increase the level of heat input on the fire, point the handset at the

fire and press the large flame button. (An audible beep will be heard)

e) To leave the fire in the standby mode (pilot only running) press the small

round button on the handset. The fire should not be left in the

standby mode when unattended.

f) To switch the appliance off completely, press the large round button on

the handset, the fire will then switch off. See fig. 1 below for image of

handset.

Fig. 1

High (Large Flame)

Low ( mall Flame)

Off Button

tandby Button

TUR I G THE PRODUCT OFF I THE U LIKELY EVE T OF A REMOTE

HA DSET MALFU CTIO .

a) In the unlikely event of the remote control handset malfunctioning (or if

lost or broken) after the appliance has been turned on, the fire can be

turned off via the emergency shut off switch on the right hand control panel.

b) Press and hold the emergency shut off switch until the fire shuts down.

The process may take up to sixty seconds to complete. (see Fig. 2

below).

c) When the fire has shut down, release the emergency shut off switch.

d) The appliance will now remain in the “off” position until activated by the

remote handset.

Fig. 2

REPLACI G THE BATTERIES (REMOTE CO TROL MODELS O LY)

E SURE THE FIRE IS COOL BEFORE REPLACI G BATTERIES

Remove the ashpan cover. The battery pack is located on the right hand side side

of the burner unit at the bottom. Carefully remove the pack and remove

batteries. Replace in the reverse order using 6 off 1.5V AA Alkaline Battery. It is

important that only an alkaline battery is used, otherwise premature battery

failure and leakage may result.

Emergency hut Off

witch Position on

Control Panel.

CLEA I G - WAR I G

Before attempting any cleaning operation ensure that the fire has been allowed to

fully cool. The trims are easily replaced by re-positioning them on the fire and

pushing it back onto the magnets. Black painted metal parts should be gently

cleaned with a damp cloth.

CLEA I G THE CO TEMPORARY TRIM

Use only a damp cloth to clean the Contemporary trim. Abrasive cleaners,

chemical cleaning agents or any type of polish must never be used as

damage to the finish of the Contemporary trim & ashpan may result.

CLEA I G THE BRASS A D PAI TED METAL PARTS

Dependent upon the trim option chosen for use with this fire, there is a variety of

methods that can be chosen to clean the trim. If a Brass trim was supplied with

this fire this is plated brass and this trim must only be cleaned using a clean damp

cloth. Metal polishes must not be used on these trims. If a stainless steel trim

was supplied, then these should only be cleaned using a clean, damp cloth also.

The trim is best cleaned by removing it from the fire and placing it face up on a flat

surface. The trim is easily replaced by repositioning it on the fire and pushing it

back onto the magnets.

Abrasive cleaners, chemical cleaning agents or any type of polish must

never be used as damage to the finish may result.

CLEA I G THE FUEL-BED

We do not recommend cleaning of the pebbles / coals or fuelbed components as

these are fragile and damage may result.

one of these parts must be washed or exposed to any cleaning agents or

water.

Any damaged parts must be replaced by contacting your dealer or telephoning

BFM Europe on the number stated on the rear cover of this book. The pebbles or

coals (dependent upon model chosen) must only be replaced with a complete and

genuine replacement set and the fire must never be run with the wrong number or

damaged pebbles or coals. The fuel-bed must be carefully re-assembled as stated

in the following sections

No e : Prior o replacing he oxypilo on his produc due o suspec ed

failure of he componen , please remove all debris ha has collec ed on

he lin guard of he oxypilo i self.

RE-ASSEMBLI G THE CERAMICS A D FUEL BED

(PEBBLE FUELBED MODELS)

a) Place the ribbed ceramic fuelbed base on top of the fuelbed support

and pull fully forwards to the burner. Make sure that the fuelbed

base is located centrally in the fire box.Ensure that the fuelbed

base fit fully down onto the fuel bed support and is not

lodged on the burner. See fig. 3 below.

