Introduction
The CK802D Bluetooth Car Kit provides hands-free communication using cell phones. It requests no
professional installation. This user guide focuses on establishing a connection with your mobile phone. You
need to have a phone with embedded Bluetooth capability. The phone can be tucked away in your pocket or
in a bag while you handle incoming call and outgoing calls, and adjust the volume up or down using the
buttons on the car kit. The power for the CK802D comes from the car cigarette lighter jack. This device
utilizes Bluetooth wireless technology. Any device that you want to work with this car kit must be compatible
with Bluetooth technology version 1.2. that supports Bluetooth HEADSET and/or HANDSFREE profile.
Product Outlook
CK802D specifications
Compatible: Bluetooth 1.2 HEADSET profile and HANDSFREE profile
Pairing distance: It is recommended that CK802D and phone distance is as close as possible with no
solid objects in between.
Working distance: Up to 3 meters (best fit in the car)
Frequency band: 2.4GHz ISM band
Speaker power: 1W
Power: 12V~24V cigarette lighter jack
Power consumption: 500mA during talk
Setting Up
1. Plug the car cigarette lighter head into the cigarette lighter.
2. You can loosen the FIXING SCREW to adjust the CK802D to fit your car. You can also adjust
MICROPHONE tube to increase sound sensitivity.
* When you turn off the engine, the Car Kit will memorize the latest power status.

Pairing
1. Ensure the car kit is switched off.
2. Hold the “Hang Up “button more than 6 seconds until you see an LED flashing rapidly and you will hear
a rising and falling tone.
3. Ensure that the mobile phone is less than 1 meter away and that Bluetooth is activated in your mobile
phone.
4. Put your mobile phone in search for new Bluetooth devices. If you are asked for a PIN number in the
mobile phone, note that the PIN number is “1234”.
5. If pairing has been completed successfully a two-tone signal shall be heard.
6. Every time you switch on the Car Kit, it will attempt connection to the last mobile phone that you have it
paired to.
7. Pairing will timeout after 60 seconds at which a two-tone signal will be heard.
* When you use CK802D at the first time (in factory setting mode), it will get into the pairing
mode automatically
External microphone
Rear mic-in jack is possibly to connect an external microphone to collect better voice output.
Storage of car kit
1. Always store CK802D safely. It is not suitable for children.
2. Avoid storage in direct constant sun light.
3. Do not expose CK802D or any of its supplied parts to rain or other liquids.
If you wish to clean CK802D, please use dry and soft cloth
Notice
Please make sure that the Car Kit has been shut-down before you leaving the car. Because some
kind of cars still supply power to cigarette lighter jack after you turn off the engine.

Function Matrix
Function Pick Up Hang Up Volume+ Volume- State
Power On ++ Power Off
Power Off ++ Power On
Pick Up + Receive Calling
Hang Up + During
Communication
Volume+ + During
Communication
Volume- +
During
Communication
Voice Dialing + Standby
Last Call Redial v v Standby
Pairing +++ Power Off
Transfer(Mobile Phone & Car kit) ++ During
Communication
Mute ++ During
Communication
Cancel Mute ++ During
Communication
Refuse Answering ++ Receive Calling
Restore Factory settings ++ ++ Standby
「Short Click: “＋”」：Clip and release less than 1 second
「Long Press: “＋＋”」：Press and release for 2 seconds
「Double Click: “v v”」：Click twice within 0.5 second
「Press and Hold: “＋＋＋”」：Press and hold the key for more than 6 seconds
Certification and Safety Approvals/General Information
1. The device is CE、FCC and E-mark approved.
2. Federal Communication Commission(FCC) Statement：
a. Rule15.21：You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
b. Rule15.105（b）：This equipment has been tested and found to comply with limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
3. Bluetooth is a trade mark owned by Bluetooth SIG, Inc.
Caution
1. Important information regarding safe and efficient operation. Read this information before using the
product. Users are not permitted to make changes or modify the device in any way. Changes or
modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
2. Operation is subject to the following two conditions:
a. this device may not cause harmful interference, and
b. this device must accept any interference received, including interference that may cause
undesired operation of the device.
3. FCC RF Radiation Exposure Statement：
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operation instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operation in conjunction with any other
antenna or transmitter.
