Global 293052 User manual

INSTRUCTION MANUAL
READ ENTIRE MANUAL BEFORE
USE
Global Industrial-11 Harbor Park Drive Port Washington-NY 11050
293052
Commercial Air Scrubber 1000cfm

Safety Instructions
Please observe the following safety instructions to avoid personal injury and property loss.
1) Do not operate any air scrubber with a damaged cord or Plug.
2) Do not move or adjust air scrubber while in operation
3) Keep this unit out of the reach of children
4) Do not alter or modify your air scrubber in any way. Only authorized Global Industrial replacement parts can
be used. Use of any unauthorized parts could cause hazards and void the unit’s warranty
5) Always store unit in a clean, dry environment when not in use. Care should be taken to prevent water from
entering the unit’s motor. In the case that the unit’s motor does become wet, ensure that the motor is dried
thoroughly before use.
6) Do not allow water near or inside the unit while in use to avoid risk of electric shock. Handle unit with care to
avoid causing damage or personal injury.
7) Always operate the air scrubber on a flat, level surface. Operating the unit where it could slip or fall increases
the risk of injury, fire, or electrical shock.
8) Never operate the air scrubber without the factory-installed safety screens in place. This will prevent liquids,
gases, and other materials from entering the air scrubber.
9) Do not use air scrubber near combustible gas or flammable materials in order to avoid fire or electrical
hazards.
10) Do not attempt to disassemble or repair unit on your own. Instead, bring to the attention of your distributor or
a certified repair center. Never attempt to disassemble or repair unit while air scrubber is plugged in.
11) Prior to use, ensure the air intake and outlet are free of obstructions to prevent the air scrubber from
overheating and causing a shock or fire hazard.
12)
Operating Procedures
The Global Industrial Air Scrubber is a portable filtration system that removes airborne particles including mold,
pet dander, dust, pollen, drywall dust, and other miscellaneous debris as small as 0.3 microns. The air scrubber
utilizes up to 4 stages of filtration including a Pre-pad filter, a pre-filter, optional 2nd stage, and a HEPA filter. The
air scrubber will create cleaner air in any environment. The pre-pad filter and pre filter capture larger particles and
the HEPA filter captures smaller particles.
1) Ensure that the unit is on a stable, level surface, and remains stationary while in use.
2) Plug the air scrubber into a grounded outlet with the correct voltage(115v) and amperage. Ensure that the
unit is plugged into a grounded outlet with voltage and wattage outputs that correspond with the unit’s
specifications. For maximum protection against electrical shock, ALWAYS use a circuit that is protected by a
ground fault circuit interrupter. If you are unsure about the outlet, check with a qualified electrician.
Controls
The air scrubber equip the 1 speed light led switch
Control fan by press the switch knob
OFF-Turn off the air scrubber
ON- Turn on the air scrubber
The air scrubber equip the Circuit breaker to protect the
Motor not over load. To reset, unplug the appliance
Causing the breaker to trip and push the reset buttom.
Hepa
Change Light
Switch
Circuit
Breaker

Maintenance
1) Inspect the electrical cord and wiring for damage or discoloration before use. NEVER use a air scrubber that
has a damaged cord to avoid risk of electrical shock or fire.
2) Inspect for loose fasteners before each use.
3) Clean safety screens of the unit before each use.
4) Listen for abnormal sounds and shut unit off immediately upon hearing unusual noises.
5) Keep unit clean and free of blockages or obstructions.
6) Use compressed air or a vacuum to remove lint and other debris from the motor, inlet, or fan blade.
7) Do not use a pressure washer, water hose, or other water source to clean the unit. Ensure that the unit is
completely dry before each use.
8) The air scrubber has sealed bearings and cannot be lubricated. No oiling is necessary.
For information about authorized repair and maintenance contact Global Industrial.
Filters
The air scrubber equip the 3 stage filters including 1 pre-pad filter, 1 pre filter, 1 optional carbon filter, 1 hepa filter.
1) The pre pad filter and Prefilter is used for Captures the largest particles to help extend the life of hepa Filter.
2) The hepa filter is used to against oily aerosol particles down to 0.3 microns
3) The carbon filter is used to Captures a wide variety of volatile organic compounds (VOCs).
Change Filters
Pre-pad filter and Prefilter is recommend to change for every job like painting or depends on the appearance.
Hepa Filter need to be changed within 3 month or when the hepa change light is on.
Carbon Filter need to be changed monthly.
The user need to change all filters if there is risk of the cross-infection application, for example water
damage restoration, fire remold.
PLS WEAR MASKS WHEN CHANGE FILTERS.
Handle Assembly
The air scrubber has the metal handle for easy transportation.
Use the 4 screw to fix the handle on the housing.

Part
Number
Descripti
on
Qt
y
AF1000
01
Metal
Cover
1
AF1000
02
Top
Hepa
Cover
1
293053
Pre Pad
Filter
1
293054
Pre-Filte
r
1
293056
Hepa
Filter
1
AF1000
06
Fan
Motor
1
AF1000
07
Handle
1
AF1000
08
Clamp
4
AF1000
09
Housing
1
AF1000
10
Wheel
2
AF1000
11
Hepa
Filter
Clamp
4
AF1000
12
Hepa
Change
Light
1
AF1000
13
Switch
1
AF1000
14
Connect
or
1
AF1000
15
Power
Cord
1
AF1000
16
Circuit
Breaker
1
AF1000
17
Switch
Panel
1
AF1000
Metal
1
Part List

18
Grill
AF1000
19
Rubber
Fee
4
Trouble Shooting
BLOWER DOES
NOT TURN ON
1) Switch not turned on - in this case, ensure that the knob is in the correct
position to turn the unit on
2) Circuit breaker or GFCI has tripped - press ‘reset button before attempting
to turn the unit on
3) Cord or wires are loose or damaged - Inspect to ensure that cords and
wires are tight and free of damage
4) Faulty switch - Contact your distributor if inside warranty period
BLOWER STARTS AND THEN
TURNS OFF
1) Obstructed inlet/outlet - remove obstructions and ensure that both inlet and
outlets are clear before use.
2) Faulty motor - Contact your distributor if inside warranty period
BLOWER VIBRATES
1) Motor shaft is bent - Contact your distributor if inside warranty period
2) Fan blade is bent - Contact your distributor if inside warranty period
3) Excessive dirt built up on fan blade - Clean blade and ensure blade
housing is free of dust and dirt before use
BLOWER MAKES SCRAPING
NOISES
1) Damaged housing - Inspect housing for warps or dents. If housing is
rubbing against blade, contact your distributor.
MOTOR MAKES NOISE, BUT
BLOWER WON’T TURN ON
1) Damaged/faulty motor or motor shaft - Contact your distributor if inside
warranty period
2) Motor shaft screw holding fan blade is loose - tighten
Specifications
Model
293052
Power Input
115Volt/60hz
Power
3/4hp
Current
6amps(Max)
Air Volume
1000cfm
Size
22.4*21.7*36.2inch
Weight
92.4lbs
Specifications may change without notice.