Fig. 3

b) Position front ceramic rail on burner front ceramic support and ensure

that the locating channel in the front ceramic rail is correctly located

onto the lip on the burner front ceramic support. (See fig. 4 below)

Fig. 4

NOTE : The posi ion of he fuel-bed componen s are cri ical o he

performance of he produc . Therefore please ensure ha he fuel-bed

componen s are posi ioned as described in he following sec ion prior o

reques ing a service call due o soo build up, poor flame pa ern e c.

c) Pick pebbles A to E and arrange along the the front rail, ensuring that

they are evenly spaced. Use the recess’s in the front ceramic rail as a

guide for placement. (See fig. 5 below)

Fig. 5

d) Select pebbles F to I and arrange behind the front row of pebbles,

ensuring that flame paths as indicated below are not interupted.

. (See fig. 6 below)

Fig. 6

Pebble C

Pebble D

Pebble E

Pebble A

Pebble B

Pebble F

Pebble G

Pebble H

Pebble I

e) Select pebbles K, L & M and arrange along the rear of the

fuelbed, using the ribs in the rear of the fuelbed as a guide for

placement. (See fig. 7 below)

Fig. 7

f) Select the two small pebbles (J & ) and position to fill the gaps at each

end of the third row of pebbles, as shown above in Fig. 7

The exact position and fit of the pebbles may be finely adjusted to give the most

pleasing and random appearance.

Warning : Use only the pebbles supplied with the fire. When replacing the

pebbles remove the old pebbles and discard them. Fit a complete set of pebbles

of the correct type. Do not fit additional pebbles or any pebbles other than a

genuine replacement set.

To ensure that the release of fibres from these R.C.F (Refractory Ceramic

Fibre) articles is kept to a minimum, during installation and servicing we

recommend that you use a HEPA filtered vacuum to remove any dust

accumulated in and around the appliance before and after working on the

appliance. When replacing these articles we recommend that the replaced

items are not broken up, but are sealed within heavy duty polythene bags,

clearly labelled as “RCF waste”. RCF waste is classed as a “stable”, non

reactive hazardous waste and may be disposed of at a landfill licensed to

accept such waste Protective clothing is not required when handling these

articles, but we recommend you follow the normal hygiene rules of not

smoking, eating or drinking in the work area, and always wash your hands

before eating or drinking.

REMOVAL / RE-FITTI G OF THE TRIM

The trim is secured onto the firebox flange by the use of magnets.

Pebble K Pebble L

Pebble M

Pebble J Pebble N

RE-ASSEMBLI G THE FUEL BED

(COAL FUELBED MODELS)

a) Place the ribbed ceramic fuelbed base on top of the fuelbed support

and pull fully forwards to the burner. Make sure that the fuelbed

base is located centrally in the fire box.Ensure that the fuelbed

base fits fully down onto the fuel bed support and is not

lodged on the burner. See fig. 10 below.

Fig. 10

b) Position the two halves of the front ceramic (L/H & R/H) on the locating

channel in the front ceramic, ensuring it is located onto the lip on the

burner front ceramic support. (See fig. 11 below)

Fig. 11

NOTE : The posi ion of he fuel-bed componen s are cri ical o he

performance of he produc . Therefore please ensure ha he fuel-bed

componen s are posi ioned as described in he following sec ion prior o

reques ing a service call due o soo build up, poor flame pa ern e c.

c) Fit five of the large sized coals onto the front ceramic rail, ensuring

that they are evenly spaced. Use the recess’s in the front ceramic rail

as a guide for placement. (See fig. 12 below)

Fig. 12

d) Select four of the large coals and arrange behind the front row of coals,

ensuring that flame paths as indicated below are not interupted.

(See fig. 13 below)

Fig. 13

e) Select three of the large coals and arrange along the rear of the

fuelbed, using the ribs in the rear of the fuelbed as a guide for

placement. (See fig. 14 below)

Fig. 14

f) Select the two small coals and position to fill the gaps at each end of

the third row of coals, as shown. below in Fig. 15

Fig. 15

g) Select the remaining four coals and position along the rear edge of the

fuelbed (see fig. 16 below)

Fig. 16

The exact position and fit of the coals may be finely adjusted to give the most

pleasing and random appearance.

Warning : Use only the coals supplied with the fire. When replacing the

coals remove the old coals and discard them. Fit a complete set of

coals of the correct type. Do not fit additional coals or any coals

other than a genuine replacement set.
